A3LSGHX636Dual-Band GSM Phone

* Some of the contents of this manual may differ from your phone, depending on the software insta lled or your service provider. World Wide Webhttp://www.samsungmobile.com Printed in Korea Code No.:GH68-0xxxxA English. 09/2005. Rev 1.0 SAMSUNG ELECTRONICS X486Eng.book Page 1 Friday, September 2, 2005 11:20 AM SGH-X636 User’s Guide X636VDEH1Draft01_050901 X486Eng.book Page 2 Friday, September 2, 2005 11:20 AM Use road safety at all timesDo not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuellingDo not use the phone at a refuelling point (service station) or near fuels or chemicals.Switch off in an aircraftWireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.Switch off the phone near all medical equipmentHospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. X486Eng.book Page 3 Friday, September 2, 2005 11:20 AM Important safety precautions 1 InterferenceAll wireless phones may be subject to interference, which could affect their performance. Be aware of special regulationsMeet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.Water resistanceYour phone is not water-resistant. Keep it dry. Sensible useUse only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.Emergency callKey in the emergency number for your present location, then press [ ]. Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children.Accessories and batteriesUse only Samsung-approved accessories and batteries. Use of any unauthorized accessories could damage your phone and may be dangerous.Qualified serviceOnly qualified service personnel may repair your phone.For more detailed safety information, see "Health and safety information" on page 58. • The phone could explode if the battery is replaced with an incorrect type.• Dispose of used batteries according to the manufacturer’s instructions. X486Eng.book Page 1 Friday, September 2, 2005 11:20 AM 2 About this GuideThis User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your phone, please refer to “Getting started and Step outside the phone.”In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features.  Indicates that you can get more information on the referenced page. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [ key name ] Indicates a key on the phone. For example, [] < soft key > Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu > •Tri-band operation Use your phone in worldwide GSM networks, in any of 850, 1900, and 1800 bands. Special features of your phone • Simple, compact design with Intenna Samsung’s powerful intenna technology allows the best call quality without an annoying external antenna. • Camera and camcorder Use the camera module on your phone to take a photo or record a video. X486Eng.book Page 2 Friday, September 2, 2005 11:20 AM 3 Special features of your phone •WAP browser Access the wireless web and access various services and up-to-the-minute information. •Phonebook Store up to 2000 contact numbers. • Multimedia Message Service (MMS) Send and receive MMS messages with a combination of text, images, and sounds. • Melody composer Create your own melodies and set them as your call ringer. • Calendar and To do list Keep track of your daily, weekly, and monthly schedules and tasks. • Voice recorder Record memos or sounds. •Java Enjoy Java ™ -based embedded games and download new games. X486Eng.book Page 3 Friday, September 2, 2005 11:20 AM 4 Contents Unpack 6 Make sure you have each itemYour phone 6 Buttons, features, and locationsGet started 7 First steps to operate your phoneInstall and charge the phone ................................... 7Power on or off ...................................................... 8Keys and display .................................................... 9Access menu functions.......................................... 11Customise your phone .......................................... 12Make/answer calls................................................ 13Step outside the phone 13 Begin with your WAP, melody composer, messages, and oth-er special featuresBrowse WAP ........................................................ 13Use Phonebook .................................................... 14 Send messages.................................................... 14View messages .................................................... 15Compose your melody .......................................... 16 Enter text 17 ABC, T9, Number, and Symbol modeCall functions 19 Advanced calling featuresMenu functions 24 All menu options listedSolve problems 56 Health and safety information 58 Index 83 X486Eng.book Page 4 Friday, September 2, 2005 11:20 AM 5 Overview of menu functions To access Menu mode, press < Menu > in Idle mode. 1 SIM AT  p. 24 2 2 Call records  p. 24 1 Missed calls2 Received calls3 Dialled calls4 Delete all5 Call time6 Call costs *  p. 24  p. 24  p. 24  p. 24  p. 25  p. 25 3 Network services  p. 26 1 Call diverting2 Call barring3 Call waiting4 Network selection5 Caller ID6 Closed user group7 Band selection  p. 26  p. 26  p. 27  p. 27  p. 27  p. 28  p. 28 4 Sound settings  p. 29 1 Ring tone2 Ring volume3 Alert type4 Keypad tone5 Message tone6 Folder tone7 Power on/off8 Alert on call9 Extra tones  p. 29  p. 29 …

Text truncated - open the document above for the full version.















































September 16         !"# $%&' ( &) "*   +,-   . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4  .(5(65(5 / (5 1 # )57/(5)8 )94144 *4    1    1: ;&/ 1&19<;3<4




















































September 16, 2005


!
 ""
 ""
#$%"
 &
'
()
*+  !

