Quick Reference Guide (Terms and Conditions) SM-T 636B SM-T638B Read this document before operating the mobile device, accessories, or software (defined collectively and individually as the “Product”) and keep it for future reference. This document contains important Terms and Conditions. Electronic acceptance, opening the packaging, use, or retention of the Product constitutes acceptance of these Terms and Conditions. Visit www.samsung.com/us to view device information, the user manual, and more. You may incur additional charges for accessing the Internet. DRAFT Device Layout To turn on the device, press and hold the Side key for a few seconds. The charger should remain close to the electric socket and easily acc essible while charging. Installing a nano-SIM card Nano-SI M cards are sold separately. Contact us Questions? Visit us.community.samsung.com Get Support Call 1.800.SAMSUNG Service locations Find a service location near you at Samsung.com/us/support/service/locations Switching made simple Whether you are coming from an iOS or Android platform, you can easily transfer your data with Smart Switch. Back up your old phone Back up your old phone using your favorite back-up app. Samsung Smart Switch 1. From your new Galaxy device, tap Settings > Accounts and backup > Smart Switch. 2. Tap Receive data. 3. Select your old device type. 4. Tap Cable (Android) or Wireless (Android and iOS) and follow the prompts to connect your phones. Customize Tap Settings to personalize your phone. Flight mode This disables all wireless functions on your device. You can use only non- network services On the setting screen, tap Flight mode. NOTE: The use of mobile devices on an aircraft or a ship may be subject to federal and local guidelines and restrictions. Check with appropriate author and always follow crew instructions regarding when and how you may use your device. Important legal information Arbitration Agreement - This Product is subject to a binding arbitration agreement between you and SAMSUNG ELECTRONICS AMERICA, INC. (“Samsung”). You can opt out of the agreement within 30 calendar days of the first consumer purchase by emailing [email protected] or calling 1-800-SAMSUNG (726-7864) and providing the applicable information. The full Arbitration Agreement, Standard One-year Limited Warranty, End User License Agreement (EULA), and Health & Safety Information for your device are available online: • English: www.samsung.com/us/Legal/Tablet-HSGuide • Spanish: www.samsung.com/us/Legal/Tablet-HSGuide-SP This information can also be found on the device in the “About device” or “About phone” or “About tablet” section, for example: • Settings > About phone or About device or About tablet > Legal information > Samsung legal • Or,Search “Legal” Health and Safety WARNING! To avoid electri c shock and damage to your device, do not charge device whil e it is wet or in an area where it could get wet. Do not handle device, charger or cords with wet hands whil e charging. Maintaining dust and water resistance The device is not impervious to dust and water damage in any situation. It is important that all compartments are closed tightly. Follow these tip s carefully to prevent damage to the device and maintain dust and water resistance performance: • Water re sistant based on IP68 rating, which tests submersion in fre sh water deeper than 1.5 meters or keep it submerged for more than 30 minutes. If device is exposed to fresh water, dry it thoroughly with a clean, soft cloth; if exposed to liquid other than fre sh water, rinse with fresh water and dry as directed. • Any device which uses accessible compartments or ports that can be opened should have th ese sealed or closed tightly to prevent liquid from entering th e system. • If th e device has been immersed in water or th e microphone or speaker is wet, sound may not be heard clearly during a call. After wipi ng th e device with a dry cloth, dry it thoroughly before using it. • Do not expose th e device to water at high pressure. • If th e device is dropped or receives an impact, th e water and dust resistant features of th e device may be damaged. Note: Liquid other than fre sh water may enter th e device fa ster. Failure to rinse th e device in fre sh water and dry it as instructed may cause th e device to suffer from operability or cosmetic issues. Samsung Knox Samsung Knox is Samsung’s security platform. Additional licensing fees may be required for enterprise use. For more information about Knox, please refer to: www.samsung.com/us/knox Specific Absorption Rate (SAR) certification information For information about SAR, visit : • https://www.fcc.gov/general/radio-frequency-safety-0 • www.fcc.gov/encyclopedia/ specific-absorption-rate-sar-cellular-telephones • www.samsung.com/sar Samsung mobile products and recycling WARNING! Never dispose of batteries in a fire because th ey may explode. Do not disassemble, crush, puncture, heat, burn or reuse. F or battery and cell phone recycling, go to call2recy cle. org or call 1-800-822-8837. For more recycling information, go to our website: www.samsung.com/recy cling or call 1-800-SAMSUNG. Your location Location-based information on that can be used to determine the appro ximate location of a mobile device. If you use applications that require location-based information (e.g., driving dir ections), such information may be shared with thi rd-parties, including your wireless service provider, applications providers, Samsung, and other thi rd- parties providing services. Navigation Maps, directions, and other navigation data, including data relating to your current location, may contain inaccurate or incomplete data. Therefore, you should always pay attention to road conditions, closures, traffic, and all other factors that may impact safe driving or walking. FCC Part 15 Information and Notices . Note: Any device that uses Bluetooth or Wi-Fi is subject to FCC Part 15. Any device with a power supply is subject to P…

