SM-F707B Package content • Device • USB cable • Ejection pin • USB power adaptor • Quick start guide Accessing more information To view the full user manual on your device, launch the Settings app and tap User manual. Visit www.samsung.com to view device information, the user manual, and more. To turn on the device, press and hold the Power key for a few seconds. Installing a nano-SIM card and a microSD card Insert the ejection pin into the hole next to the tray to loosen the tray. Gently press the card into the tray to secure it. Charging the battery Before using the device for the first time, you must charge the battery. Using the Home button When you turn on the screen, the Home button will appear at the bottom of the screen as a soft button. Correct disposal Safety information Read all safety information before using the device to ensure safe and proper use. Warning Follow the warning information provided below to prevent incidents such as fire or explosion • Do not expose the device to physical impact or damage. • Use manufacturer-approved batteries, chargers, accessories, and supplies. • Prevent the multipurpose jack and battery terminals from contacting conductive elements, such as metal or liquids. • If any part of the device, such as the glass or acrylic body, is broken, smokes, or emits a burning odor, stop using the device immediately. Use the device again only after it has been repaired at a Samsung Service Centre. • Do not turn on or use the device when the battery compartment is exposed. Follow the warnings below to prevent injury to people or damage to the device • Do not allow children or animals to chew or suck the device. • If the device has a camera flash or light, do not use it close to the eyes of people or animals. • The device can be used in locations with an ambient temperature of 0 °C to 35 °C. You can store the device at an ambient temperature of -20 °C to 50 °C. Using or storing the device outside of the recommended temperature ranges may damage the device or reduce the battery’s lifespan. • Do not use your device in a hot environment or near fire. • Comply with all safety warnings and regulations regarding mobile device usage while operating a vehicle. You can view more safety information, including device and battery disposal instructions, in the safety information menu of the Settings app. • It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods. Doing so may result in afterimages (screen burn-in) or ghosting. THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES Your mobile is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. The guidelines were developed by an independent scientific organisation (ICNIRP) and include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2.0 W/kg. The highest SAR values under the ICNIRP guidelines for this device model are: SAR values for European countries: The SAR values below are only for devices developed for use in European countries. Maximum SAR for this model and conditions under which it was recorded Head SAR TBD W/kg Body-worn SAR TBD W/kg Body-worn SAR testing has been carried out at a separation distance of 0.5 cm. To meet RF exposure guidelines during body-worn operation, the device should be positioned at least this distance away from the body. For SAR values for all other countries: For SAR values specific to your model, visit www.samsung.com/sar and search for your region and device with the model number. The use of WLAN band is restricted to indoor use only. This restriction will be applied in all countries below. The items supplied with the device may vary by region. • The user manual may not be available depending on the web browser or service provider. • You may incur additional charges for accessing the Internet. • Use only a nano-SIM card. • Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged. • If the card is not fixed firmly into the tray, the card may leave or fall out of the tray. Nano-SIM cards and microSD cards are sold separately. Use only USB Type-C cable supplied with the device. The device may be damaged if you use Micro USB cable. The charger should remain close to the electric socket and easily accessible while charging. This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. This product is RoHS compliant. This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste. To prevent possible hearing damage when using a headset, do not listen to sound at high volume for long periods. Specific Absorption Rate (SAR) certification information Draft SAMSUNG CONFIDENTIAL • To transfer data of the previous device to a new device: Visit ww.samsung.com/smartswitch for more information. • If your device is frozen and unresponsive, press nd hold the Power key and the Volume Down key simultaneously for more than 7 seconds to restart it. Some content may differ from your device depending on the region, service provider, or software v ersion, and is subject to change without prior notice. Copyright © 2019 Samsung Electronics Your device is a radio transmitter and receiver. It is designed and manufactured not to exceed the exposure limits for Radio Frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These FCC RF exposure limits are derived from the recommendations of two expert organizations: the National Council on Radiation Protection and Measurement (NCRP) and the Institute of Electrical and…

Text truncated - open the document above for the full version.

