A3LSPHM100Dual Band Analog/PCS Phone
Samsung Electronics Co Ltd
Click to zoom
Application Details
- Equipment Class
- PCE - PCS Licensed Transmitter held to ear
- Date of Grant
- Sep 06, 2000
- Application Purpose
- Original Equipment
- Date of Application
- Jun 18, 2000
- Equipment Note
- Dual Band Analog/PCS Phone
- Frequency Range
- 1851.25000000 - 1908.75000000
- Company
- Samsung Electronics Co Ltd
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Attestation Statements
May 30, 2000 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. Sincerely, Wallace Oh Engineering Manager Samsung Electronics America May 30, 2000 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.:A3LSPHM100 Request for Confidentiality To whom it may concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, and Circuit Description of the attached test report. These documents contain detailed system and equipment description and related information about the product which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. May 30, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC E911 REQUIREMENTS PER Β§22.921 Gentlemen: Samsung Electronics Co., Ltd. hereby certifies that the analog cellular telephone (FCC ID: A3LSPHM100), using the Automatic A/B Roaming β Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a β9-1-1β call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned. AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Portable Cellular Telephone (FCC ID:A3LSPHM100) is so designed that it complies with all the requirements for ESN protection specified in Sec. 22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative.
Cover Letter(s)
June 16, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSPHM100 Part 22/24 Certification Gentlemen: Attached herewith, on behalf of SAMSUNG ELECTRONICS CO., LTD. is an application for Part 22.901(d) & Part 24(E) Certification of the following Dual-Band PCS/Cellular Phone: FCC ID: A3LSPHM100 TRADE / MODEL(s): SAMSUNG SPH-M100 EUT TYPE: Licensed Portable Transmitter Held to Ear (PCE) Tx Freq. Range: 824.04 β 848.97 MHz (AMPS) 1851.25 β 1908.75 MHz (CDMA) Rx Freq. Range: 869.04 β 893.97 MHz (AMPS) 1931.25 β 1988.75 MHz (CDMA) Max. RF Output Power: 0.590 W ERP AMPS (27.70 dBm) 0.321 W EIRP PCS CDMA (25.07 dBm) Attached is the applicantβs Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 Compliance Statement, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description, parts list & tune-up procedure, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Wallace Oh Engineering Manager SAMSUNG American QA Lab
Cover Letter(s)
August 28, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSPHM100 731 Confirmation No.: EA97955 Correspondence Reference No.: 15730 Request for Tech. Info.: 8/22/00 Dear Joe: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated August 22, 2000. 1. The output power for the PCS mode (EIRP data) was performed using substitution method. For readings above 1GHz, a horn antenna was used to measure radiated measurements at 3 meters and a signal generator and horn antenna were substituted for the EUT. (See page 9 notation) 2. Please find attached a better clear version of the schematics. We will amend the RF exposure ASAP. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.
Cover Letter(s)
Test Report S/N: 24/22.200612262.A3L FCC Parts 24 & 22 Dates of Tests: June 12-16, 2000 Certification Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) 9 SAMSUNG Dual-Band Analog/PCS CDMA Phone 6.1 Test Data 6.2 Equivalent Isotropic Radiated Power (E.I.R.P.) Radiated measurements at 3 meters Supply Voltage:3.8VDC Modulation: FREQ.LEVELPOLAzimuthEIRPEIRPBattery (MHz)(dBm)(H/V) (o angle) (dBm)(W) 1851.25-22.012H65.025.070.322Standard 1880.00-22.331H65.024.920.310Standard 1908.75-23.197H65.024.220.264Standard 1851.25-22.098H65.024.980.315Extended NOTES: PCS CDMA ERP Measurements by Substitution Method: The EUT was placed on a wooden turn table 3-meters from the receive antenna. The receive antenna height and turntable rotation was adjusted for the highest reading on the receive spectrum analyzer. A half-wave dipole was substituted in place of the EUT. This dipole antenna was driven by a signal generator and the level of the signal generator was adjusted to obtain the same receive spectrum analyzer reading. This ERP level is recorded. For readings above 1GHz, the above procedure is repeated using horn antennas and the difference between the gain of the horn and an isotropic antenna are taken into consideration.
