ACJ-11GR1202COMPACT STEREO SYSTEM

RQT9655-P until 2012/03/09 Owner’s Manual Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Please keep this manual for future reference. If you have any questions, contact: U.S.A. and Puerto Rico: 1-800-211-PANA (7262) Canada: 1-800-561-5505 Compact Stereo System Model No. SC-AP01 La referencia rápida en español se puede encontrar en la página 14-16. PPC SC-AP01PPC~RQT9655.book 1 ページ ２０１２年２月２日 木曜日 午後１０時４２分 2 RQT9655 IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference. 1Read these instructions. 2Keep these instructions. 3Heed all warnings. 4Follow all instructions. 5Do not use this apparatus near water. 6Clean only with dry cloth. 7Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11 Only use attachments/accessories specified by the manufacturer. 12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. 13 Unplug this apparatus during lightning storms or when unused for long periods of time. 14 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Unit ≥To reduce the risk of fire, electric shock or product damage, – Do not expose this unit to rain, moisture, dripping or splashing. – Do not place objects filled with liquids, such as vases, on this unit. – Use only the recommended accessories. – Do not remove covers. – Do not repair this unit by yourself. Refer servicing to qualified service personnel. AC adaptor ≥Install this unit so that the AC adaptor can be unplugged from the socket outlet immediately if any problem occurs. Unit ≥Do not place sources of naked flames, such as lighted candles, on this unit. Placement ≥To reduce the risk of fire, electric shock or product damage, – Do not install or place this unit in a bookcase, built-in cabinet or in another confined space. Ensure this unit is well ventilated. – Do not obstruct this unit’s ventilation openings with newspapers, tablecloths, curtains, and similar items. AC adaptor This AC adaptor operates on AC between 100 V and 240 V. But ≥In the U.S.A. and Canada, the AC adaptor must be connected to a 120V AC power supply only. ≥When connecting to an AC supply outside of the U.S.A. or Canada, use a plug adaptor to suit the AC outlet configuration. WARNING CAUTION Product Identification Marking is located on the bottom of the unit. SC-AP01PPC~RQT9655.book 2 ページ ２０１２年２月２日 木曜日 午後１０時４２分 3 RQT9655 Unit care Pull out the AC adaptor from the outlet before maintenance. ∫Clean this unit with a soft, dry cloth ≥When dirt is heavy, wring a cloth moistened in water tightly to wipe the dirt, and then wipe it with a dry cloth. ≥When cleaning the speaker covers, use a fine cloth. Do not use tissues or other materials (towels, etc.) that can fall apart. Small grains may get stuck inside the speaker cover. ≥Never use alcohol, paint thinner or benzine to clean this unit. ≥Before using chemically treated cloth, carefully read the instructions that came with the cloth. ∫To dispose or transfer this unit The unit may keep the user settings information in the unit. If you discard this unit either by disposal or transfer, then follow the procedure to return all the settings to the factory presets to delete the user settings. (>12, “To return all settings to the factory preset”) ≥The operation history may be recorded in the memory of this unit. Licenses Table of contents IMPORTANT SAFETY INSTRUCTIONS ............ 2 Accessories ....................................................... 3 Unit care............................................................. 3 Licenses............................................................. 3 About this product ............................................ 4 Control reference guide.................................... 4 Connection ........................................................ 4 Charging from the USB port ............................ 5 Network settings ............................................... 5 Using the remote control app .......................... 9 Others............................................................... 11 Troubleshooting .............................................. 12 Specifications.................................................. 13 Spanish Quick Reference / Referencia rápida en español Conexiones...................................................... 14 Network settings ............................................. 14 Limited Warranty (ONLY FOR U.S.A. AND PUERTO RICO) ................................................ 18 Limited Warranty (ONLY FOR CANADA)....... 19 Accessory AirPlay, the AirPlay logo, iPad, iPhone, and iPod touch are trademarks of Apple Inc., registered in…

Text truncated - open the document above for the full version.