www.samsung.com USER MANUAL English. 05/2020. Rev.2.0 SM-F707B 2 Table of Contents Basics 4 Read me first 6 Device o verheating situations and solutions 9 Device layout and functions 16 Battery 21 Nano-SIM card and eSIM 24 Co ver 25 Turning the device on and off 27 Initial setup 28 Samsung acc ount 29 Transf erring data from your previous device (Smart Switch) 32 Cover screen 35 Understanding the screen 46 Notification panel 48 Screen capture and screen record 50 Entering text Apps and features 53 Installing or uninstalling apps 55 Bixby 60 Bixby Vision 63 Bixby Routines 66 Phone 71 Con tacts 76 Messages 79 Internet 81 Camera 103 Gallery 111 AR Zone 122 Always On Display 123 Edge lighting 125 Multi window 129 Samsung Daily 130 Samsung Pay 133 Samsung Health 137 Samsung Members 137 Samsung Notes 138 Galaxy Wearable 138 Calendar 140 Reminder 142 Voice Recorder 144 My Files 145 Clock 146 Calculator 147 Game Launcher 149 Game Booster 150 Kids Home 152 SmartThings 156 Sharing content 159 Music Share 160 Link to Windows 162 Samsung Global Goals 162 Google apps Table of Contents 3 199 Privacy 200 Location 200 Acc ounts and backup 201 Samsung Cloud 202 Google 203 Advanc ed features 204 Motions and gestures 205 Dual Messenger 206 Digital W ellbeing and parental controls 207 Digital Wellbeing 209 Device car e 209 Optimising your device 210 Batt ery 211 St orage 211 Memor y 211 Secur ity 212 Apps 212 General management 213 Ac cessibility 213 Soft ware update 214 About phone Appendix 215 Accessibility 233 Tr oubleshooting 238 Removing the battery Settings 164 Introduction 164 Connections 165 Wi-F i 167 Bluetooth 168 NFC and payment 170 Data sav er 171 Mobile data only apps 171 SIM card manager (dual SIM models) 172 Mobile Hotspot and Tethering 173 More c onnection settings 175 Sounds and vibra tion 176 Dolby A tmos (surround sound) 176 Separate app sound 177 Notifications 177 App icon badges 178 Display 179 Dark mode settings 179 Blue light filter 180 Changing the screen mode or adjusting the display colour 181 Font siz e and style 181 Scr eensaver 182 Wallpaper 182 Themes 182 Lock screen 183 Smart Lock 184 Biometrics and securit y 185 Face r ecognition 188 Fingerpr int recognition 191 Samsung Pass 194 Secure F older 198 Secure W i-Fi 4 Basics Read me first Please read this manual before using the device to ensure safe and proper use. • Descriptions are based on the device’s default settings. • Some content may differ from your device depending on the region, service provider, model specifications, or device’s software. • Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in. • Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung. • Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly. • Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media. • You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature. • Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers. • Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty. Basics 5 • Depending on the region or service provider, a screen protector is attached for protection during production and distribution. Damage to the attached screen protector is not covered by the warranty. • You can see the touchscreen clearly even in strong outdoor sunlight by automatically adjusting the contrast range based on the surrounding environment. Due to the nature of the product, displaying fixed graphics for extended periods may result in afterimages (screen burn-in) or ghosting. – It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods and turn off the touchscreen when not using the device. – You can set the touchscreen to turn off automatically when you are not using it. Launch the Settings app, tap Display → Screen timeout, and then select the length of time you want the device to wait before turning off the touchscreen. – To set the touchscreen to automatically adjust its brightness based on the surrounding environment, launch the Settings app, tap Display, and then tap the Adaptive brightness switch to activate it. • Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC, you can view the FCC ID of the device. To view the FCC ID, launch the Settings app and tap About phone → Status. If your device does not have an FCC ID, it means that the device has not been authorised for sale in the U.S. or its territories and may only be brought to the U.S. for the owner’s personal use. • Depending on the region, you can view the regulatory information on the device. To view the information, launch the Settings app and tap About phone → Regulatory information . Instructional icons Warning: situations that could cause injury to yo…

Text truncated - open the document above for the full version.

