A3LSMV101FCellular/PCS GSM/WCDMA Portable Hotspot with WLAN

Type E. A00000 02/2014. Rev.1.0 Samsung Mobile Hotspot User manual www.samsung.com 2 Copyright © 2014 Samsung Electronics • Please read this manual before using the device to ensure safe and proper use. • Images may differ in appearance from the actual product. Content is subject to change without prior notice. • This product includes certain free/ open source software. The exact terms of the licences, disclaimers, acknowledgements and notices are available on the Samsung's website opensource.samsung.com. 3 Trademarks • SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics. • Wi-Fi ® , Wi-Fi Protected Setup ™ , Wi-Fi CERTIFIED ™ , and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. Your device uses a non-harmonised frequency and is intended for use in all European countries. The WLAN can be operated in the EU without restriction indoors, but cannot be operated outdoors. 4 Getting Started Device layout Notification light Multipurpose jack Power button WPS button 5 Getting Started 5 Package contents Check the product box for the following items: • Device • Battery The items supplied with the device and any available accessories may vary depending on the region or service provider. Installing the SIM or USIM card and battery Insert the SIM or USIM card provided by the mobile telephone service provider, and the included battery. Only microSIM cards work with the device. 6 Getting Started 6 1 Remove the back cover. Be careful not to damage your fingernails when you remove the back cover. Do not bend or twist the back cover excessively. Doing so may damage the cover. 2 Insert the SIM or USIM card with the gold- coloured contacts facing downwards. 7 Getting Started 7 3 Insert the battery. 1 2 4 Replace the back cover. 8 Getting Started 8 Removing the SIM or USIM card and battery 1 Remove the back cover. 2 Pull out the battery. 3 Pull out the SIM or USIM card. 9 Getting Started 9 Charging the battery Before using the device for the first time or when the battery has been unused for extended periods, you must charge the battery. Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device. Connect the USB cable to the USB power adaptor and then plug the end of the USB cable into the multipurpose jack. 10 Getting Started 10 Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty. After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket. Do not remove the battery before removing the charger. This may damage the device. 11 Getting Started 11 • To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging. • The socket-outlet shall be installed near the equipment and shall be easily accessible. 12 Getting Started 12 Turning the device on and off Press and hold the Power button for a few seconds to turn on the device. While the device is turned on, all notification lights turn green. To turn off the device, press and hold the Power button again. 13 Getting Started 13 Notification light The notification light alerts you to the device’s status with the following colours. NameStatus LTE/3G/2G network • Steady green: LTE network connected • Blinking green: LTE network roaming • Steady blue: 3G or 2G network connected • Blinking blue: 3G or 2G network roaming • Steady red: Weak signal • Blinking red: Weak roaming signal 14 Getting Started 14 NameStatus Wi-Fi network • Steady green: Devices connected • Blinking green: Data transferring • Steady blue: Ready to connect to devices • Blinking blue: WPS standby mode • Blinking red: Notification alert or error occurred Battery power • Steady green: 50 % – 100 % • Blinking green: Fully charged • Steady blue: 15 % – 49 % • Steady red: Charging • Blinking red: Less than 15 % or error occurred 15 Getting Started 15 Connecting with other devices Connect your device with computers or other devices that support the Wi-Fi function. When your device is connected, recently-connected devices will automatically connect to your device whenever it is turned on. The default password is the last 8 digits of the IMEI number. The IMEI number is on a label affixed to the device. IMEI label You must insert a SIM or USIM card to use the device. 16 Getting Started 16 Connecting to a network via Wi-Fi 1 Turn on your device. 2 On other devices, access Wi-Fi settings and search for the network. 3 Select the device name from the search results. 4 Enter a password if necessary. 17 Getting Started 17 Activating Wi-Fi Protected Setup (WPS) mode You can connect devices to a network and encrypt data by pushing the WPS button. 1 Press and hold the WPS button. The notification light flashes green when the WPS mode is activated. 2 Activate the WPS mode on other devices. The devices enter WPS setup mode. 3 Press the WPS button again within 2 minutes. 18 Getting Started 18 Connecting to a network using a USB cable 1 Turn on your device. 2 Connect the device to the computer using the USB cable. 3 Select the device name from the network list. 4 Enter a password if necessary. Upgrading the device The device can be upgraded to the latest software. On the computer, launch Samsung Kies and connect the device to the computer. Refer to the Samsung Kies help for details on how to upgrade. 19 Getting Started 19 Configuring the device When the device is connected to other devices, access the administration page to configure the device. On the connected device, open the web browser and go to http://192.168.1.1. When the password request appears, enter the password. The default password is ‘admin.’ At the top o…

Text truncated - open the document above for the full version.

