Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Notices i Notices No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, mechanical photocopying, recording or otherwise, without the prior written permission of the manufacturer. The information within this manual is subject to change without notice. The manufacturer shall not be held liable for technical or editorial errors or omissions contained in herein; nor for incidental or consequential damages resulting from the furnishing, performance or use of this material. Microsoft Windows is a registered trademark of the Microsoft Corporation. Product names mentioned herein are for identification purposes only, and may be trademarks and/or registered trademarks of their respective companies. Macrovision Statement If your computer has a DVD drive and an analog TV Out port, the following paragraph applies: This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. Copyright2001 All rights are reserved ii Users Manual Important Safety Information Safety Instructions Your system is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the documentation are followed. Always follow these instructions to help guard against personal injury and damage to your system. i Setting Up your System • Read and follow all instructions marked on the product and in the documentation before you operate your system. Retain all safety and operating instructions for future use. •Do not use this product near water or a heat source such as a radiator. •Set up the system on a stable work surface. •The product should be operated only with the type of power source indicated on the rating label. •Ensure that the electrical outlet you are using to power your equipment is easily accessible in case of fire or short circuit. •If your computer has a voltage selector switch, make sure that the switch is in the proper position for your area. •Openings in the computer case are provided for ventilation. Do not block or cover these openings. Make sure you provide adequate space, at least 6 inches (15 cm), around the system for ventilation when you set up your work area. Never insert objects of any kind into the computer ventilation openings. •Ensure that the fan vents on the bottom of the casing are clear at all times. Do not place the computer on a soft surface, doing so will block the bottom vents. •If you use an extension cord with this system, make sure that the total ampere rating on the products plugged into the extension cord does not exceed the extension cord ampere rating. Important Safety Information iii Care During Use • Do not walk on the power cord or allow anything to rest on it. •Do not spill anything on the system. The best way to avoid spills is to not eat or drink near your system. •Some products have a replaceable CMOS battery on the system board. There is a danger of explosion if the CMOS battery is replaced incorrectly. Replace the battery with the same or equivalent type recommended by the manufacturer. Dispose of batteries according to the manufacturer’s instructions. If the CMOS battery requires replacement insure that a qualified technician performs the task •When the computer is turned off, a small amount of electrical current still flows through the computer. To avoid electrical shock, always unplug all power cables, remove the battery and modem cables from the wall outlets before cleaning the system. •Unplug the system from the wall outlet and refer servicing to qualified personnel if: – The power cord or plug is damaged. – Liquid has been spilled into the system. – The system does not operate properly when the operating instructions are followed. – The system was dropped or the casing is damaged. – The system performance changes. Replacement Parts and Accessories Use only replacement parts and accessories recommended by manufacturer. To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line cord. Do not use this product in areas classified as hazardous. Such areas include patient care areas of medical and dental facilities, oxygen rich environments, or industrial areas. iv Users Manual Battery Disposal Do not put rechargeable batteries or products powered by non-removable rechargeable batteries in the garbage. Contact the Samsung Helpline for information on how to dispose of batteries that you cannot use or recharge any longer. Follow all local regulations when disposing of old batteries. Federal Communications Commission (FCC) v Federal Communications Commission (FCC) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generate uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions may cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is…
Text truncated - open the document above for the full version.
