A4C-10018AGPS Device
RM Acquisition LLC.
Click to zoom
Application Details
- Equipment Class
- NII - Unlicensed National Information Infrastructure TX
- Date of Grant
- Dec 17, 2025
- Application Purpose
- Original Equipment
- Equipment Note
- GPS Device
- Frequency Range
- 5180.00000000 - 5240.00000000
- Company
- RM Acquisition LLC.
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
User Manual Rand Tablet User Manual i FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and may cause harmful interference to radio communications if not installed and used in accordance with the instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet that is on a different circuit from the GPS unit. • Consult the dealer or an experienced radio/TV technician for help. When using the device, ensure that the antenna of the device is at least 20 cm away from all persons. IC Compliance Statement This device complies with Part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. IC Caution Intentional or unintentional changes or modifications to the equipment not expressly approved by Rand McNally could void the user’s authority to operate the equipment. IC attestation de conformité Ce dispositif est conforme à la norme FCC Partie 15 et aux norme(s) RSS permis-exempte(s) d’Industrie Canada. L’opération est soumise aux deux conditions suivantes: 1. Ce dispositif ne peut pas provoquer d’interférence nocive et 2. Ce dispositif doit accepter toute interference reçue, y compris les interférences qui peuvent causer un mauvais fonctionnement du dispositif. Cet appareil numérique de la classe B est conforme à la norme NMB- 003 du Canada. Attention Les changements ou modifications à l’équipement, que ce soient intentionnelles ou non, non expressément approuvés par Rand McNally pourraient annuler l’autorisation de l’utilisateur à utiliser cet équipement. IC: 10199A-10011A Rand Tablet User Manual ii About GPS The Global Positioning System (GPS) is a constellation of satellites that a GPS receiver uses to calculate geographical positions. To determine a position, data from at least three satellites is required. To determine elevation, the data from four or more satellites is required. Accuracy of the positioning varies from 10 feet to several hundred feet, depending on vehicle placement and the surrounding environment. Geographical terrain (such as mountains), man-made structures (such as highway overpasses, bridges, and tall buildings), as well as weather can interfere with the GPS signal. For best GPS reception, position the device and mount with a clear line of sight to the sky. Some vehicles may have a limited view of the sky due to metal sun shields or a metallized windshield coating. Map data includes the geographical coordinates for address locations and points of interest (POIs). With GPS reception, your device calculates a route to your selected location. Customer Support Call toll-free: 877-446-4863 Service hours: Monday through Friday, 7 a.m. to 6 p.m. CT (Except official holidays) Email: [email protected] Rand Tablet User Manual iii Table of Contents Note: Some screens may appear slightly different depending on device model and software version. 1. Your Device..............................................................................1 What’s Included ........................................................................................2 Mounting the Rand Tablet ......................................................................3 Rand Tablet Hardware .............................................................................4 2. Getting Started ........................................................................5 Connecting to Wi-Fi .................................................................................5 Registration ................................................................................................5 Android User Interface ............................................................................6 Main Menu .................................................................................................7 Rand Tablet Settings ................................................................................8 Android Settings .......................................................................................9 3. Rand Navigation 2.0 ..............................................................10 Rand Navigation .....................................................................................10 Navigation Settings ................................................................................11 Destination Search .................................................................................15 Single-line Search ...................................................................................16 Guided Search .........................................................................................17 Guided Search: New Location Menu ..................................................18 Guided Search: Entering a New Location ............................…
Text truncated - open the document above for the full version.
