ACJ5Z6KX-P8415Color Laser Printer With Parallel Port

EXHIBIT #6 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 OPERATING INSTRUCTIONS Setup Guide Model No. KX-P8415 Color Laser Printer and Reference Guide Setup Guide . . . . . . . . . . . . . . .3 Before You Start Setup Reference Guide . . . . . . . . . . .17 Loading Media Settings and Printing Maintenance Appendix This manual includes Setup Guide and Reference Guide. Setup Guide: describes basic setup procedures for the Panasonic KX-P8415 Color Laser Printer and necessary precautions for safety and use. First read this guide to setup the printer. Reference Guide:describes the instructions in outline for printing on a media (transparency, label or envelope), troubleshooting, etc. For other detailed information, refer to Operating Instructions installed on your computer. It is automatically installed on your computer when installing the KX-P8415 software (see page 13). If the Acrobat Reader application has not been installed in your computer, you are required to install it so that you can read the documentation (see page 13). Please carefully read this manual and keep this documentation in a safe place for future reference. Keep this manual near the printer for quick reference. Setup Guide Model No. KX-P8415 Color Laser PrinterColor Laser Printer and Reference Guide Using Manuals: (QUICK START) 2 End-User License Agreement THIS IS A LEGAL AGREEMENT BETWEEN YOU AND PANASONIC. CAREFULLY READ ALL THE TERMS AND CONDITIONS OF THIS AGREEMENT PRIOR TO OPENING THE PACKET OF SOFTWARE PROGRAM. OPENING THE PACKET INDICATES YOUR ACCEPTANCE OF THESE TERMS AND CONDITIONS. If you do not agree to these terms and conditions, return the unopened packet and the other components of the Panasonic product to the place of purchase and your money will be refunded. No refunds will be given for the products that have an opened packet or missing components. 1. COPYRIGHT: Panasonic has the right to license or has been granted to license the enclosed Software Program (“SOFTWARE”), developed and copyrighted by Kyushu Matsushita Electric Co., Ltd. or its licensor (“Licensor”). You acknowledge that you are receiving only a LIMITED LICENSE TO USE the SOFTWARE and related documentation, and that you shall obtain no title, ownership nor any other rights in or to the SOFTWARE and related documentation, all of which title and rights shall remain with Licensor and Panasonic. 2. LICENSE: (1) You have the non-exclusive rights to use the SOFTWARE on your computer. (2) If you wish to use the SOFTWARE in your network, you may install the SOFTWARE into a network server and/or its clients and use the copies of SOFTWARE in your network. (3) You may make reasonable quantities of copies of the SOFTWARE solely for backup or archival purposes. (4) You may not rent or lease the SOFTWARE, but you may transfer your right under this License Agreement on a permanent basis, provided that you transfer this Agreement, all copies of the SOFTWARE, all related documentation and your Panasonic product, and the recipient thereof agrees to the terms of this Agreement. (5) You may not reverse engineer, decompile or disassemble the SOFTWARE, except that in European Union and European Free Trade Association, you may have the limited right to reverse engineer, decompile or disassemble the SOFTWARE solely to the extent specifically permitted by the terms and conditions of Article 6 of the European Community’s Directive for the Legal Protection of Computer Programs, OJL 122/42 (17 May 1991). (6) You may not use, copy, modify, alter or transfer the SOFTWARE, any copy thereof or its related documentation, in whole or in part, except as expressly provided in this Agreement. 3. TERM: This license is effective until terminated. You may terminate this Agreement at any time by destroying the SOFTWARE and related documentation and all copies thereof. This license will also terminate if you fail to comply with any term or condition of this Agreement. Upon such termination, you agree to destroy all copies of the SOFTWARE and related documentation. 4. LIMITED WARRANTY: Within ninety (90) days of your receipt of the SOFTWARE, Panasonic warrants that the storage media on which the SOFTWARE are furnished is free from defect in materials and workmanship under normal use, and that it will repair or at its option replace any defective media at no charge to you, provided that such defective media is returned to Panasonic within such ninety (90) days period. 5. LIMITATION OF LIABILITY: EXCEPT AS STATED ABOVE, NEITHER PANASONIC NOR PANASONIC’S SUPPLIER MAKES OR PASSES ON TO YOU OR OTHER THIRD PARTY, ANY WARRANTY OR REPRESENTATION INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, NEITHER PANASONIC NOR PANASONIC’S SUPPLIER WARRANTS THAT THE SOFTWARE WILL BE ERROR-FREE OR THAT IT WILL MEET YOUR REQUIREMENTS. NEITHER PANASONIC NOR PANASONIC’S SUPPLIER SHALL BE LIABLE FOR ANY DAMAGE SUFFERED BY YOU INCLUDING, BUT NOT LIMITED TO, CONSEQUENTIAL, INCIDENTAL SPECIAL OR PUNITIVE DAMAGES. THE ABOVE LIMITATIONS SHALL APPLY REGARDLESS OF THE FORM OF ACTION WHETHER IN CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT PRODUCT LIABILITY OR OTHERWISE, EVEN IF SUCH PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. End-User License Agreement . . . . .2 For Your Safety . . . . . . . . . . . . . . . . .4 Cautions . . . . . . . . . . . . . . . . . . . . . . .7 System Requirements . . . . . . . . . . .8 Minimum Space Requirements . . . .8 Power Source . . . . . . . . . . . . . . . . . .8 Unpacking . . . . . . . . . . . . . . . . . . . . .9 Part Names . . . . . . . . . . . . . . . . . . . .9 Setting Up the Printer . . . . . . . . . . .10 Connecting the Printer to a Computer . . . . . . . . . . . . . . . . .11 Loading Media in the Media Tray . .11 Installing the KX-P8415 Software .13 Reading the Operating Instructions on the KX-P8415 CD-ROM . . . . .14 Removing the KX-P8415 Software .1…

