A49PC-60NWFingertip Oximeter

User Manual for Fingertip Oximeter I Instructions to User Dear Users, Thank you very much for purchasing our product. Please read the manual very carefully before using this device. Failure to follow these instructions can cause measuring abnormality or damage to the oximeter. The manual is published in English and we have the ultimate right to explain the Manual. No part of this manual may be photocopied, reproduced or translated into another language without the prior written consent. We reserve the right to improve and amend it at any time without prior notice. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Version of the Manual: Ve r 1 . 0 Revised date: November 1, 2011 All rights reserved. 3502-2290047 User Manual for Fingertip Oximeter II Warnings 0 Check the device to make sure that there is no visible damage that may affect user’s safety or measurement performance with regard to sensors and clips. It is recommended that the device should be inspected minimally once a week. When there is obvious damage, stop using the device. 0 Special attention should be paid while the oximeter is used continuously under the ambient temperature exceeds 37°, burning hurt may occur because of over-heating on the sensor. 0 An uncomfortable or painful feeling may appear if using the oximeter continuously on the same place for a long time, especially for poor microcirculation patients. 0 It is recommended that the oximeter should not be applied to the same location for longer than 2 hours. If any abnormal condition is found, please change the position of oximeter. 0 Avoid placing the device on the same limb which is wrapped with a cuff for blood pressure measurement or during venous infusion. User Manual for Fingertip Oximeter III 0 DO NOT clip this device on edema or tender tissue. 0 The light (the infrared light is invisible) emitted from the device is harmful to the eyes, so service technician or testee should not stare at the light. 0 The oximeter is not a treatment device. 0 When disposing of the monitor and its accessories, the local law should be followed. Instructions for Operation y The finger should be put in properly and correctly. y Do not shake the finger. Keep at ease during measurement. y Do not put wet finger directly into sensor. y Avoid placing the device on the same limb which is wrapped with a cuff for blood pressure measurement or during venous infusion. y Do not let anything block the emitting light from device. y Vigorous exercise and electrosurgical device interference may affect the measuring accuracy. y The orientation-sensor works on the basis of the gravity. A small movable metal ball is built in the orientation-sensor for detecting the orientation of User Manual for Fingertip Oximeter IV the oximeter. When you want to change the oximeter’s display direction, if you move the oximeter too slowly, the movable metal ball will also move slowly because of not enough acceleration. Consequently the response of orientation detection would be delayed. Please move the oximeter with a bit of force if you want to change the display direction (such as bend/extend your finger quickly), so an acceleration is provided to the orientation-sensor for quick sensing the orientation change. y Using enamel or other makeup on the nail may affect the accuracy of measurement, too long fingernail may casue failure of measurement or unaccuracy measurement result. y Keep the oximeter away from dust, vibration, corrosive substances, explosive materials, high temperature and moisture. y Existence of high intensive light sources, such as fluorescence light, ruby lamb, infrared heater or strong sunshire, etc. may cause unaccuracy of measurement result. Please put an opaque cover on the sensor or change the measuring site. y If the first reading appears with poor waveform (irregular or not smooth), then the reading is User Manual for Fingertip Oximeter V unlikely true, the more stable value is expected by waiting for a while, or a restart is needed when necessary. Note: Due to the working principle of orientation sensor used in oximeter, there is a small metal ball which is movable within its compartment of the orientation-sensor. Therefore you can hear a slight “clatter” sound when you wave or shake the oximeter. It is normal and not caused by unwanted part. User Manual for Fingertip Oximeter VI Content 1 Overview ....................................................................... 1 1.1 Appearance............................................................. 1 1.2 Name and Model.................................................... 2 1.3 Intended Use........................................................... 2 1.4 Structure and Conformation................................ 2 1.5 Features.................................................................. 2 2 Battery Installation ...................................................... 3 3 Operation ...................................................................... 4 3.1 Directly measurement........................................... 4 3.2 Alarm and alarm silence....................................... 7 3.3 Menu Screen........................................................... 8 3.4 External SpO 2 Probe Connection...................... 10 3.5 Data transmission.................................................11 4. Technical Specifications............................................ 12 5. Accessories ................................................................. 15 6. Repair and Maintenance .......................................... 15 User Manual for Fingertip Oximeter VII 6.1 Oximeter Maintenance........................................ 15 6.2 Battery Maintenance........................................... 17 6.3 Cleaning and Disin…

Text truncated - open the document above for the full version.

