A3LSHWA310SPCS GSM Phone with Bluetooth

* Some of the contents of this manual may differ from your phone, depending on the software installed or your service provider. World Wide Web http://www.anycall.com SHW-A310S User’s Guide  Be aware of special regulations Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger. Water resistance Your phone is not water-resistant. Keep it dry. Sensible use Use only in the normal position (held to your ear). Avoid unnecessary contact with the antenna when the phone is switched on. Emergency calls Key in the emergency number for your present location, then press [ ]. Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteries Use only Samsung-approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorised accessories could damage you or your phone and may be dangerous. Qualified service Only qualified service personnel may repair your phone. For more detailed safety information, see “Health and safety information” on page 20. Drive safely at all times Do not use a hand-held phone while driving. Park your vehicle first. Switch off the phone when refuelling Do not use the phone at a refuelling point (service station) or near fuels or chemicals. Switch off in an aircraft Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous. Switch off the phone near all medical equipment Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Interference All wireless phones may be subject to interference, which could affect their performance. Failure to comply with the following precautions may be dangerous or illegal. Copyright information Bluetooth? is a registered trademark of the Bluetooth SIG, Inc. worldwide. JavaTM is a trademark or registered trademark of Sun Microsystems, Inc. Picsel and Picsel ViewerTM are trademarks of Picsel Technologies, Inc. Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audiosource and use only the minimum volume setting necessary to hear your conversation or music. Important safety precautions • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions.  Contents Make sure you have each item • Phone • Adapter • Stereo headset • Battery • Battery travel holder • User’s manual You can obtain the following accessories for your phone from your local Samsung dealer. • Multi adapter • Travel charger • Car charger • PC data cable • Portable battery kit • Portable PC data cable • Music controller • Bluetooth mono/ stereop headset kit Unpack Unpack .............................................................. 3 Make sure you have each item Get started ....................................................... 4 First steps to operate your phone Overview of menu functions .................... 7 To access Menu mode, press [메뉴] in Idle mode. Menu functions .............................................. 8 All menu options listed Solve problems ........................................... 18 Help and personal needs Health and safety information ............... 20  Power on or off Power on Do not turn on the phone when mobile phone use is prohibited. 1 Open the phone. 2 Press and hold [ ] to turn on the phone. 3 If necessary, enter the PIN and press [확인]. Power on 1 Open the phone. 2 Press and hold [ ]. Keys and display Key(s)Description SoftkeysPerform the function indicated on the bottom line of the display. Navigation keysIn Standby mode, access menu options directly. In Menu mode, scroll through the menu options. 확인 keyIn Idle mode, enters Menu mode. In Menu mode, selects the highlighted menu option. key Sends or answers a call. In Standby mode, retrieves the last number dialed, missed, or received. Install and charge the phone 1 Install the battery: 2 Plug the adapter into the phone. 3 Plug the adapter into a standard AC wall outlet. 4 When the phone is completely charged (the battery icon stops blinking), unplug the adapter from the power outlet. 5 Remove the adapter from the phone. Low battery indicator When the battery is low: • a warning tone sounds, • the battery low message displays, and • the empty battery icon [ ] blinks. If the battery level becomes too low, the phone automatically turns off. Recharge your battery. Get started First steps to operate your phone To remove the battery, slide the battery catch toward the top of the phone and hold it.  Get started Key(s)Description 취소 keyDeletes characters from the display. In Menu mode, returns to the previous menu level. key Ends a call. Hold down to switch the phone on and off. In Menu mode, cancels input and returns the phone to Idle mode. Numeric keysEnter numbers, letters, and some special characters. * /# keyEnter special characters. Use for some special functions. Key(s)Description Volume keys (on the left) Adjusts the phone volume. In Standby mode, with the phone open, adjusts the master volume. With the phone closed, hold down to turn on the display. In Menu mode, scrolls through the menu options. Camera keyIn Standby mode, with the phone open, turns on the camera. With the phone closed, hold down to turn on the camera. In Capture mode, takes a photo. 1 T Service 1 Global Roaming 2 M Help Desk 3 T Optional Service 4 NATE 5 W 6 MONETA 2 Sounds 1 Ring Tone Settings 2 Download Melody 3 Alert Tones 4 Key Tones/Others 5 Volume 6 Hourly Chime 3 Display 1 Wall Paper 2 Download Image 2 Main Menu Style 3 Font Type/Size 4 Dial Number Style 5 Lighting 4 Contents box 1 Melodies 2 Images 3 Photos/Movies 4 MMS Attached Files 5 mPlayon 6 june contents box 7 Key Jjang Album 8 Anyc…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date: August 4, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSHWA310S To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Description 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO., LTD 416,Maetan-3dong,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea Federal Communicat ions Commission 7435 Oakland Mills Road Colum bia, MD 21046 SUBJECT : Label Stat ement FCC ID : A3L Gentlemen: We hereby provide the label statement letter for the above-mentioned phone by a new label statement policy instituted at the September 12, 2006, TCB-FCC Teleconference. The label statement is as follows: The FCC ID shown in the FCC ID label page will be readily visible at the time of purchase because the phone will be marketed without the battery installed. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

Project No. : LBE20113521 Mobile Phone : SHW-A310S - 4/6- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 2. EUT photography [ Front View ] [ Rear View ] Project No. : LBE20113521 Mobile Phone : SHW-A310S - 5/6- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 [ Travel Adapter ] [ Headset ] Project No. : LBE20113521 Mobile Phone : SHW-A310S - 6/6- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 [ Data Cable ] [ Label ]

WHITE POLYESTER 50 SHW-A310S GH68-00000A 110628110628 110628 Hansung P&I MODEL : SHW-A310S RATED : 3.7 V 1000 mA MADE IN KOREA BY SAMSUNG MOBILE PHONE SSN : -A310SGSMH FCC ID : A3LSHWA310S ; Lee Jae Jin Jo Kyeong HwanKim June Sop Technical Description 1. Use ‘AI / PDF’ provided by ‘SAMSUNG’ for letter and contents 2. Background color is ‘WHITE’, letter color is ‘BLACK’ (reverse for SAMSUNG LOGO) 3. Back side should be attached to release paper once adhesive is applied. 4. No letter should be blur/smeared 5. The production must be proceed after the approval of R&D Group 6. The product must be within approved sample's specification tolerance. 7. The product must be finished in a ROLL 8. Release paper must be unifiedn for material and color(blue) 9. Do not contain any substances which are specified in (OQA-2049). The label is placed inside the battery compartment 1. 기자재의 명칭(모델명) : 이동통신용 무선설비의 기기 (SHW-A310S) 2. 식별부호 : KCC-CMM-SEC-SHWA310S 3. 정격 : 3.7 V ; 1000mA 4. FCC ID : A3LSHWA310S 5. 상호명 : 삼성전자(주) 6. 제조자/제조국가 : 삼성전자(주)/대한민국 7. 해당 무선설비는 운용 중 전파혼신 가능성이 있음 애니콜AS문의/예약 :1588-7285/www.3366.co.kr 제조연월일 : 일련번호 :