Test Report
ReportNo.:MTEB25070274-R2Page 62 of 111 IEEE802.11n_Channel38_40MHz_Antenna0IEEE802.11n_Channel46_40MHz_Antenna0 IEEE802.11n_Channel54_40MHz_Antenna0IEEE802.11n_Channel62_40MHz_Antenna0 IEEE802.11n_Channel102_40MHz_Antenna0IEEE802.11n_Channel118_40MHz_Antenna0 IEEE802.11n_Channel134_40MHz_Antenna0IEEE802.11ac_Channel36_20MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 63 of 111 IEEE802.11ac_Channel40_20MHz_Antenna0IEEE802.11ac_Channel48_20MHz_Antenna0 IEEE802.11ac_Channel52_20MHz_Antenna0IEEE802.11ac_Channel56_20MHz_Antenna0 IEEE802.11ac_Channel64_20MHz_Antenna0IEEE802.11ac_Channel100_20MHz_Antenna0 IEEE802.11ac_Channel120_20MHz_Antenna0IEEE802.11ac_Channel140_20MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 64 of 111 IEEE802.11ac_Channel38_40MHz_Antenna0IEEE802.11ac_Channel46_40MHz_Antenna0 IEEE802.11ac_Channel54_40MHz_Antenna0IEEE802.11ac_Channel62_40MHz_Antenna0 IEEE802.11ac_Channel102_40MHz_Antenna0IEEE802.11ac_Channel118_40MHz_Antenna0 IEEE802.11ac_Channel134_40MHz_Antenna0IEEE802.11ac_Channel42_80MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 65 of 111 IEEE802.11ac_Channel58_80MHz_Antenna0IEEE802.11ac_Channel106_80MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 66 of 111 APPENDIXVI.ConductedOutOfBandEmission TestResult ModeChannelAnt. OOB Emission Frequency (MHz) OOB Emission Level (dBm) Limit (dBm) OverLimit (dB) Result IEEE802.11a 36 0 2450.48-32.609-27-5.610PASS 5148.96-37.361-27-10.000PASS 5150.00-38.577-27-12.000PASS 5350.00-37.500-27-10.000PASS 5460.00-37.045-27-10.000PASS 24965.6-39.924-27-12.920PASS 40 2468.27-44.548-27-17.550PASS 5149.92-37.741-27-11.000PASS 5150.00-37.741-27-11.000PASS 5350.00-35.941-27-9.000PASS 5457.12-35.287-27-8.000PASS 24990.2-39.218-27-12.220PASS 48 2472.24-34.210-27-7.210PASS 5149.92-37.377-27-10.000PASS 5150.00-37.377-27-10.000PASS 5350.00-37.007-27-10.000PASS 5460.00-36.675-27-10.000PASS 24902.2-38.679-27-11.680PASS 52 2413.49-42.836-27-15.840PASS 5148.00-36.909-27-10.000PASS 5150.00-36.927-27-10.000PASS 5350.00-36.691-27-10.000PASS 5458.08-36.061-27-9.000PASS 24913.0-38.925-27-11.920PASS 56 2476.46-43.052-27-16.050PASS 5119.20-35.376-27-8.000PASS 5150.00-35.795-27-9.000PASS 5350.00-35.767-27-9.000PASS 5447.52-35.089-27-8.000PASS 24916.5-39.162-27-12.160PASS 64 37.04-51.014-27-24.010PASS 5148.00-36.599-27-10.000PASS 5150.00-37.369-27-10.000PASS 5350.00-35.533-27-9.000PASS 5454.24-34.423-27-7.000PASS 24970.5-38.696-27-11.700PASS 100 5468.23-30.430-27-3.000PASS 5468.91-35.285-27-8.280PASS 5470.00-32.599-27-6.000PASS 5725.00-36.901-27-10.000PASS 6222.49-36.787-27-10.000PASS 24973.0-39.445-27-12.450PASS 120 40.06-36.920-27-9.920PASS 5468.23-37.338-27-10.000PASS 5470.00-37.695-27-11.000PASS 5725.00-36.248-27-9.000PASS 6211.19-36.222-27-9.000PASS 24952.8-38.977-27-11.980PASS 140 40.06-34.983-27-7.980PASS 5468.23-37.120-27-10.000PASS 5470.00-37.124-27-10.000PASS 5725.00-32.069-27-5.000PASS 5725.51-32.069-27-5.000PASS 5731.75-32.592-27-5.590PASS IEEE 802.11n_20 36 5146.42-35.201-27-8.200PASS 5149.92-37.171-27-10.000PASS 