Cover Letter(s)
September 6, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSPHM100 731 Confirmation No.: EA97955 Correspondence Reference No.: 15924 Request for Tech. Info.: 09/05/2000 Dear Joe: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated September 5, 2000. 1. The following is a description of the substitution method used to obtain accurate EIRP readings of the EUT at the carrier fundamental frequency: A. Above 1Ghz, radiated measurements are made at 3 meters using a calibrated horn antenna, a RF data cable and a spectrum analyzer. B. A maximum signal measurement is made by raising and lowering the antenna and rotating the EUT 360 degrees. Vertical and Horizontal Polarizing data is recorded. C. A signal generator, a RF amplifier, and a horn antenna with a calibrated gain rated in dBi are then substituted for the EUT. The gain of the substituted horn antenna is added to the substituted value. D. For example at 1880 MHz measurement of the EUT produced a reading of -22.331dBm on the spectrum analyzer that level is then recorded. Next the EUT is removed and the horn antenna is put in its place driven by the signal generator. The signal generator is adjusted until the β22.331dBm reading is obtained. The horn antenna is removed and a reading is taken of the level that was at its terminals. The gain of the horn over isotropic is added and this level is recorded. The signal generator level at the terminals was 18.720dBm and the gain of the horn is 6.200dBi then the EIRP would be 24.920dBm. We trust this information is sufficient to issue the grant as soon as possible. If you have any further inquiries, please do not hesitate to contact me. cc: Samsung Electronics Co., Ltd.
External Photos
Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone
ID Label/Location Info
© 2000 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) MODEL NO: SPH-M100 FCC ID: A3LSPHM100 MADE IN KOREA
Internal Photos
Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) NVLAP Lab Code: 100431-0 Samsung Dual-Band Analog/PCS CDMA Phone
RF Exposure Info
Β© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 66606660--B Dobbin Road B Dobbin Road β’β’ Columbia, MD 21045 Columbia, MD 21045 β’β’ U.S.A. U.S.A. TEL (410) 290TEL (410) 290--6652 6652 β’β’ FAX (410) 290 FAX (410) 290--66546654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: June 12-16, 2000 416 Maetan-3 Dong, Paldal-Ku Test Report S/N: SAR.200612261.A3L Suwon City, Kyungki-Do 441-742, KOREA Test Site: PCTEST Lab, Columbia MD U.S.A. Attn: Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) FCC ID A3LSPHM100 APPLICANT SAMSUNG Electronics Industries Co., Ltd. EUT Type: Dual-Band Cellular Phone (AMPS/CDMA) Tx Frequency: 824.04 β 848.97 MHz (AMPS) / 1851.25 β 1908.75 MHz (PCS CDMA) Rx Frequency: 869.04 β 893.97 MHz (AMPS) / 1931.25 β 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.590W ERP AMPS (27.70 dBm) / 0.321W ERP PCS CDMA (25.07 dBm) Trade Name/Model(s): SAMSUNG SCH-M100 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) Application