RQT9655-P until 2012/03/09 Owner’s Manual Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Please keep this manual for future reference. If you have any questions, contact: U.S.A. and Puerto Rico: 1-800-211-PANA (7262) Canada: 1-800-561-5505 Compact Stereo System Model No. SC-AP01 La referencia rápida en español se puede encontrar en la página 14-16. PPC SC-AP01PPC~RQT9655.book 1 ページ ２０１２年２月２日 木曜日 午後１０時４２分 2 RQT9655 IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference. 1Read these instructions. 2Keep these instructions. 3Heed all warnings. 4Follow all instructions. 5Do not use this apparatus near water. 6Clean only with dry cloth. 7Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11 Only use attachments/accessories specified by the manufacturer. 12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. 13 Unplug this apparatus during lightning storms or when unused for long periods of time. 14 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Unit ≥To reduce the risk of fire, electric shock or product damage, – Do not expose this unit to rain, moisture, dripping or splashing. – Do not place objects filled with liquids, such as vases, on this unit. – Use only the recommended accessories. – Do not remove covers. – Do not repair this unit by yourself. Refer servicing to qualified service personnel. AC adaptor ≥Install this unit so that the AC adaptor can be unplugged from the socket outlet immediately if any problem occurs. Unit ≥Do not place sources of naked flames, such as lighted candles, on this unit. Placement ≥To reduce the risk of fire, electric shock or product damage, – Do not install or place this unit in a bookcase, built-in cabinet or in another confined space. Ensure this unit is well ventilated. – Do not obstruct this unit’s ventilation openings with newspapers, tablecloths, curtains, and similar items. AC adaptor This AC adaptor operates on AC between 100 V and 240 V. But ≥In the U.S.A. and Canada, the AC adaptor must be connected to a 120V AC power supply only. ≥When connecting to an AC supply outside of the U.S.A. or Canada, use a plug adaptor to suit the AC outlet configuration. WARNING CAUTION Product Identification Marking is located on the bottom of the unit. SC-AP01PPC~RQT9655.book 2 ページ ２０１２年２月２日 木曜日 午後１０時４２分 3 RQT9655 Unit care Pull out the AC adaptor from the outlet before maintenance. ∫Clean this unit with a soft, dry cloth ≥When dirt is heavy, wring a cloth moistened in water tightly to wipe the dirt, and then wipe it with a dry cloth. ≥When cleaning the speaker covers, use a fine cloth. Do not use tissues or other materials (towels, etc.) that can fall apart. Small grains may get stuck inside the speaker cover. ≥Never use alcohol, paint thinner or benzine to clean this unit. ≥Before using chemically treated cloth, carefully read the instructions that came with the cloth. ∫To dispose or transfer this unit The unit may keep the user settings information in the unit. If you discard this unit either by disposal or transfer, then follow the procedure to return all the settings to the factory presets to delete the user settings. (>12, “To return all settings to the factory preset”) ≥The operation history may be recorded in the memory of this unit. Licenses Table of contents IMPORTANT SAFETY INSTRUCTIONS ............ 2 Accessories ....................................................... 3 Unit care............................................................. 3 Licenses............................................................. 3 About this product ............................................ 4 Control reference guide.................................... 4 Connection ........................................................ 4 Charging from the USB port ............................ 5 Network settings ............................................... 5 Using the remote control app .......................... 9 Others............................................................... 11 Troubleshooting .............................................. 12 Specifications.................................................. 13 Spanish Quick Reference / Referencia rápida en español Conexiones...................................................... 14 Network settings ............................................. 14 Limited Warranty (ONLY FOR U.S.A. AND PUERTO RICO) ................................................ 18 Limited Warranty (ONLY FOR CANADA)....... 19 Accessory AirPlay, the AirPlay logo, iPad, iPhone, and iPod touch are trademarks of Apple Inc., registered in…

Text truncated - open the document above for the full version.