5150.00-37.171-27-10.000PASS 5350.00-34.531-27-8.000PASS 5449.44-34.531-27-8.000PASS 24947.4-39.289-27-12.290PASS ReportNo.:MTEB25070274-R2Page 67 of 111 40 2478.64-42.910-27-15.910PASS 5135.52-35.673-27-9.000PASS 5150.00-36.030-27-9.000PASS 5350.00-36.421-27-9.000PASS 5455.20-36.319-27-9.000PASS 24952.8-40.068-27-13.070PASS 48 2451.25-40.427-27-13.430PASS 5148.96-37.855-27-11.000PASS 5150.00-38.919-27-12.000PASS 5350.00-36.418-27-9.000PASS 5460.00-35.411-27-8.000PASS 24929.3-39.527-27-12.530PASS 52 892.98-44.066-27-17.070PASS 5143.20-36.698-27-10.000PASS 5150.00-37.071-27-10.000PASS 5350.00-35.750-27-9.000PASS 5457.12-35.644-27-9.000PASS 24988.7-40.111-27-13.110PASS 56 2477.23-45.481-27-18.480PASS 5148.96-37.226-27-10.000PASS 5150.00-37.948-27-11.000PASS 5350.00-36.340-27-9.000PASS 5455.20-35.734-27-9.000PASS 24944.5-38.480-27-11.480PASS 64 5149.92-37.859-27-11.000PASS 5150.00-37.859-27-11.000PASS 5150.00-49.339-27-22.340PASS 5350.00-36.954-27-10.000PASS 5460.00-34.798-27-8.000PASS 24969.5-39.794-27-12.790PASS 100 5468.10-31.584-27-4.580PASS 5469.49-32.355-27-5.000PASS 5470.00-32.355-27-5.000PASS 5725.00-37.205-27-10.000PASS 6217.47-37.074-27-10.000PASS 24896.4-39.861-27-12.860PASS 120 39.66-37.122-27-10.120PASS 5468.23-37.535-27-11.000PASS 5470.00-37.638-27-11.000PASS 5725.00-37.420-27-10.000PASS 6225.00-37.256-27-10.000PASS 24917.1-40.302-27-13.300PASS 140 37.48-39.960-27-12.960PASS 5469.49-36.557-27-10.000PASS 5470.00-36.557-27-10.000PASS 5725.00-32.293-27-5.000PASS 5726.77-30.932-27-4.000PASS 5727.89-34.210-27-7.210PASS IEEE 802.11n_40 38 5146.54-27.712-27-0.710PASS 5148.96-37.480-27-10.000PASS 5150.00-38.580-27-12.000PASS 5350.00-37.396-27-10.000PASS 5459.04-36.889-27-10.000PASS 24972.5-38.974-27-11.970PASS 46 2442.42-42.020-27-15.020PASS 5149.92-36.831-27-10.000PASS 5150.00-36.831-27-10.000PASS 5350.00-37.110-27-10.000PASS 5460.00-36.053-27-9.000PASS 24960.7-39.933-27-12.930PASS 54 2430.38-37.289-27-10.290PASS 5149.92-37.866-27-11.000PASS 5150.00-37.866-27-11.000PASS 5350.00-36.364-27-9.000PASS 5460.00-36.261-27-9.000PASS 24933.7-39.749-27-12.750PASS 62 896.82-33.911-27-6.910PASS 5148.96-36.746-27-10.000PASS ReportNo.:MTEB25070274-R2Page 68 of 111 5150.00-38.177-27-11.000PASS 5350.00-36.562-27-10.000PASS 5354.91-33.650-27-6.650PASS 5460.00-36.283-27-9.000PASS 102 5467.28-35.189-27-8.190PASS 5469.49-36.702-27-10.000PASS 5470.00-36.702-27-10.000PASS 5725.00-36.036-27-9.000PASS 6179.82-35.958-27-9.000PASS 24876.2-40.585-27-13.590PASS 118 35.98-42.898-27-15.900PASS 5469.49-38.010-27-11.000PASS 5470.00-38.010-27-11.000PASS 5725.00-37.464-27-10.000PASS 6223.74-36.860-27-10.000PASS 24969.6-40.147-27-13.150PASS 134 39.79-43.539-27-16.540PASS 5469.49-36.163-27-9.000PASS 5470.00-36.163-27-9.000PASS 5725.00-33.081-27-6.000PASS 5727.41-32.712-27-5.710PASS 5729.27-32.891-27-6.000PASS IEEE 802.11ac_20 36 5144.62-42.370-27-15.370PASS 5148.96-36.640-27-10.000PASS 5150.00-37.933-27-11.000PASS 5350.00-37.130-27-10.000PASS 5460.00-36.532-27-10.000PASS 24903.7-39.487-2…
Text truncated - open the document above for the full version.
