A7K-ALBC7Smart LED Light

Quick-start guide Prise en main Kurzanleitung Guía de inicio rápido Guida rapida Stručný návod k použití Hurtig startguide Snelstartgids Pika-aloitusopas Első lépések útmutató Hurtigstartveiledning Poradnik szybkiego startu Guia do utilizador Руководство пользователя Användarhandbok Navodila za uporabo Hızlı başlangıç kılavuzu 1 | AwoX AromaLIGHT Quick-start guide EN Awox AromaLIGHT Color Quick-start guide © 2015 AwoX. All rights reserved. AwoX AromaLIGHT Color, AwoX, the AwoX logo and other AwoX marks are owned by AwoX. iPhone, iPad, and iPod are trademarks of Apple, Inc., registered in the U.S and oth er countries. Android is a trademark of Google Inc. The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. All other trademarks are the property of their respective owners. Smartphone not included. Product photos are non-contractual. Rev 1. 2 | AwoX AromaLIGHT Quick-start guide CONGRATULATIONS AND THANK YOU for choosing AwoX AromaLIGHT™, a stylish essential oil diffuser integrated into a variable color low-energy LED light bulb that you can control with your Bluetooth® Smart Ready smartphone. Download the free AwoX SmartCONTROL™ smartphone application to control color tone, brightness, and diffuser intensity. This guide describes how to set up and get started with your AwoX Aroma LIGHT Color product. Download complete user guide on www.awox.com EN AwoX AromaLIGHT Quick-start guide | 3 DOWNLOAD FREE SMARTPHONE APP To control your AwoX AromaLIGHT products with your Apple or Google Android smartphone, start by downloading the free AwoX SmartCONTROL™ app for your device: Apple (the following devices or newer): iPhone 4S, iPad (3 rd gen.), iPod Touch (5 th gen.), iPad Mini – download and install AwoX SmartCONTROL™ software from the App Store. Google Android devices equipped with Bluetooth Smart Ready (4.0 or higher) – download and install AwoX SmartCONTROL™ software from the Google Play Store. EN 4 | AwoX AromaLIGHT Quick-start guide LAUNCH SMARTCONTROL TO USE YOUR AWOX AROMALIGHT BULBS 1.Install your AwoX AromaLIGHT in an appropriate lamp or fixture (see safety instructions) and turn power on with the switch. 2.Activate Bluetooth on your smartphone (in Settings) and launch AwoX SmartCONTROL. Lights within wireless range are shown as icons on the main screen. 3.Place a few drops of essential oil on the removable cartridge. Tap icons on screen to control the diffuser and color settings. Download complete user guide on www.awox.com EN 1 | AwoX AromaLIGHT Prise en main AwoX AromaLIGHT Color Prise en main © 2015 AwoX. Tous droits réservés. AwoX AromaLIGHT Color, AwoX, le logo AwoX et les autres marques AwoX sont la propriété d'AwoX. iPhone, iPad et iPod sont des marques déposées d'Apple, Inc., aux États-Unis et dans d'autres pays. Android est une marque déposée de Google Inc. La marque et le logo Bluetooth® sont la propriété de Bluetooth® SIG, Inc. Toutes les autres marques déposées sont la propriété de leurs détenteurs respectifs. Smartphone vendu séparément. Photos de produits non contractuelles. Version 1. FR 2 | AwoX AromaLIGHT Prise en main MERCI D’AVOIR CHOISI AWOX AROMALIGHT™. AwoX AromaLIGHT TM est un diffuseur d’huiles essentielles intégré à une ampoule LED multicolore à économie d'énergie, compatible Bluetooth® pour vous permettre de la télécommander depuis votre smartphone. L'application gratuite AwoX SmartCONTROL™ vous permet de régler la température et l'intensité lumineuses, ainsi que la puissance du diffuseur. Ce guide vous explique comment installer et utiliser votre produit AwoX AromaLIGHT Color. Téléchargez le mode d'emploi intégral sur www.awox.com FR AwoX AromaLIGHT Prise en main | 3 TÉLÉCHARGEZ L'APPLI GRATUITE POUR SMARTPHONE Pour télécommander vos produits AwoX AromaLIGHT depuis votre smartphone Apple ou Google Android, téléchargez l'application gratuite AwoX SmartCONTROL™ correspondant à votre appareil : Apple : iPhone 4S, iPad (3e génération), iPod Touch (5e génération), iPad Mini ou modèles ultérieurs – téléchargez et installez l’application AwoX SmartCONTROL™ disponible sur l’App Store ; Smartphones Google Android équipés de Bluetooth Smart Ready (4.0 ou version ultérieure) – téléchargez et installez l’application AwoX SmartCONTROL™ disponible sur le Google Play Store. FR 4 | AwoX AromaLIGHT Prise en main OUVREZ SMARTCONTROL ET COMMENCEZ À UTILISER VOTRE AMPOULE AWOX AROMALIGHT™. 1.Installez votre ampoule AwoX AromaLIGHT dans un luminaire compatible (voir les consignes de sécurité) et mettez ce dernier sous tension à l'aide de l’interrupteur. 2.Activez la fonction Bluetooth sur votre smartphone (dans les réglages) et ouvrez AwoX SmartCONTROL. Les ampoules situées suffisamment près du smartphone pour être détectées apparaissent à l’écran sous forme d’icônes. 3.Versez quelques gouttes d’huile essentielle dans la cartouche amovible. Appuyez sur les icônes à l’écran pour régler le diffuseur et la couleur de l’ampoule. Téléchargez le mode d'emploi intégral sur www.awox.com FR 1 | AwoX AromaLIGHT Kurzanleitung DE Awox AromaLIGHT Color Kurzanleitung © 2015 AwoX. Alle Rechte vorbehalten. AwoX AromaLIGHT, AwoX, das AwoX-Logo und andere AwoX-Marken sind im Besitz von AwoX. iPhone, iPad und iPod sind eingetragene Warenzeichen von Apple, Inc., in den US und anderen Ländern registriert. Android ist ein eingetragenes Warenzeichen von Google Inc. Die Bluetooth®- Wortmarke und –logos sind im Besitz von Bluetooth® SIG, Inc. Alle weiteren eingetragenen Warenzeichen sind im Besitz ihres jeweiligen Eigentümers. Smartphone ausgenommen. Produktfotos sind nicht vertraglich. Rev 1. 2 | AwoX AromaLIGHT Kurzanleitung HERZLICHEN GLÜCKWUNSCH UND DANKE,dass Sie sich für AromaLIGHT™, eine stilvolle Duftlampe für ätherische Öle entschieden haben, die in eine farbig variable, energiesparende LED-Glühbirne integriert ist, die Sie mit Ihrem Bluetooth® Smart Ready Smartphone steuern können. Nach dem Download der kostenlosen AwoX SmartCONTROL™ Smartphone- Anwendung können Sie den Farb…