, !
 "-

)


 .
/01
#
 23!

.
A3LSGHX636 , $
5
 5!

1  " .


 !
6
2)
5
 ,
)(
/01
#
 2
3!
  -
 $

 5!
5

' +
7"

7"

 %
8
3

 !
*%
 %
"
5

-9
%%  2

:
! "

!  !
  "
 !
$%"
! %
 !
  !
 5 "

-

% !
6
/01
#
 2
3!
 !
-  7
% %

 5!
 !

  "
! 7
 !
 6
6  !




7
%- 2




! 7


-
5 "
6
5
  7
% !
6

/01

#
 2
3!
 !


 5 "
6  !
-
5
- 5


 "%
 !


!
5

 5 "


! "
6  !
7
 "%

 5
! 7


"+ 2







;"
<
"
=
3-
/01
#
"
0





















































































September 16, 2005

!
 ""
 ""
 #
 !
$
%
$&'"
 #
(
)*
+,  !

- !
 ".

*



 /
012
$
 %
3!%

/
A3LSGHX636 - &
5
 67 "
 5!


7
8 "


   /


 !
9
%*)
 !
%*
5
 -
*)
012
$
 %
3!%
 &
 6  "
 5!
5


'
'
:
'

'
 !
 ;
"
5

 !

 ' %

7
! "

!  !
  "
 !
&'"
! '
 !
  !
 5 "
.

' !
9
012
$
 %3!

 !

.
' '
 5!
 !

  "
! <
 !
 9
9  !




<
'. %


! <


.
5 "
9
5
  <
' !
9

012
$
 %
3!
5


 5 "
9  !
.
5
. 5


 "'
 !


!
5

 5 "


! "
9  !
<

 "'

 5
! <


", %






="
>
"
?
3.
012
$
"
1%

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone

© 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone © 2005 SAMSUNG ELECTRONICS Co., Ltd. SAMSUNG FCC ID: A3LSGHX636 Dual-Band GSM850/1900 Phone

