A8J-EAP1750HDual Band AC1750 Access Point

User Manual Business Solutions Dual Band N1750 Indoor Access Point Ceiling Mount Design EAP1750H version 1.0 2 IMPORTANT To install this Access Point please refer to the Quick Installation Guide included in the product packaging. 3 Chapter 1 Product Overview................................................... 4 Key Features/Introduction........................................................... 5 System Requirements / Package Contents .............................. 6 Applications...................................................................................... 7 Technical Specifications............................................................... 8 Physical Interface........................................................................... 9 Chapter 2 Before You Begin .................................................. 10 Considerations for Wireless Installation............................. 11 Computer Settings..................................................................... 12 Hardware Installation................................................................. 15 Mounting the EAP1750H............................................................. 16 Chapter 3 Configuring Your Access Point.......................... 18 Default Settings............................................................................ 19 Chapter 4 Building a Wireless Network............................. 20 Access Point Mode....................................................................... 21 WDS AP Mode............................................................................... 22 WDS Bridge Mode........................................................................ 23 Chapter 5 Overview............................................................... 24 Overview........................................................................................... 25 Connections.................................................................................... 26 Chapter 6 Network ................................................................. 27 Operation Mode/Basic................................................................... 28 IP Settings/SpanningTree Settings...................................... 29 Chapter 7 Wireless ............................................................... 31 Wireless Network........................................................................ 31 Wireless Security......................................................................... 34 Wireless MAC Filtering............................................................ 40 Wireless Advanced ..................................................................... 41 WPS (Wi-Fi Protected Setup)................................................. 42 WDS Link Settings....................................................................... 43 Chapter 8 Management........................................................ 44 Administration.............................................................................. 45 Management VLAN Settings................................................. 46 Wireless Traffic Shaping......................................................... 47 SNMP Settings............................................................................... 48 Backup/Restore.......................................................................... 50 Auto Reboot Settings................................................................ 51 Firmware Upgrade/Time Settings............................................ 52 System Log/Tools.......................................................................... 54 Ping Test Parameters/Traceroute Parameters.................. 55 Speed Test Parameters/LED Control.........................................56 Device Display/Reset...................................................................57 Appendix ................................................................................. 58 FCC Interference Statement.................................................. 59 IC Interference Statement.................................................... 60 CE Interference Statement...................................................... 62 Table of Contents 4 Chapter 1 Product Overview 5 Maximum data rates are based on IEEE 802.11 standards. Actual throughput and range may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment, and mix of devices in the network. Features and specifications subject to change without notice. Trademarks and registered trademarks are the property of their respective owners. For United States of America: Copyright © 2013 EnGenius Technologies, Inc. All rights reserved. Key Features • High transmit power, enabling long range connectivity • Supports IEEE802.11ac/b/g/n wireless standards with up to 450 Mbps data rate on 2.4GHz and 1300Mbps data rate on 5GHz • Six internal 5dBi Omni-Directional MIMO antennas • Can be monitored after deployment with EnGenius EZ Controller™ software for Windows (Free online download) • Can be used with included power adapter or via PoE with PoE 802.3at - capable Switches or Injectors • Dual Band/Three Stream • Band Steering shifts dual band clients to 5 GHz for better throughput performance • Secured Guest Network Introduction The EAP1750H is a high-powered, long-range, Dual-band concurrent Wireless 802.11ac/b/g/n Access Point with three major functional modes. It is designed to operate in numerous environments; from large homes, small and medium-sized businesses, multiple-floor offices, hotels, and other venues, to larger enterprise deployments. Its high-powered, long-range characteristics make it a cost- Introduction can be used with 802.3at capable switches or injectors effective alternative to ordinary Access Points that don’t have the range and reach to connect to a growing number of wireless users who wish to connect to a large home or business network.…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT EUT Model: EAP1750H Page 2 Page 3 EUT Model: EWS360AP Page 4 Page 5 Page 6

EUT Model: EAP1750H EUT Model: EWS360AP Label Location Label Location

Page 7 EUT Model: EAP1750H Page 8 EUT Model: EWS360AP Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16

FCC ID: A8J-EAP1750H Report No.: RF140224C17 Operational Description This device is a Dual Band AC1750 Access Point, which operates in both of 2.4GHz and 5GHz bands; the maximum data rate could be up to 1299.9Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 1299.9Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 12Vdc from AC adapter or 48Vdc from POE. The antennas are as below: The other instruction, please have a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA140224C17 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA140224C17 MODEL NO.: EAP1750H, EWS360AP FCC ID: A8J-EAP1750H RECEIVED: Feb. 24, 2014 TESTED: Mar. 13 ~ Mar. 20, 2014 ISSUED: Mar. 28, 2014 APPLICANT: EnGenius Technologies ADDRESS: 1580 Scenic Avenue, Costa Mesa, CA92626 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C. ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SA140224C17 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 3 1. CERTIFICATION ........................................................................................................... 4 2. RF EXPOSURE ............................................................................................................. 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ....................................... 5 2.2 MPE CALCULATION FORMULA .................................................................................. 5 2.3 CLASSIFICATION ......................................................................................................... 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ................................ 6 Report No.: SA140224C17 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA140224C17 Original release Mar. 28, 2014 Report No.: SA140224C17 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: Dual Band AC1750 Access Point MODEL: EAP1750H, EWS360AP BRAND: EnGenius APPLICANT: EnGenius Technologies TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: EAP1750H) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Mar. 28, 2014 Pettie Chen / Senior Specialist APPROVED BY : , DATE :Mar. 28, 2014 Ken Liu / Senior Manager Report No.: SA140224C17 5 of 6 Report Format Version 5.0.0 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 30cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA140224C17 6 of 6 Report Format Version 5.0.0 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 28.69 8.77 30 0.493 1 5180-5240 16.72 9.77 30 0.039 1 5745-5825 27.74 9.77 30 0.498 1 NOTE: 2.4GHz Band: Directional gain = 4dBi + 10log(3) = 8.77dBi 5.0GHz Band: Directional gain = 5dBi + 10log(3) = 9.77dBi CONCULSION: Both of the WLAN 2.4G & WLAN 5G can transmit simultaneously, the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density WLAN 2.4G + WLAN 5.0G = 0.493 + 0.498 = 0.991 Therefore, the maximum calculation of this situation is 0.991, which is less than the “1” limit.