Text truncated - open the document above for the full version.

EXHIBIT #5 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 BLOCK DIAGRAM

EXHIBIT #1 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.1. Overall front view of the EUT Photo.2. Overall rear view of the EUT Photo.3. Rear inside view of the EUT with Rear Cabinet and Engine Board Cover removed Photo.4. Left side inside view of the EUT with Left Cover and Main Control Cover removed Photo.5. Top view of Main Control Board with Frame, option Network Card and expansion DIMM option added Photo.6. Top view of Main Control Board Photo.7. Bottom view of Printer Main Control Board Photo.8. Top view of option DIMM Board Photo.9. Bottom view of option DIMM Board Photo.10. Top view of option Network Card Photo.11. Bottom view of option Network Card Photo.12. Top view of Printer Engine Control Board Photo.13. Bottom view of Printer Engine Control Board Photo.14. Top view of Power Supply Board and High Voltage Power Supply Board Photo.15. Bottom view of Power Supply Board and High Voltage Power Supply Board Photo.16. Top and bottom view of Printer Front Panel Board Photo.17. Top inside view of LSU and Circuit Board on LSU Photo.18. Bottom inside view of LSU and Circuit Board on LSU Photo.19. Top view of Second Cassette Feeder Board Photo.20. Bottom view of Second Cassette Feeder Board PHOTOGRAPHS EXHIBIT #1-1 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.1 Overall front view of the EUT EXHIBIT #1-2 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.2 Overall rear view of the EUT Refer to the EXHIBIT #2 EXHIBIT #1-3 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.3 Rear inside view of the EUT with Rear Cabinet and Engine Board Cover removed EXHIBIT #1-4 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.4 Left side inside view of the EUT with Left Cover and Main Control Cover removed

EXHIBIT #1-5 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.5 Top view of Main Control Board with Frame, option Network Card and expansion DIMM option added EXHIBIT #1-6 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.6 Top view of Main Control Board 18.75MHz Crystal OSC EXHIBIT #1-7 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.7 Bottom view of Main Control Board EXHIBIT #1-8 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.8 Top view of option DIMM Board 32M Byte64M Byte128M Byte256M Byte

EXHIBIT #2 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 DRAWING OF NAMEPLATE : Space for UL Listing Mark and/or CSA Monogram WARNING SENTENCES FCC CONCERNED EXPRESSIONS OF PRODUCT Panasonic COLOR LASER PRINTER Model No. KX-P8415 Serial No. POWER SOURCE: 120 V ~ 60 Hz 8 A Manufactured by Kyushu Matsushita Electric Co., Ltd. Fukuoka Japan Made in Japan FCC ID : ACJ5Z6KX-P8415 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. EXHIBIT #1-2 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.2 Overall rear view of the EUT Refer to the EXHIBIT #2

EXHIBIT #1-9 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.9 Bottom view of option DIMM Board 32M Byte64M Byte128M Byte256M Byte EXHIBIT #1-10 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.10 Top view of option Network Card 25.00MHz Crystal OSC 33.1776MHz Crystal OSC EXHIBIT #1-11 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.11 Bottom view of option Network Card EXHIBIT #1-12 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.12 Top view of Printer Engine Control Board 25.00MHz Ceramic OSC 72.305MHz Crystal OSC