Samsung Electronics America, Inc 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: February 20, 2014 FCC ID: A3LSMV101F To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to any application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, Signature Sang Kyung (Peter), Ra General Manager Samsung Electronics America, Inc

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: February 20, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSMV101F To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics SHORT-TERM 4 External Photos 5 Internal Photos 6 Test-Setup Photos 7 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea March 19, 2014 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMV101F Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy of KDB 784748 D01. The label statement is as follows: The FCC ID label is located in the battery compartment. While the battery cover is installed when the unit is shipped from the factory, the battery is never installed prior to sale, so the user must remove the cover in order to install the battery and operate the device. At this time the FCC ID is readily visible to the user. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

amLabel and Location Model: SM-V101F FCC ID: A3LSMV101F Label: Location: Top Back of device Bottom Label is placed inside of the battery compartment. Label

FCC ID: A3LSMV101F SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 1 of 29 0Y1402070339.A3L 02/10/14 - 03/05/14 Portable Wireless Router © 2014 PCTEST Engineering Laboratory, Inc. REV 13.0 M 12/04/2013 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 02/10/14 – 03/05/14 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab, Columbia, MD, USA Gyeonggi-do 443-742, Korea Document Serial No.: 0Y1402070339.A3L FCC ID: A3LSMV101F APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. DUT Type: Portable Wireless Router Application Type: Certification FCC Rule Part(s): CFR §2.1093 Model(s): SM-V101F 1 gm Body (W/kg) PCBGPRS/EDGE Rx Only 850824.20 - 848.80 MHz0.68 PCBUMTS 850826.40 - 846.60 MHz0.44 PCBGRPS/EDGE Rx Only 19001850.20 - 1909.80 MHz0.94 PCBUMTS 19001852.4 - 1907.6 MHz0.94 DTS2.4 GHz WLAN2412 - 2462 MHz< 0.1 0.98 SAR Band & ModeTx Frequency Simulta ne ous SAR per KDB 69 07 83 D0 1v0 1r 02 : Equipment Class This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in Section 1.7 of this report; for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. +1.410.290.6652 / Fax +1.410.290.6654 http://www.pctestlab.com SAR EVALUATION REPORT FCC ID: A3LSMV101F SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 2 of 29 0Y1402070339.A3L 02/10/14 - 03/05/14 Portable Wireless Router © 2014 PCTEST Engineering Laboratory, Inc. REV 13.0 M 12/04/2013 TABLE OF CONTENTS 1 DEVICE UNDER TEST ................................................................................................................... 3 2 INTRODUCTION ............................................................................................................................. 7 3 DOSIMETRIC ASSESSMENT ........................................................................................................ 8 4 SAR TESTING PROCEDURES ...................................................................................................... 9 5 RF EXPOSURE LIMITS ................................................................................................................ 10 6 FCC MEASUREMENT PROCEDURES ........................................................................................ 11 7 RF CONDUCTED POWERS ......................................................................................................... 14 8 SYSTEM VERIFICATION .............................................................................................................. 17 9 SAR DATA SUMMARY ................................................................................................................. 19 10 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS ......................................................... 22 11 SAR MEASUREMENT VARIABILITY ........................................................................................... 24 12 EQUIPMENT LIST ......................................................................................................................... 25 13 MEASUREMENT UNCERTAINTIES ............................................................................................ 26 14 CONCLUSION ............................................................................................................................... 27 15 REFERENCES .............................................................................................................................. 28 APPENDIX A: SAR TEST PLOTS APPENDIX B: SAR DIPOLE VERIFICATION PLOTS APPENDIX C: PROBE AND DIPOLE CALIBRATION CERTIFICATES APPENDIX D: SAR TISSUE SPECIFICATIONS APPENDIX E: SAR SYSTEM VALIDATION APPENDIX F: SAR TEST SETUP PHOTOGRAPHS FCC ID: A3LSMV101F SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 3 of 29 0Y1402070339.A3L 02/10/14 - 03/05/14 Portable Wireless Router © 2014 PCTEST Engineering Laboratory, Inc. REV 13.0 M 12/04/2013 1 DEVICE UNDER TEST 1.1 Device Overview GPRS/EDGE Rx Only 850Data824.20 - 848.80 MHz UMTS 850Data826.40 - 846.60 MHz GRPS/EDGE Rx Only 1900Data1850.20 - 1909.80 MHz UMTS 1900Data1852.4 - 1907.6 MHz 2.4 GHz WLANData2412 - 2462 MHz Band & ModeTx FrequencyOperating Modes 1.2 Nominal and Maximum Output Power Specifications This device operates using the following maximum and nominal output power specifications. SAR values were scaled to the maximum allowed power to determine compliance per KDB Publication 447498 D01v05r01. 1 TX Slots 2 TX Slots Maximum32.529.5 Nominal32.029.0 Maximum30.529.0 Nominal30.028.5 Burst Average GMSK (dBm) GPRS 850 Mode / Band GPRS 1900 3GPP WCDMA 3GPP HSDPA 3GPP HSUPA Rel 99Rel 6Rel 6 Maximum23.022.522.5 Nominal22.522.022.0 Maximum23.022.522.5 Nominal22.522.022.0 Mode / Band UMTS Band 2 (1900 MHz) UMTS Band 5 (850 MHz) Modulated Average (dBm) FCC ID: A3LSMV101F SAR EVALUATION REPORT Reviewed by: Quality Manager Document S/N: Test Dates: DUT Type: Page 4 of 29 0Y1402070339.A3L 02/10/14 - 03/05/14 Portable Wireless Router © 2014 PCTEST Engineering Laboratory, Inc. REV 13.0 M 12/04/2013 Maximum Nominal Maximum Nominal Maximum Nominal 17.0 14.0 12.0 14.5 IEEE 802.11n (2.4 GHz) 12.5 Modulated Average (dBm) IEEE 802.11b (2.4 GHz) 17.5 IEEE 802.11g (2.4 GHz) Mode / Band 1.3 DUT Antenna Locations Diversity Rx only an…