-1/11- Form No.: SRA-TRF-20/0 E E E M M M C C C T T T E E E S S S T T T R R R E E E P P P O O O R R R T T T Project No. LBE20113521 Issue No. 1 Applicant Name of organizationSamsung Electronics Co., Ltd. Address 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, 443-742, Republic of Korea Date of application July 04, 2011 EUT Type of device Class B personal computers and peripherals Equipment authorization Declaration of Conformity Certification Verification FCC ID A3LSHWA310S Kind of product Mobile Phone Model No. SHW-A310S Variant Model No. Refer to clause 3.5 Manufacturer SAMSUNG ELECTRONICS CO., LTD. 94-1, Imsu-dong, Gumi-si, Gyengsangbuk-do, 730-722, Republic of Korea Applied Standards FCC Part 15, Subpart B, Class B / ANSI C63.4-2003 Test Period July 7, 2011 ~ July 10, 2011 Issue date July 11, 2011 Test result : Complied The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Tested by : Young-Jin Kim Reviewed by : No-Cheon Park The test results in this report only apply to the tested sample. This report must not be reproduced, except in full, without written permission from CS & Environment center. 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-so, 443-742, Republic of Korea Tel: 82 31 279 1750, Fax: 82 31 279 1745 Project No. : LBE20113521 Mobile Phone : SHW-A310S - 2/11- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 Table of contents 1. Summary of test results 1.1 Emission ---------------------------------------------------------------------- 3 2. General Information 2.1 Test facility -------------------------------------------------------------------- 3 3. Test configuration 3.1 Test Peripherals ------------------------------------------------------------- 3 3.2 EUT operating mode ------------------------------------------------------- 4 3.3 Details of Sampling --------------------------------------------------------- 4 3.4 Used cable description ---------------------------------------------------- 4 3.5 EUT Description ------------------------------------------------------------- 5 3.6 Clock Frequencies ---------------------------------------------------------- 5 3.7 Test configuration and condition ----------------------------------------- 6 3.8 Measurement uncertainty ------------------------------------------------- 6 4. Result of individual tests 4.1 Conducted disturbance ----------------------------------------------------- 7 4.2 Radiated disturbance -------------------------------------------------------- 10 Project No. : LBE20113521 Mobile Phone : SHW-A310S - 3/11- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 1. Summary of test results 1.1 Emission The EUT has been tested according to the following specifications: Applied Test type Applied standard Result Remarks Conducted Disturbance (Mains port) FCC Part 15 Subpart B / ANSI C63.4-2003 Complied Meets Class B Limit Radiated Disturbance Complied Meets Class B Limit 2. General Information 2.1 Test facility The CS & Environment center is located on Samsung Electronics Co., Ltd. at 416, Maetan 3-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Republic of Korea. All testing are performed in Semi-anechoic chambers conforming to the site attenuation Characteristics defined by ANSI C63.4, CISPR 22, 16-1 and 16-2. and Shielded rooms. The CS & Environment center is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:2005. 3. Test Setup configuration 3.1 Test Peripherals The cables used for these peripherals are either permanently attached by the peripheral manufacturer or coupled with an assigned cable as defined below. The following is a listing of the EUT and peripherals utilized during the performance of EMC test: Description Model No. Serial No. Manufacturer FCC ID / DoC Mobile Phone SHW-A310S - SAMSUNG A3LSHWA310S Battery EB424255VK TH1B616CS/4-B SAMSUNG - USB Cable ECC2DK0BBK - SAMSUNG - Micro SD Card 2GB - SANDISK - LCD Monitor CX502N N719HVELA11890L SAMSUNG DoC D/T PC DCSCMF BHDLKBX DELL DoC USB mouse MOARUO 0933008588 SAMSUNG DoC USB Keyboard SEM-DT-35US KB3V082SUAAB-REV2. 092000824 GPE DoC Project No. : LBE20113521 Mobile Phone : SHW-A310S - 4/11- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 3.2 EUT operating mode To achieve compliance applied standard specification, the following mode(s) were made during compliance testing: Operating Mode 1 USB Mode (Data Communication) 3.3 Details of Sampling Customer selected, single unit. 3.4 Used cable description The EUT is configured, installed, arranged and operated in a manner consistent with typical applications. Interface cables/loads/devices are connected to at least one of each type of interface port of the EUT, and where practical, each cable shall be terminated in a device typical of actual usage. The type(s) of interconnecting cables to be used and the interface port (of the EUT) to which these were connected; Connected cable Length [m] Shielded [Y/N] Note Data Cable 0.8 Yes From EUT to D/T PC D-Sub 1.5 Yes From EUT to Monitor Power 1.8 No For D/T PC Power 1.8 No For Monitor USB 1.8 Yes From D/T PC to Mouse USB 1.5 Yes From D/T PC to Keyboard Project No. : LBE20113521 Mobile Phone : SHW-A310S - 5/11- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 3.5 EUT Description 1. The following features describe EUT represented by this report: Item Specification Frequency Range WCDMA TX : 1 922.8 ~ 1 977.2 MHz RX : 2 112.8 ~ 2 167.2 MHz Max. Power : 300 mW GSM TX : 880.2 ~ 914.8 MHz RX : 925.2 ~ 959.8 MHz Max. Power : 2 W DCS TX : 1 710.2 ~ 1 784.8 MHz RX : 1 805.2 ~ 1 879.8 MHz Max. Power : 1 W US PCS TX : 1 850.2 ~ 1 909.8 MHz RX…

Text truncated - open the document above for the full version.

Project No. : LBE20113521 Mobile Phone : SHW-A310S - 2/6- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 1. Photograph of Test Setup [ Conducted Disturbance – Front ] [ Conducted Disturbance – Rear ] Project No. : LBE20113521 Mobile Phone : SHW-A310S - 3/6- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-20/0 [ Radiated Disturbance – Front ] [ Radiated Disturbance – Rear ]
