ACJ927134LRF Light for LCD Electronic Viewfinder

Panasonic Corporation of North America

Click to zoom

Application Details

Equipment Class: 8CC - Part 18 Consumer Device
Date of Grant: Sep 24, 2000
Application Purpose: Original Equipment
Date of Application: Sep 11, 2000
Equipment Note: RF Light for LCD Electronic Viewfinder
Frequency Range: 0.10000000 - 0.10000000
Company: Panasonic Corporation of North America
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Block Diagram

EXHIBIT # : 4-2 FCC ID: ACJ927134L OUR REF.: MKES00-F008 Block DiagramMODEL NO.: PV-L551D

Cover Letter(s)

FCC ID : ACJ927134L OUR REF. : MKES00-F008 MODEL NO.: PV-L551D Description of Application Models Application models are as below. FCC ID:ACJ927134L Trade Name:Panasonic Model No. of Video Camera:PV-L551D Name of Device:Color LCD Electronic View Finder, part of Video Camera Grantee Name:Matsushita Electric Industrial Co., Ltd. Manufacturer:Matsushita-Kotobuki Electronics Ind. Ltd. Cabinet Material:Plastics

External Photos

EXHIBIT #: FCC ID: ACJ927134L OUR REF. : MKES00-F008 MODEL NO.: PV-L551D Sheet 1 of 5 Sheets Color LCD electronic view finder (Part of video camera) EXHIBIT #: FCC ID: ACJ927134L OUR REF. : MKES00-F008 MODEL NO.: PV-L551D Sheet 2 of 5 Sheets EXHIBIT #: FCC ID: ACJ927134L OUR REF. : MKES00-F008 MODEL NO.: PV-L551D Sheet 3 of 5 Sheets LCD Power PCB (Top view) Oscillator circuit EXHIBIT #: FCC ID: ACJ927134L OUR REF. : MKES00-F008 MODEL NO.: PV-L551D Sheet 4 of 5 Sheets LCD Power PCB (Bottom view) EXHIBIT #: FCC ID: ACJ927134L OUR REF. : MKES00-F008 MODEL NO.: PV-L551D Sheet 5 of 5 Sheets LCD RF Lighting device (Fluorescent lamp)

ID Label/Location Info

EXHIBIT # : 1 FCC ID: ACJ927134L OUR REF.: MKES00-F008 MODEL NO.: PV-L551D Sample of FCC Identifier FCC ID : ACJ927134L FCC Statements for compliance with FCC Rules Part 18 in User's Manual EXHIBIT # : 2 FCC ID: ACJ927134L OUR REF.: MKES00-F008 MODEL NO.: PV-L551D Location of FCC Identifier FCC Identifier

Test Report

EXHIBIT # : FCC ID: ACJ927134L OUR REF.: MKES00-F008 MODEL NO.: PV-L551D Sheet 4 of 5 Sheets 18.307 POWER LINE CONDUCTED INTERFERENCE - CONFIGURATION OF THE EQUIPMENT UNDER TEST - ( Arrangement of accessories on the test table ) VHS-C MOVIE With LCD EVF Test table RF lighting device (Color LCD EVF Part FCC ID : ACJ927134L) Video/Audio cable (1.5 meter) DC Out cable (2 meter) AC Adaptor (PV-A19) EXHIBIT # : FCC ID: ACJ927134L OUR REF.: MKES00-F008 MODEL NO.: PV-L551D Sheet 5 of 5 Sheets