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division Power of Attorney February 6, 2012 AVSG-12-F001 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To Whom It May Concern: Panasonic Corporation of North America hereby authorizes TUV SUD PSB Pte Ltd to act as our testing facility, FCC agent and TCB for our Certification application for a one year period from the date of this letter. This Compact Stereo System with built-in WLAN is being submitted for TCB Certification approval in compliance with FCC Part 15C and Section 15.247. Product Name: Compact Stereo System, Model SC-AP01 with built-in WLAN, Type CX870 FCC ID: ACJ-11GR1202 FCC Rule Part / Type Equip: FCC Part 15C, Section 15.247 / Digital Transmission System Transmitter Specification: 2412~2464 MHz WLAN / IEEE 802.11b/g Conformity Rated RF Output: Maximum Peak Conducted RF Output Power is 190 mW Antenna: Sheet Metal Pattern Antenna with 0.35 dBi antenna gain Power Supply: AC Adaptor, Model RFEA228C-AG Input AC 100~240V, 50/60 Hz / Output DC 12V, 3A RF Exposure Evaluation: This transmitter is intended for mobile operation in uncontrolled environments and satisfies RF Exposure Evaluation with calculated maximum permissive exposure. The Operating Instructions is provide with warning notice regarding recommended minimum 20 cm spacing must be provided between antenna and person’s body and must not be co-located or used with another antenna or transmitter. Applicant & Grantee: Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094 FRN Number: 0003762242 Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division February 6, 2012 AVSG-12-F001 We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. This Certification application has not been submitted to any other TCB for Certification. Thank you for your attention to this matter. Sincerely, Richard Mullen Richard Mullen Group Manager Product Safety & Compliance Division

FCC ID: ACJ-11GR1202 External Photo EUT PHOTOGRAPHS Front View Rear View FCC ID: ACJ-11GR1202 External Photo EUT ADAPTOR PHOTOGRAPHS Front View RearView

FCC ID: ACJ-11GR1202 External Photo EUT PHOTOGRAPHS Front View Rear View FCC ID: ACJ-11GR1202 External Photo EUT ADAPTOR PHOTOGRAPHS Front View RearView

FCC ID: ACJ-11GR1202 Label and Location Sample Label Physical Location of FCC Label on EUT

FCC ID: ACJ-11GR1202 Label and Location Sample Label Physical Location of FCC Label on EUT

FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Internal View FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Ma in-BoardPCB Component Side FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Main-BoardPCB Trace Side FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS USB-DC BoardPCB Component Side FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS U SB-DC BoardPCB TraceSide FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Air-Play BoardPCB Component Side(RF Module) FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Air-Play BoardPCBTraceSide(RF Module) FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS RF Module Circuit with RF Shield Removed FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS LED BoardPCBComponent Side FCC ID: ACJ-11GR1202 Internal Photo LED BoardPCB Trace Side

FCC ID: ACJ-11GR1202 Internal Photo RF module EUT PHOTOGRAPHS Air-Play BoardPCB Component Side(RF Module) FCC ID: ACJ-11GR1202 Internal Photo RF module EUT PHOTOGRAPHS Air-Play BoardPCBTraceSide(RF Module) FCC ID: ACJ-11GR1202 Internal Photo RF module EUT PHOTOGRAPHS RF Module Circuit with RF Shield Removed

FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Internal View FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Ma in-BoardPCB Component Side FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Main-BoardPCB Trace Side FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS USB-DC BoardPCB Component Side FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS U SB-DC BoardPCB TraceSide FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Air-Play BoardPCB Component Side(RF Module) FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS Air-Play BoardPCBTraceSide(RF Module) FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS RF Module Circuit with RF Shield Removed FCC ID: ACJ-11GR1202 Internal Photo EUT PHOTOGRAPHS LED BoardPCBComponent Side FCC ID: ACJ-11GR1202 Internal Photo LED BoardPCB Trace Side

