ACJ8GL-PAN802154OEM Wireless Network Module

LR/WPAN PAN802154HAR Application Notes Doc Number: Rev A3 1 ZB-01 LR-WPAN Module P/N PAN802154____ Application Notes Rev Author/Editor Issue Reason Date Release Approval A Fox / Nguyen Initial release / Revise 3-22-2005 RBNguyen A1 Trueman Revise 3-29-2005 RBNguyen A2 Cardenas Connector Nomenclature Change. (Use Rev.A1 for earlier Engineering Samples with Rev. 5 or earlier artwork) 7-06-2005 RBNguyen A3 Cardenas Add FCC restrictions and mechanical drawing 9-22-05 LR/WPAN PAN802154HAR Application Notes Doc Number: Rev A3 2 Table of content 1 INTRODUCTION .............................................................................................. 3 1.1 Regulatory information................................................................................................................................ 3 1.2 Abbreviations and Acronyms ...................................................................................................................... 3 2 LR/WPAN PAN802154HAR FEATURES, AND COMPONENT DESCRIPTION ............... 5 2.1 PAN802154 Image, Component Layout and Block Diagram ................................................................... 6 2.2 Component and Descriptions....................................................................................................................... 7 2.2.1 J3: General Purpose Header.................................................................................................................... 7 2.2.2 J2: Serial Port Header ............................................................................................................................. 7 2.2.3 J4: Power/GND Header .......................................................................................................................... 9 2.2.4 J1: BDM Programming header/Debugger .............................................................................................. 9 2.2.5 SW1: General Purpose Switch.............................................................................................................. 10 2.2.6 D1: LED ............................................................................................................................................... 10 2.2.7 U1: MCU .............................................................................................................................................. 10 2.2.8 U3: RF IC ............................................................................................................................................. 10 2.3 Mechanical Dimensions.............................................................................................................................. 10 3 APPLICABLE SW COMPONENTS .................................................................................. 12 3.1 SW Architecture ......................................................................................................................................... 12 3.1.1 Different Possible Applications with Available Software Components ............................................... 12 3.2 Bootloader ................................................................................................................................................... 12 3.3 Required SW Tools..................................................................................................................................... 13 3.4 Freescale™ ZigBee Development Platform.............................................................................................. 13 3.5 Special mapping for the PAN802154 Module in Metrowerks Code Warrior Development Tool. ...... 13 3.5.1 Compiling with a Z-Stack Project ........................................................................................................ 14 3.5.2 Compiling without using the Z-Stack ................................................................................................... 14 3.6 Differences between the Panasonic PAN802154 and the Freescale SARD Development Board ......... 15 3.6.1 Switch ................................................................................................................................................... 15 3.6.2 LED ...................................................................................................................................................... 15 3.6.3 RS-232 Interface................................................................................................................................... 16 3.6.4 Editing SARD Header File for the Panasonic Module ......................................................................... 16 3.7 How to load a SW program into the Panasonic Module ......................................................................... 20 4 FREQUENTLY ASKED QUESTIONS .............................................................................. 24 5 REFERENCE DOCUMENTS ............................................................................................ 27 APPENDIX 1 FCC AND CANADA CERTIFICATIONS .......................................................... 30 Instruction to the user ............................................................................................................................................ 30 Integration in OEM products: VERY IMPORTANT! ....................................................................................... 30 APPENDIX 2 ORDERING INFORMATION ............................................................................ 32 LR/WPAN PAN802154HAR Application Notes Doc Number: Rev A3 3 1 INTRODUCTION The purpose of this document is to present a method for designing products using the Panasonic Low Rate / Low Power Wireless Area Network Communication Module Part Number PAN802154HAR00 and familiarize engineers with application details. A Frequently Asked Questions (FAQ’s) section is also provided for engineering quick references. Panasonic ZB-01 LR/WPAN PAN802154…

Text truncated - open the document above for the full version.

