A3LSMG736BMobile Phone

Printed in Korea GH68-54628A Rev.1.0 English. 04/2022 SM-G736B/DS QUICK START GUIDE ► To view the user manual, scan the QR code. 2 Package contents • Device • USB cable • Battery • Quick start guide The items supplied with the device and their images may vary by region. Installing a nano-SIM card (sold separately) and battery • Ensure that the back cover is closed tightly. • Use only Samsung-approved back covers and accessories with the device. 2 2 1 Press Align 1 Ensure that the back cover is closed tightly to prevent water and dust from entering the device. Open or loose back cover may allow water and dust to enter the device and cause damage. English English 3 Accessing more information Visit www.samsung.com to view device information and more. To view the user manual, scan the QR code on the front cover. You may incur additional charges for accessing the Internet. Safety information Read all safety information before using the device to ensure safe and proper use. You can view more safety information in the safety information menu of the Settings app. Follow the warnings below to prevent incidents, such as fires or explosions, injuries, or damage to the device • Your device contains magnets. Keep a safe distance between your device and objects that may be affected by magnets such as credit cards and implantable medical devices. If you have an implantable medical device, consult your physician before use. • Do not expose the device to physical impact or damage. • Use only Samsung-approved batteries, chargers, and cables specifically designed for your device. • Prevent the multipurpose jack and battery terminals from coming into contact with foreign materials such as metal, liquids, or dust. • If any part of the device, such as the glass or acrylic body, is broken, smokes, or emits a burning odor, stop using the device immediately. Use the device again only after it has been repaired at a Samsung Service Centre. • Do not turn on or use the device when the battery compartment is exposed. • Do not disassemble or reuse the battery. • The device can be used in locations with an ambient temperature of 0 °C to 35 °C. You can store the device at an ambient temperature of -20 °C to 50 °C. Using or storing the device outside of the recommended temperature ranges may damage the device or reduce the battery’s lifespan. 4 To prevent possible hearing damage when using a headset, do not listen to sound at high volume for long periods. This marking on the product, accessories or literature and without the bar on batteries indicates that the product, battery and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. • For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, visit our sustainability page available via www.samsung.com. Specific Absorption Rate (SAR) certification information Your device conforms to U.S. Federal Communications Commission (FCC) standards that limit human exposure to radio frequency (RF) energy emitted by radio and telecommunications equipment. These standards prevent the sale of mobile devices that exceed a maximum exposure level (known as the Specific Absorption Rate, or SAR) of 1.6 W/kg. In normal use, the actual SAR is likely to be much lower, as the device has been designed to emit only the RF energy necessary to transmit a signal to the nearest base station. By automatically emitting lower levels when possible, your device reduces your overall exposure to RF energy. The FCC has granted an Equipment Authorization for this model device based on the compliance of all reported SAR levels with the FCC RF exposure guidelines. Some devices are required to receive approval from the FCC. Follow the instructions on the website to use the FCC ID to find SAR values for the device. SAR information for this device can also be found on Samsung’s website: www.samsung.com/sar. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5cm separation between the device and the user's body. 5 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The device may cause TV or radio interference if used in close proximity to receiving equipment. The FCC can require you to stop using the mobile device if such interference cannot be eliminated. 6 • The back cover may be loosened if the device is dropped or receives an impact. Ensure that all the covers are properly aligned and tightly closed. • If the device has been immersed in water or the microphone or speaker is wet, sound may not be heard clearly during a call…

Text truncated - open the document above for the full version.

Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu Suwon-City, Gyeonggi-do, 16677, Korea Date: April 29, 2022 To Whom it May Concern Subject : FCC ID: U-NII 6 GHz Client Operation A3LSMG736B We attest the following: 1.This device will only associate with a low power indoor AP for WIFI 6E operations. Hotspot Mode, ad-hoc and any other P2P service is disabled for WIFI 6E operations. This device will not connect directly to another client device using WIFI 6E frequencies. 2.This device will operate only under the control of an indoor access point, except for transmitting brief messages to an AP when attempting to join its network after detecting a signal that confirms that an access point is operating on a particular channel. These brief messages will have a time-out mechanism such that if it does not receive a response from an AP, it will not continually repeat the request. 3.Transmissions will be lower or equal to the power advertised by the indoor low-power access point and never above the maximum output power allowed by the FCC grant. 4.This device is prohibited for control of or communications with unmanned aircraft systems, including drones. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jenni Chun / General Manager Samsung Electronics America, Inc. Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1- 973-808-6375