Report No.: RF140224C17 1 of 112 Report Format Version 5.2.0 FCC TEST REPORT (15.247) REPORT NO.: RF140224C17 MODEL NO.: EAP1750H (Refer to item 3.1 for the more details) FCC ID: A8J-EAP1750H RECEIVED: Feb. 24, 2014 TESTED: Mar. 13 ~ Mar. 20, 2014 ISSUED: Mar. 28, 2014 APPLICANT: EnGenius Technologies ADDRESS: 1580 Scenic Avenue, Costa Mesa, CA92626 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140224C17 2 of 112 Report Format Version 5.2.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................. 5 1. CERTIFICATION .......................................................................................................... 6 2. SUMMARY OF TEST RESULTS ................................................................................. 7 2.1 MEASUREMENT UNCERTAINTY ............................................................................... 7 3. GENERAL INFORMATION .......................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ............................................................................ 8 3.2 DESCRIPTION OF TEST MODES ............................................................................ 10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................ 11 3.3 DUTY CYCLE OF TEST SIGNAL .............................................................................. 15 3.4 DESCRIPTION OF SUPPORT UNITS ...................................................................... 17 3.4.1 CONFIGURATION OF SYSTEM UNDER TEST ....................................................... 18 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................... 19 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND) ................................................ 20 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................... 20 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................. 20 4.1.2 TEST INSTRUMENTS ............................................................................................... 21 4.1.3 TEST PROCEDURES ............................................................................................... 22 4.1.4 DEVIATION FROM TEST STANDARD...................................................................... 22 4.1.5 TEST SETUP ............................................................................................................. 23 4.1.6 EUT OPERATING CONDITIONS .............................................................................. 24 4.1.7 TEST RESULTS ........................................................................................................ 25 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................ 39 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT .......................................... 39 4.2.2 TEST INSTRUMENTS ............................................................................................... 39 4.2.3 TEST PROCEDURES ............................................................................................... 40 4.2.4 DEVIATION FROM TEST STANDARD...................................................................... 40 4.2.5 TEST SETUP ............................................................................................................. 40 4.2.6 EUT OPERATING CONDITIONS .............................................................................. 40 4.2.7 TEST RESULTS ........................................................................................................ 41 4.3 6dB BANDWIDTH MEASUREMENT ......................................................................... 45 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ...................................................... 45 4.3.2 TEST SETUP ............................................................................................................. 45 4.3.3 TEST INSTRUMENTS ............................................................................................... 45 4.3.4 TEST PROCEDURE .................................................................................................. 45 4.3.5 DEVIATION FROM TEST STANDARD......................................................................…

Text truncated - open the document above for the full version.

Report No.: RF140224C17-1 1 of 59 Report Format Version 5.2.0 FCC TEST REPORT (15.407) REPORT NO.: RF140224C17-1 MODEL NO.: EAP1750H (Refer to item 3.1 for the more details) FCC ID: A8J-EAP1750H RECEIVED: Feb. 24, 2014 TESTED: Mar. 13 ~ Mar. 20, 2014 ISSUED: Mar. 28, 2014 APPLICANT: EnGenius Technologies ADDRESS: 1580 Scenic Avenue, Costa Mesa, CA92626 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140224C17-1 2 of 59 Report Format Version 5.2.0 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................. 4 1. CERTIFICATION........................................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY ................................................................................ 6 3. GENERAL INFORMATION ........................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 7 3.2 DESCRIPTION OF TEST MODES ............................................................................... 9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 10 3.3 DUTY CYCLE OF TEST SIGNAL ............................................................................... 12 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 16 3.4.1 CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 17 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 18 4. TEST TYPES AND RESULTS .................................................................................... 19 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT ..................................... 19 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .................. 19 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS .............. 19 4.1.3 TEST INSTRUMENTS ................................................................................................ 20 4.1.4 TEST PROCEDURES ................................................................................................ 21 4.1.5 DEVIATION FROM TEST STANDARD ...................................................................... 21 4.1.6 TEST SETUP .............................................................................................................. 22 4.1.7 EUT OPERATING CONDITION .................................................................................. 23 4.1.8 TEST RESULTS ......................................................................................................... 24 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 35 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................... 35 4.2.2 TEST INSTRUMENTS ................................................................................................ 35 4.2.3 TEST PROCEDURES ................................................................................................ 36 4.2.4 DEVIATION FROM TEST STANDARD ...................................................................... 36 4.2.5 TEST SETUP .............................................................................................................. 36 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 36 4.2.7 TEST RESULTS ......................................................................................................... 37 4.3 PEAK TRANSMIT POWER MEASUREMENT ........................................................... 41 4.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT ......................................... 41 4.3.2 TEST SETUP .............................................................................................................. 41 4.3.3 TEST INSTRUMENTS ................................................................................................ 41 4.3.4 TEST PROCEDURE .......................................................................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (TEST MODE A) 2 CONDUCTED EMISSION TEST (TEST MODE B) 3 RADIATED EMISSION TEST (TEST MODE A) 4 RADIATED EMISSION TEST (TEST MODE B)