Click here and type:Address. Tel: 201.XXX.XXXX v Fax: 201.XXX.XXXX lastname first name [email protected] Francisco Cardenas Engineering Manager Panasonic Electronic Devices Corporation of America Engineering Section 7 September 05 Nemko 11696 Sorrento Valley Rd. San Diego CA, 92121 USA SUBJECT: Panasonic Electronic Devices Corporation of America, Module approval FCC ID: ACJ8GL-PAN802154 To whom it may concern: The DUT uses integrated printed antennas on the board, the specification and application notes describe that modification to the module, connecting external antennas or connecting to the AC lines by an AC adapter will make the product not authorized and the OEM will be the responsible in getting the proper authorization for the final product. The radio portion is covered by a shield. The PWB is two sides and the bottom side has a ground plane. Only the digital portion of the board is not shielded. The circuit is voltage limited trough an internal regulator in the radio circuit and the microprocessor. Current is decoupled trough the use of several capacitors The label for external enclosure is included with the label sample. The Application manual and product specifications make reference to that label. Sincerely, Francisco Cardenas Engineering manager Panasonic Electronic Devices Corporation of America

Click here and type:Address. Tel: 201.XXX.XXXX v Fax: 201.XXX.XXXX lastname first name [email protected] Francisco Cardenas Engineering manager Panasonic Electronic Devices Corporation of America Engineering Section Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent RE: FCC ID# ACJ-PAN802154 On our behalf, I appoint Nemko USA, 11696 Sorrento Valley Rd. San Diego, CA, USA. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Panasonic Electronic Devices corporation of America. Dated this 7 h Day of SEPTEMBER 20 05 Agency agreement expiration date: 1 st Day of December, 2005 By: Francisco Cardenas Signature Printed Title: Engineering Manager On behalf of : Panasonic Electronic Devices Corporation of America Telephone: 619-661-8740

Click here and type:Address. Tel: 201.XXX.XXXX v Fax: 201.XXX.XXXX lastname first name [email protected] Francisco Cardenas Engineering Manager Panasonic Electronic Devices Corporation of America Engineering 7 September 05 Nemko 11696 Sorrento Valley Rd. San Diego CA, 92121 USA Re: Request of Confidentiality for FCC ID#: ACJ8GL-PAN802154 Pursuant to Sections 0.457(d)(I)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below: Schematics, Parts List, Operating Description, Block Diagrams The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(I)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Francisco Cardenas Engineering Manager Panasonic Electronic Devices Corporation of America

November 4’ 05 7625 Panasonic Way, 31H-1 San Diego, CA, 92154. Tel: 619-661-8740 [email protected] Francisco Cardenas Engineering Manager Panasonic Electronic Devices Corporation of America Engineering Section Nemko 11696 Sorrento Valley Rd. San Diego CA, 92121 USA SUBJECT: PAN802154 model differences FCC ID: ACJ8GL-PAN802154, IC: 216A-PN802154 To whom it may concern: The module is available in eight (2 3 ) configurations that provide options for user interface and operation temperature range. Those configurations are pre-selected before the product is shipped and they are: 1- Include or not serial communication IC; 2-Include or not standard 2.54” header connectors and 3-Industrial or commercial operation temperature range. The next table explains the composition of the part number for the eight versions to be certified. Sincerely, Francisco Cardenas Engineering manager Panasonic Electronic Devices Corporation of America

0.50in. 1.25in. 0.73in. 1.89in. 1.34in. ZB-01 MODULE LABEL 18.65mm. 34.00mm. 48.00mm. Part #: PAN802154 HAR00 FCC ID: ACJ8GL-PAN802154 IC: 216A-PN802154 Date code: 5722

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 8.45 (dBm) Maximum peak output power at antenna input terminal: 7.0 (mW) Antenna gain(typical): 0 (dBi) Maximum antenna gain: 1 (numeric) Prediction distance: 20 (cm) Prediction frequency: 2400 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.00139 (mW/cm^2) Maximum allowable antenna gain: 28.6 (dBi) Margin of Compliance: 28.56 2 4 R PG S π =