Type: Certification Serial Number: B01E1737 FCC Rule Part(s): 2.1093; ET Docket 96.326 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992 (See Test Report). Part 22 AMPS Mode - Head Max. SAR: 1.4771 W/kg Body Max. SAR: 1.3018 W/kg Part 24 PCS Mode - Head Max. SAR: 1.4327 W/kg Body Max. SAR: 0.7173 W/kg I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C. 862. SAR Measurement Report FCC Part 22 Certification Β© 2000 PCTEST Lab Table of Contents 1.1: SCOPE .............................................................. 1 2.1-2: INTRODUCTION / SAR DEFINITION .......................... 2 3.1: SAR MEASUREMENT SET-UP ................................. 3 4.1-2: E-FIELD PROBE SYSTEM ....................................... 4 5.1-4: E-FIELD PROBE CALIBRATION .............................. 5-6 6.1-3: PHANTOM & EQUIVALENT TISSUE ........................... 7 7.1-2: SYSTEM SPECIFICATIONS ..................................... 8 8.1-2: MEASUREMENT PROCESS .................................... 9 9.1-2: TEST POSITION OF THE PHONE ............................. 10 10.1-2: BODY-WORN TEST SETUP .................................. 11 11.1: ANSI/IEEE C95.1 RF EXPOSURE LIMITS .................. 12 12.1: MEASUREMENT UNCERTAINTIES ....................... 13 13.1-3: TEST DATA SUMMARY ......................................... 14-17 14.1: SAR TEST EQUIPMENT LIST ............................... 18 15.1: CONCLUSION / REFERENCES .............................. 19 Test Report S/N: SAR.200612261.A3L SAR Measurement Report Test Dates: June 12-16, 2000 FCC Part 22 Certification SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) 1 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name: SAMSUNG ELECTRONICS CO., LTD. Address: 416 Maetan-3 Dong, Paldal-Ku Suwon City, Kyungki-Do 441-742, KOREA Attention: Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) β’ EUT Type: Dual-Band Cellular Phone (AMPS/CDMA) β’ Trade Name: SAMSUNG β’ FCC IDENTIFIER: A3LSPHM100 β’ Model: SCH-M100 β’ S/N: B01E1737 β’ Tx Frequency: 824.04 β 848.97 MHz (AMPS) 1851.25 β 1908.75 MHz (PCS CDMA) β’ Rx Frequency: 869.04 β 893.97 MHz (AMPS) 1931.25 β 1988.75 MHz (PCS CDMA) β’ Application Type: Certification β’ FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) β’ FCC Rule Part(s): Β§2.1093, Docket 96-326 β’ Max. RF Output Power: 0.590W ERP AMPS (27.70 dBm) 0.321W EIRP PCS CDMA (25.07 dBm) β’ Modulation: AMPS / CDMA β’ Antenna Type: Helical (Ξ»/4) β’ Antenna Dimensions: 10.21 cm. (Length) β’ Dates of Test(s): June 12-16, 2000 β’ Place of Test(s): PCTEST Engineering Lab. Columbia, MD, U.S.A. β’ Report Serial No.: SAR.200612261.A3L 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.200612261.A3L SAR Measurement Report Test Dates: June 12-16, 2000 FCC Part 22 Certification SAMSUNG Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2000 PCTEST Lab FCC ID: A3LSPHM100 (Model: SPH-M100) 2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electriβ¦
Text truncated - open the document above for the full version.
