A3LSPHN105PCS CDMA Phone

User Guide ELECT ELECTRONICS GH00-000000 ‘2000/3. Rev. 1. 1 SCH-N101 Series CDMA DIGITAL CELLULAR TELEPHONE Features Congratulations on the purchase of your Samsung Phone. Using the latest digital technlolgy,the Samsung Phone oper- ates similar to other wireless phones,while providing superi- or resonanc and tone quality. Your Samsung phone is packed with productive features that are easy to use.Here are some of them: u Answer and hang up calls just by opening the phone u Large,easy-to-use Phone Book with 229 memory locations u Turbo Dialing u Voice Dialing-20 memory locations with one-touch access u Event Scheduler,to-do list,world clock,and calculator u Web Browser u Data and Fax call capable u Short Message Services (SMS) and Voicemail u Fast Ringer Mute during incoming calls u 10 ring tones,11 melodies,or Vibrate alert u 10 Incoming and 10 Outgoing Call Logs with Caller ID u Pause Dialing for tele-services u Security features including Call Restriction u Alarm Clock u Dynamic Character Display 1 Table of Contents Your Consumer Package 7 Getting to Know Your Phone 8 Turning your Samsung Phone On and Off 15 To Turn it On 15 To Turn it Off 15 The Top Line of the Display 16 Using the Battery 18 Installing the Battery 18 Removing the Battery 18 Charging the Battery 18 Charging with the Tra veler Adapter 19 Your Phone’s Modes 20 Standby Mode 20 Conversation Mode 20 Power Save Mode 21 Basic Voice Call Functions 22 Making a Voice Call 22 Redialing Calls 22 Correcting Dialing Mistakes 23 Ending a Call 23 Incoming Call Notification 23 Answering a Call 24 Adjusting Ring Volume 24 Silencing the Ringer on an Incoming Call 25 Setting the Ringer Type 25 To Mute the Microphone During a Call 25 Adjusting Voice Volume 26 Using Caller ID 26 Three-Way Calling 27 3 Setting the Language of the Display 45 Displaying your phone’s Hardware and Software Version 46 Alarm 47 Setting the Alarm 47 To Change the Alarm Setting 48 To Cancel the Alarm 48 Sounds 49 Key Beep Volume Setting 49 Ringer Options 50 One-Touch Vibrate Ringer 50 Fast Ringer Mute 50 Ring type setting for Data and Fax Calls 51 Ring Volume Setting for all Incoming Calls 51 Differential Ring 53 Voice-Activated Dialing 54 Tips on Recording Names 54 Program the Phone for Voice-Activated Dialing 55 Voice Dialing Activation 56 Placing a Call using Voice Dialing 57 Reviewing Voice Dialing Entries 57 Erasing Voice Dialing Entries 58 Message Services 59 Incoming Messages 59 Incoming Message Memory Capacity 59 Reviewing Incoming Page,Text,or Browser Messages 60 Incoming Message Ringer 61 Incoming Messages and Lock Mode 61 Options when Reviewing Incoming Messages 61 Erasing Inbox Messages 62 Voicemail 63 Setting up your Voicemail 63 Reviewing Voicemail Messages 63 2 Call Forwarding 27 Call Waiting 28 Answering a Call Waiting Call 28 Missed Calls 29 Dropped Calls 29 Failed Calls 29 Prepend Dialing 30 Emergency Dialing 31 Pause Dialing 32 Storing Pauses in a Phone Book Entry 32 Pause Dialing From a Stored Phone Book Entry 33 Manual Pause Dialing 33 Basic Setup of Your Phone 34 Automatic Retry 34 Automatic Answer 34 Automatic Hyphenation 35 Answer Options 35 Tone Length Setting 36 Setting the Time 36 Setting Your NAM 37 System Selection 38 How to Setup For a Voice,Data,or Fax Call 39 How to Setup the Web Browser Prompts 39 Audible Alerts 40 Minute Beep 40 Service Alert 40 Connect Alert 41 Disconnect Alert 41 Display Options 43 Backlight Control 43 Personal Greeting 44 Animation Display 44 Displaying your own Phone Number 45 54 The Phone Book 64 Viewing Stored Entries 64 Storing Phone Numbers and Names 66 Storing phone numbers shortcuts 67 Storing phone numbers at the end of a call 67 Prepend a Phone Number 68 Adding a Name Ringer 69 Changing Your Phone Book 70 Editing Phone Book numbers 70 Secret Phone Book numbers 70 Erasing Phone Book Entries 71 Erasing the Phone Book 71 Set Speed Dial 71 Dialing numbers from your Phone Book 72 Memory Dialing Shortcuts 72 Your Phone’s Security Features 73 Lock Mode 73 Dialing in Lock Mode 73 Locking the Phone 74 Unlocking the Phone 75 Call Restriction Options 75 Lock Code Setting 76 Priority Numbers 77 Storing a Priority Number 77 Dialing Priority Numbers in Lock Mode 78 Personal Identification Number (PIN) 78 Erasing Your Phone Book (Clear Memory) 79 Hiding your Phone Number 79 Vocoder 80 Resetting Your Phone 81 Keeping Track of Your Calls 82 Displaying Your Call Logs 82 Erasing Call Logs 83 Reviewing Air Time 84 Scheduler 86 Today 86 View Month 88 Jump To Date 89 To Do List 90 Count Down 91 World Time 93 Calculator 94 Game 95 Fax and Data Calls 96 Receiving a Fax 96 Receiving a Data File 97 Sending a Fax or Data File 98 The Web Browser(WAP) 99 To Setup the Web Browser Prompts 99 Launching the Web Browser 100 To exit the Web Browser 101 The Web Browser Soft Keys 101 Navigating the Web Browser 102 Entering text,numbers,or symbols 104 Using Links 105 Initiating a Phone Call during a Web Browser Session 105 Receiving a phone call while in the Web Browser 105 Using Bookmarks 106 To Create a Bookmark 106 Finding a Bookmark 106 Orange Menu 107 Menus 108 Main Menu 108 In Use Menu 108 Navigating Menus 108 Your Phon’s Main Menu 109 76 Usage Guidelines: All about Performance and Safety 110 Understanding Signal Strength 110 Understanding Power Save Mode 110 Understanding How Your Phone Operates 110 Specifications Subject to Change 110 Radio Frequency Safety 111 Emergency Calls IMPORTNAT NOTICE! PLEASE READ! 111 Maintaining Your Phone’s Peak Performance 112 Protecting Your Battery 112 Battery Disposal and Recycling 113 Operating a Motor Vehicle 114 Following Safety Guidelines 115 Turn off Your Phone Before Flying 115 Restricting Children’s Access to Your Phone 115 Cautions 115 FCC Notice 115 Storing Your Phone 115 Using Your Phone Near Other Electronic Devices 116 FCC Compliance Information 116 Liquefied Petroleum Gas 117 Turn Off Your Phone in Dangerous Areas or Posted Areas117 Your Phone as a Network Device 117 Information To User 1…