Test Setup Photos
ModelNo.:RandTab7N CETESTSETUP RETESTSETUP ModelNo.:RandTab7N RETESTSETUP
Test Report
Product OC: Y4SCV0MA0CA Version: 1.0 Date: 2025-07-24 Status: Preliminary Product Name: Wi-Fi Adhesive Mount FPC Monopole Antenna Key Features: Frequency Band: 2400–2500 MHz, 5150–5850 MHz Dimensions: 25 mm × 13 mm Efficiency: Up to 58.4% RoHS and REACH Compliant Antenna Datasheet Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 1 / 15 Contents Contents ...................................................................................................................................................... 1 1 Specification ........................................................................................................................................ 2 1.1. Electrical ..................................................................................................................................... 2 1.2. Mechanical & Environmental ..................................................................................................... 3 1.3. Antenna Assembly ..................................................................................................................... 4 1.4. Matching Circuit ......................................................................................................................... 5 2 Drawing ................................................................................................................................................ 6 3 Detailed Performance ......................................................................................................................... 7 3.1. S-Parameter Test ....................................................................................................................... 7 3.1.1. VSWR ............................................................................................................................ 7 3.2. Radiation Performance Test ....................................................................................................... 8 3.2.1. Efficiency ........................................................................................................................ 8 3.2.2. Peak Gain ...................................................................................................................... 9 3.2.3. 3D & 2D Radiation Pattern .......................................................................................... 10 Contact Us................................................................................................................................................. 12 Legal Notices ............................................................................................................................................ 13 Revision History ....................................................................................................................................... 15 Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 2 / 15 1 Specification Test Condition: Assembled in test device 1.1. Electrical Electrical Frequency Range 2400–2500 MHz, 5150–5850 MHz Impedance50 Ω Polarization Linear Radiation Pattern Omni-directional Electrical - Detail Band SPEC Band B71 B12 /B13 /B28 B5 /B8 /B26 n74 /n75 /n76 B1 /B2 /B3 B40 Wi-Fi 2G B38 /B41 B42 /B48 /n77 n79 Wi-Fi 5G Freq. (MHz) 600– 700 700– 810 820– 960 1420– 1520 1700– 2170 2300– 2400 2400– 2500 2500– 2690 3300– 4200 4400– 5000 5150– 5850 Max. VSWR - - - - - - 2.0 - - - 1.5 Max. Return Loss (dB) - - - - - - -9.4 - - - -13.8 AVG Eff. (%) - - - - - - 54.0 - - - 53.4 AVG AVG Gain (dB) - - - - - - -2.7 - - - -2.7 Max. Peak Gain (dBi) - - - - - - 2.6 - - - 3.8 VSWR ≤ 2.0 Return Loss ≤ -9.4 dB Peak Gain ≤ 3.8 dBi Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 3 / 15 1.2. Mechanical & Environmental Mechanical Antenna Dimensions 25 mm × 3 mm Material & Color FPC & Black Cable & Length & Color Φ 0.81 mm & 175 mm & Black Connector Type ECT RF 2 Mounting Type Adhesive Weight Typ. 0.5 g Environmental Operation Temperature -40 °C to +85 °C Storage Temperature -40 °C to +85 °C RoHS & REACH Compliant Yes Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 4 / 15 1.3. Antenna Assembly Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 5 / 15 1.4. Matching Circuit E1 E1 E3 E4 E5 Default Matching DNI 0 Ohm DNI 0 Ohm DNI Tolerance N/A N/A N/A Wireless Module E1 E2 E3 E5 Antenna E4 Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 6 / 15 2 Drawing Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 7 / 15 3 Detailed Performance 3.1. S-Parameter Test 3.1.1. VSWR 1 2 3 4 5 6 7 8 9 10 20002100220023002400250026002700280029003000310032003300340035003600370038003900400041004200430044004500460047004800490050005100520053005400550056005700580059006000 VSWR Frequency(MHz) VSWR VSWR Frequency (MHz) 2400 2450 2500 5150 5500 5850 5925 6525 7125 VSWR 1.6 1.4 2.0 1.2 1.4 1.3 - - - Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 8 / 15 3.2. Radiation Performance Test 3.2.1. Efficiency 0 10 20 30 40 50 60 70 80 90 100 20002100220023002400250026002700280029003000310032003300340035003600370038003900400041004200430044004500460047004800490050005100520053005400550056005700580059006000 Efficiency(%) Frequency(MHz) Efficiency Efficiency (%) Frequency (MHz) 2400 2450 2500 5150 5500 5850 5925 6525 7125 VSWR 53.1 53.6 50.9 56.3 53.6 51.4 - - - Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 9 / 15 3.2.2. Peak Gain -10 -8 -6 -4 -2 0 2 4 6 8 10 20002100220023002400250026002700280029003000310032003300340035003600370038003900400041004200430044004500460047004800490050005100520053005400550056005700580059006000 Peak Gain(dBi) Frequency(MHz) Peak Gain Peak Gain (dBi) Frequency (MHz) 2400 2450 2500 5150 5500 5850 5925 6525 7125 VSWR 2.5 1.6 0.4 3.8 2.5 1.9 - - - Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 10 / 15 3.2.3. 3D & 2D Radiation Pattern ⚫Test Condition: Assembled in test device ⚫Test Chamber: GL-G-1 Antenna Services Y4SCV0MA0CA Datasheet Antenna_Datasheet 11 / 15 2450 MHz 5500 MHz Antenna S…
Text truncated - open the document above for the full version.
Test Report
Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Page 1 of 23 Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China FCC TEST REPORT FCC ID: A4C-10018A On Behalf of RM Acquisition LLC. GPS Device Model No.: RandTab7N Prepared for : RM Acquisition LLC. Address : 8770 W. Bryn Mawr Avenue,Chicago,Illinois,United States,60631 Prepared By : Shenzhen PSI Testing Co., Ltd. Address : 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Report Number : psi2509207-C01-R01 Date of Receipt : September 30, 2025 Date of Test : September 30, 2025- October 10, 2025 Date of Report : October 11, 2025 Version Number : V0 Page 2 of 23 Report No.: psi2509207-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ------------------------------------------------------------------------------------------------- 5 1.1.Description of Device (EUT) ------------------------------------------------------------------------------------------- 5 1.2.Accessories of Device (EUT) ------------------------------------------------------------------------------------------ 6 1.3.Tested Supporting System Details ----------------------------------------------------------------------------------- 6 1.4.Block Diagram of connection between EUT and simulators --------------------------------------------------- 6 2. EMC EQUIPMENT LIST----------------------------------------------------------------------------------------------------- 7 3. SUMMARY OF MEASUREMENT ----------------------------------------------------------------------------------------- 8 3.1. Summary of test result ---------------------------------------------------------------------------------------------- 8 3.2. Equipment Type ------------------------------------------------------------------------------------------------------ 8 3.3. Channel list ------------------------------------------------------------------------------------------------------------ 9 3.4. Test Conditions and channel -------------------------------------------------------------------------------------10 3.5. Measurement Uncertainty (95% confidence levels, k=2) --------------------------------------------------10 3.6. Test Facility -----------------------------------------------------------------------------------------------------------10 4. DFS PARAMETERS --------------------------------------------------------------------------------------------------------- 11 4.1. DFS Parameters ---------------------------------------------------------------------------------------------------- 11 4.2. Calibration Setup and DFS Test Results ----------------------------------------------------------------------17 4.2.1. Calibration of Radar Waveform ----------------------------------------------------------------------------------17 4.2.1.1. Radar Waveform Calibration Procedure--------------------------------------------------------------17 4.2.1.2. Radiated Calibration Setup ------------------------------------------------------------------------------17 4.2.1.3. Calibration Deviation --------------------------------------------------------------------------------------17 4.2.1.4. Radar Waveform Calibration Result -------------------------------------------------------------------18 4.3. In-Service Monitoring: Channel Move Time, Channel Closing Transmission Time and Non-Occupancy Period -----------------------------------------------------------------------------------------------------19 4.3.1. Limit of In-Service Monitoring ------------------------------------------------------------------------------------19 4.3.2. Test Procedures -----------------------------------------------------------------------------------------------------19 4.3.3. Test Setup----------------------------------------------------------------------------------------------------------------20 4.3.4. Test Deviation ------------------------------------------------------------------------------------------------------------20 4.3.5. Result of Channel Move Time, Channel Closing Transmission Time and Non-Occupancy Period for Client Beacon Test 20 4.3.6. Channel Move Time, Channel Closing Transmission Time and Non-Occupancy Period for Client Beacon Test Plots -------------------------------------------------------------------------------------------------------------21 4.3.7. Data Traffic and Noise Floor Plots -------------------------------------------------------------------------------22 5. Setup Photo ------------------------------------------------------------------------------------------------------------------23 Page 3 of 23 Report No.: psi2509207-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China TEST REPORT DECLARATION Applicant : RM Acquisition LLC. Address : 