1 of 31 SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Team IT R&D Center 416, Maetan-3dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 442-742 TEST REPORT ON SAR Model Tested: SGH-X636 FCC ID (Requested): A3LSGHX636 Job No: FC-124 Report No: FC-124-S1 Date issued: Sep. 14, 2005 - Abstract – This document reports on SAR Tests carried out in accordance with FCC/OET Bulletin 65, Supplement C(July 2001). Prepared By Date EH JUNG - Test Engineer Checked By Date SH PARK - Senior Manager Authorized By Date JK CHOI - General Manager Report Number : FC-124-S1 2 of 31 Contents 1. General Information.............................................................................................3 2. Description of Device...........................................................................................3 3. Description of Test Equipment..............................................................................4 3.1 SAR Measurement Setup.........................................................................................4 3.2 DASY4 E-Field Probe.............................................................................................5 3.3 SAM Phantom.....................................................................................................6 3.4 Brain & Muscle Simulating Mixture Characterization.......................................................7 3.5 Device Holder for transmitters....................................................................................8 3.6 Validation Dipole....................................................................................................8 3.7 Equipment Calibration.............................................................................................9 4. SAR Measurement Procedure.............................................................................10 5. Description of test position..............................................................................11 5.1 SAM Phantom Shape.............................................................................................11 5.2 Cheek/Touch Position............................................................................................11 5.3 Ear/Tilt 15 Position..............................................................................................13 5.4 Body/Holster/Belt Clip Configuration..........................................................................14 6. Measurement Uncertainty...................................................................................16 7. System Verification............................................................................................18 7.1 Tissue Verification.................................................................................................18 7.2 Test System Validation...........................................................................................18 8. SAR Measurement Results.................................................................................19 8.1 Measurement Results(GSM850 Right Head SAR-Touch)............................................20 8.2 Measurement Results(GSM850 Right Head SAR-Tilt)................................................21 8.3 Measurement Results(GSM850 Left Head SAR-Touch)..............................................22 8.4 Measurement Results(GSM850 Left Head SAR-Tilt)..................................................23 8.5 Measurement Results(GSM1900 Right Head SAR-Touch)............................................24 8.6 Measurement Results(GSM1900 Right Head SAR-Tilt)................................................25 8.7 Measurement Results(GSM1900 Left Head SAR-Touch)..............................................26 8.8 Measurement Results(GSM1900 Left Head SAR-Tilt)..................................................27 8.9 Measurement Results(GPRS850 Body SAR w/o Holster)..........................................28 8.10 Measurement Results(GPRS1900 Body SAR w/o Holster)..........................................29 9. Conclusion.......................................................................................................30 10. Reference.......................................................................................................31 Report Number : FC-124-S1 3 of 31 1. GENERAL INFORMATION Test Sample : Dual-Band GSM850 / GSM1900 Phone Model Number : SGH-X636 Serial Number : Identical prototype (S/N : FC-124-A) Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Contact : JI Kim, Engineer Phone : +82-31-279-6072 Fax : +82-31-279-4289 Test Standard : §2.1093; FCC/OET Bulletin 65, Supplement C(July 2001) FCC Classification : Licensed Portable Transmitter Held to Ear (PCE) Test Dates : Sep. 12, 2005 - Sep. 12, 2005 Tested for : FCC/TCB Certification 2. DESCRIPTION OF DEVICE Tx Freq. Range : 824.2 – 848.8 MHz (GSM850) 1850.20 – 1909.80 MHz (GSM1900) Rx Freq. Range : 869.2 – 893.8 MHz (GSM850) 1930.20 – 1989.80 MHz (GSM1900) Max. RF Output Power : 2.188 W EIRP GSM850 (33.40 dBm) 1.683 W EIRP GSM1900 (32.26 dBm) Antenna Manufacturer : Samsung Electro-Mechanics Model No.: IAPG0X636A Antenna Dimensions : 38mm Report Number : FC-124-S1 4 of 31 3. DESCRIPTION OF TEST EQUIPMENT 3.1 SAR Measurement Setup Robotic System Measurements are performed using the DASY4 automated dosimetric assessment system. Which is made by Schmid & Partner Engineering AG (SPEAG) in Zurich, Switzerland and consists of high precision robotics system (Stäubli), robot controller, measurement server, Samsung computer, near- field probe, probe alignment sensor, and the SAM twin phantom containing the brain equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF) (see Fig. 3.1). Figure 3.1 SAR Measurement System Setup System Hardware A cell controller system contains the power supply, robot controller, teach pendant (Joystick), and a remote control is us…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID : A3LSGHX636 835MHz GSM850 Head SAR DUT: SGH-X636; Serial: FC-124-A Program Name: SGH-X636 GSM850 Right (Job No. : FC-124) Procedure Name: Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-20.7; Test Date-12/Sep/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 848.8 MHz; σ = 0.91 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ES3DV3 - SN3085; ConvF(5.91, 5.91, 5.91); Calibrated: 2005-05-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn670; Calibrated: 2005-04-05 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 1.35 mW/g Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 11.0 V/m; Power Drift = -0.082 dB Peak SAR (extrapolated) = 1.77 W/kg SAR(1 g) = 1.22 mW/g; Maximum value of SAR (measured) = 1.32 mW/g 0 dB = 1.32mW/g SAMSUNG FCC ID : A3LSGHX636 835MHz GSM850 Head SAR DUT: SGH-X636; Serial: FC-124-A Program Name: SGH-X636 GSM850 Right (Job No. : FC-124) Procedure Name: Ear/Tilt, Ch.190, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-20.7; Test Date-12/Sep/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 836.6 MHz; σ = 0.91 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ES3DV3 - SN3085; ConvF(5.91, 5.91, 5.91); Calibrated: 2005-05-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn670; Calibrated: 2005-04-05 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.190, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.389 mW/g Ear/Tilt, Ch.190, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.6 V/m; Power Drift = -0.00 dB Peak SAR (extrapolated) = 0.477 W/kg SAR(1 g) = 0.371 mW/g Maximum value of SAR (measured) = 0.389 mW/g 0 dB = 0.389mW/g SAMSUNG FCC ID : A3LSGHX636 835MHz GSM850 Head SAR DUT: SGH-X636; Serial: FC-124-A Program Name: SGH-X636 GSM850 Left (Job No. : FC-124) Procedure Name: Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-20.7; Test Date-12/Sep/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 848.8 MHz; σ = 0.91 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ES3DV3 - SN3085; ConvF(5.91, 5.91, 5.91); Calibrated: 2005-05-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn670; Calibrated: 2005-04-05 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 1.31 mW/g Cheek/Touch, Ch.251, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 9.75 V/m; Power Drift = -0.012 dB Peak SAR (extrapolated) = 1.68 W/kg SAR(1 g) = 1.2 mW/g Maximum value of SAR (measured) = 1.28 mW/g 0 dB = 1.28mW/g SAMSUNG FCC ID : A3LSGHX636 835MHz GSM850 Head SAR DUT: SGH-X636; Serial: FC-124-A Program Name: SGH-X636 GSM850 Left (Job No. : FC-124) Procedure Name: Ear/Tilt, Ch.190, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-20.7; Test Date-12/Sep/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 836.6 MHz; σ = 0.91 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: ES3DV3 - SN3085; ConvF(5.91, 5.91, 5.91); Calibrated: 2005-05-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn670; Calibrated: 2005-04-05 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Ear/Tilt, Ch.190, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 0.348 mW/g Ear/Tilt, Ch.190, Ant.Intenna, Bat.Standard/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 12.7 V/m; Power Drift = 0.044 dB Peak SAR (extrapolated) = 0.429 W/kg SAR(1 g) = 0.334 mW/g Maximum value of SAR (measured) = 0.350 mW/g 0 dB = 0.350mW/g SAMSUNG FCC ID : A3LSGHX636 1900MHz GSM1900 Head SAR DUT: SGH-X636; Serial: FC-124-A Program Name: SGH-X636 GSM1900 Right (Job No. : FC-124) Procedure Name: Cheek/Touch, Ch.810, Ant.Intenna, Bat.Standard Procedure Notes: Meas.Tissue Temp(celsius)-21.8; Test Date-12/Sep/2005 [OET Bulletin 65- Supplement C, July 2001] Communication System: GSM 1900; Frequency: 1909.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1909.8 MHz; σ = 1.39 mho/m; ε r = 39.5; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: ES3DV3 - SN3080; ConvF(4.92, 4.92, 4.92); Calibrated: 2005-05-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn670; Calibrated: 2005-04-05 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 Cheek/Touch, Ch.810, Ant.Intenna, Bat.Standard/Area Scan (51x71x1): Measurement grid: dx=20mm, dy=20mm M…

