until 2012/04/30 Owner’s Manual Home Theater Audio System Model No. SC-HTB550 P Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Please keep this manual for future reference. If you have any questions, contact: U.S.A. and Puerto Rico: 1-800-211-PANA (7262) Canada: 1-800-561-5505 RQT9660-P PC SC-HTB550_RQT9660_mst.book Page 1 Tuesday, December 20, 2011 1:55 PM 2 RQT9660 IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference. 1Read these instructions. 2Keep these instructions. 3Heed all warnings. 4Follow all instructions. 5Do not use this apparatus near water. 6Clean only with dry cloth. 7Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11Only use attachments/accessories specified by the manufacturer. 12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13 Unplug this apparatus during lightning storms or when unused for long periods of time. 14 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Unit ≥To reduce the risk of fire, electric shock or product damage, jDo not expose this unit to rain, moisture, dripping or splashing. jDo not place objects filled with liquids, such as vases, on this unit. jUse only the recommended accessories. jDo not remove covers. jDo not repair this unit by yourself. Refer servicing to qualified service personnel. Button-type battery (Lithium battery) ≥Risk of fire, explosion and burns. Do not disassemble, heat above 60 o C (140 o F) or incinerate. Unit ≥Do not place sources of naked flames, such as lighted candles, on this unit. Placement ≥To reduce the risk of fire, electric shock or product damage, jDo not install or place this unit in a bookcase, built-in cabinet or in another confined space. Ensure this unit is well ventilated. jDo not obstruct this unit’s ventilation openings with newspapers, tablecloths, curtains, and similar items. Button-type battery (Lithium battery) ≥Danger of explosion if battery is incorrectly replaced. Replace only with the type recommended by the manufacturer. ≥When disposing the batteries, please contact your local authorities or dealer and ask for the correct method of disposal. ≥Insert with poles aligned. ≥Do not touch the terminals (i and j) with metal objects. ≥Do not recharge, disassemble, remodel, heat or throw into fire. ≥Keep out of reach of children. ≥Mishandling of batteries can cause electrolyte leakage and may cause a fire. jRemove the battery if you do not intend to use the remote control for a long period of time. Store in a cool, dark place. ≥Do not heat or expose to flame. ≥Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with doors and windows closed. WARNING If any electrolyte should come into contact with your hands or clothes, wash it off thoroughly with water. If any electrolyte should come into contact with your eyes, never rub the eyes. Rinse eyes thoroughly with water, and then consult a doctor. <For USA-California only> This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material s special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. CAUTION SC-HTB550_RQT9660_mst.book Page 2 Tuesday, December 20, 2011 1:55 PM RQT9660 3 Precautions THE FOLLOWING APPLIES ONLY IN THE U.S.A. AND CANADA This device complies with Part 15 of FCC Rules and RSS- Gen of IC Rules. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This product is restricted to indoor use due to its operation in the 5.150 GHz to 5.250 GHz and 5.725 GHz to 5.850 GHz frequency range. FCC and IC require this product to be used indoors for the frequency range 5.150 GHz to 5.250 GHz and 5.725 GHz to 5.850 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 GHz to 5.35 GHz and 5.65 GHz to 5.85 GHz bands. These radar stations can cause interference with and/or damage this product. This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that is deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirabl…

Text truncated - open the document above for the full version.