8770 W. Bryn Mawr Avenue,Chicago,Illinois,United States,60631 Manufacturer : SHENZHEN APICAL TECHNOLOGY CO., LTD Address : 9/F,B Building, Tinghua Unis Infoport, Langshan RD, North district, Hi-tech Industrial Park, Nanshan, Shenzhen EUT Description : GPS Device (A) Model No. : RandTab7N (B) Trademark : Measurement Standard Used: FCC Part 15 Subpart E, FCC KDB 905462 D02, FCC KDB 905462 D03 ANSI C63.10:2020 Test Result: PASS The device described above is tested by Shenzhen PSI Testing Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC li…
Text truncated - open the document above for the full version.
Test Report
ReportNo.:MTEB25070274-R2Page 111 of 111 IEEE802.11n_Channel151_40MHz_Antenna0IEEE802.11n_Channel159_40MHz_Antenna0 IEEE802.11ac_Channel149_20MHz_Antenna0IEEE802.11ac_Channel157_20MHz_Antenna0 IEEE802.11ac_Channel165_20MHz_Antenna0IEEE802.11ac_Channel151_40MHz_Antenna0 IEEE802.11ac_Channel159_40MHz_Antenna0IEEE802.11ac_Channel155_80MHz_Antenna0 **********************EndofReport**********************
Test Report
ReportNo.:MTEB25070274-R2Page 105 of 111 IEEE802.11n_Channel40_20MHz_Antenna0IEEE802.11n_Channel48_20MHz_Antenna0 IEEE802.11n_Channel52_20MHz_Antenna0IEEE802.11n_Channel56_20MHz_Antenna0 IEEE802.11n_Channel64_20MHz_Antenna0IEEE802.11n_Channel100_20MHz_Antenna0 IEEE802.11n_Channel120_20MHz_Antenna0IEEE802.11n_Channel140_20MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 106 of 111 IEEE802.11n_Channel38_40MHz_Antenna0IEEE802.11n_Channel46_40MHz_Antenna0 IEEE802.11n_Channel54_40MHz_Antenna0IEEE802.11n_Channel62_40MHz_Antenna0 IEEE802.11n_Channel102_40MHz_Antenna0IEEE802.11n_Channel118_40MHz_Antenna0 IEEE802.11n_Channel134_40MHz_Antenna0IEEE802.11ac_Channel36_20MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 107 of 111 IEEE802.11ac_Channel40_20MHz_Antenna0IEEE802.11ac_Channel48_20MHz_Antenna0 IEEE802.11ac_Channel52_20MHz_Antenna0IEEE802.11ac_Channel56_20MHz_Antenna0 IEEE802.11ac_Channel64_20MHz_Antenna0IEEE802.11ac_Channel100_20MHz_Antenna0 IEEE802.11ac_Channel120_20MHz_Antenna0IEEE802.11ac_Channel140_20MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 108 of 111 IEEE802.11ac_Channel38_40MHz_Antenna0IEEE802.11ac_Channel46_40MHz_Antenna0 IEEE802.11ac_Channel54_40MHz_Antenna0IEEE802.11ac_Channel62_40MHz_Antenna0 IEEE802.11ac_Channel102_40MHz_Antenna0IEEE802.11ac_Channel118_40MHz_Antenna0 IEEE802.11ac_Channel134_40MHz_Antenna0IEEE802.11ac_Channel42_80MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 109 of 111 IEEE802.11ac_Channel58_80MHz_Antenna0IEEE802.11ac_Channel106_80MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 110 of 111 TestResult ModeChannel Ant.0 MeasPSD (dBm/0.5MHz) Limit (dBm/0.5MHz) Result IEEE802.11a 1492.512 30 PASS 1574.761PASS 1652.902PASS IEEE802.11n_20 1490.909PASS 1572.841PASS 1652.076PASS IEEE802.11n_40 151-1.937PASS 159-0.725PASS IEEE 802.11ac_20 149-0.011PASS 1571.200PASS 1650.880PASS IEEE 802.11ac_40 151-3.872PASS 159-3.141PASS IEEE 802.11ac_80 155-6.815PASS TestGraphs IEEE802.11a_Channel149_20MHz_Antenna0IEEE802.11a_Channel157_20MHz_Antenna0 IEEE802.11a_Channel165_20MHz_Antenna0IEEE802.11n_Channel149_20MHz_Antenna0 IEEE802.11n_Channel157_20MHz_Antenna0IEEE802.11n_Channel165_20MHz_Antenna0
Test Report