Text truncated - open the document above for the full version.

Label location

MADE IN CHINA LED LAMP 100-240VAC, 50/60Hz,85mA,7W Input ratings: CAUTION: Risk of Electric Shock DOUBLE INSULATED USE IN DRY LOCATION ONLY E468490 MMYYYY Model:AromaLIGHT E26 AL-Bc7 Model:AromaLIGHT E26 AL-Bc7 FCC ID:A7K-ALBC7 Canada IC:10994A-ALBC7 ,HPF

FCC ID: A7K-ALBC7 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) --- 3m So pt = (EXd) 2 /30 x gt Field strength = 92.84dBuV/m @3m Ant gain =0dBi, so Ant numeric gain= 1 So pt={ [10 (92.84) /10 6 x 3] 2 /30x1 }x1000 mW = 0.581mW So (0.581 mW /5mm)x √2.480 = 0.183<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE15040059001 FCC REPORT Applicant: AWOX Address of Applicant: 93 place Pierre Duhem, 34000 Montpellier, France Equipment Under Test (EUT) Product Name:Smart LED Light Model No.:AromaLIGHT E26 AL-Bc7 FCC ID: A7K-ALBC7 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2014 Date of sample receipt: April 30, 2015 Date of Test: May 04-05, 2015 Date of report issued: May 06, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. RobinsononoonnnnnnnnononononnnnononnnnnnnnnnonnnnnnnnLo Report No.: GTSE15040059001 2Version Version No.DateDescription 00May 06, 2015Original Prepared By: Date: May 06, 2015 Project Engineer Check By:Date: May 06, 2015 Reviewer Pj tE i Global United Technology Services Co., Ltd.Project No.: GTSE150400590RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960Page 2 of 30 Report No.: GTSE15040059001 3Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 5.7 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 RADIATED EMISSION METHOD........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions.................................................................................................................... 16 7.3.3 Bandedge emissions.................................................................................................................. 20 7.4 20DBOCCUPY BANDWIDTH.............................................................................................................. 21 8 TEST SETUP PHOTO ............................................................................................................................ 23 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................25 Global United Technology Services Co., Ltd.Project No.: GTSE150400590RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960Page 3 of 30 Report No.: GTSE15040059001 4Test Sum…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