RF Exposure Info
File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00061209_ZOOM.VLT Start : 12-Jun-100 02:14:48 pm End : 12-Jun-100 02:26:04 pm Radio Type : SAMSUNG Model Number : A3LSPHM100 Serial Number : B01E1737 Frequency : 824.04 MHz Peak Trans. Pwr : 0.400 W Start Trans. Pwr: 0.400 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 43.400 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL BAND PHONE FM MODE CHAN 0991 26.0 dBm conducted SAMSUNG DUAL BAND PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = -1.750, Y = -1.750, Z = 0.000 (cm) Value = 19.658 Measured Values (volts) = 1.880E-002 1.533E-002 1.204E-002 9.830E-003 8.156E-003 6.946E-003 6.043E-003 5.578E-003 5.303E-003 5.186E-003 4.929E-003 4.560E-003 4.091E-003 3.361E-003 2.568E-003 1.749E-003 1.214E-003 8.790E-004 8.273E-004 1.009E-003 1.282E-003 Calc. Voltage @ Surface (Vs) = 0.0235 Voltage @ 1.00 cm (Vt) = 0.0098 Ave. Voltage (Vs+Vt)/2 = 0.0167 Ave. SAR over 1 g (mW/g) = 1.2158 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 mW/g -1012345 Z centimeters SAR Scan File : 00061209_ZOOM Start : 12-Jun-100 02:14:48 pm End : 12-Jun-100 02:26:04 pm SAMSUNG/A3LSPHM100/B01E1737;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 File : 00061209_ZOOM Start : 12-Jun-100 02:14:48 pm End : 12-Jun-100 02:26:04 pm SAMSUNG/A3LSPHM100/B01E1737;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 1.434 1.358 1.281 1.204 1.128 1.051 0.974 0.898 0.821 0.744 File : 00061209_ZOOM Start : 12-Jun-100 02:14:48 pm End : 12-Jun-100 02:26:04 pm SAMSUNG/A3LSPHM100/B01E1737;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 1.434 1.358 1.281 1.204 1.128 1.051 0.974 0.898 0.821 0.744 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00061210_ZOOM.VLT Start : 12-Jun-100 02:37:56 pm End : 12-Jun-100 02:47:03 pm Radio Type : SAMSUNG Model Number : A3LSPHM100 Serial Number : B01E1737 Frequency : 824.04 MHz Peak Trans. Pwr : 0.400 W Start Trans. Pwr: 0.400 W Antenna Type : Helical Antenna Posn. : Out Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 43.400 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL BAND PHONE FM MODE CHAN 0991 26.0 dBm conducted SAMSUNG DUAL BAND PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = -1.000, Y = -2.750, Z = 0.000 (cm) Value = 15.581 Measured Values (volts) = 1.509E-002 1.184E-002 9.745E-003 8.342E-003 7.266E-003 6.771E-003 6.248E-003 5.984E-003 5.696E-003 5.334E-003 4.771E-003 4.155E-003 3.246E-003 2.425E-003 1.588E-003 1.079E-003 8.507E-004 9.347E-004 1.215E-003 1.673E-003 1.946E-003 Calc. Voltage @ Surface (Vs) = 0.0188 Voltage @ 1.00 cm (Vt) = 0.0083 Ave. Voltage (Vs+Vt)/2 = 0.0136 Ave. SAR over 1 g (mW/g) = 0.9894 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 mW/g -1012345 Z centimeters SAR Scan File : 00061210_ZOOM Start : 12-Jun-100 02:37:56 pm End : 12-Jun-100 02:47:03 pm SAMSUNG/A3LSPHM100/B01E1737;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 File : 00061210_ZOOM Start : 12-Jun-100 02:37:56 pm End : 12-Jun-100 02:47:03 pm SAMSUNG/A3LSPHM100/B01E1737;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 1.137 1.082 1.027 0.972 0.917 0.862 0.807 0.752 0.697 0.642 File : 00061210_ZOOM Start : 12-Jun-100 02:37:56 pm End : 12-Jun-100 02:47:03 pm SAMSUNG/A3LSPHM100/B01E1737;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 1.137 1.082 1.027 0.972 0.917 0.862 0.807 0.752 0.697 0.642 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00061215_ZOOM.VLT Start : 12-Jun-100 04:27:53 pm End : 12-Jun-100 04:37:00 pm Radio Type : SAMSUNG Model