EXHIBIT #1-13 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.13 Bottom view of Printer Engine Control Board EXHIBIT #1-14 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.14 Top view of Power Supply Board and High Voltage Power Supply Board Power Supply Board High Voltage Power Supply Board Switching Frequency: 80kHz Center EXHIBIT #1-15 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.15 Bottom view of Power Supply Board and High Voltage Power Supply Board Power Supply Board High Voltage Power Supply Board EXHIBIT #1-16 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.16 Top and bottom view of Front Panel Board Top view Bottom view

EXHIBIT #1-17 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.17 Top inside view of LSU and Circuit Board on LSU Laser Driver Board Parts side of Laser Driver Board EXHIBIT #1-18 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.18 Bottom inside view of LSU and Circuit Board on LSU Pattern side of Laser Driver Board EXHIBIT #1-19 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.19 Top view of Second Cassette Feeder Board EXHIBIT #1-20 Fty Control No.: KM6-99-F008 FCC ID : ACJ5Z6KX-P8415 Photo.20 Bottom view of Second Cassette Feeder Board

Test Report No.TR99-0038I 1 of 11 (EMI) REPORT NUMBER:TR 99-0070 APPLICANT: KYUSHU MATSUSHITA ELECTRIC CO., LTD. PRINTER DIVISION MODEL NUMBER:KX-P8415 REGULATION:FCC Rules and Regulations Part 15 Subpart B - Unintentional Radiators ISSUE DATE:December 7, 1999 Kyushu Matsushita Electric EMC Testing Laboratory Corporate Quality Assurance Division Kyushu Matsushita Electric Co., LTD.(KME) 441-13 Nagahasu Tateishi-cho, Tosu, Saga, 841-8585 Japan TEL 0942-84-8472 (+81-942-84-8472) FAX 0942-84-8470 (+81-942-84-8470) TEST REPORT Test Report No.TR 99-0070 2 of 11 TABLE of CONTENTS Page SECTION 1.EMI TEST REPORT ON EUT3 SECTION 2.TEST CERTIFICATION3 SECTION 3.TEST RESULTS EMISSION4 3.1Radiated Emission5 3.2Conducted Emission6 SECTION 4.DESCRIPTION OF TEST EQUIPMENT 4.1Configuration of Equipment7 4.2EUT and Support Equipment Used7 4.3Cable(s) Used8 4.4Operating Conditions8 4.5Any Deviations from, Additions to or Exclusions from the Test Method 8 SECTION 5.PHOTOGRAPHS OF MAXIMUM EMISSION SET-UP 5.1Radiated Emission9 5.2Conducted Emission9 SECTION 6.TEST ARRANGEMENT AND LIST OF TEST INSTRUMENTS 6.1Radiated Emission10 6.2Conducted Emission11 It is not allowed to copy this report even partly without the permission of KME EMC TESTING LABORATORY. Test Report No.TR 99-0070 3 of 11 SECTION 1. EMI TEST REPORT ON EUT APPLICANT INFORMATION Company:Kyushu Matsushita Electric Co., Ltd. Printer Division Address:1471 Murata-machi, Tosu, Saga, 841-8501 Japan Phone Number:0942-83-3131 (+81-942-83-3131) Facsimile Number:0942-81-2725 (+81-942-81-2725) DESCRIPTION of TEST ITEM Kind of Equipments:Color Laser Printer Condition of Equipment:Pre-Production Type:Desk-Top Type Trademark:Panasonic Model Number:KX-P8415 Serial Number:9KMFIA00044 Power Supply:AC 120V 60Hz TEST PERFORMED Location:Kyushu Matsushita Electric EMC Testing Laboratory (FCC File No. 31040/SIT 1300F2) Address:441-13 Nagahasu Tateishi-cho, Tosu, Saga, 841-8585 Japan Receipt Date:November 30, 1999 Test Date:November 30, 1999 Regulation:FCC Rules and Regulations Part 15 Class B Test Procedure:ANSI C63.4-1992 SECTION 2. TEST CERTIFICATION 1.Measurement Results The results obtained from the measurement of the above mentioned device are shown in the attached sheets. The results in this report apply only to the sample(s) tested. 