A4C-10015AGPS Device

QUICK START GUIDE Support randmcnally.com/support 877-446-4863 OVERDRYVEPRO_II_QSG_101920_v001 1OverDryve ™ Pro II Quick Start Guide Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage; (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This equipment should be installed and operated with a minimum distance of 0mm between the radiator and your body. Cet équipement devrait être installé et actionné avec une distance minimum de 0mm entre le radiateur et votre corps. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne ou émetteur. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This device complies with FCC SAR exposure limits set forth for an uncontrolled environment. SAR compliance for using the equipment in close proximity to the human body has been evaluated at 0mm. This equipment must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and consider removing the no-collocation statement. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Canada Statement This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. 23OverDryve ™ Pro II Quick Start GuideOverDryve ™ Pro II Quick Start Guide Your OverDryve ™ Pro II Unit Caution: Important Safety Information Navigation •Use this device at your own risk. •Attend to this device only when it is safe to do so. •Traffic laws and regulations always have priority over any instructions from the navigation system. NOTE: If you do not understand the spoken instructions or are unsure of what to do, refer to the navigation map on your device. Installation •Make sure that the mount is securely mounted and properly adjusted before each trip. •Make sure that the mount does not impair the driver’s visibility. •Do not attach the mount within the airbag deployment zone. •Install the mount in a manner that minimizes risk in the event of an accident. •After installation, check all safety-related equipment to ensure that it operates without interference from the device, its cables, or any other accessories. •Connect the wall charger to a 120-volt or 240-volt outlet only. •Connect the vehicle charger to a 12-volt outlet only. Device •Do not use sharp-edged objects on the device touch screen. •The device is not waterproof and is not protected against water damage. •Protect the device from extreme temperatures. Operating temperature for the device is between 32 degrees F and 120 degrees F. •Do not open the device casing. •Do not attempt to replace the battery. Contact Rand McNally Customer Support with questions about the battery. •Always follow local regulations when disposing of this device. NOTE: Make sure that there are no kinks in the cable and that it will not be damaged by any sharp objects. NOTE: Use only a moist cloth to clean the device. NOTE: Do not pull the cable to unplug the unit. Your OverDryve ™ Pro II Box Contents •OverDryve ™ Pro II Unit •Smart mount with SiriusXM ® •Bracket with suction cup •Truck charger •USB cable and wall charger •Dash mount disc •FM transmitter antenna •AUX cable •Anti-glare screen protector •SiriusXM ® magnetic mount antenna •Alcohol prep pad 45OverDryve ™ Pro II Quick Start GuideOverDryve ™ Pro II Quick Start Guide Home Volume DownUp Power Your OverDryve ™ Pro IIInstall the Mount NOTE: Follow all local laws and regulations governing the placement of the mount. 1.Select an area with a line of sight to the sky and GPS satellites. 2.Clean and dry the mounting area. 3.Remove the suction cup protective film. 4.Attach the two pieces of the mount together and lock into place. 5.Adjust the angle of the mount. 6.Pull the suction cup lever up to release suction. 7.Plug the power cord into the mount and the vehicle’s 12-volt power source. 8.Place and hold the mount suction cup against the mounting surface. 9.Press the suction cup lever down until it snaps into…

Text truncated - open the document above for the full version.

RM ACQUISITION LLC Agent Authorization Letter 2020-11-12 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen Huaxia Testing Technology Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Grace Chang Position: CFO Company Name: RM Acquisition LLC Address: 9855 Woods Drive Skokie. IL 60077 U.S.A Tel / Fax 8473296587 / 847-329-6414 E-Mail: [email protected]

RM Acquisition LLC Long Term Confidentiality Request Letter 2020-11-12 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (FCC ID: A4C-10015A) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - e.g. Block diagram - e.g. SCH - e.g. Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that could never get into the possession of your competition. Please contact me if there is any information you may need. Sincerely, Name: Grace Chang Position: CFO Company Name: RM Acquisition LLC Address: 9855 Woods Drive Skokie. IL 60077 U.S.A Tel / Fax 8473296587 / 847-329-6414 E-Mail: [email protected]