Samsung Electronics America, Inc 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: May 2, 2022 FCC ID: A3LSMG736B To whom it may concern: We, the undersigned, hereby authorize HCT Co., LTD to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by HCT Co., LTD on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to any application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, ---------------------------------------------------- Jenni Chun / General Manager Samsung Electronics America, Inc. Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1-973-808-6375

DATE : May 3, 2022 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMG736B To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards ---------------------------------------------------- Jenni Chun / General Manager Samsung Electronics America, Inc. Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1-973-808-6375

Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu Suwon-City, Gyeonggi-do, 16677, Korea Date: April 29, 2022 To Whom it May Concern Subject : FCC ID: U-NII 6 GHz Client Operation A3LSMG736B We attest the following: 1.This device will only associate with a low power indoor AP for WIFI 6E operations. Hotspot Mode, ad-hoc and any other P2P service is disabled for WIFI 6E operations. This device will not connect directly to another client device using WIFI 6E frequencies. 2.This device will operate only under the control of an indoor access point, except for transmitting brief messages to an AP when attempting to join its network after detecting a signal that confirms that an access point is operating on a particular channel. These brief messages will have a time-out mechanism such that if it does not receive a response from an AP, it will not continually repeat the request. 3.Transmissions will be lower or equal to the power advertised by the indoor low-power access point and never above the maximum output power allowed by the FCC grant. 4.This device is prohibited for control of or communications with unmanned aircraft systems, including drones. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jenni Chun / General Manager Samsung Electronics America, Inc. Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1- 973-808-6375

FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 1 / 7 HCT CO.,LTD. - EXTERNAL PHOTOGRAPHS FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 2 / 7 HCT CO.,LTD. 1. External Photo (Front view) FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 3 / 7 HCT CO.,LTD. 2. External Photo (Rear view) FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 4 / 7 HCT CO.,LTD. 3. External Photo (Left side view) FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 5 / 7 HCT CO.,LTD. 4. External Photo (Right side view) FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 6 / 7 HCT CO.,LTD. 5. External Photo (Top view) FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 7 / 7 HCT CO.,LTD. 6. External Photo (Bottom view)

Label and Location Model: SM-G736B/DS FCC ID: A3LSMG736B Label: Location: Label TOP Bottom Bottom side of device Phone: Label is placed inside of the battery compartment.

FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 1 / 17 HCT CO.,LTD. - INTERNAL PHOTOGRAPHS FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 2 / 17 HCT CO.,LTD. ■ Main / Bluetooth & WLAN Antenna Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 3 / 17 HCT CO.,LTD. 1. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 4 / 17 HCT CO.,LTD. 2. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 5 / 17 HCT CO.,LTD. 3. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 6 / 17 HCT CO.,LTD. 4. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 7 / 17 HCT CO.,LTD. 5. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 8 / 17 HCT CO.,LTD. 6. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 9 / 17 HCT CO.,LTD. 7. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 10 / 17 HCT CO.,LTD. 8. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 11 / 17 HCT CO.,LTD. 9. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 12 / 17 HCT CO.,LTD. 10. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 13 / 17 HCT CO.,LTD. 11. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 14 / 17 HCT CO.,LTD. 12. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 15 / 17 HCT CO.,LTD. 13. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 16 / 17 HCT CO.,LTD. 14. Internal Photo FCC ID: A3LSMG736B F-TP22-03 (Rev.00) 17 / 17 HCT CO.,LTD. 15. Internal Photo