Using the Battery 35 Using the Battery Your computer uses a smart rechargeable Lithium-ion (Li-ion) battery pack for power when the AC adapter is not attached to an electrical outlet. The smart battery gives a accurate measurement of the current battery capacity which helps extend operating time by enabling effective power management in operating systems that take advantage of the accurate information supplied by the battery. Charging the Battery Your computer’s battery starts charging automatically when you connect the power to the computer and to an electrical outlet. If the computer is off, the battery charges faster than if the computer’s power is on. Approximate charging times for the Li-Ion battery are •3 hours with the computer off. •6 hours with the computer on. While the battery is charging normally, the battery charge light on the computer is red. When the battery is fully charged, the light changes to green. When you use a new battery pack for the first time or use a battery after a long period of storage, the initial battery life is shorter than normal. Normal battery life resumes after a few discharge-recharge cycles. Follow these rules for charging your battery: •A battery normally discharges power when not used for long periods of time. Be sure to recharge the battery every two months when it is not in use. •Make it a practice to discharge your battery fully before recharging the battery. This can help extend the life of the battery. •Do not attempt to charge the battery in temperatures of under 5 o C or over 35 o C All batteries eventually wear out and lose the ability to hold a charge. You may need to replace your battery pack after a year of average usage. 36 Users Manual Safely Using the Battery Follow these guidelines to safely use the battery: •Turn off your computer and unplug it if you accidentally: – Expose the equipment to liquid. – Drop, jar, or damage the computer. •Use only approved battery chargers. •Do not disassemble the battery, heat it above 100°C, or burn it. The battery used in this computer may cause a fire or chemical burn if mistreated. •Your computer's rechargeable battery may be considered hazardous waste. If you replace your battery with a new one: – Keep the old battery out of the reach of children. – Dispose of the old battery promptly. – Make sure that you follow all local requirements when you dispose of the old battery. Removing the Battery Your computer comes with the battery pack inserted in the computer. To remove the battery from the computer: 1.Turn the computer’s power off. 2.Close the LCD panel, and turn the computer over so that the bottom of the unit faces up. 3.Slide the battery compartment cover straight up and off the computer. 4.Grasp the tab on the battery and pull the battery out of the compartment. Using the Battery 37 Installing the Battery To install the battery pack: 1.With the computer’s power off, close the LCD panel and turn the computer over so the bottom of the unit faces up. 2.Slide the battery compartment cover straight up and off the computer. Insert the battery into the battery compartment, ensuring the correct orientation so that the battery fits in its slot properly. 3.Slide the battery pack into the compartment. Make sure the battery is fully inserted into the compartment. 4.Align the tabs on the battery compartment cover with the slots on the battery compartment. 5.Push the cover straight down until it snaps into place. Monitoring the Battery Charge Battery life is affected by factors such as the power-management settings in System Setup, the applications you use, and the brightness settings of the LCD. Under normal usage, the battery charge lasts approximately 3 hours. Battery life estimates are subject to variation. The actual life of your battery may be less than the estimates given in the manual. You can monitor the charge of the battery pack installed in your computer by using the Power Meter or Battery Gauge. 38 Users Manual Power Meter The Power Meter displays the charge of the batteries and the current source of computer power, AC or batteries. You may monitor the battery charge or usage by using the “Power Meter”. To access the power meter click icon on the task bar or click Start > Settings > Control Panel > Power Options > Power Meter Tab. You may also check battery charge by moving the cursor to the icon, a small dialog box will display the % of charge. Battery Gauge You may display the battery gauge while you are in any program by pressing <Fn+F6>. While the battery gauge is being displayed, all keys except <Esc> are disabled. The battery gauge is only displayed for a few seconds. Power Source: •Indicates that the computer is powered by the AC adapter. •Indicates that the computer is powered by the battery. Battery Level: •The top/right section indicates the approximate amount of the primary battery charge remaining. The Power Status icons shown below are displayed during Battery Charging Operations At ~15% and 10% remaining battery power the current power source and the battery Icons respectively change to the icon shown below and you should follow the instructions in “Battery Warnings” section below Using the Battery 39 Battery Warnings If the battery charge is low (about 10%) you have approximately 5–10 minutes of battery life left. You should: •Save your work and, •Connect the power cord to the computer or turn off the computer and install a fully charged battery. You can adjust the battery alarm features by using the operating systems power management program (Start > Settings > Control Panel > Power Options > Alarm Tab in Windows). If you cannot run your computer from the battery and the battery will not charge when you attach the power cord, the problem may be that: •The battery temperature is below 10°C or over 32°C. If you think the battery temperature is too hot or too cold, turn off the computer, remove the battery, and let the battery reach room temperature. Then try charging the batter…
Text truncated - open the document above for the full version.