Nemko USA, Inc. 11696 Sorrento Valley Rd., Suite F San Diego, CA 92121-1024 Phone (858) 755-5525 Fax (858) 452-1810 CERTIFICATION TEST REPORT PART 15.247, SUBPART C RSS-210, ISSUE 6 - LOW POWER LICENSE EXEMPT RADIO- COMMUNICATION DEVICES (ALL FREQUENCY BANDS) DECLARATION OF CONFORMANCE PROCEDURES TEST REPORT For The LR-WPAN Module Model: Product Family “ZB-01" (PAN802154HAR00, PAN802154HARI0, PAN802154HAX00,PAN802154HAXI0, PAN802154XAR00, PAN802154XARI0, PAN802154XAX00, PAN802154XAXI0) FCC ID: ACJ8GL- PAN802154 IC: 216A-PN802154 PREPARED FOR: Panasonic Electronic Devices Corporation of America 7625 Panasonic Way San Diego, CA 92154 PREPARED ON 8-30-05 REPORT NUMBER: 2005 080471-FCC PROJECT NUMBER: 25-471-PAN Total Pages: 31 Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 DATE DOCUMENT NAME DOCUMENT # PAGE August 30, 2005 FCC Test Report 2005 030471 FCC FCC ID ACJ8GL- PAN802154 2 of 31 DOCUMENT HISTORY REVISION DATE COMMENTS - 8-30-05 Prepared By: A. LAUDANI - 8-30-05 Initial Release: F. Fleury NOTE: Nemko USA, Inc. hereby makes the following statements so as to conform to Chapter 10 (Test Reports) Requirements of ANSI C63.4 (2003) “Methods and Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz”: o The unit described in this report was received at Nemko USA, Inc.'s facilities on March 11, 2004. Testing was performed on the unit described in this report on March 11, 2004 to March 16, 2004. o The Test Results reported herein apply only to the Unit actually tested, and to substantially identical Units. o This report does not imply the endorsement of the Federal Communications Commission (FCC), NVLAP or any other government agency. This Report is the property of Nemko USA, Inc., and shall not be reproduced, except in full, without prior written approval of Nemko USA, Inc. However, all ownership rights are hereby returned unconditionally to HME, and approval is hereby granted to HME and its employees and agents to reproduce all or part of this report for any legitimate business purpose without further reference to Nemko USA, Inc. Nemko USA, Inc. 11696 Sorrento Valley Road, Suite F, San Diego, CA 92121 Phone (858) 755-5525 Fax (858) 452-1810 DATE DOCUMENT NAME DOCUMENT # PAGE August 30, 2005 FCC Test Report 2005 030471 FCC FCC ID ACJ8GL- PAN802154 3 of 31 TABLE OF CONTENTS DOCUMENT HISTORY...................................................................................................................................2 CERTIFICATION.............................................................................................................................................4 1. ADMINISTRATIVE DATA AND TEST SUMMARY..........................................................................5 1.1.ADMINISTRATIVE DATA..................................................................................................................................5 1.2.TEST SUMMARY..............................................................................................................................................5 2. SYSTEM CONFIGURATION.................................................................................................................6 2.1.SYSTEM COMPONENTS AND POWER CABLES...................................................................................................6 2.2.DEVICE INTERCONNECTION AND I/O CABLES.................................................................................................6 2.3.DESIGN MODIFICATIONS FOR COMPLIANCE.....................................................................................................6 3. DESCRIPTION OF TEST SITE AND EQUIPMENT...........................................................................7 3.1.DESCRIPTION OF TEST SITE.............................................................................................................................7 4. DESCRIPTION OF TESTING METHODS...........................................................................................8 4.1.INTRODUCTION................................................................................................................................................8 4.2.CONFIGURATION AND METHODS OF MEASUREMENTS FOR RADIATED EMISSIONS.........................................10 5. TEST RESULTS......................................................................................................................................11 5.1. CFR 47 PART 15C §15.247 TEST RESULTS........................................................................12 5.2 Peak Power, Radiated Spurious, and Peak Power Density.....................................................13 5.3 Bandwidth............................................................................................................14 5.4 Bandedge..............................................................................................................16 5.5 Duty Cycle............................................................................................................20 5.6 Radiated Emissions 30 MHz to 1000 MHz......................................................................21 5.7 Test Equipment......................................................................................................23 TEST SETUP DIAGRAMS Figure 1. General EUT Test Setup Diagram.....................................................................................................9 APPENDICES A. ADDITION CONDUCTED SPURIOUS PLOTS B. CONDUCTED & RADIATED EMISSIONS MEASUREMENT UNCERTAINTIES........................................................26 C. NEMKO USA, INC.’S TEST EQUIPMENT & FACILITIES CALIBRATION PROGRAM.............................................28 D. FCC AND NVLAP ACCREDITATION...............................................................................................................30 Nemko USA…

Text truncated - open the document above for the full version.

Conducted Output Power Bandwidth Spurious Emissions at Antenna Terminals Peak Power, Peak Power Density & Field Strength of Spurious Radiation 3 METERS EUT NON-CONDUCTING TURN-TABLE 0.8 METER VARIABLE SEARCH HEIGHT (1 TO 4 m) TO TEST RECEIVER/SPECTRUM ANALYZER SEARCH ANTENNA RF Radiated 15C measurements. 15B conducted 15B Radiated