Text truncated - open the document above for the full version.

www.samsung.com USER MANUAL English. 08/2022. Rev.1.0 SM-T630 SM-T636B SM-T638B 2 Table of Contents Getting started 4 Device layout and functions 7 Charg ing the battery 12 SIM or USIM card (nano-SIM card) (Mobile network enabled models) 13 Memory card (microSD card) 15 Protective case 17 Tur ning the device on and off 17 Initial setup 18 Samsung account 19 Tr ansferring data from your previous device (Smart Switch) 21 Understanding the screen 28 Notification panel 30 Screen capture and screen record 31 Entering text Apps and features 34 Installing or uninstalling apps 35 S Pen 44 P hone 47 Contacts 49 Messages 50 I nternet 51 Camera 62 Gallery 66 Bixby 68 Bixby Vision 69 Bixby Routines 71 Multi windo w 73 Samsung Notes 77 Samsung Members 77 Samsung K ids 78 Samsung Global Goals 78 Galaxy Shop 79 PENUP 79 Calendar 80 Reminder 81 Voice Recorder 82 My Files 82 Clock 82 Calculator 83 SmartThings 83 Sharing content 85 Music Share 86 Smart V iew 87 Samsung Flow 88 Daily Board 90 Samsung D eX 96 Google apps Table of Contents 3 126 Google 126 Advanced features 128 Motions and gestur es 129 Dual Messenger 130 Digital Wellbeing and parental controls 130 Battery and device care 130 Optimising your devic e 131 Ba ttery 131 Storage 132 M emory 132 Devic e protection 132 Software update 132 Diag nostics 132 A pps 133 Gener al management 134 A ccessibility 134 Sof tware update 135 Remote support 135 About tablet Usage notices 136 Precautions for using the device 138 Notes on package contents and accessories 139 Main taining water and dust resistance 140 Devic e overheating situations and solutions Appendix 143 Troubleshooting Settings 97 Introduction 97 Samsung account 97 C onnections 99 Wi-Fi 100 Bluetooth 102 NFC and con tactless payments 103 Data saver (Mobile network enabled models) 104 Mobile data only apps (Mobile network enabled models) 104 Mobile Hotspot (Mobile network enabled models) 105 More connection settings 106 Sounds and vibration 107 Sound qualit y and effects 107 Separ ate app sound 108 Notifica tions 108 Displa y 109 Wallpaper and st yle 109 Home screen 109 Lock scr een 110 Smart Lock 110 Biometrics and security 111 Fac e recognition 113 Fingerprint recognition 116 Samsung P ass 118 Secur e Folder 121 Secur e Wi-Fi 122 P rivacy 122 L ocation 123 Saf ety and emergency 123 Ac counts and backup 124 U sers 125 Samsung Cloud 4 Getting started Device layout and functions Multipurpose jack (USB Type-C) Side key Speaker Keyboard dock port Touchscreen Volume key Active key Microphone Earphone jack Light sensor Front camera Home key (Fingerprint recognition sensor) Back key Recents key Speaker Back cover NFC antenna Rear camera Main antenna (SM-T636B, SM-T638B) Flash GPS antenna Getting started 5 The device and some accessories (sold separately) contain magnets. The American Heart Association (US) and the Medicines and Healthcare Products Regulatory Agency (UK) both warn that magnets can affect the operation of implanted pacemakers, cardioverters, defibrillators, insulin pumps or other electro medical devices (collectively, “Medical Device”) within the range of 15 cm (6 inches). If you are a user of any of these Medical Devices, DO NOT USE THIS DEVICE AND SOME ACCESSORIES (SOLD SEPARATELY) UNLESS YOU HAVE CONSULTED WITH YOUR PHYSICIAN. • Do not store your device and some accessories (sold separately) near magnetic fields. Magnetic stripe cards, including credit cards, phone cards, passbooks, and boarding passes, may be damaged by magnetic fields. • When using the speakers, such as when playing media files or using speakerphone, do not place the device close to your ears. • Be careful not to expose the camera lens to a strong light source, such as direct sunlight. If the camera lens is exposed to a strong light source, such as direct sunlight, the camera image sensor may be damaged. A damaged image sensor is irreparable and will cause dots or spots in pictures. • If you use the device with its glass or acrylic body broken, there may be a risk of injury. Use the device only after it has been repaired at a Samsung Service Centre. • If dust or foreign materials enter the microphone, speaker, or receiver, the device’s sound may become quiet or certain features may not work. If you attempt to remove the dust or foreign materials with a sharp object, the device may be damaged and its appearance may be affected. • Connectivity problems and battery drain may occur in the following situations: – If you attach metallic stickers on the antenna area of the device – If you attach a device cover made with metallic material to the device – If you cover the device’s antenna area with your hands or other objects while using certain features, such as calls or the mobile data connection • Do not cover the light sensor area with accessories, such as stickers or a cover. Doing so may cause the sensor to malfunction. Getting started 6 Hard keys KeyFunction Side key • When the device is off, press and hold to turn it on. • Press to turn on or lock the screen. • Press and hold to start a conversation with Bixby. Refer to Using Bixby for more information. • Press twice or press and hold to launch the app or feature you set. Side key + Volume Down key • Press simultaneously to capture a screenshot. • Press and hold simultaneously to turn off the device. Active key • Press or press and hold to launch preset apps. Recents key • Press to open the list of recent apps. Home key • Press to turn on the screen while the screen is locked. • Press to return to the Home screen. • Press and hold to launch Google Assistant app. Back key • Press to return to the previous screen. Setting the Side key Select an app or feature to launch by pressing the Side key twice or pressing and holding the Side key. Launch the Settings app, tap Advanced features → Side key, and then select an option you want. Setting the Active key Select an app to launch by pressing or pressing and holding the Active key. Launch the Settings app, tap Advanced fea…