Getting started RQT9660 19 Step 3 Connections ≥Turn off all equipment before connection and read the appropriate owner’s manual. Do not connect the AC power supply cord until all other connections are complete. ∫HDMI The HDMI connection supports VIERA Link “HDAVI Control” (>25) when used with a compatible Panasonic TV. ≥Use the High Speed HDMI Cables. It is recommended that you use Panasonic’s HDMI cable. Recommended part number (High Speed HDMI cable): RP-CDHS15 (1.5 m/4.9 ft), RP-CDHS30 (3.0 m/9.8 ft), RP-CDHS50 (5.0 m/16.4 ft), etc. ≥Non-HDMI-compliant cables cannot be utilized. Verify if the TV’s HDMI terminal is labeled “HDMI (ARC)”. ∫What is ARC? ARC is an abbreviation of Audio Return Channel, also known as HDMI ARC. It refers to one of the HDMI functions. When you connect the main unit to the terminal labeled “HDMI (ARC)”, the optical digital audio cable that is usually required in order to listen to sound from a TV is no longer required, and TV pictures and sound can be enjoyed with a single HDMI cable. Make the connection. Connection with the TV Connection differs depending on the label printed next to the HDMI terminal. Labeled “HDMI (ARC)”: Connection [A] Not Labeled “HDMI (ARC)”: Connection [B] [A] Labeled “HDMI (ARC)” HDMI cable [B] Not labeled “HDMI (ARC)” HDMI cable Optical digital audio cable ≥When you use the optical digital audio cable, insert the tip correctly into the terminal. SPEAKERS / HAUT-PARLEURS AV OUT DIGITAL AUDIO IN TV (ARC) AC IN HDMI IN (ARC) AV IN TV (ARC) BD/DVD (HDMI1) BD/DVD (HDMI1) AUX1 (HDMI2) AV OUT  TV Main unit Be sure to connect to the TV’s ARC compatible terminal. (Refer to the operating instructions for the TV.) SPEAKERS / HAUT-PARLEURS 6 R L AV OUT DIGITAL AUDIO IN TV (OPT1) TV (ARC) AC IN HDMI IN OPTICAL OUT TV (ARC) AV OUT DIGITAL AUDIO IN TV (OPT1)   TV Main unit SC-HTB550_RQT9660_mst.book Page 19 Tuesday, December 20, 2011 1:55 PM 20 RQT9660 You can direct the audio signal from the connected Blu-ray Disc player TM , DVD player, Set Top Box, etc. to this system. Preparation ≥Connect the main unit to the TV (>19). ∫HDMI standby pass-through Even if the main unit is in standby mode, the audio and/or video signal from the device connected to the BD/DVD or AUX1 terminal will be sent to the TV connected to the HDMI OUT terminal (the sound will not be output from this system). When devices are connected to both BD/DVD and AUX1 terminals, audio and/or video signal of the device whose input is lastly selected is output. ∫3D compatibility Compatible with FULL HD 3D TV and Blu-ray Disc player TM . ≥The main unit can pass the 3D video signal from a 3D compatible Blu-ray Disc player TM to a FULL HD 3D TV. Connection with other devices When the device has an HDMI terminal HDMI cable When the device has an optical digital audio output terminal Refer to the operating instructions of the respective devices for the optimal connection Optical digital audio cable HDMI OUT HDMI OUT SPEAKERS / HAUT-PARLEURS AV IN DIGITAL AUDIO IN BD/DVD (HDMI1) BD/DVD (HDMI1) AUX1 (HDMI2) AC IN AV IN BD/DVD (HDMI1) BD/DVD (HDMI1) AUX1 (HDMI2)  e.g., Video game console Main unit e.g., Blu-ray Disc player TM OPTICAL OUT SPEAKERS / HAUT-PARLEURS DIGITAL AUDIO IN AUX2 (OPT2) AC IN DIGITAL AUDIO IN AUX2 (OPT2)   e.g., Set top box Main unit TV SC-HTB550_RQT9660_mst.book Page 20 Tuesday, December 20, 2011 1:55 PM Getting started RQT9660 21 Match the connector shape and connect to the terminals of the same color. ≥Connect only after all other connections are complete. ≥The main unit and active subwoofer consume a small amount of AC power, even when it is turned off (this unit: approx. 0.1 W, active subwoofer: approx. 0.1 W). In the interest of power conservation, if you will not be using this system for a long time, unplug it from the household AC outlet. Speaker cable connection RED Right speaker channel (R) WHITE Left speaker channel (L) AC power supply cord connection AC power supply cordTo a household AC outlet Install this unit so that the power cord can be unplugged from the socket outlet immediately if any problem occurs. Saving energy The main unit is designed to conserve its power consumption and save energy. ≥ The main unit will automatically switch to standby mode when no signal is input and no operation is performed for approx. 30 minutes. SPEAKERS / HAUT-PARLEURS 6 R L DIGITAL AUDIO IN AC IN SPEAKERS / HAUT-PARLEURS 6 RL   Main unit AC IN SPEAKERS / HAUT-PARLEURS DIGITAL AUDIO IN AC IN     AC IN Main unit Active subwoofer SC-HTB550_RQT9660_mst.book Page 21 Tuesday, December 20, 2011 1:55 PM 22 RQT9660 Preparation ≥Turn on the main unit. Press [BÍ CI]. Check that the wireless link is activated. WIRELESS LINK indicator lights ≥Red: The wireless link is not activated. ≥Green: The wireless link is activated. The unit will still consume a small amount of power even when it is turned off (B, Í) With the Bluetooth ® connection you can output the audio from the connected wireless device. Preparation ≥Turn on the Bluetooth ® feature of the device and place the device near this unit. Press [, j PAIRING]. ≥“” indicator will blink quickly. Select “SC-HTB550” from the Bluetooth ® device’s Bluetooth ® menu. ≥Refer to the operating instructions of the Bluetooth ® device for further instruction on how to connect a Bluetooth ® device. ≥Once the Bluetooth ® device is connected, the “” indicator stops flashing and lights up. ≥If prompted for the passkey on the Bluetooth ® device, enter “0000”. Press [, j PAIRING]. Press and hold the [ , j PAIRING] until the “ ” indicator flashes quickly. Repeat step 2 of “Pairing a device”. ≥You can register up to 6 devices with this unit. If a 7th device is paired, the device that has not been used for the longest time will be replaced. ≥This unit can only be connected to one device at a time. ≥To change the sound quality, refer to “Bluetooth ® communication mode” on page 26. Active subwoofer wireless connection Bluetooth ® conn…

