FCC ID: A8JEDS5115 Report No.: RF150313C14 Operational Description This device is a Megapixel Wi-Fi Bullet Camera, which operates in 2.4GHz band; the maximum data rate could be up to 150 Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 150Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 12Vdc adapter or 48Vdc POE. The EUT is used Dipole antenna with RSMA connector. The other instruction, please have a look at the user’s manual.

Report No.: SA150313C14 Page No. 1 / 5 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA150313C14 FCC ID: A8JEDS5115 Test Model: EDS5115 Series Model: IPC5115, EDS5110v2, WLC-4000 v1 001 Received Date: Mar. 09, 2015 Test Date: Mar. 18 ~ Apr. 01, 2015 Issued Date: Apr. 13, 2015 Applicant: EnGenius Technologies Address: 1580 Scenic Avenue, Costa Mesa, CA92626 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan (R.O.C.) Test Location: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used b y the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA150313C14 Page No. 2 / 5 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits For Maximum Permissible Exposure (MPE) ............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result Of Maximum Conducted Power .......................................................................... 5 Report No.: SA150313C14 Page No. 3 / 5 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA150313C14 Original release. Apr. 13, 2015 Report No.: SA150313C14 Page No. 4 / 5 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Megapixel Wi-Fi Bullet Camera Brand: EnGenius, Senao, Sitecom Test Model: EDS5115 Series Model: IPC5115, EDS5110v2, WLC-4000 v1 001 Sample Status: Engineering sample Applicant: EnGenius Technologies Test Date: Mar. 18 ~ Apr. 01, 2015 Standards: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date:Apr. 13, 2015 Ivy Lin / Specialist Approved by : , Date:Apr. 13, 2015 Ken Liu / Senior Manager Report No.: SA150313C14 Page No. 5 / 5 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 3 Calculation Result Of Maximum Conducted Power Frequency Band (MHz) Max Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412-2462 22.84 1.68 20 0.056 1 --- END ---

Report No.: RF150313C14 Page No. 1 / 53 Report Format Version: 6.1.1 FCC Test Report Report No.: RF150313C14 FCC ID: A8JEDS5115 Test Model: EDS5115 Series Model: IPC5115, EDS5110v2, WLC-4000 v1 001 Received Date: Mar. 09, 2015 Test Date: Mar. 18 ~ Apr. 01, 2015 Issued Date: Apr. 13, 2015 Applicant: EnGenius Technologies Address: 1580 Scenic Avenue, Costa Mesa, CA92626 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan (R.O.C.) Test Location: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used b y the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150313C14 Page No. 2 / 53 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 9 3.3 Duty Cycle of Test Signal ................................................................................................................... 11 3.4 Description of Support Units ............................................................................................................. 12 3.4.1 Configuration of System under Test .................................................................................................. 12 3.5 General Description of Applied Standards ........................................................................................ 14 4 Test Types and Results ...................................................................................................................... 15 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 15 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 15 4.1.2 Test Instruments ................................................................................................................................ 16 4.1.3 Test Procedures ................................................................................................................................. 17 4.1.4 Deviation from Test Standard ............................................................................................................ 17 4.1.5 Test Set Up ........................................................................................................................................ 18 4.1.6 EUT Operating Conditions ................................................................................................................. 18 4.1.7 Test Results ....................................................................................................................................... 19 4.2 Conducted Emission Measurement .................................................................................................. 33 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 33 4.2.2 Test Instruments ................................................................................................................................ 33 4.2.3 Test Procedures ................................................................................................................................. 33 4.2.4 Deviation from Test Standard ...............…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Test Mode A) 2 CONDUCTED EMISSION TEST (Test Mode B) 3 RADIATED EMISSION TEST (Above 1GHz) 4 RADIATED EMISSION TEST (Below 1GHz) (Test Mode A) 5 RADIATED EMISSION TEST (Below 1GHz) (Test Mode B)
