ACJ-SU-G30Network Audio amplifier

SU-G30 Network Audio AmplifierOwner’s Manual Amplificateur lecteur réseauManuel d’utilisation 03 (03) Music is borderless and timeless, touching people’s hearts across cultures and generations. Each day the discovery of a truly emotive experience from an unencountered sound awaits. Let us take you on your journey to rediscover music. Sans frontières, la musique est aussi intemporelle, touchant le coeur des gens en traversant les cultures et les générations. Tous les jours, nous attendons la révélation d’une expérience émotionnelle authentique à partir d’un son venu de nulle part. Permettez-nous de vous emmener en voyage pour redécouvrir la musique. 04 (04) 05 (05) Delivering the Ultimate Emotive Musical Experience to All At Technics we understand that the listening experience is not purely about technology but the magical and emotional relationship between people and music. We want people to experience music as it was originally intended and enable them to feel the emotional impact that enthuses and delights them. Through delivering this experience we want to support the development and enjoyment of the world’s many musical cultures. This is our philosophy. With a combination of our love of music and the vast high-end audio experience of the Technics team, we stand committed to building a brand that provides the ultimate emotive musical experience by music lovers, for music lovers. Apportez à tous l’expérience musicale empreinte d’émotions Chez Technics, nous savons que l’expérience de l’écoute n’est pas purement et simplement une question de technologie, mais de relation magique entre les personnes et la musique. Nous voulons que tout un chacun puisse ressentir la musique telle qu’elle a été conçue à l’origine et lui permettre de ressentir le choc émotionnel qu’il brûle de connaître. En apportant ce vécu, nous cherchons à accompagner le développement et le plaisir des nombreuses cultures musicales du monde. Telle est notre philosophie. Ici et maintenant, alliant l’amour de la musique et la grande expérience musicale de l’équipe Technics, nous sommes pleinement déterminés à construire une marque qui apporte le vécu musical émotionnel aux fervents de la musique. Director Directeur Michiko Ogawa 06 Thank you for purchasing this product. Please read these instructions carefully before using this product, and save this manual for future use. • About descriptions in this Owner’s Manual - Pages to be referred to are indicated as “ ○○”. - The illustrations shown may differ from your unit. If you have any questions, visit: U.S.A.: http://shop.panasonic.com/support Canada: www.panasonic.ca/english/support Register online at http://shop.panasonic.com/support (U.S. customers only) High-Quality Audio Technologies Employed including JENO Engine and GaN-FET Driver The JENO Engine transmits and processes audio signals in full digital and with minimal jitter from the input stage to the power stage. The GaN- FET Driver performs high-speed switching with minimal loss. The LAPC conducts speaker load adaptive phase calibration to achieve ideal gain and phase characteristics for any type of speaker. Also, the low-distortion switching power supply specifically designed for the SU-G30 which stabilizes the output voltage realizes accurate signal amplification Technics regards as ideal. High-Quality Processing of All Types of Signal Sources Ranging from High-Res Audio Sources to Analog Audio Sources Supporting a diversity of input sources, such as digital audio (DLNA, USB and Bluetooth ® ), iOS devices and analogue audio (Line and Phono), the SU-G30 digitally processes all types of signal sources with the high-quality sound technology developed by Technics. Ideal Sound Quality and Performance Realized by the Integrated Simple Configuration. The SU-G30 features a built-in network audio circuit with thorough measures taken against jitter and noise. It transmits digital audio data through the shortest possible signal path from the music sources all the way to the power stage to pursue uncompromised sound quality with extremely low signal degradation. Features (06) English 07 Table of contents IMPORTANT SAFETY INSTRUCTIONS 09 Please carefully read the “IMPORTANT SAFETY INSTRUCTIONS” of this manual before use. Installation 11 Installation Control reference guide 12 Main unit, Remote control Connections 16 Speaker connection, AC power supply cord connection, Network settings Operations 24 Playing back connected devices Settings 36 Other settings, Using output correction function (LAPC) Troubleshooting 40 Before requesting service, read the troubleshooting. Others 45 Playable media, Specifications, etc. Accessories AC power supply cord (1) K2CG3YY00191 Remote control (1) N2QAYA000115 Batteries for remote control (2) (ONLY FOR CANADA) The enclosed Canadian French label sheet corresponds to the English display on the unit. • Product numbers provided in this Owner’s Manual are correct as of December 2015. • These may be subject to change. • Do not use AC power supply cord with other equipment. (07) 08 Licenses The Wi-Fi CERTIFIED™ Logo is a certification mark of Wi-Fi Alliance ® . The Wi-Fi Protected Setup™ Identifier mark is a certification mark of Wi-Fi Alliance ® . “Wi-Fi ® ” is a registered trademark of Wi-Fi Alliance ® . “Wi-Fi Protected Setup™”, “ W PA™”, and “WPA2™” are trademarks of Wi-Fi Alliance ® . “Made for iPod”, “Made for iPhone”, and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless performance. AirPlay, iPad, iPhone, iPod, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. iPad Air and iPad mini are t…

Text truncated - open the document above for the full version.

Panasonic Corporation 1-15, MATSUO-CHO, KADOMA, OSAKA, 571-8504 JAPAN Antenna Specification (WiFi) Specifications Summary Antenna typeDipole antenna Antenna ModelN/A Antenna TrademarkN/A Antenna ManufactureSANSEI ELECTRIC CO., Ltd. Horizontal Vertical 2400MHz2450MHz2500MHz2400MHz2450MHz2500MHz -3.58 -6.55 -12.69 -1.96-2.24-1.77 -3.96 -4.61-5.46-0.55-1.59-1.57 MAX Gain-0.55dBi Horizontal Vertical 5180MHz5300MHz5500MHz5750MHz5180MHz5300MHz5500MHz5750MHz -14.52 -8.59-4.60-9.36-1.01-1.75-2.26-2.37 -3.45 -3.08-5.77-5.97-0.82-0.07-0.95-0.63 MAX Gain-0.07dBi PolarizationHorizontal and Vertical Azimuth Beam PatternOmni-Directional Impedance50ohm Antenna Length65mm ManufactureSANSEI ELECTRIC CO., Ltd ItemSPEC Center Frequency Antenna1 Antenna2 Center Frequency Antenna1 Antenna2 Panasonic Corporation 1-15, MATSUO-CHO, KADOMA, OSAKA, 571-8504 JAPAN Horizontal5GHz Antenna 1Antenna 2 Max.Max. 51805300 5500 575051805300 5500 5750 -14.52-8. 59-4.60 -9.36 -3.45-3.08-5.77-5.97 Vertical Antenna 1Antenna 2 Max.Max. 51805300 5500 575051805300 5500 5750 -1.01-1. 75-2.26-2.37-0.82-0.07-0.95-0.63 Frequency[MHz] Gain[dBi] Antenna 2 Frequency[MHz] Gain[dBi] Gain[dBi] Frequency[MHz] Antenna 1Antenna 2 Frequency[MHz] Gain[dBi] Antenna 1 Panasonic Corporation 1-15, MATSUO-CHO, KADOMA, OSAKA, 571-8504 JAPAN 2.4GHz Horizontal Antenna 1Antenna 2 240024502500240024502500 -3.58-6.55-12.69-3.96-4.61-5.46 Vertical Antenna 1Antenna 2 Max.Max. 240024502500240024502500 -1.96-2.24-1.77-0.55-1.59-1.57 Max. Gain[dBi] Gain[dBi] Antenna 1 Frequency[MHz] Antenna 1 Frequency[MHz] Frequency[MHz] Gain[dBi] Antenna 2Max. Frequency[MHz] Gain[dBi] Antenna 2 Panasonic Corporation 1-15, MATSUO-CHO, KADOMA, OSAKA, 571-8504 JAPAN Antenna type Internal antenna Antenna Model N/A Antenna Trademark N/A Antenna Manufacture SANSEI ELECTRIC CO., Ltd. HorizontalVertical 2400MHz 2450MHz2500MHz 2400MHz 2450MHz 2500MHz -5.13-4.97-2.76-8.03-8.37-7.21 MAX Gain-2.76dBi Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-Directional Impedance 50ohm Antenna Length 65mm Manufacture N/A ItemSPEC Center Frequency Antenna Specification (Bluetooth) Specifications Panasonic Corporation 1-15, MATSUO-CHO, KADOMA, OSAKA, 571-8504 JAPAN Horizontal 240024502500 -5.13-4.97-2.76 Vertical 240024502500 -8.03-8.37-7.21 Gain[dBi] Frequency[MHz] Gain[dBi] AntennaMax. Frequency[MHz] AntennaMax.

Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Tel/Fax: 201-348-7758 / [email protected] Richard Mullen, Group Manager Product Safety and Compliance Department Request for Confidentiality December 14, 2015 HEG-15-U005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046-1609 Re: Original Certification for Network Audio Amplifier, Model SU-G30 under FCC ID: ACJ-SU-G30 To Whom It May Concern: In accordance with provisions of Sections 0.457 and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for the below indicated exhibits. This transmitter is not user adjustable and the end-user is not provided with any tune-up procedure or parts list. These exhibits contain proprietary, confidential and/or trade secret materials, which would not be routinely made available for public inspection. • Schematic Diagram • Block Diagram • Operational Description In accordance with FCC Public DA 04-1705, we request for 180 days short-term confidentiality 1, starting from the issuance of equipment authorization date, for the below indicated exhibits. These exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. • External Photographs • Internal Photographs • Test Setup Photographs • User Manual The above materials contain trade secrets and proprietary information not customarily released to the general public. Since this design is a basis from which future technological products will evolve, the public disclosure of these materials can be harmful to the Applicant by providing unfair advantage and benefits to its competitors. Thank you for your attention to this matter. Sincerely yours, Richard Mullen Group Manager Panasonic Corporation of North America Product Safety & Compliance Department 1 KDB 726920 D01 v01r01 dated May 5, 2015 allows request for 180 days short-term confidentiality.

Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Tel/Fax: 201-348-7758 / [email protected] Richard Mullen, Group Manager Product Safety and Compliance Department Ad Hoc Mode Function Declaration December 14, 2015 HEG-15-U005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046-1609 Re: Original Certification for Network Audio Amplifier, Model SU-G30 under FCC ID: ACJ-SU-G30 To Whom It May Concern: We, Panasonic Corporation of North America, declare that the subject device does not support any non-US channels and country code selection in all the operational mode(s) for the following product. Thank you for your attention to this matter. Sincerely, Richard Mullen Group Manager Panasonic Corporation of North America Product Safety & Compliance Department

CERTIFICATE OF COMPLIANCE Authorized under Declaration of Conformity according to 47 CFR, Part 2 and Part 15 of the FCC Rules. The product listed in follows was (were) tested in the BTL EMC Laboratory to comply with the criteria limits Class B of conducted and radiated emissions of the Technical Standards FCC Part 15, Subpart B, established by the FCC, USA. Equipment Network Audio amplifie r Model Name SU-G30 Brand Name Technics Applicant Panasonic Corporation of North America Address Two Riverfront Plaza, 9 th Floor Newark New Jersey United States07102-5490 Standard(s) FCC Part 15, Subpart B: 2014 ANSI C63.4-2014 Report(s) BTL-FICE-1-1510C009 A The test data, data evaluation, and equipment configuration contained in our test report(s) above was(were) obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). The test data contained in the referenced test report relate only to the EUT sample and item(s) tested. Andy Chiu Authorized Signatory BTL INC. B1, No. 37, Lane 365, Yang-Guang St., Nei-Hu District, Taipei City 114, Taiwan. TEL:+886-2-2657-3299 FAX:+886-2-2657-3331

Project No.: 1510C009A Page 2 of 33 Project No.: 1510C009A Page 3 of 33 Project No.: 1510C009A Page 4 of 33 Project No.: 1510C009A Page 5 of 33 Project No.: 1510C009A Page 6 of 33 Project No.: 1510C009A Page 7 of 33

印刷内容チェック Contents Check 表示 Indication 新旧 Old/New 合議印 Consent 安全 電気設計 Safety Electrical Outline Layer ; Panasonic Corporation Unit:mm Part Name ; A2 Confidential 秘 手配図面 FINAL ISSUE DRG ～ ～ ～ ～ ～ ～ * 仕様決定後、2次加工仕様書を提出のこと。 * 印刷文字は写真原稿によること。 * 表面処理強度は、検査規格MAS-CQ00A-01を満足すること。 * 表面処理に、にじみ、かすれ、はげ、ピンホール等の外観仕上げは 技術部の承認を得ること。 * 印刷のズレは±0.3、傾きは0.1以下とする。 記事 * パナソニック指定の禁止物質を使用していないこと。 * 化学物質調査データを回答期限までにGP-WEBへ登録（アップロード）のこと。 * 納入荷姿の見やすい場所に｢ロットＮｏ．｣を表示すること。 * ロットＮｏ．表示詳細内容は、工場受入部門と協議し、決定のこと。 * 仕様決定後、2次加工仕様書を提出のこと。 * 印刷文字は写真原稿によること。 * 表面処理強度は、検査規格MAS-CQ00A-01を満足すること。 * 表面処理に、にじみ、かすれ、はげ、ピンホール等の外観仕上げは 技術部の承認を得ること。 * 印刷のズレは±0.3、傾きは0.1以下とする。 記事 * パナソニック指定の禁止物質を使用していないこと。 * 化学物質調査データを回答期限までにGP-WEBへ登録（アップロード）のこと。 * 納入荷姿の見やすい場所に｢ロットＮｏ．｣を表示すること。 * ロットＮｏ．表示詳細内容は、工場受入部門と協議し、決定のこと。 * Printing letters to be followed art work． NOTES * Submit additional processing specification after deciding spec. * Surface finish quality must be kept MAS standard(MAS-CQ00A-01). * Surface finish (bruise,dirt,pinhole etc.) must be approved by Engineering. * Printing offset must be less than 0.3 and slanting must be less than 0.1. * Submission of "Chemical Substance Survey Data" sheet. * Submission of "Content Survey Sheet" for Prohibition-Ranked Substances Level 1 and Level 2". * No using of Prohibited Substances specified by Panasonic are permitted. * Indicating the lot number at an easy-to-find location on an incoming part/material package. * Detail of Lot No. indication content must be determined by discussion with CQA. * Printing letters to be followed art work． NOTES * Submit additional processing specification after deciding spec. * Surface finish quality must be kept MAS standard(MAS-CQ00A-01). * Surface finish (bruise,dirt,pinhole etc.) must be approved by Engineering. * Printing offset must be less than 0.3 and slanting must be less than 0.1. * Submission of "Chemical Substance Survey Data" sheet. * Submission of "Content Survey Sheet" for Prohibition-Ranked Substances Level 1 and Level 2". * No using of Prohibited Substances specified by Panasonic are permitted. * Indicating the lot number at an easy-to-find location on an incoming part/material package. * Detail of Lot No. indication content must be determined by discussion with CQA. Z2RGR0482AC PAVCJM T.YAMASHIROT.YAMASHIROM.MATSUOKAA .O M O RI 21.AUG.2015 HOME ENTERTAINMENT DEVELOPMENT CENTER SECOND DEVELOPMENT DEPARTMENT SIXTH SECTION REAR PANEL PRINTING RGR0482A-C SU-G30PP-S N New Process qt Approved Model Parts No. Name Draw No. Material & Size SectionDie / Note CheckedDrawnDesignedScale Fin Pre Issued Item or Code No.Sym 1 : 1 1 SECC t=1.0 NIPPON EGALV STEEL SECC EQS1(E16/E16) OR SUMITOMO SECC-TIN (NEO COAT) OR NIPPON STEEL EGC-QFK20/20, EGC-QF20/20, EGC-QS20/20 OR GFCC-UZ-NBX-20/20, GEO FRONTIER COAT (NKK) OR KOBE STEEL KOBEZINK GREENCOAT GX DEGREASE, SPRAY COLOR:BLACK SILK SCREEN PRINITNG COLOR:WHITE (SILK SCREEN DETAIL SHALL REFER TO INDIVIDUAL PRINTING DRAWING) SymDateRevision Changed fromSigned Checked Approved SU-G30PP-S Film No. RGR0482A-C Conforms to UL STD 60065 Certified to CAN/CSA STD C22.2 No.60065 Conforme à la norme CAN/CSA C22.2 No.60065 （）（） This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ( 1 ) This device may not cause harmful interference, and ( 2 ) this device must accept any interference received, including interference that may cause undesired operation. Model/Modèle NET WORK AUDIO AMPLIFIER/ AMPLIFICATEUR RÉSEAU AUDIO Panaso nic Corporation Kadoma, Osaka, Japan 10BASE - T / 100BASE - TX LAN PCOPTCOAX2COAX1 PHONO LR LINE IN LR L R DIGITAL IN SER. No. AC IN HAUT-PARLEURS Class 2 Wiring ( 4 W 16Ω ) W120VW96WW60Hz FCC ID: IC: Made in Malaysia/ Fabriqué en Malaisie SPEAKERS

Project No.: 1510C009A Page 8 of 33 Project No.: 1510C009A Page 9 of 33 Project No.: 1510C009A Page 10 of 33 Project No.: 1510C009A Page 11 of 33 Project No.: 1510C009A Page 12 of 33 Project No.: 1510C009A Page 13 of 33 Project No.: 1510C009A Page 14 of 33 Project No.: 1510C009A Page 15 of 33 Project No.: 1510C009A Page 16 of 33 Project No.: 1510C009A Page 17 of 33 Project No.: 1510C009A Page 18 of 33 Project No.: 1510C009A Page 19 of 33 Project No.: 1510C009A Page 20 of 33 Project No.: 1510C009A Page 21 of 33 Project No.: 1510C009A Page 22 of 33 Project No.: 1510C009A Page 23 of 33 Project No.: 1510C009A Page 24 of 33 Project No.: 1510C009A Page 25 of 33 Project No.: 1510C009A Page 26 of 33 Project No.: 1510C009A Page 27 of 33 Project No.: 1510C009A Page 28 of 33 Project No.: 1510C009A Page 29 of 33 Project No.: 1510C009A Page 30 of 33 Project No.: 1510C009A Page 31 of 33 Project No.: 1510C009A Page 32 of 33 Project No.: 1510C009A Page 33 of 33

FCC RF EXPOSURE REPORT FCC ID: ACJ-SU-G30 Project No. : 1510C009A Equipment : Network Audio amplifier Model : SU-G30 Applicant : Panasonic Corporation of North America Address : Two Riverfront Plaza,9th Floor Newark New Jersey United States 07102-5490 According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna 2.4G Ant. Manufacturer Model NameAntenna TypeConnector Gain (dBi) 1 SANSEI ELECTRIC CO.,Ltd. N/A Dipole N/A -1.77 2 SANSEI ELECTRIC CO.,Ltd. N/A Dipole N/A -0.55 5G Ant. Manufacturer Model NameAntenna TypeConnector Gain (dBi) 1 SANSEI ELECTRIC CO.,Ltd. N/A Dipole N/A -1.01 2 SANSEI ELECTRIC CO.,Ltd. N/A Dipole N/A -0.82 TEST RESULTS 2.4G EUT： Network Audio amplifier Model Name : SU-G30 Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX B MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.55 0.8810 13.55 22.6464 0.003971461 Complies -0.55 0.8810 13.85 24.2661 0.004255501 Complies -0.55 0.8810 13.69 23.3884 0.004101571 Complies EUT： Network Audio amplifier Model Name : SU-G30 Temperature： 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode ： TX G MODE /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.55 0.8810 17.76 59.7035 0.010470091 Complies -0.55 0.8810 16.81 47.9733 0.008412991 Complies -0.55 0.8810 16.69 46.6659 0.008183711 Complies EUT： Network Audio amplifier Model Name : SU-G30 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-20M MODE_ Total /CH01, CH06, CH11 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.55 0.8810 17.92 61.9441 0.010863011 Complies -0.55 0.8810 17.31 53.8270 0.009439531 Complies -0.55 0.8810 17.11 51.4044 0.009014681 Complies EUT： Network Audio amplifier Model Name : SU-G30 Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : TX N-40M MODE_ Total /CH03, CH06, CH09 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.55 0.8810 15.19 33.0370 0.005793621 Complies -0.55 0.8810 16.18 41.4954 0.007276971 Complies -0.55 0.8810 16.42 43.8531 0.007690431 Complies UNII-1 EUT： Network Audio amplifier Model Name : SU-G30 Temperature: 24 °C Relative Humidity: 52 % Test Voltage : AC 120V/60Hz Test Mode : TX A MODE /CH36, CH40, CH48 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.82 0.8279 6.54 4.5082 0.000742931 Complies -0.82 0.8279 6.41 4.3752 0.000721031 Complies -0.82 0.8279 6.70 4.6774 0.000770821 Complies EUT： Network Audio amplifier Model Name : SU-G30 Temperature: 24 °C Relative Humidity: 52 % Test Voltage : AC 120V/60Hz Test Mode : TX N20 MODE_ Total /CH36, CH40, CH48 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.82 0.8279 6.63 4.6026 0.000758491 Complies -0.82 0.8279 6.44 4.4055 0.000726021 Complies -0.82 0.8279 6.82 4.8084 0.000792411 Complies EUT： Network Audio amplifier Model Name : SU-G30 Temperature: 24 °C Relative Humidity: 52 % Test Voltage : AC 120V/60Hz Test Mode : TX N40 MODE_Total /CH38, CH46 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.82 0.8279 9.40 8.7096 0.001435331 Complies -0.82 0.8279 9.67 9.2683 0.001527391 Complies UNII-3 EUT： Network Audio amplifier Model Name : SU-G30 Temperature: 24 °C Relative Humidity: 52 % Test Voltage : AC 120V/60Hz Test Mode : TX A MODE /CH149, CH157, CH165 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.82 0.8279 7.18 5.2240 0.000860901 Complies -0.82 0.8279 6.20 4.1687 0.000686991 Complies -0.82 0.8279 6.91 4.9091 0.000809001 Complies EUT： Network Audio amplifier Model Name : SU-G30 Temperature: 24 °C Relative Humidity: 52 % Test Voltage : AC 120V/60Hz Test Mode : TX N20 MODE_ Total /CH149, CH157, CH165 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.82 0.8279 7.24 5.2966 0.000872871 Complies -0.82 0.8279 6.36 4.3251 0.000712771 Complies -0.82 0.8279 6.14 4.1115 0.000677561 Complies EUT： Network Audio amplifier Model Name : SU-G30 Temperature: 24 °C Relative Humidity: 52 % Test Voltage : AC 120V/60Hz Test Mode : TX N40 MODE_ Total /CH151, CH159 Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -0.82 0.8279 9.50 8.9125 0.001468761 Complies -0.82 0.8279 9.55 9.0157 0.001485771 Complies Note: the calculated distance is 20 cm.

Report No.: BTL-FCCP-3-1510C009A Page 1 of 274 FCC Radio Test Report FCC ID: ACJ-SU-G30 This report concerns (check one): Original Grant Class II Change Project No. : 1510C009A Equipment : Network Audio amplifier Model Name : SU-G30 Applicant : Panasonic Corporation of North America Address : Two Riverfront Plaza, 9 th Floor Newark New Jersey United States07102-5490 Date of Receipt : Oct. 09, 2015 Date of Test : Oct. 09, 2015~ Dec. 04, 2015 Issued Date : Dec. 07, 2015 Tested by : BTL Inc. Testing Engineer : (Niklaus Lai) Technical Manager : (David Mao) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-3-1510C009A Page 2 of 274 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTLshall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-3-1510C009A Page 3 of 274 Table of Contents Page 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 13 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 15 3.5 DESCRIPTION OF SUPPORT UNITS 15 4 . EMC EMISSION TEST 16 4.1 CONDUCTED EMISSION MEASUREMENT 16 4.1.1 POWER LINE CONDUCTED EMISSION 16 4.1.2 TEST PROCEDURE 16 4.1.3 DEVIATION FROM TEST STANDARD 16 4.1.4 TEST SETUP 17 4.1.5 EUT OPERATING CONDITIONS 17 4.1.6 EUT TEST CONDITIONS 17 4.1.7 TEST RESULTS 17 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 TEST PROCEDURE 19 4.2.3 DEVIATION FROM TEST STANDARD 19 4.2.4 TEST SETUP 20 4.2.5 EUT OPERATING CONDITIONS 21 4.2.6 EUT TEST CONDITIONS 21 4.2.7 TEST RESULTS (9K TO 30MHz) 22 4.2.8 TEST RESULTS (BETWEEN 30 TO 1000 MHz) 22 4.2.9 TEST RESULTS (ABOVE 1000 MHz) 22 5 . SPECTRUM BANDWIDTH 23 5.1 APPLIED PROCEDURES / LIMIT 23 5.1.1 TEST PROCEDURE 23 5.1.2 DEVIATION FROM STANDARD 23 5.1.3 TEST SETUP 23 5.1.4 EUT OPERATION CONDITIONS 23 5.1.5 EUT TEST CONDITIONS 23 5.1.6 TEST RESULTS 23 6 . MAXIMUM CONDUCTED OUTPUT POWER 24 Report No.: BTL-FCCP-3-1510C009A Page 4 of 274 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 24 6.1.1 TEST PROCEDURE 24 6.1.2 DEVIATION FROM STANDARD 25 6.1.3 TEST SETUP 25 6.1.4 EUT OPERATION CONDITIONS 25 6.1.5 EUT TEST CONDITIONS 25 6.1.6 TEST RESULTS 25 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 26 7.1 APPLIED PROCEDURES / LIMIT 26 7.1.1 TEST PROCEDURE 26 7.1.2 DEVIATION FROM STANDARD 26 7.1.3 TEST SETUP 26 7.1.4 EUT OPERATION CONDITIONS 26 7.1.5 EUT TEST CONDITIONS 26 7.1.6 TEST RESULTS 26 8 . POWER SPECTRAL DENSITY TEST 27 8.1 APPLIED PROCEDURES / LIMIT 27 8.1.1 TEST PROCEDURE 27 8.1.1 DEVIATION FROM STANDARD 28 8.1.2 TEST SETUP 28 8.1.3 EUT OPERATION CONDITIONS 28 8.1.4 EUT TEST CONDITIONS 28 8.1.5 TEST RESULTS 28 9 . FREQUENCY STABILITY MEASUREMENT 29 9.1 APPLIED PROCEDURES / LIMIT 29 9.1.1 TEST PROCEDURE 29 9.1.2 DEVIATION FROM STANDARD 29 9.1.3 TEST SETUP 30 9.1.4 EUT OPERATION CONDITIONS 30 9.1.5 EUT TEST CONDITIONS 30 9.1.6 TEST RESULTS 30 10 . MEASUREMENT INSTRUMENTS LIST 31 11 . EUT TEST PHOTOS 33 ATTACHMENT A - CONDUCTED EMISSION 37 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ) 40 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 42 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 67 ATTACHMENT E - BANDWIDTH 202 Report No.: BTL-FCCP-3-1510C009A Page 5 of 274 Table of Contents Page ATTACHMENT F - MAXIMUM OUTPUT POWER 227 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 232 ATTACHMENT H - POWER SPECTRAL DENSITY 245 ATTACHMENT I - FREQUENCY STABILITY 270 Report No.: BTL-FCCP-3-1510C009A Page 6 of 274 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-3-1510C009A Original Issue. Dec . 07, 2015 Report No.: BTL-FCCP-3-1510C009A Page 7 of 274 1. CERTIFICATION Equipment : Network Audio amplifier Brand Name : Technics Model Name : SU-G30 Applicant : Panasonic Corporation of North America Manufacturer : Panasonic Corporation Address : 1-15 Matsuo-cho, Kadoma City, Osaka 571-8504, Japan Factory : Panasonic AVC Networks Johor Malaysia Sdn. Bhd. Address : IE, PLO 460, Jalan Bandar, 81700 PasirGudang, Johor, Malaysia Date of Test : Oct. 09, 2015~ Dec. 04, 2015 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart E(15.407) / ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-3-1510C009A) were obtain…