Test model No.:OD7Pro2

Test model No.:OD7Pro2

The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. FCC 47 CFR PART 15 SUBPART C TEST REPORT For Applicant : RM ACQUISITION LLC Address : 9855 Woods Drive Skokie. IL 60077 U.S.A Product Name : GPS Device Model Name : OD7Pro2 Brand Name : FCC ID : A4C-10015A Report No. : CQASZ20201001234E-03 Date of Issue : 2020-11-02 Issued by : Shenzhen Huaxia Testing Technology Co., Ltd Address : 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Tel : +86-755-26648640 Fax : +86-755-26648637 Page 2 of 19 TABLE OF CONTENTS 1．VERIFICATION OF CONFORMITY ........................................................................................ 3 2. GENERAL INFORMATION ....................................................................................................... 4 2.1 Product Information ................................................................................................................ 4 2.2 Objective ................................................................................................................................ 5 2.3 Test Standards and Results .................................................................................................... 5 2.4 Environmental Conditions ....................................................................................................... 5 3. TEST METHODOLOGY ........................................................................................................... 6 3.1 TEST FACILITY ...................................................................................................................... 6 3.2 GENERAL TEST PROCEDURES .......................................................................................... 6 4 SETUP OF EQUIPMENT UNDER TEST .................................................................................. 7 4.1 SETUP CONFIGURATION OF EUT ....................................................................................... 7 4.2 SUPPORT EQUIPMENT ........................................................................................................ 7 4.3 Statement of the measurement uncertainty ............................................................................ 8 4.4 TEST EQUIPMENT LIST ........................................................................................................ 9 5.1.1 Definition ........................................................................................................................... 10 5.1.2 Test Configuration ............................................................................................................... 11 5.1.3 Test Data ........................................................................................................................... 12 5.2 20dB Bandwidth ................................................................................................................... 16 5.2.1 MEASUREMENT PROCEDURE ....................................................................................... 16 5.3.2 Test Description ................................................................................................................. 16 5.2.3 Test Result ..................................................................................................................... 16 5.3 Antenna Requirement ........................................................................................................... 19 5.3.1 Definition ........................................................................................................................... 19 5.3.2 Evaluation Criteria ............................................................................................................. 19 5.3.3 Evaluation Results ............................................................................................................. 19 Page 3 of 19 1．VERIFICATION OF CONFORMITY Equipment Under Test: GPS Device Brand Name: Model Number: OD7Pro2 FCC ID： A4C-10015A Applicant: RM ACQUISITION LLC Manufacturer: SHEN ZHEN APICAL TECHNOLOGY CO., LTD Technical Standards: 47 CFR Part 15 Subpart C File Number: CQASZ20201001234E-03 Date of test: 2020-10-26 to 2020-11-02 Deviation: None Condition of Test Sample: Normal Test Result: PASS The above equipment was tested by Huaxia. for compliance with the requirements set forth in FCC rules and the Technical Standards mentioned above. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment and the level of the immunity endurance of the equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Tested by (+ signature): ( Martin Lee ) Review by (+ signature): ( Sheek Luo ) Approved by (+ signature): ( Jack Ai ) Page 4 of 19 2. GENERAL INFORMATION 2.1 Product Information Product GPS Device Brand Name Model Number OD7Pro2 Series Model Name: N/A Difference description: N/A Power Supply lithium battery:DC3.7V, Charge by car charger(DC5V) Frequency Range 88.1MHz – 107.9MHz Antenna Type: External antenna Antenna Gain: 0dbi Channel Number: 199CH Channel Separation: 100 kHz Modulation Technique FM Temperature Range -20°C- 50°C NOTE: 1. For a more detailed features description about the EUT, please refer to User’s Manual. Page 5 of 19 2.2 Objective Perform FCC Part 15 Subpart C tests for FCC Marking. 2.3 Test Standards and Results Test items and the results are as bellow: No. Section Description Result Date of Test 1 §15.239 (b) (c)/ §15.209 Spurious emissions PASS 2020/10/30 2 §15.215 (c)/ §15.239(a) Occupied Bandwidth PASS 2020/10/30 3 §15.239 (b) Field strength of the fundamental signal PASS 2020/10/30 4 §15.203 Antenna Requirement PASS 2020/10…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup 1.1 Radiated Emission 9kHz~30MHz: 30MHz~1GHz: Above 1GHz:
