ACJ8D8-EUE24BVehicle Door Lock Transceiver

Dear Sirs: Our product, CY-MH646 is a Keyless Access System of a motor vehicle. CY-MH646 is provided for a vehicle manufacture as original equipment (OE), and it will be fitted to a motor vehicle before it is placed in the US market. For this reason, we, Matsushita Electric Co., Ltd., do not publish a manual to this product, but a formal thing is appended by the carrying vehicles maker. Matsushita Electric Industrial Co., Ltd. Panasonic Automotive Systems Company Draft KEYLESS ACCESS SYSTEM USER MANUAL Matsushita Electric Industrial Co., Ltd. Panasonic Automotive Systems Company What is the KEYLESS ACCESS SYSTEM? KEYLESS ACCESS SYSTEM is a system which can unlock doors (Driver’s door, Assistant’s door), unlock the trunk, and start engine by only carrying a KEYLESS REMOTE. It is not necessary for you to mind a Key. Moreover, a transmitter for the Keyless Entry System is included in a KEYLESS REMOTE. You can also unlock and lock all doors and the trunk by pressing a KEYLESS REMOTE Button. KEYLESS REMOTE Door Unlock and Lock You can unlock and lock doors from driver’s door handle and assistant’s door handle. Door Unlock All doors are unlocked, if a KEYLESS REMOTE is carried and a door handle is grasped. Door Lock All doors and the trunk are locked, if a KEYLESS REMOTE is carried and a door handle outside portion is touched, Trunk Unlock T unk Unlockr The trunk opens, if a KEYLESS REMOTE is carried and the trunk open switch is pulled. Engine Switch Knob How to rotate Engine Switch Knob Please push the Engine Switch Knob. At that time, ID authentication is carried out. If the ID authentication succeeds, you can rotate the Engine Switch Knob. Engine Switch Knob Keyless Entry You can unlock or lock all doors and the trunk by pressing the Button of a KEYLESS REMOTE. Button KEYLESS REMOTE Transmitter included Door Unlock Please press the Door Unlock Button of a KEYLESS REMOTE. T unk Unlockr Please press the Trunk Unlock Button of a KEYLESS REMOTE. Door Lock Please press the Lock Button of a KEYLESS REMOTE. As required by the FCC; This device complied with Part 15 of the FCC rules, Operation is subject t the following two conditions; (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. o r Changes or modifications not expressly app oved by the party responsible for compliance could void the user’s authority to ope ate the equipment. r e This device complies with Industry Canada Standard RSS-210, Operation is subject to the following two conditions; (1) this device may not cause interference, and (2) this device must accept any interferenc that may cause

Matsushita Electric Industrial Co., Ltd. FCC ID: ACJ8D8-EUE24B (External Photos) Matsushita Electric Industrial Co., Ltd. FCC ID: ACJ8D8-EUE24B

Label Material: PET(polyethylene terephthalate) RFU

Matsushita Electric Industrial Co., Ltd. FCC ID: ACJ8D8-EUE24B (Internal Photos) Matsushita Electric Industrial Co., Ltd. FCC ID: ACJ8D8-EUE24B

Test report No. : 24HE0054-HO-2 Page : 2 of 16 Issued date : August 9, 2004 FCC ID : ACJ8D8-EUE24B Revised date : August 10, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) CONTENTS PAGE SECTION 1: Client information...................................................................................................... 3 SECTION 2: Equipment under test (E.U.T.) ................................................................................. 3 SECTION 3: Test specification, procedures & results .................................................................. 4 SECTION 4: Operation of E.U.T. during testing........................................................................... 7 SECTION 5: Radiated Emission (Fundamental and Spurious Emission) .................................. 8 APPENDIX 1: Photographs of test setup........................................................................................ 9 Radiated Emission(Worst case position) ................................................................................................ 9 APPENDIX 2:Test Instruments...................................................................................................... 10 APPENDIX 3: Data of EMI test ..................................................................................................... 11 Radiated Emission (Electric Field Strength of Fundamental and Spurious Emission)........................... 11 Duty Factor and Automatically deactivate ........................................................................................... 12 -20dB Bandwidth .................................................................................................................................... 13 99%Occupied Bandwidth ...................................................................................................................... 14 Radiated Emission (Receiving) .............................................................................................................. 15 Test report No. : 24HE0054-HO-2 Page : 3 of 16 Issued date : August 9, 2004 FCC ID : ACJ8D8-EUE24B Revised date : August 10, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) SECTION 1: Client information Company Name : Matsushita Electric Industrial Co., Ltd. Address : 1006 Oaza Kadoma Kadoma Osaka 571-8501 Japan Telephone Number : +81-585-32-4709 Facsimile Number : +81-585-34-1310 Contact Person : Yoshio Takahashi, Group Manager SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : RF Unit of KEYLESS ACCESS SYSTEM Model No. : EUE24B Sample No. : 1 Country of Manufacture : JAPAN Receipt Date of Sample : June 14, 2004 Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) 2.2 Product Description Model No: EUE24B is the KEYLESS REMOTE of KEYLESS ACCESS SYSTEM. The clock frequency of EUT is 60.24MHz Equipment Type : Transceiver Power Supply : DC 5.0V Transmitter Section Frequency operation 311.9MHz Type of modulation FSK Information antenna Internal / Reverse F Antenna Communication Device Keyless Remote (FCC ID: ACJ8D8E24A04) Receiver Section Receiver Section 1 Receiving frequency 311.9MHz Receiver type Super heterodyne Intermediate frequency 10.7MHz Local oscillator frequency 301.2MHz Information antenna Internal / Reverse F Antenna Communication Device Keyless Remote (FCC ID: ACJ8D8E24A04) FCC 15.31 (e) This EUT provides stable voltage(DC5.0V) constantly to RF Unit regardless of input voltage. Therefore, this EUT complies with the requirement. FCC Part 15.203 Antenna requirement It is impossible for end users to replace the antenna, because the antenna is mounted inside of the EUT. Therefore, the equipment complies with the antenna requirement of Section 15.203. Test report No. : 24HE0054-HO-2 Page : 4 of 16 Issued date : August 9, 2004 FCC ID : ACJ8D8-EUE24B Revised date : August 10, 2004 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) SECTION 3: Test specification, procedures & results 3.1 Test Specification Test Specification : FCC Part 15 Subpart C 2004 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.231 Periodic operation in the band 40.66-40.70MHz and above 70MHz Test Specification : FCC Part 15 Subpart B 2004 Section 15.109 Radiated emission limits Title : FCC 47CFR Part15 Radio Frequency Device Subpart B Unintentional Radiators 3.2 Procedures and results No. Item Test Procedure Specification Deviation Worst margin Results 1 Automatically Deactivate ANSI C63.4:2003 13. Measurement of intentional radiators Section 15.231(a)(2) N/A - Complied *1) 2 Electric Field Strength of Fundamental Emission ANSI C63.4:2003 13. Measurement of intentional radiators Section 15.231(b) N/A 8.9dB(AV(Pulse)) 311.933MHz Horizontal Complied 3 Electric Field Strength of Spurious Emission ANSI C63.4:2003 13. Measurement of intentional radiators Section 15.205 Section 15.209 Section 15.231(b) N/A 9.3dB(AV) 3.11936GHz Horizontal Complied 4 -20dB Bandwidth ANSI C63.4:2003 13. Measurement of intentional radiators Section 15.231(c) N/A - Complied 5 Conducted emission AC Mains ANSI C63.4:2003 7. AC powerline conducted emission measurements Section 15.207 N/A*2) N/A N/A Note: UL Apex’s EMI Work procedures No. QPM05 *1) EUT has the specification of Automatically cease within 5 seconds. *2) The test is not applicable since the EUT is DC drive and is not connected to the public utility (AC) power line. Test report No. : 24HE0054-HO-2 Page : 5 of 16 Issued date : August 9, 2004 FCC ID : ACJ8D8-EUE24B Revised date : August 10, 2004 UL Apex Co., Ltd. Head Office EMC L…

Text truncated - open the document above for the full version.

Test report No. : 24HE0054-HO-2 Page : 9 of 16 Issued date : August 9, 2004 FCC ID : ACJ8D8-EUE24B UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(10.04.03) APPENDIX 1: Photographs of test setup Radiated Emission(Worst case position) Front Rear