Text truncated - open the document above for the full version.

DUT: Dipole 835 MHz; Serial: 4d014 Program Name: 835MHz Dipole Validation 2005.09.12 Procedure Name: 835MHz @ 250mW Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.91 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ES3DV3 - SN3085; ConvF(5.91, 5.91, 5.91); Calibrated: 2005-05-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn670; Calibrated: 2005-04-05 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 835MHz @ 250mW/Area Scan (51x61x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 2.64 mW/g 835MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 54.5 V/m; Power Drift = -0.036 dB Peak SAR (extrapolated) = 3.64 W/kg SAR(1 g) = 2.44 mW/g Maximum value of SAR (measured) = 2.62 mW/g 0 dB = 2.62mW/g DUT: Dipole 835 MHz; Serial: 4d014 Program Name: 835MHz Dipole Validation 2005.09.12 Procedure Name: 835MHz @ 250mW Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium parameters used: f = 835 MHz; σ = 0.96 mho/m; ε r = 53.3; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ES3DV3 - SN3080; ConvF(5.82, 5.82, 5.82); Calibrated: 2005-05-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn670; Calibrated: 2005-04-05 - Phantom: SAM 835/900 MHz; Type: SAM; Serial: TP-1141 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 835MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 51.5 V/m; Power Drift = 0.023 dB Peak SAR (extrapolated) = 3.65 W/kg SAR(1 g) = 2.49 mW/g Maximum value of SAR (measured) = 2.68 mW/g 835MHz @ 250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 2.77 mW/g 0 dB = 2.77mW/g DUT: Dipole 1900 MHz; Serial: 5d023 Program Name: 1900MHz Dipole Validation 2005.09.12 Procedure Name: 1900MHz @ 250mW Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium parameters used: f = 1900 MHz; σ = 1.39 mho/m; ε r = 39.5; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: - Probe: ES3DV3 - SN3080; ConvF(4.92, 4.92, 4.92); Calibrated: 2005-05-26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn670; Calibrated: 2005-04-05 - Phantom: SAM 1800/1900 MHz; Type: SAM; Serial: TP-1143 - Measurement SW: DASY4, V4.5 Build 19; Postprocessing SW: SEMCAD, V1.8 Build 146 1900MHz @ 250mW/Area Scan (51x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 14.8 mW/g 1900MHz @ 250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 90.6 V/m; Power Drift = -0.069 dB Peak SAR (extrapolated) = 18.2 W/kg SAR(1 g) = 10.2 mW/g Maximum value of SAR (measured) = 11.5 mW/g 0 dB = 11.5mW/g