Text truncated - open the document above for the full version.

May 22, 2000 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.853(a) Sincerely, Wallace Oh Engineering Manager Samsung Electronics America May 30, 2000 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.:A3LSPHN105 Request for Confidentiality To whom it may concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, and Circuit Description of the attached test report. These documents contain detailed system and equipment description and related information about the product which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market.

May 30, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSPHN105 Part 24 Certification Gentlemen: Attached herewith, on behalf of SAMSUNG ELECTRONICS CO., LTD. is an application for Part 24 Certification of the following PCS CDMA Phone: FCC ID:A3LSPHN105 TRADE / MODEL(s):SAMSUNG SPH-N105 EUT TYPE:Licensed Portable Transmitter Held to Ear (PCE) Tx Freq. Range:1851.25 – 1908.75 MHz Rx Freq. Range:1931.25 – 1908.75 MHz Max. RF Output Power:0.3258 W EIRP (25.13 dBm) Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description, parts list & tune-up procedure, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Wallace Oh Engineering Manager SAMSUNG American QA Lab

August 14, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Frank Coperich SUBJECT:SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSPHN105 731 Confirmation No.: EA97831 Correspondence Reference No.: 15490 Request for Tech. Info.: 8/9/00 Dear Errol: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated August 9, 2000. 1. Please find the attached letter from Samsung indicating the exclusion of the necklace accessory option. Also attached is the deletion of the necklace accessory from the user’s manual page. 2. Please find the attached body-worn RF exposure statement which will be placed at the beginning of the user’s manual. We trust this information is sufficient to issue the grant ASAP. If you have any further questions, please do not hesitate to contact us. cc:Samsung Electronics Co., Ltd.

© 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone

© 2000 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) MODEL NO: SPH-N105 FCC ID: A3LSPHN105 CANADA: MADE IN KOREA

© 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone

SEC-CODE B'DPART NO DECRIPTIONREMARK 0405-001035D402DIODE-VARACTOR1SV279,15V,3nA,USC,TP 0405-001035D403DIODE-VARACTOR1SV279,15V,3nA,USC,TP 0405-001035D501DIODE-VARACTOR1SV279,15V,3nA,USC,TP 0405-001035D502DIODE-VARACTOR1SV279,15V,3nA,USC,TP 0406-001051ZD102DIODE-TVSSMS05C,6V,300W,SOT-23-6 0406-001051ZD103DIODE-TVSSMS05C,6V,300W,SOT-23-6 0407-000115D100DIODE-ARRAYDAN202U,80V,100mA,CA2-3,SC-70, 0407-000115D202DIODE-ARRAYDAN202U,80V,100mA,CA2-3,SC-70, 0407-001006D200DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006D201DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0407-001006D500DIODE-ARRAYDA221,20V,100mA,C2-3,EM3,TR 0409-001016D401DIODE-PINBAR63-02W,50V,100mA,SCD-80,TP 0501-000162Q106TR-SMALLSIGNAL2SA1576,PNP,200MW,SOT-323,TP,180-390 0501-000162Q301TR-SMALLSIGNAL2SA1576,PNP,200MW,SOT-323,TP,180-390 0501-000218Q400TR-SMALLSIGNAL2SC4081,NPN,200mW,UMT,TP,180-3 0501-000225Q102TR-SMALLSIGNAL2SC4617,NPN,200mW,EM3,TP,120-5 0501-000225Q108TR-SMALLSIGNAL2SC4617,NPN,200mW,EM3,TP,120-5 0501-002096Q503TR-SMALLSIGNALBFP420,NPN,160MW,SOT-343,TP,50-150 0501-002110Q401TR-SMALLSIGNALAT32033,NPN,200mW,SOT-23,TP,70 0501-002202Q107TR-SMALLSIGNALMMBT2222AWT1,NPN,150mW,SOT-323 0501-002202Q201TR-SMALLSIGNALMMBT2222AWT1,NPN,150mW,SOT-323 0504-000167Q104TR-DIGITALRN1102,NPN,100MW,10K/10K,SSM,TP 0504-000167Q160TR-DIGITALRN1102,NPN,100MW,10K/10K,SSM,TP 0504-000167Q302TR-DIGITALRN1102,NPN,100MW,10K/10K,SSM,TP 0504-000167Q502TR-DIGITALRN1102,NPN,100MW,10K/10K,SSM,TP 0504-000167Q510TR-DIGITALRN1102,NPN,100MW,10K/10K,SSM,TP 0504-000167Q511TR-DIGITALRN1102,NPN,100MW,10K/10K,SSM,TP 0504-000168Q100TR-DIGITALRN1104,NPN,100MW,47K/47K,SSM,TP 0504-000168Q103TR-DIGITALRN1104,NPN,100MW,47K/47K,SSM,TP 0504-000168Q410TR-DIGITALRN1104,NPN,100MW,47K/47K,SSM,TP 0504-000172Q200TR-DIGITALRN2104,PNP,100MW,47K/47K,SSM,TP 0504-000172Q500TR-DIGITALRN2104,PNP,100MW,47K/47K,SSM,TP 0505-001037U502FET-SILICON-,P,-12V,+-2.5A,0.1ohm,1W,TSSO 0505-001119Q402FET-SILICON2SK2685,P,6V,20mA,-,100mW,CMPA 0505-001165Q110FET-SILICONSI3443DV,P,-20V,+-3.5mA,65mohm 0505-001165Q501FET-SILICONSI3443DV,P,-20V,+-3.5mA,65mohm 1001-001048U407IC-ANALOGSWITCHSW395TR,SPDP,SOT-26,6P,-,DUAL, 1103-001184U105IC-EEPROM24C256,32Kx8Bit,dBGA,8P,92MIL,-,2.7V 1109-001133U102IC-ETC.MEMORY84VD21194,2MX8/1MX16Bit,BGA,61P,354MIL 1201-001248U300IC-CASCODEAMP0916,SOT-143,4P,-,-,2.7V,-,6Vd 1201-001248U301IC-CASCODEAMP0916,SOT-143,4P,-,-,2.7V,-,6Vd 1201-001259U500IC-POWERAMP23124,LCC,8P,-,SINGLE,-,PLASTI 9.PARTSLIST 1201-001384U400IC-MMICAMPMD57-0001,SOT-26,6P,114MIL,SIN 1202-000192U200IC-VOLFAGECOMP.75W393,-,8P,-,DUAL,36V,CMOS,PL 1203-001285U403IC-SWITCHVOL.REG.5205,SOT-23,5P,150MIL,PLASTIC, 1203-001285U404IC-SWITCHVOL.REG.5205,SOT-23,5P,150MIL,PLASTIC, 1203-001285U503IC-SWITCHVOL.REG.5205,SOT-23,5P,150MIL,PLASTIC, 1203-001717U201IC-VOLTAGEREGULATOR5210,MSOP,8P,117MIL,PLASTIC,3.0V 1203-001835U101IC-RESET3470,SOT23,5P,-,PLASTIC,0.99/1.01V 1204-001375U202IC-ENCODER/DECODERST5092TQFPTR,QFP,44P,-,PLASTIC 1204-001504U401IC-IFCIRCUITIFR3000,TQFP,48P,-,PLASTIC,3.5V 1204-001505U501IC-IFCIRCUITIFT3000,TQFP,48P,-,PLASTIC,3.5V 1205-001535U504IC-MIXERRF2628,MSOP,8P,190MIL,PLASTIC, 1205-001670U104IC-TRANSCEIVERMSM3000,PBGA,196P,-,PLASTIC,3.5V 1209-001197U302IC-PLLLMX2332LSLB,CSP,20P,-,PLASTIC, 1404-001040R502THERMISTOR-NTC10Kohm,5%,3650K,-,TP 1404-001165TH1THERMISTOR-NTC10KOHM,3%,4100K,30MW/C,TP 2007-000137R143R-CHIP2Kohm,5%,1/16W,DA,TP,1005 2007-000137R330R-CHIP2Kohm,5%,1/16W,DA,TP,1005 2007-000137R405R-CHIP2Kohm,5%,1/16W,DA,TP,1005 2007-000137R526R-CHIP2Kohm,5%,1/16W,DA,TP,1005 2007-000138R101R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R103R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R106R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R108R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R111R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R144R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000138R302R-CHIP100ohm,5%,1/16W,DA,TP,1005 2007-000139R416R-CHIP220ohm,5%,1/16W,DA,TP,1005 2007-000140R110R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R117R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R126R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R127R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R135R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R146R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R210R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000140R213R-CHIP1Kohm,5%,1/16W,DA,TP,1005 2007-000141R204R-CHIP2.2Kohm,5%,1/16W,DA,TP,1005 2007-000141R309R-CHIP2.2Kohm,5%,1/16W,DA,TP,1005 2007-000142R505R-CHIP2.7Kohm,5%,1/16W,DA,TP,1005 2007-000143R124R-CHIP4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143R187R-CHIP4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143R206R-CHIP4.7Kohm,5%,1/16W,DA,TP,1005 2007-000143R529R-CHIP4.7Kohm,5%,1/16W,DA,TP,1005 2007-000144R281R-CHIP5.1Kohm,5%,1/16W,DA,TP,1005 2007-000144R310R-CHIP5.1Kohm,5%,1/16W,DA,TP,1005 2007-000145R506R-CHIP6.2Kohm,5%,1/16W,DA,TP,1005 2007-000146R105R-CHIP6.8Kohm,5%,1/16W,DA,TP,1005 2007-000146R128R-CHIP6.8Kohm,5%,1/16W,DA,TP,1005 2007-000147R532R-CHIP8.2Kohm,5%,1/16W,DA,TP,1005 2007-000148R109R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R121R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R132R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R139R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R194R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R196R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R426R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R427R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R510R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R512R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R517R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000148R582R-CHIP10Kohm,5%,1/16W,DA,TP,1005 2007-000151R134R-CHIP15Kohm,5%,1/16W,DA,TP,1005 2007-000153R100R-CHIP22Kohm,5%,1/16W,DA,TP,1005 2007-000153R123R-CHIP22Kohm,5%,1/16W,DA,TP,1005 2007-000153R125R-CHIP22Kohm,5%,1/16W,DA,TP,1005 2007-000153R129R-CHIP22Kohm,5%,1/16W,DA,TP,1005 2007-000153R145R-CHIP22Kohm,5%,1/16W,DA,TP,1005 2007-000153R147R-CHIP22Kohm,5%,1/16W,DA,TP,1005 2007-000155R185R-CHIP27Kohm,5%,1/16W,DA,TP,1005 2007-000157R102R-CHIP47Kohm,5%,1/16W,DA,TP,1005 2007-000157R107R-CHIP47Kohm,5%,1/16W,DA,TP,1005 2007-000157R520R-C…