Text truncated - open the document above for the full version.

FCC ID: A3LSMV101F FCC Pt. 15.247 802.11b/g/n MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 1 of 48 0Y1402070341.A3L Feb. 26 - 27, 2014 Wireless Hot Spot © 2014 PCTEST Engineering Laboratory, Inc. V 3.10 06/17/2013 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. Feb. 26 - 27, 2014 129, Samsung-ro, Maetan dong, Test Site/Location: Yeongtong-gu, Suwon-si PCTEST Lab, Columbia, MD, USA Gyeonggi-do 443-742, Korea Test Report Serial No.: 0Y1402070341.A3L FCC ID: A3LSMV101F APPLICANT: Samsung Electronics, Co. Ltd. Application Type: Certification Model(s): SM-V101F EUT Type: Wireless Hot Spot FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part 15.247 Test Procedure(s): KDB 558074 v03r01 Max. Power (mW ) Max. Power (dBm) Max. Power (mW ) Max. Power (dBm) 802.11b 2412 - 246255.33517.43184.07722.65 802.11g 2412 - 246228.11914.49102.80220.12 802.11n 2412 - 246215.95912.0369.34318.41 Avg Conducted Mode Tx Frequency (MHz) Peak Conducted This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in KDB 558074 v03r01. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST ENGINEERING LABORATORY, INC. 7185 Oakland Mills Road, Columbia, MD 21046 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC PART 15.247 WLAN 802.11b/g/n FCC ID: A3LSMV101F FCC Pt. 15.247 802.11b/g/n MEASUREMENT REPORT (CERTIFICATION) Reviewed by: Quality Manager Test Report S/N: Test Dates: EUT Type: Page 2 of 48 0Y1402070341.A3L Feb. 26 - 27, 2014 Wireless Hot Spot © 2014 PCTEST Engineering Laboratory, Inc. V 3.10 06/17/2013 TABLE OF CONTENTS FCC PART 15.247 MEASUREMENT REPORT .................................................................................................. 3 1.0 INTRODUCTION ...................................................................................................................................... 4 1.1 SCOPE ........................................................................................................................................................... 4 1.2 PCTEST TEST LOCATION ............................................................................................................................ 4 2.0 PRODUCT INFORMATION ..................................................................................................................... 5 2.1 EQUIPMENT DESCRIPTION......................................................................................................................... 5 2.2 DEVICE CAPABILITIES ................................................................................................................................. 5 2.3 TEST CONFIGURATION ............................................................................................................................... 5 2.4 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ...................................................................................... 5 2.5 LABELING REQUIREMENTS ........................................................................................................................ 5 3.0 DESCRIPTION OF TEST ........................................................................................................................ 6 3.1 EVALUATION PROCEDURE ......................................................................................................................... 6 3.2 AC LINE CONDUCTED EMISSIONS ............................................................................................................. 6 3.3 RADIATED EMISSIONS ................................................................................................................................ 7 4.0 ANTENNA REQUIREMENTS .................................................................................................................. 8 5.0 TEST EQUIPMENT CALIBRATION DATA .............................................................................................. 9 6.0 TEST RESULTS .................................................................................................................................... 10 6.1 SUMMARY ................................................................................................................................................... 10 6.2 6DB BANDWIDTH MEASUREMENT – 802.11B/G/N .................................................................................. 11 6.3 OUTPUT POWER MEASUREMENT – 802.11B/G/N (2.4GHZ) ................................................................... 18 6.4 POWER SPECTRAL DENSITY (802.11B/G/N) ........................................................................................... 20 6.5 CONDUCTED EMISSIONS AT THE BAND EDGE ...................................................................................... 27 6.6 CONDUCTED SPURIOUS EMISSIONS ...................................................................................................... 32 6.7 RADIATED SPURIOUS EMISSION MEASUREMENTS .............................................................................. 37 6.8 RADIATED RESTRICTED BAND EDGE MEASUREMENTS ...................................................................... 42 6.9 LINE-CONDUCTED TEST DATA ................................................................................................................. 46 7.0 CONCLUSION .....................................................................................................................…