2.Summary of Results Test sample complies with FCC Rules and Regulations Part 15 Subpart B - Unintentional Radiators(Class B). Worst Margin(Radiated Emission)--31.762MHz(V)9.0dB(at page 5) Worst Margin(Conducted Emission)--14.6291MHz6.4dB(at page 6) 3.These test results are traceable to the National and International Standards. 4.Measurements Uncertainty, at time of test, and at last 95% Confidence, was estimated to be as follows: Radiated Emission Measurements : 5.46dB(3m)[30-300MHz] 4.76dB(3m)[300- 1GHz] Conducted Emission Measurements: 2.40dB[0.09- 1MHz], 2.63dB[1-30MHz] Issue Date : December 7, 1999 Certifying Manager : H.Hara Test Report No.TR 99-0070 4 of 11 SECTION 3. TEST RESULTS EMISSION 3.1 Radiated Emission (at Page 5) 3.2 Conducted Emission (at Page 6) Tested by: T.Yamagami Reviewed by: M.Horie 80 70 60 50 40 30 20 10 1000M700M500M300M200M100M70M50M30M RADIATED EMISSION Model NameColor Laser Printer: model No.KX-P8415: Serial No.9KMFIA00044: OperatorT.Yamagami: Points11: DetectorQP: RBW120kHz: Test condition of instrument Date1999/11/30 11:10: Temperature19 deg: Humidity38 %: EUT Warm-up Time30minutes: Distance3m: Test ModeParallel Printing Mode: CommentLevel=Emission Level=Meter Reading: +Antenna Factor+Cable Loss(Cable, Preamp) The measurement was radiated the worst emissions condition. Power Supply: 120V60Hz Limit: [FCC Part 15] Class B<3m> Limit(QP) Horizontal(QP) Vertical(QP) Frequency[Hz] Level[dBμV/m] Test Report No.TR 99-0070 5 of 11 BC: BiconicalLP: Log-peri Frequency [MHz] Meter Reading (QP) [dBμV] Ant. Type Antenna Factor [dB/m] Cable & Preamp [dB] Level(QP) [dBμV/m] Angle[°] Height [cm] Pola. Limit [dBμV/m] Margin [dB] 31.50937.4BC19.3-26.230.5162100Vert.40.09.5 31.76237.9BC19.2-26.131.0171100Vert.40.09.0 50.71942.4BC12.1-25.728.8121100Vert.40.011.2 63.00742.8BC8.6-25.426.0277343Hori.40.014.0 71.46243.9BC7.5-25.226.261301Hori.40.013.8 343.45040.9LP16.5-22.235.276100Vert.46.010.8 542.30138.4LP19.9-21.936.4124114Hori.46.09.6 614.60831.6LP21.5-21.731.4163100Hori.46.014.6 672.12428.8LP22.1-21.329.6338100Vert.46.016.4 733.91530.4LP22.5-21.231.749100Vert.46.014.3 801.87429.4LP23.2-20.632.04100Vert.46.014.0 Test Report No.TR 99-0070 5 of 11 70 60 50 40 30 20 10 30M10M7M3M1M700k450k LINE CONDUCTION Model NameColor Laser Printer: model No.KX-P8415: Serial No.9KMFIA00044: OperatorT.Yamagami: Points18: DetectorQP: RBW10kHz: Test condition of instrument Date1999/11/30 18:56: Temperature17deg: Humidity38%: EUT Warm-up Time30minutes: Test ModeParallel Printing Mode: CommentLevel=Emission Level: =Meter Reading+Factor(LISN, Cable) The measurement was conducted the worst emissions condition. Power Supply: 120V60Hz Limit: [FCC Part15] Class B Limit(QP) VA(QP) VB(QP) Frequency[Hz] Level[dBμV] Test Report No.TR 99-00706 of 11 Frequency[MHz] Meter Reading (QP)[dBμV] Factor[dB] Level(QP) [dBμV] LineLimit[dBμV]Margin[dB] 0.495533.60.133.7VA47.914.2 1.891427.60.227.8VA47.920.1 2.466728.80.229.0VA47.918.9 3.533430.10.230.3VA47.917.6 7.151126.80.327.1VA47.920.8 13.312838.00.338.3VA47.99.6 14.629141.20.341.5VA47.96.4 15.448240.10.440.5VA47.97.4 21.373931.00.531.5VA47.916.4 0.495533.50.133.6VB47.914.3 1.891426.30.226.5VB47.921.4 2.468126.40.226.6VB47.921.3 3.533423.00.223.2VB47.924.7 7.149333.60.333.9VB47.914.0 13.312834.10.334.4VB47.913.5 14.629140.60.340.9VB47.97.0 15.448239.50.439.9VB47.98.0 21.375530.00.530.5VB47.917.4 Test Report No.TR 99-00706 of 11 Test Report No.TR 99-0070 7 of 11 SECTION 4. DESCRIPTION OF TEST EQUIPMENT 4.1 Construction of Equipment The Construction of EUT during the test as follows. Symbols or number assigned to equipment or cables on this diagram is used on tables in section 4.2 to 4.3. 4.2 EUT and Support Eq…
