www.samsung.com SM-P605 You can access the full user manual for more in formation. To learn to access the user manual, see “Viewing the user manual” in this quick start guide. Quick Start Guide 4 Instructional icons Warning: situations that could cause injury to yourself or others Caution: situations that could cause damage to your device or other e quipment Note: notes, usage tips, or additional informatio n Copyright Copyright © 2013 Samsung Electronics This guide is protected under international copyright laws . No part of this guide may be reproduced, distributed , translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in an y information storage and retrieval s ystem, without the prior written permission of Samsung Electronics. 5 Trademarks •SAMSUNG and the SAMSUNG logo are registered trademarks o f Samsung E lectronics. •The Android logo, Google ™ , Google Maps ™ , Google Mail ™ , Yo uTube ™ , Goog le Play ™ Store, and Google Talk ™ are trademarks o f Google, Inc. •Bluetooth ® is a registered trademark of B luetooth SIG, Inc. worldwide. •Wi-Fi ® , Wi-Fi Protected Setup ™ , Wi-Fi Direct ™ , Wi-Fi CERTIFIED ™ , and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance . Your device uses a non-harmonised frequency and is intended for use in all European countries. T he WLAN can be operated in the EU without restriction in doors, but cannot be operated outdoors. • All other trademarks and cop yrights are the property o f their respective owners. 6 Getting started Device layout Back button Home button Speaker Light sensor Menu button Multipurpose jack Touch screen Front camera Power button Volume button Microphone SIM card slot Rear camera Memory card slot Speaker Main antenna Headset jack S Pen slot Flash GPS antenna 7 Getting started Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the batter y. Installing the SIM or USIM card Insert the SIM or USIM card provided by the mobile telephone service provider. • Only microSIM cards work with the device. • Some LTE services may not be avai lable depending on the service provider. For details about service availabilit y, contact your service provider. 8 Getting started 1 Insert the SIM or USIM card with the gold- coloured contacts facing downwards. Do not insert a memory card into the SIM card slot. I f a memory card happens to be lodged in the SIM card s lot, take the device to a Samsung Service Centre to remove the memory car d. 2 Push the SIM or USIM card into the slot until it lock in place. 9 Getting started Charging the battery Before using the device for the first time or when the batter y has been unused for exten ded periods, you must charge the batter y. Use only Samsung-approved c hargers, batteries, and cables. Unapproved char gers or cables can cause the battery to explode or dama ge the device. Connect the USB cable to the USB power adaptor and then plug the end o f the USB cable into the multipurpose jack . 10 Getting started Connecting the charger improperly may cause serious damage to the device. An y damage caused b y misuse is not covered by the warran ty. After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket. To save energy, unplug the charger when not in use. The char ger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging. 11 Getting started Checking the battery charge status When you charge the battery while the device is o ff, the following icons will show the current battery charge status: ChargingFully charged Turning the device on and off When turning on the device for the first time, follow the on-screen instructions to set up your device. 12 Getting started Press and hold the Power button for a few seconds to turn the device on and off. Viewing the user manual The user manual provides complete in formation about operating your device. You may incur additional charges for accessing the Internet or downloading media files. For details, contact your service provider. 13 Getting started From your device 1 Open the Internet application. 2 Tap to open the bookmarks list. 3 Select the bookmark for the user manual. To access the user manual more easily, place a shortcut or widget for the user manual on the Home screen. The user manual may not be available depending on the web browser or service provider. From your computer Access www.samsung.com and then searchm for the user manual by the model name of your device . 14 Safety information This safety information contains content for mobile devices. Some content may be not applicable to your device. To prevent injury to yourself and others or damage to your device, read the safety in formation about your device before using the device. Warning Failure to comply with safety warnings an d regulations can cause serious injury or death Do not use damaged power cords or plugs, or loose e lectrical sockets Unsecured connections can cause electric shock or fire. Do not touch the power cord with wet hands or disconnect the charger by pulling the cord Doing so may result in electrocution. Do not bend or dama ge the power cord Doing so may cause electric shock or fire. 15 Safety information Do not use your device while it is charging or touch your device with wet hands Doing so ma y cause electric shock. Do not s hort-circuit the charger or the device Doing so may cause electric shock or fire, or the battery ma y malfunction or explode. Do not use your device outdoor during a thunderstorm Doing so may resu lt in electric shock or device mal function. Use manufacturer-approved batteries, chargers, accessories, and su pplies • Using generic batteries or chargers may shorten the life of your…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: September 5, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSMP605 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics 4 Parts List & Tune-Up Procedure SHORT-TERM 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea September 5, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMP605 Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy of KDB 784748 D01.. The label statement is as follows: The FCC ID label is located on the rear of the device with the battery installed. At this time the FCC ID is readily visible to the user. The label is permanently engraved by laser and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