Apps and features 103 Gallery Introduction View images and videos stored in your device. You can also manage images and videos by album or create stories. Using Gallery Launch the Gallery app. • Videos: View the videos saved in your device. • Favourites: View your favourite photos and videos. • Recent: View recent photos and videos. • Suggested: View recommended content. Apps and features 104 Grouping similar images Launch the Gallery app and tap to group similar images and display only the best shots as a preview of the images. When you tap the image preview, you can view all the images in the group. The icon appears only when there are similar images. Creating movies Create a movie by selecting images or videos. Launch the Gallery app, tap , tick the files you want to use, and then tap Create movie. When you select Highlight reel, the device will automatically combine the highlights from the images or videos and create a movie. Searching for images Launch the Gallery app and tap to view images sorted by category, such as types or locations. To search for images by entering keywords, tap the search field. Apps and features 105 Viewing images 1 Launch the Gallery app and tap Pictures. 2 Select an image. Access additional options. Delete the image. Share the image with others. Modify the image. Bixby Vision Add the image to favourites. Apps and features 106 Cropping images by enlarging an area 1 Launch the Gallery app and tap Pictures. 2 Select an image. 3 Double-tap or spread two fingers apart on the area you want to save and tap . The cropped area will be saved as a file. Saved image thumbnail Apps and features 107 Viewing videos 1 Launch the Gallery app and tap Pictures. 2 Select a video to play. 3 Tap Play video to play the video. Lock the playback screen. Skip to the previous video. Tap and hold to rewind. Switch to the pop-up video player. Capture the current screen. Rewind or fast-forward by dragging the bar. Create an animated GIF. Access additional options. Rotate the screen. Skip to the next video. Tap and hold to fast-forward. Pause and resume playback. Change the screen ratio. Drag your finger up or down on the left side of the playback screen to adjust the brightness, or drag your finger up or down on the right side of the playback screen to adjust the volume. To rewind or fast-forward, swipe to the left or right on the playback screen. Apps and features 108 Using the Video enhancer feature Enhance the image quality of your videos to enjoy brighter and more vivid colours. Launch the Settings app, tap Advanced features, and then tap the Video enhancer switch to activate it. • This feature is only available in some apps. • Using this feature will increase battery consumption. Viewing albums You can view your images and videos sorted by folders or albums. Launch the Gallery app, tap Albums, and then select an album. Creating albums You can add albums and sort files. 1 Launch the Gallery app and tap Albums. 2 Tap → Create album. 3 Enter a title for the album and tap Create. Moving photos and videos to albums 1 Launch the Gallery app and tap Albums. 2 Select an album and tap Add items. 3 Tap Pictures, or tap Albums and select an album with the images or videos you want. 4 Tick files and tap Done. 5 Tap Move. The files will be deleted from the original folder and moved to the album. To copy the files, tap Copy. Apps and features 109 Deleting albums 1 Launch the Gallery app and tap Albums. 2 Tap and hold an album to delete, and tap Delete. Creating album groups You can add groups and sort albums. 1 Launch the Gallery app and tap Albums. 2 Tap → Create group. 3 Enter a title for the group and tap Create. 4 Select the group, tap Add albums, tick albums, and then tap Add. The albums will be moved to the group. Viewing stories When you capture or save images and videos, the device will read their date and location tags, sort the images and videos, and then create stories. To create stories automatically, you must capture or save multiple images and videos. Launch the Gallery app, tap Stories, and then select a story. Editing stories • To add images or videos to a story, select a story and tap Story album → → Add. • To remove images or videos from a story, select a story, tap Story album → → Edit, tick images or videos to remove, and then tap Remove from story. Deleting stories 1 Launch the Gallery app and tap Stories. 2 Tap and hold a story to delete, and tap Delete. Apps and features 110 Syncing images and videos When you sync your Gallery app with the cloud, photos and videos you take will also be saved in the cloud. You can view images and videos saved in the cloud in your Gallery app and from other devices. Launch the Gallery app, tap → Settings → Cloud sync, and then follow the on-screen instructions to complete the sync. The Gallery app and the cloud will be synced. When you connect your Samsung account and Microsoft account, you can set the cloud storage as Microsoft OneDrive. Deleting images or videos 1 Launch the Gallery app. 2 Select an image or a video to delete. To delete multiple files, tap and hold a file to delete on the list and tick more files to delete. 3 Tap or Delete. Using the recycle bin feature You can keep the deleted images and videos in the recycle bin. The files will be deleted after a certain period. Launch the Gallery app, tap → Settings, and then tap the Recycle bin switch to activate it. To view files in the recycle bin, launch the Gallery app and tap → Recycle bin. Apps and features 111 AR Zone Introduction AR Zone provides you AR related features, such as AR Emoji and AR Doodle. Choose a feature and capture fun photos or videos. Launching AR Zone Use the following methods to launch AR Zone: • Launch the AR Zone app. • Launch the Camera app and tap MORE → AR ZONE. Available features may vary depending on the region or service provider. • AR Emoji Camera: Create an emoji that looks just like you, and take photos and record videos using your emojis or chara…