Text truncated - open the document above for the full version.

Samsung Electronics Co., Ltd. FCC ID: A3LSMV101F Model: A3LSMV101F Test Set-Up Photos EUT Type: Wireless Hot Spot Page 1 of 3 © 2014 PCTEST Engineering Laboratory Inc. TEST SETUP PHOTOGRAPHS Samsung Electronics Co., Ltd. FCC ID: A3LSMV101F Model: A3LSMV101F Test Set-Up Photos EUT Type: Wireless Hot Spot Page 2 of 3 © 2014 PCTEST Engineering Laboratory Inc. Samsung Electronics Co., Ltd. FCC ID: A3LSMV101F Model: A3LSMV101F Test Set-Up Photos EUT Type: Wireless Hot Spot Page 3 of 3 © 2014 PCTEST Engineering Laboratory Inc.

FCC ID: A3LSMV101F SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 1 of 4 02/10/ 14 - 03/05/14 Portable Wireless Router © 2014 PCTEST Engineering Laboratory, Inc. REV 13.0 M 12/04/2013 APPENDIX F: S AR TEST SETUP PHOTOGRAPHS FCC ID: A3LSMV101F SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 2 of 4 02/10/ 14 - 03/05/14 Portable Wireless Router © 2014 PCTEST Engineering Laboratory, Inc. REV 13.0 M 12/04/2013 SAR Test Setup Photo 1 - Back Side at 10 mm SAR Test Setup Photo 2 - Front Side at 10 mm FCC ID: A3LSMV101F SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 3 of 4 02/10/ 14 - 03/05/14 Portable Wireless Router © 2014 PCTEST Engineering Laboratory, Inc. REV 13.0 M 12/04/2013 SAR Test Setup Photo 3 - Top Edge at 10 mm SAR Test Setup Photo 4 - Bottom Edge at 10 mm FCC ID: A3LSMV101F SAR EVALUATION REPORT Reviewed by: Quality Manager Test Dates: DUT Type: APPENDIX F: Page 4 of 4 02/10/ 14 - 03/05/14Portable Wireless Router © 2014 PCTEST Engineering Laboratory, Inc. REV 13.0 M 12/04/2013 SAR Test Setup Photo 5 - Right Edge at 10 mm SAR Test Setup Photo 6 - Left Edge at 10 mm