Label and Location Samsung Model: FCC ID: A3LSMP605 Label: Location: Top Back of device Bottom FCC ID is printed on bottom of the device SM-P605

Reviewed by: FCC ID:A3LSMP605 SAR EVALUATION REPORT Quality Manager Document S/N: Test Dates: DUT Type: 0Y1308121582-R2.A3L 08/21/13 - 08/28/13 Portable Tablet Page 1 of 62 © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 08/21/13 - 08/28/13 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab, Columbia, MD, USA Gyeonggi-do 443-742, Korea Document Serial No.: 0Y1308121582-R2.A3L FCC ID: A3LSMP605 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. DUT Type: Portable Tablet Application Type: Certification FCC Rule Part(s): CFR §2.1093 Model(s): SM-P605 1 gm Body (W/kg) PCBGSM/GPRS/EDGE 850824.20 - 848.80 MHz31.40 0.84 PCBUMTS 850826.40 - 846.60 MHz22.55 0.69 PCBGSM/GPRS/EDGE 19001850.20 - 1909.80 MHz25.91 1.09 PCBUMTS 19001852.4 - 1907.6 MHz22.610.78 PCBLTE Band 5 (Cell)824.7 - 848.3 MHz22.950.54 DTS2.4 GHz WLAN2412 - 2462 MHz11.741.08 DTS5.8 GHz WLAN5745 - 5825 MHz7.760.84 NII5.2 GHz WLAN5180 - 5240 MHz8.030.60 NII5.3 GHz WLAN5260 - 5320 MHz8.060.85 NII5.5 GHz WLAN5500 - 5700 MHz7.991.06 DSS/DTSBluetooth2402 - 2480 MHz8.13 1.56 N/A SAR Band & ModeTx Frequency Measured Conducted Power [dBm] Simultaneous SAR per KDB 690783 D01v01r02: Equipment Class Note: Powers in the above table represent output powers for the SAR test configurations and may not represent the highest output powers for all configurations for each mode. Note: This revised Test Report (S/N: 0Y1308121582-R2.A3L) supersedes and replaces the previously issued test report on the same subject device for the same type of testing as indicated. Please discard or destroy the previously issued test report(s) and dispose of it accordingly This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in Section 1.7 of this report; for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctestlab.com SAR EVALUATION REPORT Reviewed by: FCC ID:A3LSMP605 SAR EVALUATION REPORT Quality Manager Document S/N: Test Dates: DUT Type: 0Y1308121582-R2.A3L 08/21/13 - 08/28/13 Portable Tablet Page 2 of 62 © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 TABLE OF CONTENTS 1 DEVICE UNDER TEST ................................................................................................................... 3 2 LTE INFORMATION ...................................................................................................................... 10 3 INTRODUCTION ........................................................................................................................... 11 4 DOSIMETRIC ASSESSMENT ...................................................................................................... 12 5 SAR TESTING PROCEDURES .................................................................................................... 13 6 RF EXPOSURE LIMITS ................................................................................................................ 14 7 FCC MEASUREMENT PROCEDURES........................................................................................ 15 8 RF CONDUCTED POWERS......................................................................................................... 20 9 SYSTEM VERIFICATION.............................................................................................................. 32 10 SAR DATA SUMMARY ................................................................................................................. 34 11 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS......................................................... 39 12 SAR MEASUREMENT VARIABILITY ........................................................................................... 56 13 EQUIPMENT LIST......................................................................................................................... 57 14 MEASUREMENT UNCERTAINTIES ............................................................................................ 58 15 CONCLUSION............................................................................................................................... 60 16 REFERENCES .............................................................................................................................. 61 APPENDIX A: SAR TEST PLOTS APPENDIX B: SAR DIPOLE VERIFICATION PLOTS APPENDIX C: PROBE AND DIPOLE CALIBRATION CERTIFICATES APPENDIX D: SAR TISSUE SPECIFICATIONS APPENDIX E: SAR SYSTEM VALIDATION APPENDIX F: SAR TEST SETUP PHOTOGRAPHS Reviewed by: FCC ID:A3LSMP605 SAR EVALUATION REPORT Quality Manager Document S/N: Test Dates: DUT Type: 0Y1308121582-R2.A3L 08/21/13 - 08/28/13 Portable Tablet Page 3 of 62 © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 1 DEVICE UNDER TEST 1.1 Device Overview GSM/GPRS/EDGE 850Voice/Data824.20 - 848.80 MHz UMTS 850Voice/Data826.40 - 846.60 MHz GSM/GPRS/EDGE 1900Voice/Data1850.20 - 1909.80 MHz UMTS 1900Voice/Data1852.4 - 1907.6 MHz LTE Band 5 (Cell)Data824.7 - 848.3 MHz 2.4 GHz WLANData2412 - 2462 MHz 5.8 GHz WLANData5745 - 5825 MHz 5.2 GHz WLANData5180 - 5240 MHz 5.3 GHz WLANData5260 - 5320 MHz 5.5 GHz WLANData5500 - 5700 MHz BluetoothData2402 - 2480 MHz ANT+Data2402 -2480 MHz Band & ModeTx Frequency Operating Modes 1.2 Power …

Text truncated - open the document above for the full version.