Number : A3LSPHM100 Serial Number : B01E1737 Frequency : 835.89 MHz Peak Trans. Pwr : 0.400 W Start Trans. Pwr: 0.400 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 43.400 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL BAND PHONE FM MODE CHAN 0363 26.0 dBm conducted SAMSUNG DUAL BAND PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = -1.500, Y = -2.000, Z = 0.000 (cm) Value = 20.006 Measured Values (volts) = 1.822E-002 1.425E-002 1.152E-002 9.212E-003 7.795E-003 6.661E-003 5.980E-003 5.640E-003 5.413E-003 5.193E-003 4.914E-003 4.473E-003 3.753E-003 3.071E-003 2.179E-003 1.504E-003 1.024E-003 8.126E-004 9.092E-004 1.173E-003 1.540E-003 Calc. Voltage @ Surface (Vs) = 0.0229 Voltage @ 1.00 cm (Vt) = 0.0092 Ave. Voltage (Vs+Vt)/2 = 0.0161 Ave. SAR over 1 g (mW/g) = 1.1721 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 mW/g -1012345 Z centimeters SAR Scan File : 00061215_ZOOM Start : 12-Jun-100 04:27:53 pm End : 12-Jun-100 04:37:00 pm SAMSUNG/A3LSPHM100/B01E1737;835.89MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 File : 00061215_ZOOM Start : 12-Jun-100 04:27:53 pm End : 12-Jun-100 04:37:00 pm SAMSUNG/A3LSPHM100/B01E1737;835.89MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 1.460 1.379 1.299 1.219 1.139 1.058 0.978 0.898 0.817 0.737 File : 00061215_ZOOM Start : 12-Jun-100 04:27:53 pm End : 12-Jun-100 04:37:00 pm SAMSUNG/A3LSPHM100/B01E1737;835.89MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/43.400/0.900 1.46β¦
Text truncated - open the document above for the full version.
RF Exposure Info
FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 1 inch (2.5cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 1 inch (2.5cm) must be maintained between the userβs body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain 1 inch (2.5cm) separation distance between the userβs body and the back of the phone, and have not been tested for typical body-worn operations may not comply with FCC RF exposure limits and should be avoided. For more information about RF exposure, please visit the FCC website at www.fcc.gov WARNING! Read this information before using your phone
RF Exposure Info
August 30, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSPHM100 731 Confirmation No.: EA97955 Correspondence Reference No.: 15799 Request for Tech. Info.: 8/28/00 Dear Joe: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated August 28, 2000. 1. Attached are revised Technical Specs and Tune-Up procedures that exhibit AMPS output levels matching the AMPS output levels used for the SAR evaluation. 2. Attached are the revised technical descriptions with correlating PCS output levels. 3. We acknowledge that the middle and low channels were tested at a conducted level of 26.0 dBm. Please note that the factory setting will be at a conducted level of 25.8 dBm. 4. The body-worn SAR Statement is to be located at the beginning of the manual. 5. Attached are the head and body peak SAR location illustrations for both the PCS and AMPS modes. The photos have been revised to show the true antenna position yielding the peak SAR. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.
RF Exposure Info