Text truncated - open the document above for the full version.

© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road 6660-B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SAMSUNG ELECTRONICS CO., LTD.Dates of Tests: May 18-26, 2000 416-Maetan-3 Dong, Paldal-KuTest Report S/N: SAR.200508219.A3L Suwon City, Kyungki-Do 441-742, KOREATest Site: PCTEST Lab, Columbia, MD Attn: Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) FCC ID A3LSPHN105 APPLICANT SAMSUNG ELECTRONICS CO., LTD. EUT Type:Single-Mode PCS CDMA Phone Tx Frequency:1851.25 – 1908.75 MHz Rx Frequency:1931.25 – 1988.75 MHz Max. RF Output Power:0.3258W EIRP (25.13 dBm) Trade Name/Model(s):SAMSUNG SPH-N105 FCC Classification:Licensed Portable Transmitter Held to Ear (PCE) Application Type:Certification Serial Number:n/a (pre production) FCC Rule Part(s):2.1093; ET Docket 96.326 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.862. 200508219.A3L SAR Measurement ReportFCC Part 22 Certification © 2000 PCTEST Labi Table of Contents 1.1 SCOPE1 2.1 INTRODUCTION / SAR DEFINITION2 3.1 SAR MEASUREMENT SET-UP3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM4 5.1 E-FIELD PROBE SYSTEM5-6 6.1 PHANTOM & EQUIVALENT TISSUES7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS9 9.1 TEST POSITION OF THE PHONE10 10.1 BODY-WORN TEST SETUP11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS12 12.1 MEASUREMENT UNCERTAINTIES13 13.1 TEST DATA SUMMARY14-15 14.1 SAR TEST EQUIPMENT LIST16 15.1 CONCLUSION / REFERENCES17 Test Report S/N: SAR.200508219.A3LSAR Measurement Report Test Dates: May 18-26, 2000FCC Part 24 Certification SAMSUNG FCC ID: A3LSPHN105 (Model: SPH-N105) © 2000 PCTEST LabSingle-Mode PCS CDMA Phone1 Figure 1. SAR Test Set-up SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant:SAMSUNG ELECTRONICS CO., LTD. Address:416 Maetan-3 Dong, Paldal-Ku Suwon City, Kyungki-Do 441-742, KOREA Attention:Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) • EUT Type:Single-Mode PCS CDMA Phone • FCC Rule Part(s):§2.1093, Docket 96-326 • Trade Name:SAMSUNG • FCC IDENTIFIER:A3LSPHN105 • Model(s):SPH-N105 • S/N:Pre-production • Tx Frequency:1851-25 – 1908.75 MHz • Rx Frequency:1931.25 – 1988.75 MHz • Application Type: Certification • FCC Classification:Licensed Portable Transmitter Held to Ear (PCE) • FCC Rule Part(s):§ 2.1093, Docket 96-326 • Modulation(s):CDMA • Max. RF Output Power:0.3258W EIRP (25.13 dBm) • Antenna Type:Helical (λ/2)(λ/3) ??? • Antenna Dimensions:11.2 cm. (Length) ??? • Dates of Tests:May 18-26, 2000 • Place of Tests:PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.:SAR.200508219.A3L 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Test Report S/N: SAR.200508219.A3LSAR Measurement Report Test Dates: May 18-26, 2000FCC Part 24 Certification SAMSUNG FCC ID: A3LSPHN105 (Model: SPH-N105) © 2000 PCTEST LabSingle-Mode PCS CDMA Phone2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[4] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source. SAR values have been related to threshold levels for potential biological hazards. 2.2 SAR Definition Specific Absorption Rate (SAR) is defined as the time derivative (rate) of the incremental energy (dU) absorbed by (dissip…