Text truncated - open the document above for the full version.

until 2012/04/30 Owner’s Manual Home Theater Audio System Model No. SC-HTB350 P Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Please keep this manual for future reference. If you have any questions, contact: U.S.A. and Puerto Rico: 1-800-211-PANA (7262) RQT9670-P SC-HTB350_RQT9670_mst.book Page 1 Tuesday, December 20, 2011 2:05 PM 2 RQT9670 Table of contents IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference. 1Read these instructions. 2Keep these instructions. 3Heed all warnings. 4Follow all instructions. 5Do not use this apparatus near water. 6Clean only with dry cloth. 7Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11Only use attachments/accessories specified by the manufacturer. 12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13 Unplug this apparatus during lightning storms or when unused for long periods of time. 14 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Unit ≥To reduce the risk of fire, electric shock or product damage, jDo not expose this unit to rain, moisture, dripping or splashing. jDo not place objects filled with liquids, such as vases, on this unit. jUse only the recommended accessories. jDo not remove covers. jDo not repair this unit by yourself. Refer servicing to qualified service personnel. Button-type battery (Lithium battery) ≥Risk of fire, explosion and burns. Do not disassemble, heat above 60 o C (140 o F) or incinerate. Unit ≥Do not place sources of naked flames, such as lighted candles, on this unit. Placement ≥To reduce the risk of fire, electric shock or product damage, jDo not install or place this unit in a bookcase, built-in cabinet or in another confined space. Ensure this unit is well ventilated. jDo not obstruct this unit’s ventilation openings with newspapers, tablecloths, curtains, and similar items. Button-type battery (Lithium battery) ≥Danger of explosion if battery is incorrectly replaced. Replace only with the type recommended by the manufacturer. ≥When disposing the batteries, please contact your local authorities or dealer and ask for the correct method of disposal. ≥Insert with poles aligned. ≥Do not touch the terminals (i and j) with metal objects. ≥Do not recharge, disassemble, remodel, heat or throw into fire. ≥Keep out of reach of children. ≥Mishandling of batteries can cause electrolyte leakage and may cause a fire. jRemove the battery if you do not intend to use the remote control for a long period of time. Store in a cool, dark place. ≥Do not heat or expose to flame. ≥Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with doors and windows closed. WARNING If any electrolyte should come into contact with your hands or clothes, wash it off thoroughly with water. If any electrolyte should come into contact with your eyes, never rub the eyes. Rinse eyes thoroughly with water, and then consult a doctor. <For USA-California only> This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material s special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate . CAUTION SC-HTB350_RQT9670_mst.book Page 2 Tuesday, December 20, 2011 2:05 PM RQT9670 3 Precautions THE FOLLOWING APPLIES ONLY IN THE U.S.A. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This product is restricted to indoor use due to its operation in the 5.150 GHz to 5.250 GHz and 5.725 GHz to 5.850 GHz frequency range. FCC require this product to be used indoors for the frequency range 5.150 GHz to 5.250 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 GHz to 5.35 GHz and 5.65 GHz to 5.85 GHz bands. These radar stations can cause interference with and/or damage this product. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy that is deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated keeping the radiator at least 20 cm (7 7 / 8q) or more away from person’s body (excluding…

Text truncated - open the document above for the full version.