Test Report No. 7191024569-EEC12/01 dated 01 Feb 2012 Note: This report is issued subject to the Testing and Certification Regulations of the TÜV SÜDGroup and the General Terms and Conditions of Business of TÜV SÜD PSB Pte Ltd. In addition, this report is governed by the terms set out within this report. LA-2007-0380-A LA-2007-0381-F LA-2007-0382-B LA-2007-0383-G LA-2007-0384-G LA-2007-0385-E LA-2007-0386-C LA-2010-0464-D The results reported herein have been performed in accor dance with the laboratory’s terms of accreditation under the Singapore Accreditation Council - Singapore Laboratory Accreditation Scheme. Tests/Calibrations marked "Not SAC-SINGLAS Accredited" in this Report are not included in the SAC- SINGLAS Accreditation Schedule for our laboratory. Laboratory: TÜV SÜD PSB Pte. Ltd. No.1 Science Park Drive Singapore 118221 Phone : +65-6885 1333 Fax : +65-6776 8670 E-mail: [email protected] www.tuv-sud-psb.sg Co. Reg : 199002667R Regional Head Office: TÜV SÜD Asia Pacific Pte. Ltd. 3 Science Park Drive, #04-01/05 The Franklin, Singapore 118223 Page 1 of 151 FORMAL REPORT ON TESTING IN ACCORDANCE WITH 47 CFR FCC Parts 15B & C : 2011 OF A COMPACT STEREO SYSTEM [ Model : SC-AP01 ] [ FCC ID : ACJ-11GR1202 ] TEST FACILITY TÜV SÜD PSB Pte Ltd, Electrical & Electronics Centre (EEC), Product Services, No. 1 Science Park Drive, Singapore 118221 TÜV SÜD PSB Pte Ltd, Electrical & Electronics Centre (EEC), Product Services, 13 Internatonal Business Park #01-01, Singapore 609932 FCC REG. NO. 99142 (3m and 10m Semi-Anechoic Chamber, Science Park) 160581 (3m and 10m Semi-Anechoic Chamber, International Business Park) IND. CANADA REG. NO. 2932I-1 (3m and 10m Semi-Anechoic Chamber, Science Park) 2932N-1 (10m Semi-Anechoic Chamber, International Business Park) PREPARED FOR Panasonic AVC Networks (S) Pte Ltd 202, Bedok South Avenue 1, Singapore 469332 Tel : +65 6240 1891Fax : +65 6245 8804 QUOTATION NUMBER 219143816 JOB NUMBER 7191024569 TEST PERIOD 12 Jan 2012 – 19 Jan 2012 PREPARED BYAPPROVED BY ____________________ Quek Keng Huat Associate Engineer ____________________ Lim Cher Hwee Assistant Vice President Panasonic AVC Networks (S) Pte LtdPage 2 of 151 Compact Stereo System [ Model : SC-AP01 ] [ FCC ID : ACJ-11GR1202 ] Test Report No. 7191024569-EEC12/01 dated 01 Feb 2012 TABLE OF CONTENTS TEST SUMMARY ........................................................................................................................................ 3 PRODUCT DESCRIPTION .......................................................................................................................... 5 SUPPORTING EQUIPMENT DESCRIPTION ............................................................................................... 6 EUT OPERATING CONDITIONS ................................................................................................................. 7 CONDUCTED EMISSION TEST .................................................................................................................. 8 RADIATED EMISSION TEST ..................................................................................................................... 13 SPECTRUM BANDWIDTH (6dB BANDWIDTH MEASUREMENT) TEST ................................................... 20 MAXIMUM PEAK POWER TEST ............................................................................................................... 47 RF CONDUCTED SPURIOUS EMISSIONS TEST ..................................................................................... 50 BAND EDGE COMPLIANCE (CONDUCTED) TEST................................................................................... 94 BAND EDGE COMPLIANCE (RADIATED) TEST ..................................................................................... 112 PEAK POWER SPECTRAL DENSITY TEST ............................................................................................ 119 ANNEX A EUT PHOTOGRAPHS / DIAGRAMS ....................................................................................... 148 ANNEX B USER MANUALTECHNICAL DESCRIPTION BLOCK & CIRCUIT DIAGRAMS ........................ 149 ANNEX C FCC LABEL & POSITION ........................................................................................................ 150 Panasonic AVC Networks (S) Pte LtdPage 3 of 151 Compact Stereo System [ Model : SC-AP01 ] [ FCC ID : ACJ-11GR1202 ] Test Report No. 7191024569-EEC12/01 dated 01 Feb 2012 TEST SUMMARY The product was tested in accordance with the customer's specifications. Test Results Summary Test StandardDescriptionPass / Fail 47 CFR FCC Part 15: 2011 15.107(a), 15.207Conducted EmissionsPass 15.109(a), 15.205, 15.209Radiated Emissions (Spurious Emissions inclusive Restricted Bands Requirement) Pass 15.247(a)(2)Spectrum Bandwidth (6dB Bandwidth Measurement) Pass 15.247(b)(3)Maximum Peak PowerPass 15.247(d)RF Conducted Spurious EmissionsPass 15.247(d)Band Edge Compliance (Conducted)Pass 15.247(d)Band Edge Compliance (Radiated)Pass 15.247(e)Peak Power Spectral DensityPass 1.1310Maximum Permissible Exposure Pass 15.35(c)Duty Cycle Factor ComputationRefer to Note 6 Panasonic AVC Networks (S) Pte LtdPage 4 of 151 Compact Stereo System [ Model : SC-AP01 ] [ FCC ID : ACJ-11GR1202 ] Test Report No. 7191024569-EEC12/01 dated 01 Feb 2012 TEST SUMMARY Notes 1. The channels as listed below, under the different configurations were tested for Wi-Fi 802.11b. Transmit Channel Frequency (GHz)ModulationData Rate Channel 12.412DBPSK1Mbps Channel 62.437DBPSK1Mbps Channel 112.462DBPSK1Mbps Channel 12.412DQPSK2Mbps Channel 62.437DQPSK2Mbps Channel 112.462DQPSK2Mbps Channel 12.412CCK11Mbps Channel 62.437CCK11Mbps Channel 112.462CCK11Mbps 2. The channels as listed below, under the different configurations were tested for Wi-Fi 802.11g. Transmit ChannelFrequency (GHz)ModulationData Rate Channel 12.412BPSK9Mbps Channel 62.437BPSK9Mbps Channel 112.462BPSK9Mbps Channel 12.412QPSK18Mbps Channel 62.437QPSK18Mbps Channe…

Text truncated - open the document above for the full version.

Test Report No. 7191024569-EEC12/01 dated 01 Feb 2012 Note: This report is issued subject to the Testing and Certification Regulations of the TÜV SÜDGroup and the General Terms and Conditions of Business of TÜV SÜD PSB Pte Ltd. In addition, this report is governed by the terms set out within this report. LA-2007-0380-A LA-2007-0381-F LA-2007-0382-B LA-2007-0383-G LA-2007-0384-G LA-2007-0385-E LA-2007-0386-C LA-2010-0464-D The results reported herein have been performed in accor dance with the laboratory’s terms of accreditation under the Singapore Accreditation Council - Singapore Laboratory Accreditation Scheme. Tests/Calibrations marked "Not SAC-SINGLAS Accredited" in this Report are not included in the SAC- SINGLAS Accreditation Schedule for our laboratory. Laboratory: TÜV SÜD PSB Pte. Ltd. No.1 Science Park Drive Singapore 118221 Phone : +65-6885 1333 Fax : +65-6776 8670 E-mail: [email protected] www.tuv-sud-psb.sg Co. Reg : 199002667R Regional Head Office: TÜV SÜD Asia Pacific Pte. Ltd. 3 Science Park Drive, #04-01/05 The Franklin, Singapore 118223 Page 1 of 151 FORMAL REPORT ON TESTING IN ACCORDANCE WITH 47 CFR FCC Parts 15B & C : 2011 OF A COMPACT STEREO SYSTEM [ Model : SC-AP01 ] [ FCC ID : ACJ-11GR1202 ] TEST FACILITY TÜV SÜD PSB Pte Ltd, Electrical & Electronics Centre (EEC), Product Services, No. 1 Science Park Drive, Singapore 118221 TÜV SÜD PSB Pte Ltd, Electrical & Electronics Centre (EEC), Product Services, 13 Internatonal Business Park #01-01, Singapore 609932 FCC REG. NO. 99142 (3m and 10m Semi-Anechoic Chamber, Science Park) 160581 (3m and 10m Semi-Anechoic Chamber, International Business Park) IND. CANADA REG. NO. 2932I-1 (3m and 10m Semi-Anechoic Chamber, Science Park) 2932N-1 (10m Semi-Anechoic Chamber, International Business Park) PREPARED FOR Panasonic AVC Networks (S) Pte Ltd 202, Bedok South Avenue 1, Singapore 469332 Tel : +65 6240 1891Fax : +65 6245 8804 QUOTATION NUMBER 219143816 JOB NUMBER 7191024569 TEST PERIOD 12 Jan 2012 – 19 Jan 2012 PREPARED BYAPPROVED BY ____________________ Quek Keng Huat Associate Engineer ____________________ Lim Cher Hwee Assistant Vice President Panasonic AVC Networks (S) Pte LtdPage 2 of 151 Compact Stereo System [ Model : SC-AP01 ] [ FCC ID : ACJ-11GR1202 ] Test Report No. 7191024569-EEC12/01 dated 01 Feb 2012 TABLE OF CONTENTS TEST SUMMARY ........................................................................................................................................ 3 PRODUCT DESCRIPTION .......................................................................................................................... 5 SUPPORTING EQUIPMENT DESCRIPTION ............................................................................................... 6 EUT OPERATING CONDITIONS ................................................................................................................. 7 CONDUCTED EMISSION TEST .................................................................................................................. 8 RADIATED EMISSION TEST ..................................................................................................................... 13 SPECTRUM BANDWIDTH (6dB BANDWIDTH MEASUREMENT) TEST ................................................... 