SAMSUNG PG 11 Battery PSB-1.2V,133MHz MINIPCI 421 BGA Control ELECTRONICS FWH PROPRIETARY INFORMATION THAT IS Super I/O A PG 23 22Pin Connector Hitachi H8S Power DC/DC PG 29 (IMVP-II) PG 11 USB4 PG 24 CD-RW ANT D PG 33 B PG 17 EXCEPT AS AUTHORIZED BY SAMSUNG. RJ11 Hub Interface System 33MHz, 3.3V PCI PG 29 Audio 3 ES1988 SAMSUNG PROPRIETARY SwapBay ANT IDE ATA 33, 66/100 OZ165 KBD 4 USB0 Phone-Jack 133MHz SAMSUNG ELECTRONICS CO’S PROPERTY. PG 24,40 PG 22 PG 30 PG 29 PG 16 THIS DOCUMENT CONTAINS CONFIDENTIAL PG 28 1 CARINA 13.3" B SODIMM 0 Module Sensor PG 17 PG 21 PCI1420 MIC,Line-in,HP-out Clocking Charging Circuit CARDBUS Connector PG 19 USB1 625 BGA Mouse,KBD Mobile Tualatin PAD PG 4 CPU PG 7 LAN Thermal PG 28 2169 Almador-M RJ45 PG 25 PG 40 Scan CD/DVD ICH3-M 30Pin Connector C PG 29 A PG 26 PG 8,9,10 FAN HDD 14.1" Selector PG 5,6 SODIMM 1 3.3V LPC, 33MHz PG 11 PG 15 PG 7 Harness VID PG 33 PG 14 LCD PG 12,13,14 SDRAM 3.3V, 1.8V, 66MHz Damping Floppy BUS ACLink Modem Parallel DVO A Video 40Pin Connector DVD-Combo PG 29 33MHz, 3.3V PCI (Micro-FCBGA) Module 1 PG 20 4 FDD PG 31,32 PG 41 3 Wireless LAN Touch DC/DC CPU D PG 35 2 PS/2 Kinnereth 2 CRT C Hub SMC/KBC or Coppermine-T CK TITAN USB CPU PG 20 Serial GMCH-M PC87393 MC97 Smart DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS
Page 16 of 17 Project No. : SE-02-0059 5. FCC Label Configuration and Location 5.1 Label Configulation 5.2 Location of Label This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory.
Page 1 of 17 Project No. : SE-02-0059 Product :Notebook PC Model No. :Transport VN FCC ID : A3LSV10 1. This test reports shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 2. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 3. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. Date of test :January 18, 2002 Issued Date :January 21, 2002 Tested by: Il Kwon, BAE / Test Engineer Reviewed by: Yang Soo, KIM / Manager of EMC Lab. Authorised by: Kyu Baek, CHUNG / Chief of EMC Lab. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. EMI TEST REPORT According to FCC Part 15 Subpart B/Class B NVLAP Code: 200447 Page 2 of 17 Project No. : SE-02-0059 Table of Contents 1. General Information 1.1 Product Description 1.2 Configuration of EUT and peripherals 1.3 Used Cable Description 1.4 System Block Diagram of Test Configuration 1.5 Test Facility 2. System Test Configuration 2.1 Configuration of Radiated and Conducted Interference Measurement 2.2 Operation Environment 2.3 Test Procedure 3. Conducted Emission Test Data 4. Radiated Emission Test Data 5. Label Configuration and Location 6. Test Equipment Used Distribution This test report has been made available as follows: CS Management Center, EMC Laboratory1 original Computer Division1 copy This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 3 of 17 Project No. : SE-02-0059 1. General Information Applicant :Samsung Electronics Co., Ltd. CS Management Center EMC Test Laboratory Tel.: +81-(0)31-200-2135 Fax.: +81-(0)31-200-2189 Full Address :416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 Kind of Product :Notebook PC FCC ID:A3LSV10 Project Name :Carina Model & Variant Names :Transport VN(Brand Name: Micronpc) Test Report Produced by :Il Kwon, BAE / Test Engineer This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 4 of 17 Project No. : SE-02-0059 1.1 Product Description 1) Justification The system was configured for testing in typical fashion use. Cable were attached to each of the available I/O Ports. Where applicable, peripherals were attached to the I/O cables. The mode of operation utilized for testing was selected to best simulate typical EUT use. The system was pre-tested using the below additional components, and we found worst emission level for the components, were selected as the final components for the test. - Samsung, SN-124Q, CDI001369 - Teac, CD-232E, CDI001375 - Matsushita, UJDA-330A, CDI001372 - Toshiba, SD-C2502, DVD001144 - Toshiba, SD-R2102, CDI001370 In each test mode, Finally we found worst case emission that is the Worst Case components (in the above table). So, the DATA of the maximum(worst case) EUT operation was reported. Further details of cabling and configuration are shown in the test system configuration. This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. ComponentBrand and Model NameRemark FDD - Teac, FD-05HG-7765, FDD001246Worst Case CD-ROM CD-RW DVD CD-ROM DVD_CDRW_ComboWorst Case Page 5 of 17 Project No. : SE-02-0059 2) Operating Frequency : 1266MHz(CPU Speed), 133MHz(Host Clock), 133MHz(SDRAM Clock), 33.3MHz(PCI Clock), 14.318MHz(Ref. OSC), 49.152MHz(Audio Clock), 25M(Network) 12.288MHz(Audio Bit Clock), 24.576MHz(Audio C24), 66.6MHz(VCH/ICH Clock) 10MHz(Micom Clock), 48MHz(USB Clock), 65MHz(LCD Clock), 66.6(Hub) 3) Description of Testing operating mode LCD Screen LCD Monitor Hard disk drive & DVD-CDRW drive LPT1 to Printer Media Player Playing through Video CD in Network Server Audio out to Head Set 4) Tested Resolution : 1024 X 76860Hz32bits 1024 X 76860Hz32bits This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Refresh ratesColors LCD(14.1") Ext. Monitor Tested Video modeResolutions Network Audio Output Operating Mode Operating section of EUT "H" Pattern display & Read / Write Page 6 of 17 Project No. : SE-02-0059 5) Assemble Parts ItemSpecificationRemark CPUIntel Pentium-III 1266MHzPSB 133 uFCPGA2, Cache 512KB Main MemorySEC, PC133, 512MB (256MB x 2EA)M464S3254 x 2EA (RAM)Max. 1GB (512MB x 2EA)M464S6453 x 2EA Video ControllerIGD(Internal Graphics Device) in GMCH-M 16MB, 400MHz DRDRAM Graphics MemorySupport Composite Video out Video DisplaySEC, LCD 14.1" TFT, LTN141XU-L02 Upto 1024x768 Pixels; 18-bit colors Swap BayToshiba DVD_CDRW COMBO Drive SD-R2102, 8x(CDR),8x(CD-RW), 8x (DVD),24x(CD) FDDTeac, FD-05HG-7765, 3.5", 1.44MB HDDToshiba 30GB , MK3017GAPUser-removable ; 2.5", 9.5mmH LAN10/100 Base-T Ethernet support ModemSEC, SEM-2400iC, V.90 compliant / V92 ready , 56KbpsAC-Link (Conexant SmartMCII) Wireless LANAgere, MPCI3A-20, Mini-PCI Type IIIAIEEE 802.11b(11MBPS), Mini PCI Input DevicesKeyboard, 19mm pitch, 2.5mmH travel length Pointing Device, PS/2 Touchpad w/ 4 buttonSynaptics TM41P-351 BatteryToshiba, Removable 8-cell Li-Ion Smart, 58.46Wh AC AdapterSEC, 60-Watts, AC 100~240V FREE-VOLTAGEAD-6019 Ports2 USB, SIO, PIO, PS/2, RJ-11, RJ-45, DC IN, EXT. MONITOR, MIC-IN, LINE-IN,HEADPHONE- OUT, Card bus slot. Etc This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 7 of 17 Project No. : SE-02-0059 1.2 Configuration of EUT and peripherals MarkItemModel No.Serial No.ManufacturerFCC ID ANotebook PCTransport VN-SamsungA3LSV10 BExternal MonitorTFT7010147CK23DA274COMPAQDoc CPrinter LQ-580HCG2Y014504EPSON Doc DUSB MouseM-U48aLZC11304011LOGITECHJNZ211360 EUSB MouseM-U48aLZE12702570LOGITECH…
Text truncated - open the document above for the full version.
Page 10 of 17 Project No. : SE-02-0059 2. System Test Configuration 2.1 Configuration of Radiated and Conducted Interference Measurement * Cabling was taken into consideration and test data was taken under worse case conditions. 1)Conduction(Front View) 2)Conduction(Rear View) This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Page 11 of 17 Project No. : SE-02-0059 3) Radiation(Front View) 4) Radiation(Rear View) This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory.