AVSG-11-F003 FCC ID: ACJ-11AT1201 January 5, 2012 CRT-FCC TCB-04.01 Rev01 May2011 Page1 of7 T ÜV SÜD PSB PTE LTD TELECOMMUNICATIONS CERTIFICATION BODY FOR FEDERAL COMMUNICATIONS COMMISSION (TCB-FCC) APPLICATION FORM A. APPLICANT DETAIL (GRANT HOLDER) Company Name:Panasonic Corporation of North America Address:One Panasonic Way Panazip 4B-8 Secaucus, NJ 07094, USA Contact Name:Richard Mullen Telephone:+201 348 7758 E-mail Address:[email protected] FCC Grantee Code: ACJ B. CUSTOMER (Main Point of Contact) Company Name:Panasonic AVC Networks Singapore Pte. Ltd. Address:202, Bedok South Avenue 1, Singapore 469332 Contact Name:Vincent Yee Hong Pak Telephone:+65 62401891 E-mail Address:[email protected] FCC Grantee Code: ACJ B. PRODUCT DETAIL FCC ID: ACJ-11AT1201 DESCRIPTION OF PRODUCT AS IT IS MARKETED: Description: Home Theater Audio System Applicable Main Unit Model Numbers SU-HTB550 and SU-HTB350 Application is for: Original Equipment Class II permissive change or modification of presently authorized equipment Class III permissive change to software defined radio AVSG-11-F003 FCC ID: ACJ-11AT1201 January 5, 2012 CRT-FCC TCB-04.01 Rev01 May2011 Page2 of7 C . COMPANY·S DECLARATION We, (i) have read and accept the Term and Conditions governing under Testing and Certification Regulations TÜV SÜD Group, General Terms and Conditions of Business of TÜV SÜD PSB Pte Ltd, and also TÜV SÜD PSB Pte Ltd TCB-FCC Scheme Factsheet. (ii) Agree to inform TÜV SÜD PSB of any changes to the information submitted For more information on Terms and Condition, please refer to TÜV SÜD website: NAME AND TITLE OF APPLICANT (PLEASE PRINT OR TYPE): Richard Mullen/ Group Manager SIGNATURE OF APPLICANT: Richard Mullen DATE: January 5, 2012

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division Letter of Attorney January 5, 2012 AVSG-11-F003 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD. 21046 To Whom It May Concern: Panasonic Corporation of North America hereby authorizes TUV SUD PSB Pte Ltd to act as our testing facility, FCC agent and TCB for our Certification application for a one year period from the date of this letter. This Home Theater Audio System, Main unit has built-in 2.4GHz Bluetooth Transmitter, which is in compliance with FCC Part 15C, Section 15.247; and 5GHz U-NII Transmitter, which is in compliance with FCC Part 15E, Section 15.401. Product Name: Home Theater Audio System Main Unit Models SU-HTB350 and SU-HTB550 FCC ID: ACJ-11AT1201 Product Specification: 2.4GHz Bluetooth Transmitter / 2402~2480 MHz 5 GHz U-NII Transmitter / 5180~5240 MHz and 5745~5825 MHz Applicant & Grantee: Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094 FRN Number: 0003762242 Responsible Factory: Panasonic AVC Networks Singapore Pte Ltd 202 Bedok South Avenue 1 Singapore 469332 We certify that we are not subject to denial of federal benefits that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Sincerely, Richard Mullen Richard Mullen Group Manager Product Safety & Compliance Division Cc: Irene Tan / PAVCSG (Panasonic AVC Networks Singapore Pte Ltd.)