TEST ITEMS PROCEDURE 1. Set test equipments up. PREPARATION 2. RF POWER β47*889#l233β: EntertheTestMode β0 1β : Suspend Confirm that the phone is in the Analog Mode! ( β 10000β or β 10001β at Test Command β20β.) β4 6β : Initialize Vocoder in Analog mode If a wrong key would be selected, press βV, and then enter new command. To exit the Test Mode at any time, just press [0 21. β0 1β: Suspend β4 6β :Initialize Vocoder in Analog mode. β0 9 Q 1 6 3 #β: set channel to 363. β0 7β : Carrier On, β1 0 2β : RF Power level selection, β2β means one of the power levels (O-7) - Measurement of the Power Output Levels vel_ F Pow= 0-2 +25.6 dBm + 0.2/-4 dB 3 + 24 dBm +1/-4 dB 4 + 20 dBm +2/-4 dB 5 + 16 dBm +2/-4 dB 6 + 12 dBm +2/-4 dB 7 + 8 dBm +2/-4 dB β0 8β: Carrier off Note 1 : In case of using the antenna cable, compensation for the cable loss should be added (about 1.4dB). Note 2 : To prevent phones from being damaged, they musf be measured only by calibrated test equipments. Warning ! 3. TX FREQUENCY Adjustments without calibrated equipments can cause phones to be heated excessively and would void the warranty. β0 1β: Suspend. β4 6β : Initialize Vocoder in Analog mode. β0 9 Q 3 4 2 #β: Set channel to 363. β0 7β : carrier on. Measure the TX frequency : 835.89 MHzf2Sppm. SPH-MlOO@ual-Band Dual-Mode) Jun 3, 2000 * CONFIDENTIAL , 1-2. AMPS 1-2-l. General Frequency Range .Transmitter : 824-849 MHz .Receiver : 869 - 894MHz Channel Spacing :3OkHz Number of Channels : 832 Duplex Spacing : 45MHz Frequency Stability : *2Sppm(-30 βC - 60 βC, -220 F - 1400 F) Modulation/Demodulation .Voice: PM .Data : FM Operating Temperature Supply Voltate : 3.6V l-2-2. Transmitter :-3oβc - 60 βc, -220 F - 1400 F RF output power : 0.365W(+ 0.2/-4dB) Carrier ON/OFF conditions βONβ Condition : within f3d.B of specification output(in 2 ms) βOFFβ Condition : below -6OdBm(in 2ms) Compresssor Compression Rate : 2 : 1 Attack Time : 3ms Recovery Time: 13Sms Reference Input : input power level for producing a nominal f2.9kHz : peak frequency deviation of transmitted carrier Preamphasis: 6dEVCKT within 0.3 Lc 3 kHz Maxirnum Frequency Deviation F3 of G3 : f12 kHz Supervisory Audio Tone : f2 kHz(flO%) Signaling Tone - *8 kHz(flO%). Wideband Data : *8 kHz(*lO%) SPH-MlOO(DuaI-Band Dual-Mode) Jun 3, 2000 \. <,. .:- l-3. PCS l-3-1. General Frequency Range .Transmitter : 1850-- 1910 MHz .Receiver : 1930-1990 MHz Channel Spacing : 5OkHz Number of Channels : 1200 Duplex Spacing : 8OMHz Frequency Stability : ( Fu-SOMHz)* 15OHz Operating Temperature :-30Β°C - 6oΒ°C, -220 F - 1400 F Supply Voltate : 3.6V 1-3-2. Transmitter Waveform Quality : 0.944 or more Open Loop Power Control Range . -25dBm: -60.5dBm - -41.5dBm * -65dBm : -20.5dBm - +l.SdBm . -104dBm : +15.OdBm - +3OdBm Minimum TX Power Control : below -5OdBm below Closed Loop Power Control Range : f24dB Maximum RF Output Power : 250 mW(+24 dBm) Occupied Bandwidth : 1.23MHz Conducted Spurious Emission @900 KHz : -42dBc/3OkHz al.25 MHz : -54dBcI3OkHz , CONFIDENTIAL . 1-3-3. Receiver Rx Sensitivity and Dynamic Range : -104dBm FER=O.5% or less * . -25dBm, FER=O.5% or less Conducted Spurious Emission . 1930-1990 MHz : c-8 1dBm . 1850- 1910 MHz : GldBm . All Other Frequencies : <-47dBm Single Tone Desensitization : lower than 1 % SPH-MlOO(Dual-Band Dual-Mode) Jun 3, 2000 Peak SAR Location Β© 2000 PCTEST Labβ¦
Text truncated - open the document above for the full version.
Contact Information
Applicant
Jenni Chun(General Manager)
Technical Contact
PCTEST Engineering Laboratory, Inc.Randy Ortanez
[email protected]410-290-6652
6660-B Dobbin Road Β· Columbia, Maryland Β· United States
Non-Technical Contact
PCTEST Engineering Laboratory, Inc.Randy Ortanez
[email protected]410-290-6652
Test Firm
PCTEST Engineering Laboratory, Inc.Randy Ortanez
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 3 | 24 | 1.85 GHz - 1.91 GHz | 321.00 mW | 1M25F9W | 2.5 ppm |