ReportNo.:MTEB25070274-R2Page 99 of 111 IEEE802.11ac_40MHz_Channel38IEEE802.11ac_40MHz_Channel46 IEEE802.11ac_40MHz_Channel54IEEE802.11ac_40MHz_Channel62 IEEE802.11ac_40MHz_Channel102IEEE802.11ac_40MHz_Channel118 IEEE802.11ac_40MHz_Channel134IEEE802.11ac_80MHz_Channel42 ReportNo.:MTEB25070274-R2Page 100 of 111 IEEE802.11ac_80MHz_Channel58IEEE802.11ac_80MHz_Channel106 ReportNo.:MTEB25070274-R2Page 101 of 111 TestResult Mode Data rates ChannelAntenna On Time (ms) Period (ms) Duty Cycle (%) Duty Cycle (linear) Duty Cycle Factor (dB) 1/T IEEE 802.11a 54 149 1 0.1780.79722.350.22356.50725.6180 1570.1780.79722.300.22306.5175.6180 1650.1780.79722.300.22306.5175.6180 IEEE 802.11n_20 MCS7 1490.1660.78521.110.21116.75516.0241 1570.1660.78621.150.21156.74696.0241 1650.1660.78521.110.21116.75516.0241 IEEE 802.11n_40 1510.1020.72014.130.14138.49869.8039 1590.1020.72014.130.14138.49869.8039 IEEE 802.11ac_20 MCS9 1490.1500.76919.470.19477.10636.6667 1570.1500.76919.470.19477.10636.6667 1650.1500.76919.530.19537.0936.6667 IEEE 802.11ac_40 1510.0900.70812.740.12748.948311.1111 1590.0900.70812.740.12748.948311.1111 IEEE 802.11ac_80 1550.0670.6849.740.097410.114414.9254 TestGraphs IEEE802.11a_20MHz_Channel149IEEE802.11a_20MHz_Channel157 IEEE802.11a_20MHz_Channel165IEEE802.11n_20MHz_Channel149 IEEE802.11n_20MHz_Channel157IEEE802.11n_20MHz_Channel165 ReportNo.:MTEB25070274-R2Page 102 of 111 IEEE802.11n_40MHz_Channel151IEEE802.11n_40MHz_Channel159 IEEE802.11ac_20MHz_Channel149IEEE802.11ac_20MHz_Channel157 IEEE802.11ac_20MHz_Channel165IEEE802.11ac_40MHz_Channel151 IEEE802.11ac_40MHz_Channel159IEEE802.11ac_80MHz_Channel155 ReportNo.:MTEB25070274-R2Page 103 of 111 APPENDIXVIII.PeakPowerSpectralDensity TestResult ModeChannel Ant.0 MeasPSD (dBm/MHz) Limit (dBm/MHz) Result IEEE802.11a 36-8.044 11 PASS 400.242PASS 481.697PASS 522.684PASS 563.813PASS 643.908PASS 1002.642PASS 1202.242PASS 1403.414PASS IEEE802.11n_20 360.578PASS 400.573PASS 480.736PASS 520.578PASS 562.004PASS 643.081PASS 1001.305PASS 1201.459PASS 1401.503PASS IEEE802.11n_40 38-3.588PASS 46-2.457PASS 54-2.208PASS 62-2.141PASS 102-3.629PASS 118-3.548PASS 134-1.777PASS IEEE 802.11ac_20 36-1.836PASS 40-0.923PASS 48-0.592PASS 52-0.622PASS 56-0.038PASS 641.480PASS 100-0.294PASS 120-0.953PASS 1400.477PASS IEEE 802.11ac_40 38-5.527PASS 46-4.802PASS 54-4.062PASS 62-3.408PASS 102-4.364PASS 118-3.977PASS 134-4.129PASS IEEE 802.11ac_80 42-7.325PASS 58-6.890PASS 106-8.979PASS TestGraphs IEEE802.11a_Channel36_20MHz_Antenna0IEEE802.11a_Channel40_20MHz_Antenna0 ReportNo.:MTEB25070274-R2Page 104 of 111 IEEE802.11a_Channel48_20MHz_Antenna0IEEE802.11a_Channel52_20MHz_Antenna0 IEEE802.11a_Channel56_20MHz_Antenna0IEEE802.11a_Channel64_20MHz_Antenna0 IEEE802.11a_Channel100_20MHz_Antenna0IEEE802.11a_Channel120_20MHz_Antenna0 IEEE802.11a_Channel140_20MHz_Antenna0IEEE802.11n_Channel36_20MHz_Antenna0
Test Report
ReportNo.:MTEB25070274-R2Page 94 of 111 APPENDIXVII.DutyCycle TestResult Mode Data rates ChannelAntenna On Time (ms) Period (ms) Duty Cycle (%) Duty Cycle (linear) Duty Cycle Factor (dB) 1/T IEEE 802.11a 54 36 1 0.1780.79722.350.22356.50725.6180 400.1780.79722.300.22306.5175.6180 480.1780.79722.300.22306.5175.6180 520.1780.79722.300.22306.5175.6180 560.1780.79722.300.22306.5175.6180 640.1780.79722.350.22356.50725.6180 1000.1780.79722.300.22306.5175.6180 1200.1780.79722.350.22356.50725.6180 1400.1780.79722.300.22306.5175.6180 IEEE 802.11n_20 MC…
Text truncated - open the document above for the full version.
Contact Information
Applicant
George Minehart(Director, Human Resources)
[email protected]Fax: 8473296101
Technical Contact
RM Acquisition LLC.Hans Molin
18022 Cowan Ste 185, Irvine, California 92614, · California, 92614 · United States
Test Firm
Shenzhen Most Technology Service Co., Ltd.Sunny Deng
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15E | 5.18 GHz - 5.24 GHz | 42.17 mW |
| 2 | 15E | 5.26 GHz - 5.32 GHz | 68.86 mW |
| 3 | 15E | 5.50 GHz - 5.70 GHz | 65.77 mW |
| 4 | 15E | 5.75 GHz - 5.83 GHz | 35.62 mW |