Text truncated - open the document above for the full version.

SAMSUNG CONFIDENTIAL Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 16677, Korea Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 E- label Attestation Letter - FCC ID : A3LSMF707B - Model : SM-F707B To Whom It May Concern We hereby provide the following attestations according to CFR 2.935 and FCC KDB 784748 D02: At the time of purchase, the FCC ID is readily and physically visible to the purchaser on the exterior package per CFR 2.935(f). The FCC ID will be readily legible without the aid of magnification according to CFR 2.935(d). The literature in the package describes how to access the electronic display to find FCC ID per CFR 2.935(b) and FCC KDB 784748. Per CFR 2.935(c), the user will be able to access this information within a maximum of 3 steps. The user will be able to access this information without a SIM card, special accessories or supplemental plug-ins. Per CFR 2.935(e), We, Samsung Electronics Co., Ltd., have programmed the e-label and it is not able to be modified by any third party. Per CFR 2.935(f), the FCC ID will be able to survive normal shipping and handling so it is visible for inspection at the time of import. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Ms. Jenni Chun General Manager Regulatory & Environmental Affairs Samsung Electronics CO. LTD TEL: +1-973-808-6375 E-mail: [email protected]

Date: November 27, 2019 UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea To whom it may concern: I, the undersigned, hereby authorize UL Korea, Ltd. Suwon Laboratory, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Korea, Ltd. Suwon Laboratory on our behalf shall have the same effect as acts of our own. In authorizing UL Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. l) the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

May 25, 2020 Federal Comm unications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMF707B To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0. 457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above docu ments might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

A. Information to be displayed 1. The information that will be displayed on the e-label and information that will remain in the user manual is shown below: Information On E-label In Manual FCC ID number Yes Yes DoC logo Not Applicable Not Applicable 15.19 statement (“This device complies with part 15 of the FCC Rules. Operation is s ubject to the following two conditions: (1) This d evice may not cause harmful interference, and (2) this d evice must accept any interference received, including interference that may cause undesired operation.”) - Yes Class A / B Digital Device user manual statements1 - Yes DoC declaration1 Not Applicable Not Applicable Caution to the user that changes or modifications not expressly approved by the party responsib le for compliance could void the user's authority to operate the equipment1 - Yes Describe any other FCC regulatory - Yes Describe any other FCC regulatory information included in e-label 1 None Not Applicable If the e-label includes information typically included in the manual then the e-label shall clearly differentiate between information required to be on the device’s surface and information required to be in the manual – refer to 784748 D02 e labe lling v01 section II D 3(b) Images of the e-label screen are provided below: B.Access to the required information on the e-label 1.Users are able to access the information in no more t han three steps i n a device’s menu. The actual steps are: From the home screen: a) Click on Setti ngs Apps b) About phone c) Stat us No special access codes or permissions are required to go through the above steps beyond entering a user defined password to protect against unauthorized access to the device. 2. The information is stored on the device, no special a ccessories or supplemental plug-ins (e.g., a SIM/USIM card) are req uir ed to access the information. 3.Users are provided specific instructions on how to access the information. The information is provided in User manual.