FCC ID: A3LSMP605 FCC Pt. 22 & 24 GSM / EDGE / WCDMA MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 61 0Y1308121583.A3L 8/20 - 8/21/2013 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. V 3.0 06/17/2013 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 8/20 - 8/21/2013 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab., Columbia, MD, USA Gyeonggi-do 443-742, Korea Test Report Serial No.: 0Y1308121583.A3L FCC ID: A3LSMP605 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. Application Type: Certification Model(s): SM-P605 EUT Type: Portable Tablet FCC Classification: PCS Licensed Transmitter (PCB) FCC Rule Part(s): §2 §22(H) §24(E) Test Procedure(s): ANSI/TIA-603-C-2004, KDB 971168 v02r01 Test Device Serial No.: identical prototype [S/N: 93502455_156] Max. Power (W ) Max. Power (dBm) GSM850824.2 - 848.8246KGXW0.30324.82 EDGE850824.2 - 848.8243KG7W0.07218.57 GSM19001850.2 - 1909.8248KGXW0.59227.72 EDGE19001850.2 - 1909.8247KG7W0.27124.33 WCDMA850826.4 - 846.64M15F9W0.02413.78 WCDMA19001852.4 - 1907.64M15F9W0.07718.87 ERP/EIRP Mode Tx Frequency (MHz) Emission Designator This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC Part 22 & 24 FCC ID: A3LSMP605 FCC Pt. 22 & 24 GSM / EDGE / WCDMA MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 61 0Y1308121583.A3L 8/20 - 8/21/2013 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. V 3.0 06/17/2013 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT .......................................................................................... 3 1.0 INTRODUCTION .............................................................................................................................. 4 1.1 SCOPE ................................................................................................................................................ 4 1.2 TESTING FACILITY ............................................................................................................................. 4 2.0 PRODUCT INFORMATION .............................................................................................................. 5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 DEVICE CAPABILITIES....................................................................................................................... 5 2.3 TEST CONFIGURATION ..................................................................................................................... 5 2.4 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 3.0 DESCRIPTION OF TESTS .............................................................................................................. 6 3.1 EVALUATION PROCEDURE .............................................................................................................. 6 3.2 CELLULAR - BASE FREQUENCY BLOCKS ....................................................................................... 6 3.3 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 6 3.4 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 6 3.5 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.6 RADIATED MEASUREMENTS ............................................................................................................ 8 4.0 TEST EQUIPMENT CALIBRATION DATA ...................................................................................... 9 5.0 SAMPLE CALCULATIONS ............................................................................................................ 10 6.0 TEST RESULTS ............................................................................................................................. 11 6.1 SUMMARY ......................................................................................................................................... 11 6.2 OCCUPIED BANDWIDTH ................................................................................................................. 12 6.3 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL ............................................ 16 6.4 BAND EDGE EMISSIONS AT ANTENNA TERMINAL ...................................................................... 31 6.5 PEAK-AVERAGE RATIO ................................................................................................................... 37 6.6 RADIATED POWER (ERP/EIRP) ...................................................................................................... 40 6.7 RADIATED SPURIOUS EMISSIONS MEASUREMENTS ................................................................. 44 6.8 FREQUENCY STABILITY / TEMPERATURE VARIATION ............................................................... 52 7.0 CONCLUSION ..........................................................................................…

Text truncated - open the document above for the full version.