F-TP22-03 (Rev.00) Page 1 of 90 HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 Fax. +82 31 645 6401 WIFI 6 GHz RF Exposure Report Applicant Name: SAMSUNG Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu, Suwon-Si, Gyeonggi-do, 16677 Rep. of Korea Date of Issue: May. 12, 2022 Test Report No.: HCT-SR-2204-FC005-R1 Test Site: HCT CO., LTD. FCC ID: Equipment Type: Mobile Phone Application Type Certification FCC Rule Part(s): CFR §2.1093 Model Name: SM-G736B/DS Additional Model Name: SM-G736B Date of Test: Apr. 21, 2022 ~ Apr. 21, 2022 Band Tx. Frequency Equipment Class SAR APD PD 1g Head 1g Body-Worn 10g Phablet Head Body-Worn Phablet psPD (W/kg) (W/kg) (W/kg) (mW/cm²) (mW/cm²) (mW/cm²) (mW/cm²) WIFI 6㎓ 5 955㎒ ~ 7 115㎒ 6XD 0.047 0.09 0.216 0.023 0.048 0.374 0.275 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Tested By Jinnyeong, Choi Test Engineer SAR Team Certification Division Reviewed By Yun Jeang, Heo Technical Manager SAR Team Certification Division This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the HCT Co., Ltd. A3LSMG736B FCC ID:A3LSMG736B Report No:HCT-SR-2204-FC005-R1 F-TP22-03 (Rev.00) Page 2 of 90 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 May. 02, 2022 Initial Release 1 May. 12, 2022 Revised U-NII-5 Frequency Range This test results were applied only to the test methods required by the standard. FCC ID:A3LSMG736B Report No:HCT-SR-2204-FC005-R1 F-TP22-03 (Rev.00) Page 3 of 90 Table of Contents REVISION HISTORY ......................................................................................................................................... 2 1. Test Regulations ........................................................................................................................................... 4 2. Test Location ................................................................................................................................................ 5 3. Information of the EUT ................................................................................................................................. 6 4. Device Under Test Description ................................................................................................................... 6 5. Limits ............................................................................................................................................................. 9 6. RF Conducted Powers ............................................................................................................................... 10 7. System Verification .................................................................................................................................... 11 8. SAR Test Data Summary ........................................................................................................................... 13 9. Measurement Uncertainty ......................................................................................................................... 18 10. SAR Test Equipment ................................................................................................................................ 20 11. Conclusion ................................................................................................................................................ 21 12. References ................................................................................................................................................ 22 Appendix A. – DUT Ant. Information & SETUP PHOTO .............................................................................. 24 Appendix B. – SAR Test Plots ....................................................................................................................... 25 Appendix C. – Dipole Verification Plots ....................................................................................................... 30 Appendix D. – Probe Calibration Data ......................................................................................................... 33 Appendix E. – Dipole Calibration Data ......................................................................................................... 77 FCC ID:A3LSMG736B Report No:HCT-SR-2204-FC005-R1 F-TP22-03 (Rev.00) Page 4 of 90 1. Test Regulations FCC RF Exposure evaluation of U-NII 6 -7 GHz Band of this device were measured by referring to the interim procedures in TCB Workshop document of Oct 2020, IEC/IEEE 62209-1528:2020 and also the AppNote of SPEAG, the manufacturer of measuring equipment. SAR Testing was performed using 6.5 GHz SAR Probe calibration factor according to FCC TCBC Document. November 2017, October 2018, April 2019, November 2019, October 2020 TCBC Workshop Notes. SPEAG DASY6 System Handbook SPEAG DASY6 Application Note (Interim Procedures for Operating at 6 -10GHz) (June 2021) IEEE 1528-2013 IEC TR 63170:2018 IEC 62479:2010 FCC KDB 865664 D02 v01r02 FCC KDB 64 D04 v01r03 FCC KDB 248227 D01 v02r02 FCC KDB 447498 D01 v06 FCC KDB 864664 D01 v01r04 FCC KDB 648474 D04 v01r03 In Addition to the above, the following information was used. - November 2019 TCBC Workshop Notes (SPLSR Hotspot Combination) FCC ID:A3LSMG736B Report No:HCT-SR-2204-FC005-R1 F-TP22-03 (Rev.00) Page 5 of 90 2. Test Location 2.1 Test Laboratory Company Name HCT Co., Ltd. Address 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si,Gyeonggi-do, 17383 KOREA Telephone 031-645-6300 Fax. 031-645-6401 2.2 Test Facilities Our laboratories are accredited a…