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division Request for Confidentiality January 5, 2012 AVSG-11-F003 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD. 21046 Re: Request for Confidentiality for Home Theater Audio System, Main Unit Models SU-HTB350 and SU-HTB550 FCC ID: ACJ-11AT1201 To Whom It May Concern: In accordance with provisions of Sections 0.457 and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for the below indicated exhibits. This transmitter is not user adjustable and does not have user tune-up procedure. These exhibits contain proprietary, confidential and/or trade secret materials, which would not be routinely made available for public inspection. • Schematic Diagram • Block Diagram • Parts List • Theory of Operation / Operational Descriptions In accordance with FCC Public DA 04-1705, we request forty-five day short-term confidentiality, starting from the issuance of equipment authorization date, for the below indicated exhibits. These exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. • External Photographs • Internal Photographs • Test Setup Photographs and Test Setup Configuration • User Manual. The above materials contain trade secrets and proprietary information not customarily released to the general public. Since this design is a basis from which future technological products will evolve, the public disclosure of these materials can be harmful to the Applicant by providing unfair advantage and benefits to its competitors. Thank you for your attention to this matter. Sincerely, Richard Mullen Richard Mullen Group Manager Product Safety & Compliance Division

FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Front View Rear View

FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Label and Location SU-HTB350 REAR PANEL PRINTING: SU-HTB550 REAR PANEL PRINTING:

FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Internal View FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Main-BoardPCB Component Side FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Main-BoardPCB Trace Side FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 D-Amp BoardPCB Component Side FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 D-Amp BoardPCB Trace Side FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Power SupplyPCB Component Side FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Power SupplyPCB Trace Side FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Front PanelPCB Component Side FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 Front PanelPCB Trace Side FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 BLUETOOTH MODULE Bluetooth Module Component Side Bluetooth ModuleTrace Side RF ModuleAntenna FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 5GHz MODULE 5GHzModule Component Side (with RF Shield Removed) 5GHz ModuleTraceSide RF Module Antenna 0 Antenna 1 FCC ID: ACJ-11AT1201 Model: SU-HTB550 & SU-HTB350 5GHz MODULE Tx Module Slot PCBComponent Side Tx Module Slot PCBTraceSide