Text truncated - open the document above for the full version.

File : 00051812_AREA Start : 18-May-100 03:29:13 pm End : 18-May-100 03:37:38 pm SAMSUNG/SPH-N105/B01E00DE;1908.75MHz;W;Helical/In; Head/Left Ear;AREA;PCTEST/E Field/0 DegreesBrain/41.300/1.650 0.424 0.377 0.330 0.282 0.235 0.188 0.141 0.094 0.047 0.000 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00051812_ZOOM.VLT Start : 18-May-100 03:37:38 pm End : 18-May-100 03:47:37 pm Radio Type : SAMSUNG Model Number : SPH-N105 Serial Number : B01E00DE Frequency : 1908.75 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.300 Mixture Conductivity = 1.650 Comment : SAMSUNG PCS PHONE CDMA MODE CHAN 1175 24.5 dBm conducted FCC ID:A3LSPHN105 Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 1.201 PCTEST Amplifier Channel Settings : 0.245 0.231 0.224 Max Location : X = -2.000, Y = -0.500, Z = 0.000 (cm) Value = 3.916 Measured Values (volts) = 3.747E-003 2.688E-003 1.852E-003 1.264E-003 9.014E-004 6.253E-004 4.401E-004 3.229E-004 1.870E-004 1.236E-004 7.927E-005 2.700E-005 2.961E-006 0.000E+000 3.877E-006 6.345E-007 3.313E-006 0.000E+000 0.000E+000 0.000E+000 0.000E+000 Calc. Voltage @ Surface (Vs) = 0.0053 Voltage @ 1.00 cm (Vt) = 0.0013 Ave. Voltage (Vs+Vt)/2 = 0.0033 Ave. SAR over 1 g (mW/g) = 0.3667 -0.1 0.0 0.1 0.2 0.3 0.4 0.5 0.6 mW/g 012345 Z centimeters SAR Scan File : 00051812_ZOOM Start : 18-May-100 03:37:38 pm End : 18-May-100 03:47:37 pm SAMSUNG/SPH-N105/B01E00DE;1908.75MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.300/1.650 File : 00051812_ZOOM Start : 18-May-100 03:37:38 pm End : 18-May-100 03:47:37 pm SAMSUNG/SPH-N105/B01E00DE;1908.75MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.300/1.650 0.435 0.394 0.352 0.310 0.269 0.227 0.185 0.143 0.102 0.060 File : 00051812_ZOOM Start : 18-May-100 03:37:38 pm End : 18-May-100 03:47:37 pm SAMSUNG/SPH-N105/B01E00DE;1908.75MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.300/1.650 0.435 0.394 0.352 0.310 0.269 0.227 0.185 0.143 0.102 0.060 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00051814_ZOOM.VLT Start : 18-May-100 04:26:20 pm End : 18-May-100 04:40:12 pm Radio Type : SAMSUNG Model Number : SPH-N105 Serial Number : B01E00DE Frequency : 1908.75 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : Out Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.300 Mixture Conductivity = 1.650 Comment : SAMSUNG PCS PHONE CDMA MODE CHAN 1175 24.5 dBm conducted FCC ID:A3LSPHN105 Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 1.201 PCTEST Amplifier Channel Settings : 0.245 0.231 0.224 Max Location : X = -2.000, Y = -0.500, Z = 0.000 (cm) Value = 4.117 Measured Values (volts) = 3.404E-003 2.571E-003 1.808E-003 1.242E-003 9.493E-004 6.362E-004 4.451E-004 3.049E-004 2.103E-004 1.573E-004 9.355E-005 1.952E-005 