A3LSPP300MProjector

AD9883 RGB ADC DDP2000 u-COM, Scaler DMD Controller DAD1000 DMD Power & Reset Driver Flash Mem. Sequence & Program K4R271669B RAMBUS. DRAM CDCR83 RAMBUS. Clock Generator OSC. 100MHz EEPROM System Mem. TVP5150 Video Decoder Battery Pack Power Adapter LED Driver Power Circuit (DC-DC)

Page : 1 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. EMC Test Report According to FCC Part 15 Subpart B Project No. LBE052532 Equipment under Test Address 416 Maetan3-Dong,Yeongtong-Gu,Suwon- Si, Gyeonggi-Do,Korea,443-742 Product Name Projector Model Name SP-P300M Manufacturer Samsung Electronics Co., Ltd. Brand Name SAMSUNG Variant Model See Page 3 FCC ID A3LSPP300M Date of Test September 14 ~ 21, 2005 Issued Date November 3, 2005 Name/Position Signature Tested by Hyun Jeong, Jang Test Engineer Reviewed by No Cheon, Park Manager of EMC Lab. Authorized by Seung Kyu, Cha Chief of EMC Lab. 1. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 2. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. NVLAP LAB CODE 200623-0 Page : 2 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Table of Contents 1. General Information 1.1 Basic Information related Product 1.2 Detail Information related Product 1.3 Test Configuration 1.4 EUT Operating Conditions 1.5 Applied Standard 1.6 Test Facility 2. Summary of Test Results 3. Description of individual tests 3.1 Conducted Emission 3.2 Radiated Emission 4. Appendix A 4.1 Test Photography 4.2 EUT Photography Page : 3 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1. General Information 1.1 Basic Information related Product Applicant Samsung Electronics Co., Ltd. Model name SP-P300M Applicant Address 416 Maetan3-Dong,Yeongtong-Gu,Suwon- Si, Gyeonggi-Do,Korea,443-742 Contact Person Chang Seub, Eum Kind of product Projector Valiant list None Manufacturer Samsung Electronics Co., Ltd. 1.2 Detail Information related Product Specification Voltage AC 100 ~ 240 V, 50/60 Hz Power Consumption 18 W Resolution 800×600 Size 0.6Inch 1.3 Operating Mode and Condition The system was configured for testing in typical fashion use. Cables were attached to each of the available I/O Ports. Where applicable, peripherals were attached to the I/O cables. The mode of operation utilized for testing was selected to best simulate typical EUT use. - D-Sub Cable 1.4 Equipment Modifications No equipment modifications were required. Page : 4 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.5 Test Configuration Used EUT and Peripherals Seq Device Model Name Serial No. Maker Note A Projector SP-P300M - SAMSUNG EUT B PC M6320 E-A011-004072(B) SAMSUNG C Printer LQ-580H CG2Y016889 EPSON D USB Keyboard TKB-3000 C0412158564 TRUTION E PS/2 Mouse CCM-202 E-C011-03-0032(B) COSY Port Description No Connect Cable Length [m] Shielded [Y/N] Remark 1 Power 1.8 No EUT 2 Power 1.8 No PC 3 Power 1.8 No Printer 4 D-SUB Cable 1.7 Yes - 5 Parallel (Printer) 1.8 Yes - 6 USB (Keyboard) Cable 1.5 No - 7 PS/2(Mouse) Cable 1.5 No - Page : 5 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Block Diagram A Page : 6 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.6 Applied Standards List Applied Standards Test Procedure FCC Part15 Subpart B ANSI C63.4 : 2003 1.7 Test Facility General Information The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR 16-1, 16-2. This EMC Testing Lab. is accredited by Korea Laboratory Accreditation Scheme(KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). This Lab. is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:1998. Accreditation and Listing Uncertainty Test Item Expanded Uncertainty Conducted Emission ±3.3 Radiated Emission (Hor) ±4.0 (Ver) ±4.4 (According to NAMAS Pub.NIS81) Page : 7 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 2. Summary of Test Results Result : PASS The equipment under test(EUT) has been found to comply with the applied standards. Test Name Applied Standard Result Electromagnetic Emission Test 3.1 Conducted Emission FCC Part15 Subpart B Complied 3.2 Radiated Emission FCC Part15 Subpart B Complied Page : 8 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 3. Description of Individual Tests 3.1 Conducted Emission Test Information Test Engineer Hyun Jeong, Jang Test Date September 21, 2005 Climate Condition Ambient Temperature : 23°C Relative Humidity : 52% Test Place Shield Room #5 Test Equipments Calibration Equipment Modal Name Manufacturer Serial No. Next Date Interval L.I.S.N ESH3-Z5 R&S 100261 2006-07-13 12 Test Software EP5CE TOYO None N/A N/A Field strength meter ESS-30 R&S 844861/005 2006-01-11 12 RF Relais Matrix PSU R&S 861206/024 N/A N/A EMI Test Receiver ESI R&S 8326921/002 2006-02-26 12 EUT Test Setup The EUT was set up as per normal use on a wooden table 0.4m from a vertical ground reference plane, at least 0.8m from other conduction surfaces and 0.8m from the LISN. See photo. Test Result Measurement Results Pass The measured emissions of the EUT have found to be below the specified limits. Page : 9 of 14 Project NO. :LBE052532…

Text truncated - open the document above for the full version.

Page : 12 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 4. Appendix A 4.1 Test Photography Picture 1. Conducted Emission Picture 2. Radiated Emission (front view) Page : 13 of 14 Project NO. :LBE052532 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Picture 3. Radiated Emission (rear view)