Text truncated - open the document above for the full version.

Apps and features 63 Viewing images Launch the Gallery app and select an image. To view other files, swipe to the left or right on the screen. More options Delete the image. Share the image with others. Modify the image. Image and video thumbnail Bixby Vision View the content on a large screen using the Smart View feature. Add the image to favourites. Cropping enlarged images 1 Launch the Gallery app and select an image. 2 Spread two fingers apart on the area you want to save and tap . The cropped area will be saved as a file. Saved image thumbnail Apps and features 64 Viewing videos Launch the Gallery app and select a video to play. To view other files, swipe to the left or right on the screen. To use more options during playback, tap → Open in Video player. Lock the playback screen. Skip to the previous video. Tap and hold to rewind. Switch to the pop-up video player. Capture the current screen. Display your videos. Configure the caption settings. Rewind or fast-forward by dragging the bar. Create an animated GIF. More options Rotate the screen. Skip to the next video. Tap and hold to fast-forward. Pause and resume playback. Change the screen ratio. View the content on a large screen using the Smart View feature. Drag your finger up or down on the left side of the playback screen to adjust the brightness, or drag your finger up or down on the right side of the playback screen to adjust the volume. To rewind or fast-forward, swipe to the left or right on the playback screen. Apps and features 65 Albums Create albums and sort your images and videos. 1 Launch the Gallery app and tap → Albums → → Create album to create an album. 2 Select the album, tap Add items, and then copy or move the images or videos you want. Stories When you capture or save images and videos, the device will read their date and location tags, sort the images and videos, and then create stories. Launch the Gallery app, tap → Stories, and then select a story. To add or delete images or videos, select a story and tap → Add or Edit. Syncing images and videos Launch the Gallery app, tap → → Sync with OneDrive, and then follow the on-screen instructions to complete the sync. The Gallery app and the cloud will be synced. When your Gallery app is synced with the cloud, pictures and videos you take will also be saved in the cloud. You can view images and videos saved in the cloud in your Gallery app and from other devices. When you connect your Samsung account and Microsoft account, you can set the cloud storage as Microsoft OneDrive. Deleting images or videos Launch the Gallery app, tap and hold an image, a video, or a story to delete, and then tap Delete. Using the recycle bin feature You can keep the deleted images and videos in the recycle bin. The files will be deleted after a certain period. Launch the Gallery app, tap → , and then tap the Recycle bin switch to activate it. To view files in the recycle bin, launch the Gallery app and tap → Recycle bin. Apps and features 66 Bixby Introduction Bixby is a user interface that helps you use your device more conveniently. You can talk to Bixby or type text. Bixby will launch a function you request or show the information you want. Visit www.samsung.com/bixby for more information. Bixby is only available in some languages, and it may not be available depending on the region. Starting Bixby Press and hold the Side key to launch Bixby. The Bixby intro page will appear. After you select the language to use with Bixby, sign in to your Samsung account, and complete