1.909E-005 0.000E+000 3.877E-006 0.000E+000 0.000E+000 0.000E+000 0.000E+000 0.000E+000 0.000E+000 Calc. Voltage @ Surface (Vs) = 0.0047 Voltage @ 1.00 cm (Vt) = 0.0012 Ave. Voltage (Vs+Vt)/2 = 0.0030 Ave. SAR over 1 g (mW/g) = 0.3289 -0.1 0.0 0.1 0.2 0.3 0.4 0.5 0.6 mW/g 012345 Z centimeters SAR Scan File : 00051814_ZOOM Start : 18-May-100 04:26:20 pm End : 18-May-100 04:40:12 pm SAMSUNG/SPH-N105/B01E00DE;1908.75MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.300/1.650 File : 00051814_ZOOM Start : 18-May-100 04:26:20 pm End : 18-May-100 04:40:12 pm SAMSUNG/SPH-N105/B01E00DE;1908.75MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.300/1.650 0.458 0.408 0.358 0.308 0.258 0.208 0.158 0.108 0.058 0.007 File : 00051814_ZOOM Start : 18-May-100 04:26:20 pm End : 18-May-100 04:40:12 pm SAMSUNG/SPH-N105/B01E00DE;1908.75MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.300/1.650 0.458 0.408 0.358 0.308 0.258 0.208 0.158 0.108 0.058 0.007 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00051815_ZOOM.VLT Start : 18-May-100 04:53:51 pm End : 18-May-100 05:08:22 pm Radio Type : SAMSUNG Model Number : SPH-N105 Serial Number : B01E00DE Frequency : 1880 MHz Peak Trans. Pwr : 0.285 W Start Trans. Pwr: 0.285 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.300 Mixture Conductivity = 1.650 Comment : SAMSUNG PCS PHONE CDMA MODE CHAN 0600 24.5 dBm conducted FCC ID:A3LSPHN105 Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 1.201 PCTEST Amplifier Channel Settings : 0.245 0.231 0.224 Max Location : X = -2.000, Y = -0.500, Z = 0.000 (cm) Value = 3.288 Measured Values (volts) = 3.909E-003 2.457E-003 1.730E-003 1.290E-003 8.797E-004 6.214E-004 4.366E-004 3.025E-004 1.893E-004 1.061E-004 9.608E-005 3.955E-005 1.079E-005 0.000E+000 1.100E-005 2.171E-005 0.000E+000 0.000E+000 0.000E+000 0.000E+000 0.000E+000 Calc. Voltage @ Surface (Vs) = 0.0059 Voltage @ 1.00 cm (Vt) = 0.0013 Ave. Voltage (Vs+Vt)/2 = 0.0036 Ave. SAR over 1 g (mW/g) = 0.3989 -0.1 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 mW/g 012345 Z centimeters SAR Scan File : 00051815_ZOOM Start : 18-May-100 04:53:51 pm End : 18-May-100 05:08:22 pm SAMSUNG/SPH-N105/B01E00DE;1880MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.300/1.650 File : 00051815_ZOOM Start : 18-May-100 04:53:51 pm End : 18-May-100 05:08:22 pm SAMSUNG/SPH-N105/B01E00DE;1880MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.300/1.650 0.366 0.331 0.297 0.263 0.229 0.195 0.160 0.126 0.092 0.058 File : 00051815_Z…

Text truncated - open the document above for the full version.

© 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTEST Lab Samsung FCC ID: A3LSPH-N105 NVLAP Lab Code: 100431-0 PCS CDMA Only Cellular Phone © 2000 PCTE…

Text truncated - open the document above for the full version.