20 MAXIMUM PEAK POWER TEST ............................................................................................................... 47 RF CONDUCTED SPURIOUS EMISSIONS TEST ..................................................................................... 50 BAND EDGE COMPLIANCE (CONDUCTED) TEST................................................................................... 94 BAND EDGE COMPLIANCE (RADIATED) TEST ..................................................................................... 112 PEAK POWER SPECTRAL DENSITY TEST ............................................................................................ 119 ANNEX A EUT PHOTOGRAPHS / DIAGRAMS ....................................................................................... 148 ANNEX B USER MANUALTECHNICAL DESCRIPTION BLOCK & CIRCUIT DIAGRAMS ........................ 149 ANNEX C FCC LABEL & POSITION ........................................................................................................ 150 Panasonic AVC Networks (S) Pte LtdPage 3 of 151 Compact Stereo System [ Model : SC-AP01 ] [ FCC ID : ACJ-11GR1202 ] Test Report No. 7191024569-EEC12/01 dated 01 Feb 2012 TEST SUMMARY The product was tested in accordance with the customer's specifications. Test Results Summary Test StandardDescriptionPass / Fail 47 CFR FCC Part 15: 2011 15.107(a), 15.207Conducted EmissionsPass 15.109(a), 15.205, 15.209Radiated Emissions (Spurious Emissions inclusive Restricted Bands Requirement) Pass 15.247(a)(2)Spectrum Bandwidth (6dB Bandwidth Measurement) Pass 15.247(b)(3)Maximum Peak PowerPass 15.247(d)RF Conducted Spurious EmissionsPass 15.247(d)Band Edge Compliance (Conducted)Pass 15.247(d)Band Edge Compliance (Radiated)Pass 15.247(e)Peak Power Spectral DensityPass 1.1310Maximum Permissible Exposure Pass 15.35(c)Duty Cycle Factor ComputationRefer to Note 6 Panasonic AVC Networks (S) Pte LtdPage 4 of 151 Compact Stereo System [ Model : SC-AP01 ] [ FCC ID : ACJ-11GR1202 ] Test Report No. 7191024569-EEC12/01 dated 01 Feb 2012 TEST SUMMARY Notes 1. The channels as listed below, under the different configurations were tested for Wi-Fi 802.11b. Transmit Channel Frequency (GHz)ModulationData Rate Channel 12.412DBPSK1Mbps Channel 62.437DBPSK1Mbps Channel 112.462DBPSK1Mbps Channel 12.412DQPSK2Mbps Channel 62.437DQPSK2Mbps Channel 112.462DQPSK2Mbps Channel 12.412CCK11Mbps Channel 62.437CCK11Mbps Channel 112.462CCK11Mbps 2. The channels as listed below, under the different configurations were tested for Wi-Fi 802.11g. Transmit ChannelFrequency (GHz)ModulationData Rate Channel 12.412BPSK9Mbps Channel 62.437BPSK9Mbps Channel 112.462BPSK9Mbps Channel 12.412QPSK18Mbps Channel 62.437QPSK18Mbps Channe…

Text truncated - open the document above for the full version.

FCC ID: ACJ-11GR1202 Test setup photo Conducted Emissions Test Setup (Front View) Conducted Emissions Test Setup (Rear View) FCC ID: ACJ-11GR1202 Test setup photo Radiated Emissions Test Setup (Front View) Radiated Emissions Test Setup (Rear View)

FCC ID: ACJ-11GR1202 Test setup photo Conducted Emissions Test Setup (Front View) Conducted Emissions Test Setup (Rear View) FCC ID: ACJ-11GR1202 Test setup photo Radiated Emissions Test Setup (Front View) Radiated Emissions Test Setup (Rear View)