FCC ID: A3LSMP605 FCC Pt. 22 LTE MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 31 0Y1308121584.A3L 8/20 - 8/21/2013 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. V4.5 04/15/2013 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 8/20 - 8/21/2013 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab., Columbia, MD, USA Gyeonggi-do 443-742, Korea Test Report Serial No.: 0Y1308121584.A3L FCC ID : A3LSMP605 APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. FCC Classification: PCS Licensed Transmitter (PCB) FCC Rule Part(s): §2; §22 EUT Type: Portable Tablet Model(s): SM-P605 Test Device Serial No.: identical prototype [S/N: 93502455_156] Max. Power (W) Max. Power (dBm) LTE Band 5824.7 - 848.31M12G7DQPSK0.04516.55 LTE Band 5824.7 - 848.31M12W7D16QAM0.03415.31 LTE Band 5825.5 - 847.52M72G7DQPSK0.04716.72 LTE Band 5825.5 - 847.52M72W7D16QAM0.04316.29 LTE Band 5826.5 - 846.54M49G7DQPSK0.05417.29 LTE Band 5826.5 - 846.54M51W7D16QAM0.04016.00 LTE Band 5829 - 8448M99G7DQPSK0.04816.82 LTE Band 5829 - 8449M01W7D16QAM0.03615.57 Mode Tx Frequency (MHz) Emission Designator ERP/EIRP Modulation This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC Part 22 LTE FCC ID: A3LSMP605 FCC Pt. 22 LTE MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 31 0Y1308121584.A3L 8/20 - 8/21/2013 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. V4.5 04/15/2013 TABLE OF CONTENTS FCC PART 22 MEASUREMENT REPORT .................................................................................................. 3 1.0 INTRODUCTION .............................................................................................................................. 4 1.1 SCOPE ................................................................................................................................................ 4 1.2 TESTING FACILITY ............................................................................................................................. 4 2.0 PRODUCT INFORMATION .............................................................................................................. 5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 DEVICE CAPABILITIES....................................................................................................................... 5 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.4 LABELING REQUIREMENTS .............................................................................................................. 5 3.0 DESCRIPTION OF TESTS .............................................................................................................. 6 3.1 MEASUREMENT PROCEDURE ......................................................................................................... 6 3.2 CELLULAR - BASE FREQUENCY BLOCKS ....................................................................................... 6 3.3 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 6 3.4 OCCUPIED BANDWIDTH ................................................................................................................... 6 3.5 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL .............................................. 6 3.6 RADIATED POWER AND RADIATED SPURIOUS EMISSIONS ........................................................ 8 3.7 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 9 4.0 TEST EQUIPMENT CALIBRATION DATA .................................................................................... 10 5.0 SAMPLE CALCULATIONS ............................................................................................................ 11 6.0 TEST RESULTS ............................................................................................................................. 12 6.1 SUMMARY ......................................................................................................................................... 12 6.2 EFFECTIVE RADIATED POWER (ERP) ........................................................................................... 13 6.3 BAND 5 RADIATED SPURIOUS EMISSIONS .................................................................................. 14 6.4 BAND 5 FREQUENCY STABILITY MEASUREMENTS..................................................................... 17 7.0 BAND 5 PLOTS OF EMISSIONS ................................................................................................... 19 8.0 CONCLUSION ................................................................................................................................ 31 FCC ID: A3LSMP605 FCC Pt. 22 LTE MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 3 of 31 0Y1308121584.A3L 8/20 - 8/21/2013 Portable Tablet © 2013 PCTEST Engineering Laboratory, Inc. V4.5 04/15/2013 MEASUREMENT …

Text truncated - open the document above for the full version.

Samsung Electronics, Co. Ltd. FCC ID: A3LSMP605 Model: SM-P605 Test Set-Up Photos EUT Type: Portable Tablet Page 1 of 2 © 2013 PCTEST Engineering Laboratory Inc. TEST SETUP PHOTOGRAPHS Samsung Electronics, Co. Ltd. FCC ID: A3LSMP605 Model: SM-P605 Test Set-Up Photos EUT Type: Portable Tablet Page 2 of 2 © 2013 PCTEST Engineering Laboratory Inc.

Reviewed by: FCC IDA3LSMP605 SAR EVALUATION REPORT Quality Manager Test Dates: DUT Type: 08/21/13 - 08/28/13 Portable Tablet APPENDIX F: Page 1 of 4 © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 APPENDIX F: SAR TEST SETUP PHOTOGRAPHS Reviewed by: FCC IDA3LSMP605 SAR EVALUATION REPORT Quality Manager Test Dates: DUT Type: 08/21/13 - 08/28/13 Portable Tablet APPENDIX F: Page 2 of 4 © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 SAR Test Setup Photo 1 – Back Side at 0 mm SAR Test Setup Photo 2 – Back Side at 12 mm Reviewed by: FCC IDA3LSMP605 SAR EVALUATION REPORT Quality Manager Test Dates: DUT Type: 08/21/13 - 08/28/13 Portable Tablet APPENDIX F: Page 3 of 4 © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 SAR Test Setup Photo 3 – Bottom Edge at 0 mm SAR Test Setup Photo 4 – Right Edge at 0 mm Reviewed by: FCC IDA3LSMP605 SAR EVALUATION REPORT Quality Manager Test Dates: DUT Type: 08/21/13 - 08/28/13 Portable Tablet APPENDIX F: Page 4 of 4 © 2013 PCTEST Engineering Laboratory, Inc. REV 12.5 M 05/20/2013 SAR Test Setup Photo 5 – Left Edge at 0 mm SAR Test Setup Photo 6 – Left Edge at 15 mm