SAMSUNG ELECTRONICS Co., Ltd., Regulatory Compliance Group IT R&D Center 416 Maetan3-Dong, Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 442-742 FCC CFR47 PART 22 & 24 SUBPART CERTIFICATION REPORT Model Tested: SGH-X636 FCC ID (Requested): A3LSGHX636 Report No: FC-124-R1 Job No: FC-124 Date issued: September 15, 2005 - Abstract – All measurement reported herein accordance with FCC Rules, 47CFR Part2, Part22, Part24. Prepared By Date YE PARK– Test Engineer Checked By Date SH PARK –Senior Manager Authorized By Date JK CHOI – General Manager © Copyright SAMSUNG Electronics 2005 Report Number : FC-124-R1 TABLE OF CONTENT MEASUREMENT REPORT Page 1. FCC Certification Information 3 1.1 2.1033 General Information 3 2. INTRODUCTION 4 2.1 General 4 3. MEASURING INSTRUMENT CALIBRATION 5 4. TEST EQUIPMENT LIST 6 5. DESCRIPTION OF TESTS 7 5.1 Effective Radiated Power/Equivalent Isotropic Radiated Power 7 5.2 Radiated Spurious & Harmonic Emission 8 5.3 Occupied Bandwidth 10 5.4 Spurious and Harmonic Emissions at Antenna Terminal 10 5.4.1 Occupied Bandwidth Emission Limits 10 5.4.2 Conducted Spurious Emission 11 5.5 Frequency Stability / Temperature Variation 12 6. TEST DATA 13 6.1 Effective Radiated Power(E.R.P.) 13 6.2 Equivalent Isotropic Radiated Power(E.I.R.P.) 14 6.3 GSM850 Radiated Spurious & Harmonic Measurement 15 6.4 GSM1900 Radiated Spurious & Harmonic Measurement 16 6.5 GSM850 Radiated Spurious & Harmonic Conversion Table 17 6.6 GSM1900 Radiated Spurious & Harmonic Conversion Table 18 6.7 Frequency Stability 19 6.7.1 GSM850 Frequency Stability Table 19 6.7.2 GSM850 Frequency Stability Graph 20 6.7.3 GSM1900 Frequency Stability Table 22 6.7.4 GSM1900 Frequency Stability Graph 23 7.SAMPLE CALCULATION 25 7.1 Emission Designator 8. CONCLUSION 26 9. TEST PLOTS 27 Report Number : FC-124-R1 MEASUREMENT REPORT 1. FCC Certification Information The following information is in accordance with FCC Rules, 47CFR Part2, Subpart J, Sections 2.1033 – 2.1055. 1.1 §2.1033 General Information Applicant Name: SAMSUNG ELECRONICS CO., LTD. Address: 416 Maetan3-Dong, Yeongtong-gu, Suwon City Gyeonggi-Do, Korea 443-742 Attention: FCC ID: SungJoo KIM, Engineering Manager (QA Lab) A3LSGHX636 Quantity: Quantity production is planned Emission Designators: 249KGXW Tx Freq. Range: 824.2 - 848.8MHz (GSM850) 1851.25 -1908.75MHz (GSM1900) Rx Freq. Range: 869.2 - 893.8 MHz (GSM850) 1931.25 -1988.75 MHz (GSM1900 ) Max. Power Rating: 2.188W ERP GSM850 ( 33.40dBm) 1.683W EIRP GSM1900 (32.26dBm) FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) Equipment (EUT) Type: Dual-Band GSM850/1900 Phone Modulation(s): GSM850/ GSM1900 Frequency Tolerance: 0.00025% (2.5ppm) FCC Rule Part(s): 24(E), 22(H), 2. Dates of Test: September 09-12 2005 Place of Test: SAMSUNG Lab, Test Report S/N: FC-124-R1 Report Number : FC-124-R1 2. INTRODUCTION 2.1 General These measurement test were conducted at SAMSUNG ELECTRONICS CO., LTD(SUWON). The site address is 416 Maetan3-Dong, Yeongtong-gu, Suwon City, Gyeonggi-Do, Korea 443-742. The site have 1 Fully-anechoic chamber and measurement facility. Measurement Procedure The radiated and spurious measurements were made Fully-anechoic chamber at a 3-meter test range (see Figure2). The equipment under testing was placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spectrum analyzer. The substitution antenna will replace the EUT antenna it the same position and in vertical polarization. The frequency of the signal generator shall be set to the frequencies that were measured on the EUT. The test antenna shall be raised and lowered, if necessary, to ensure that the maximum signal is still being received. The signal generator, output level, shall be adjusted until an equal or a known related level to what was measured from the EUT is obtained in the spectrum analyzer. This l…

Text truncated - open the document above for the full version.