the setup by following the on-screen instructions, the Bixby screen will appear. Using Bixby While pressing and holding the Side key, say what you want to Bixby, and then release your finger from the key. Alternatively, say “Hi, Bixby” and say what you want. For example, while pressing and holding the Side key, say “How’s the weather today?” The weather information will appear on the screen. If Bixby asks you a question during a conversation, you can continue to talk to Bixby without pressing the Side key or tapping . Apps and features 67 Waking up Bixby using your voice You can start a conversation with Bixby by saying “Hi, Bixby”. Register your voice so that Bixby will respond to your voice when you say “Hi, Bixby”. 1 Launch the Bixby app and tap → → Settings → Voice wake-up. 2 Tap the Wake with “Hi, Bixby” switch to activate it. 3 Tap the Recognise voice switch to activate it. 4 Follow the on-screen instructions to complete the setup. Now you can say “Hi, Bixby” and start a conversation. Communicating by typing text If your voice is not recognised due to noisy environments or if you are in a situation where speaking is difficult, you can communicate with Bixby via text. Launch the Bixby app, tap , and then type what you want. During the communication, Bixby also will answer you through text instead of voice feedback. Apps and features 68 Bixby Vision Introduction Bixby Vision is a service that provides various features based on image recognition. You can use Bixby Vision to quickly search for information by recognising objects. Use a variety of useful Bixby Vision features. • This feature may not be available or you may not get correct search results depending on the image size, format, or resolution. • Samsung is not responsible for the product information provided by Bixby Vision. Launching Bixby Vision Launch Bixby Vision using one of these methods. • In the Camera app, tap MORE on the shooting modes list and tap BIXBY VISION. • In the Gallery app, select an image and tap . • In the Internet app, tap and hold an image and tap Search with Bixby Vision. • If you added the Bixby Vision app icon to the Apps screen, launch the Bixby Vision app. Using Bixby Vision 1 Launch Bixby Vision. 2 Select a feature you want to use. • : Recognise text from documents or images and translate it. • : Recognise text from documents or images and extract it. • : Search for images similar to the recognised object online and related infor…

Text truncated - open the document above for the full version.

Date: November 19, 2021 UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea To whom it may concern: I, the undersigned, hereby authorize UL Korea, Ltd. Suwon Laboratory, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Korea, Ltd. Suwon Laboratory on our behalf s hall have the same effect as acts of our own. In authorizing UL Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. l) the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

July 26, 2022 Federal Comm unications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMT636B To Whom It May Concern: Pursuant to the provisions of Sec tions 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0. 457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give c ompetitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Label and Location Model: FCC ID: SM-T636B A3LSMT636B Label: Location: Tablet: Label is plac ed inside of the battery compartment. MODEL : SM-T636B FCC ID : A3LSMT636B RATED : 3.8 V ;1800 mA DESIGNED & ENGINEERED BY SAMSUNG MANUFACTURED IN VIETNAM PO Box 12987, Dublin. IE TABLET PC