Shenzhen Creative Industry Co., Ltd AGENCY AUTHORIZATION LETTER FCC ID: A49PC-60NW Date: Dec.01,2011 To whom it may concern: We, the undersigned, hereby authorize Shenzhen Huatongwei International Co.,Ltd of China to act on our behalf, as our agent in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification, Any act carried out by Shenzhen Huatongwei International Co.,Ltd. within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely, (签名人英文名): Zhu Wangui (签名人职称): Quality management department manager Shenzhen Creative Industry Co., Ltd. Tel: 0755-26433325 Fax: 0755-26435433 We b s i t e : www.creative-sz.com E-mail: [email protected]

Shenzhen Creative Industry Co., Ltd Federal Communications Commission Authorization and Evaluation Division Date:2011-12-01 Confidentiality Request regarding application for certification of FCC ID: A49PC-60NW Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1.Schematic 2.Theory of Operation 3.Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely, (签名人英文名): Zhu Wangui (签名人职称): Quality management department manager Shenzhen Creative Industry Co., Ltd. Tel: 0755-26433325 Fax: 0755-26435433 Web site: www.creative-sz.com E-mail: [email protected]

FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No......................: FCC ID............................................. : TRE11110036 A49PC-60NW Compiled by ( position+printed name+signature)..: File administrators Eric Zhang Supervised by ( position+printed name+signature)..: Test Engineer Tim Zhang Approved by ( position+printed name+signature)..: Manager Wenliang Li Date of issue.....................................: Dec 01, 2011 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: Shenzhen Creative Industry Co., Ltd. Address ............................................: 2/F, Block 3, Nanyou Tian' an Industry Town, 518054 Shenzhen, GD, PEOPLE’ S REPUBLIC OF CHINA. Test specification: Standard ...........................................: FCC Part 15.247: Operation within the bands 920-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz Direct Sequence System TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Fingertip Oximeter Trade Mark .......................................: / Model/Type reference.......................: PC-60NW , Prince-100NW Listed Models ..................................: / Result................................................: Positive V1.0 Page 2 of 56 Report No.: TRE11110036 T E S T R E P O R T Test Report No. : TRE11110036 Dec 01, 2011 ______________________________________________________________________________________________ Date of issue Equipment under Test : Fingertip Oximeter Model /Type : PC-60NW , Prince-100NW Listed Models : / Applicant : Shenzhen Creative Industry Co., Ltd. Address : 2/F, Block 3, Nanyou Tian' an Industry Town, 518054 Shenzhen, GD, PEOPLE’ S REPUBLIC OF CHINA. Manufacturer : Shenzhen Creative Industry Co., Ltd. Address : 2/F, Block 3, Nanyou Tian' an Industry Town, 518054 Shenzhen, GD, PEOPLE’ S REPUBLIC OF CHINA. Test Result according to the standards on page 7: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 56 Report No.: TRE11110036 Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 6 2.6. Configuration of Test System 6 2.7. Related Submittal(s) / Grant (s) 7 2.8. Modifications 7 2.9. NOTE 7 3. TEST ENVIRONMENT............................................................... 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 9 3.4. Statement of the measurement uncertainty 9 3.5. Test Description 10 3.6. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS ............................................ 11 4.1. AC Power Conducted Emission 11 4.2. Radiated Emission 12 4.3. Maximum Peak Output Power 22 4.4. 20dB Bandwidth 26 4.5. Band Edge 30 4.6. Frequency Separation 33 4.7. Number of hopping frequency 37 4.8. Time Of Occupancy(Dwell Time) 39 4.9. Antenna Requirement 50 5. TEST SETUP PHOTOS OF THE EUT .......................................... 51 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 53 V1.0 Page 4 of 56 Report No.: TRE11110036 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2009 : American National Standard for Testing Unlicensed Wireless Devices V1.0 Page 5 of 56 Report No.: TRE11110036 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Oct 30, 2011 Testing commenced on : Nov 23, 2011 Testing concluded on : Dec 01, 2011 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 3.0V from battery 2.3. Short description of the Equipment under Test (EUT) 2.4GHz (Fingertip Oximeter (PC-60NW , Prince-100NW)) For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. There are EDR (Enhanced Data Rate) and BDR (Basic Data Rate)mode.The Applicant provides communication tools software to control the EUT for staying in continous transmitting and receiving mode for testing. There are 79 channels of EUT, and the test carried out at the lowest channel, middle channel and highest channel . Frequency Range: 2400-2483.5MHz Channel number: 79 channels Modulation type: Frequency Hopping Spread Spectrum Antenna: PCB Antenna V1.0 Page 6 of 56 Report No.: TRE11110036 2.5. EUT configuration EUT Exercise Software The Applicant provides communication tools software. Local Support Equipment List and Details Manufacture r Description Model Serial Number FCC ID Dell PC 5300 N/A N/A External I/O Cable Cable Description Length (m) From/Port To…