Plot No. 1 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-05-14 GSM 850 Frequency: 836.6 MHz; Duty Cycle: 1:4.00037; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.926 S/m; ε r = 41.296; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE4 Sn1591; Calibrated: 2019-09-11 - Probe: EX3DV4 - SN7545; ConvF(9.8, 9.8, 9.8) @ 836.6 MHz; Calibrated: 2019-09-23 - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: Twin-SAM V8.0 (20deg probe tilt); Type: QD 000 P41 AA; Serial: 1989 RHS/Touch/GPRS 2slot ch.190/Area Scan (8x14x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.355 W/kg RHS/Touch/GPRS 2slot ch.190/Zoom Scan (6x6x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 19.82 V/m; Power Drift = 0.09 dB Peak SAR (extrapolated) = 0.419 W/kg SAR(1 g) = 0.319 W/kg; SAR(10 g) = 0.237 W/kg Maximum value of SAR (measured) = 0.364 W/kg 0 dB = 0.364 W/kg = -4.39 dBW/kg Plot No. 2 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-05-14 GSM 850 Frequency: 836.6 MHz; Duty Cycle: 1:4.00037; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.926 S/m; ε r = 41.296; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE4 Sn1591; Calibrated: 2019-09-11 - Probe: EX3DV4 - SN7545; ConvF(9.8, 9.8, 9.8) @ 836.6 MHz; Calibrated: 2019-09-23 - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: Twin-SAM V8.0 (20deg probe tilt); Type: QD 000 P41 AA; Serial: 1989 Rear/GPRS 2slot ch.190/Area Scan (8x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.456 W/kg Rear/ GPRS 2slot ch.190/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 22.27 V/m; Power Drift = -0.05 dB Peak SAR (extrapolated) = 0.577 W/kg SAR(1 g) = 0.384 W/kg; SAR(10 g) = 0.252 W/kg Maximum value of SAR (measured) = 0.466 W/kg 0 dB = 0.466 W/kg = -3.32 dBW/kg Plot No. 3 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-05-14 GSM 850 Frequency: 848.8 MHz; Duty Cycle: 1:4.00037; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used (interpolated): f = 848.8 MHz; σ = 0.929 S/m; ε r = 41.278; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE4 Sn1591; Calibrated: 2019-09-11 - Probe: EX3DV4 - SN7545; ConvF(9.8, 9.8, 9.8) @ 848.8 MHz; Calibrated: 2019-09-23 - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: Twin-SAM V8.0 (20deg probe tilt); Type: QD 000 P41 AA; Serial: 1989 Rear/GPRS 2slot ch.251/Area Scan (8x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.731 W/kg Rear/GPRS 2slot ch.251/Zoom Scan (6x6x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 28.05 V/m; Power Drift = -0.17 dB Peak SAR (extrapolated) = 0.937 W/kg SAR(1 g) = 0.604 W/kg; SAR(10 g) = 0.389 W/kg Maximum value of SAR (measured) = 0.732 W/kg 0 dB = 0.732 W/kg = -1.35 dBW/kg Plot No. 4 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-05-18 GSM 1900 Frequency: 1880 MHz; Duty Cycle: 1:2.60016; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used: f = 1880 MHz; σ = 1.416 S/m; ε r = 39.778; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE4 Sn1591; Calibrated: 2019-09-11 - Probe: EX3DV4 - SN7545; ConvF(7.91, 7.91, 7.91) @ 1880 MHz; Calibrated: 2019-09-23 - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: Twin-SAM V8.0 (20deg probe tilt); Type: QD 000 P41 AA; Serial: 1989 RHS/Touch GPRS 3slot ch.6…