Test Report No. 7191020377-EEC11/08 dated 03 Jan 2012 Note: This report is issued subject to the Testing and Certification Regulations of the TÜV SÜDGroup and the General Terms and Conditions of Business of TÜV SÜD PSB Pte Ltd. In addition, this report is governed by the terms set out within this report. LA-2007-0380-A LA-2007-0381-F LA-2007-0382-B LA-2007-0383-G LA-2007-0384-G LA-2007-0385-E LA-2007-0386-C LA-2010-0464-D The results reported herein have been performed in accor dance with the laboratory’s terms of accreditation under the Singapore Accreditation Council - Singapore Laboratory Accreditation Scheme. Tests/Calibrations marked "Not SAC-SINGLAS Accredited" in this Report are not included in the SAC- SINGLAS Accreditation Schedule for our laboratory. Laboratory: TÜV SÜD PSB Pte. Ltd. No.1 Science Park Drive Singapore 118221 Phone : +65-6885 1333 Fax : +65-6776 8670 E-mail: [email protected] www.tuv-sud-psb.sg Co. Reg : 199002667R Regional Head Office: TÜV SÜD Asia Pacific Pte. Ltd. 3 Science Park Drive, #04-01/05 The Franklin, Singapore 118223 Page 1 of 16 TEST FACILITY TÜV SÜD PSB Pte Ltd, Electrical & Electronics Centre (EEC), Product Services, No. 1 Science Park Drive, Singapore 118221 FCC REG. NO. 99142 (3m and 10m Semi-Anechoic Chamber, Science Park) IND. CANADA REG. NO. 2932I-1 (3m and 10m Semi-Anechoic Chamber, Science Park) PREPARED FOR Panasonic AVC Networks (S) Pte Ltd 202, Bedok South Avenue 1, Singapore 469332 Tel : (+65) 6240 1891Fax : (+65) 6245 8804 QUOTATION NUMBER 219140675 JOB NUMBER 7191020377 TEST PERIOD 14 Nov 2011 – 03 Jan 2012 PREPARED BYAPPROVED BY ____________________ Quek Keng Huat Associate Engineer ____________________ Lim Cher Hwee Assistance Vice President FORMAL REPORT ON TESTING IN ACCORDANCE WITH 47 CFR FCC Parts 15B & C & E: 2011 OF A HOME THEATER AUDIO SYSTEM [ Model : SU-HTB550 & SU-HTB350 ] [ FCC ID : ACJ-11AT1201 ] Panasonic AVC Networks (S) Pte LtdPage 2 of 16 Home Theater Audio System [ Model : SU-HTB550 & SU-HTB350 ] [ FCC ID : ACJ-11AT1201 ] Test Report No. 7191020377-EEC11/07 dated 03 Jan 2012 TABLE OF CONTENTS TEST SUMMARY PRODUCT DESCRIPTION SUPPORTING EQUIPMENT DESCRIPTION EUT OPERATING CONDITIONS MAXIMUM CONDUCTED OUTPUT POWER TEST MAXIMUM PERMISSIBLE EXPOSURE (MPE) TEST ANNEX B- FCC LABEL & POSITION ANNEX C- USER MANUAL, TECHNICAL DESCRIPTION, BLOCK & CIRCUIT DIAGRAMS Panasonic AVC Networks (S) Pte LtdPage 3 of 16 Home Theater Audio System [ Model : SU-HTB550 & SU-HTB350 ] [ FCC ID : ACJ-11AT1201 ] Test Report No. 7191020377-EEC11/07 dated 03 Jan 2012 TEST SUMMARY The product was tested in accordance with the customer's specifications. Test Results Summary Test StandardDescriptionPass / Fail 47 CFR FCC Part 15: 2011 15.247(b)(3), 15.407(a)Maximum Conducted Output PowerPass 1.1310Maximum Permissible Exposure Pass Panasonic AVC Networks (S) Pte LtdPage 4 of 16 Home Theater Audio System [ Model : SU-HTB550 & SU-HTB350 ] [ FCC ID : ACJ-11AT1201 ] Test Report No. 7191020377-EEC11/07 dated 03 Jan 2012 TEST SUMMARY Notes 1. Three channels as listed below, which respectively represent the lower, middle and upper channels of the Equipment Under Test (EUT) were chosen and tested. For each channel, the EUT was configured to operate in the test mode. Transmit Channel Frequency (GHz) Lower Band (5150GHz – 5250GHz) Channel 05.180 Channel 25.220 Channel 35.240 Upper Band (5725GHz – 5825GHz) Channel 45.745 Channel 65.785 Channel 85.825 2. The EUT is a Class B device when in non-transmitting state and meets the 47 CFR FCC Part15B Class B requirements. 3. All test measurement procedures are according to ANSI C63.4: 2003. 4. The maximum measured RF power of the Equipment Under Test (SU-HTB550) is 15.0dBm. 5. The EUT was tested in continuous transmission mode; ie 0dB duty cycle. 6. Panasonic AVC Networks Singapore Pte Ltd declared that the modelsSC-HTB550, SC-HTB450, SC- HTB350 & SC-HTB351 are using the same RF module and identical in term of components, circuitry design, PCB layouts and mechanical structures. The modelSC-HTB550 is the worst case model among the declared models in view of RF and EMC performance. Shall the modelSC-HTB550 passes the RF and EMC test, the declared modelsSC-HTB450, SC-HTB350 & SC-HTB351 are deemed to meet the same requirements. See below tables for the differences: Basic model Similar model Similar model Similar model Similar model SC-HTB550 US SC-HTB550 Canada SC-HTB450 Canada SC-HTB350 US SC-HTB351 US Main UnitSU-HTB550 SU-HTB550 SU-HTB450 SU-HTB350 SU-HTB350 HDMI InputYes (2X)Yes (2X)Yes (2X)NoNo HDMI Output YesYesYesNoNo Analog Input NoNoNoYes (Stereo) Yes (Stereo) Function Indicator 8 LEDS8 LEDS8 LEDS7 LEDS7 LEDS Active Subwoofer SB-HWA550 SB-HWA550 SB-HWA450 SB-HWA350 SB-HWA350 Wooden Box GlossyGlossyMattMattMatt Front Speaker SB-HTB550SB-HTB550SB-HTB350SB-HTB350SB-HTB350 Metal MeshAnodizingAnodizingED Coating ED CoatingED Coating Panasonic AVC Networks (S) Pte LtdPage 5 of 16 Home Theater Audio System [ Model : SU-HTB550 & SU-HTB350 ] [ FCC ID : ACJ-11AT1201 ] Test Report No. 7191020377-EEC11/07 dated 03 Jan 2012 TEST SUMMARY Notes (Continued) MAIN UNI…
