ACJ932AT1601Car Radio

AT1601 User Manual Confidential Since this device is always used with vehicle, it is not sold to general end users separately. Therefore there is no user manual of this device by alone. The following statements must be described on the User manual of the vehicle. FCC ID: ACJ932AT1601 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment has very low levels of RF energy that is deemed to comply without maximum permissive exposure evaluation (MPE). Confidential (1) CD Eject (Push) (2) Power ON/OFF (Push) (3)(4) Volume Control (Push) (5) Off Hook in Hands Free mode (Push) (6) On Hook in Hands Free mode (Push) (7) Mode Switching (Push) (8) Setup Mode (Push) (9)(10) Manual Tuning in Radio mode (Push) (11)(12) Automatic Tuning in Radio mode (Push) (13)-(18) Station Preset (Push) About Bluetooth Hands Free mode ・The mode is changed into a hands-free mode by pushing(5). ･It changes into the last mode of Audio by pushing(6) at hands free mode. Registration of Bluetooth telephone （Initial setting） ・Push (8) then choose "Bluetooth“ → "Pairing“ . ・During Pass Key indication, input 4 to 8 codes into a Bluetooth Telephone. It is registered afterwards. Connection OK ：”Phone is connected” Connection NG ：”Bluetooth connection failed” Each command is carried out by pushing (8). Confidential (13) (14) (15) (16) (17) (18) (1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) Product Description For radio broadcast reception and Bluetooth hands free phone system or audio.

Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Tel/Fax: 201-348-7758 / [email protected] Richard Mullen, Group Manager Product Safety and Compliance Department Letter of Authorization August 26, 2015 PAS-15-F002 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan Re: Original Certification for Car Radio with Blue Tooth Transmitter, Model AT1601 under FCC ID: ACJ932AT1601 To Whom It May Concern: Please be advised Panasonic Corporation of North America hereby authorizes Yoshihisa Maeda of Consumer Technology Division, UL Japan, Inc. (“UL”) to act on our behalf for this single filing and for a period of six months from the date of this letter. Any and all acts carried out by UL on our behalf shall have the same effect as acts of our own. We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. The application for the subject equipment has not been submitted to another TCB for certification. Equipment Name: Car Radio with Blue Tooth Transmitter, Model AT1601 FCC ID: ACJ932AT1601 Equipment Classifications: Spread Spectrum Transmitter / Equipment Code DSS FCC Rule Parts: FCC Part 15, Subpart C BT Frequency Range: 2402 ~ 2480 MHz BT Version: Ver 3.0 + EDR Applicant & Grantee: Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 USA FRN Number: 0003762242 Authorized by, Richard Mullen Group Manager Panasonic Corporation of North America Product Safety & Compliance Department Cc: Takahisa Sakai / Design Section 3, Product Design Department 1 / Global Product Design Center, Automotive Infotainment Systems Business Division, Automotive & Industrial Systems Company Panasonic Corporation 4261, Ikonobe-cho, Tsuzuki-ku, Yokohama, 224-8520, Japan E-mail: [email protected]

Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Tel/Fax: 201-348-7758 / [email protected] Richard Mullen, Group Manager Product Safety and Compliance Department Request for Permanent Confidentiality August 26, 2015 PAS-15-F002 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan Re: Original Certification for Car Radio with Blue Tooth Transmitter, Model AT1601 under FCC ID: ACJ932AT1601 To Whom It May Concern: In accordance with provisions of Sections 0.457 and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for the below indicated exhibits. This transmitter is not user adjustable and does not have user tune-up procedure. These exhibits contain proprietary, confidential and/or trade secret materials, which would not be routinely made available for public inspection. xBlock Diagram xSchematic Diagram xParts List xTheory of Operation Thank you for your attention to this matter. Authorized by, Richard Mullen Group Manager Panasonic Corporation of North America Product Safety & Compliance Department xxxxBlBBlBlBBBlllBlBBBllBBBBBlBlBllBlocoooooocoocococcooccoooook kk kkkkkDiDDiDDDiDDiDDiDDDiDDDiDDDDDDDDiDiagaggagagagagaaaaaggagagagagaaaggaaggaggggaagaggagagraraaaararrarararaaraaarrrarrrrrraaarm mmmmmmmmmmmmm xScSSSScScScSSScSSScScSSccSScchehhhhhhehehhheheeeehhheheeeemamaamaamaamamaamaamamamammamammmammamamamaatittttiiittiic DiDDiDDiDDiDDDDDiDDiDDDDDiDDDDDDDDiDDDagagagagaggaggagagagggaggagaggggggggggggrararrarraraararraaaarrraam mmmmmmmmmmmmmmmmm xTheory of OpOOOOOOOOOOOOeration xParts Listststsssttststststsstt

Photo Photo Photo

FCC ID: ACJ932AT1601 AT1601 ******** ***** ***** FCC ID: ACJ932AT1601 AT1601 ******** ***** ***** Since this device is always used with vehicle, it is not sold to general end users separately . Since the product is attached on the vehicle, the user can not see the label. The following statements describe on the user manual of the vehicle. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Photo Photo Photo

UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone: +81 463 50 6400 Facsimile: +81 463 50 6401 2015/7/27 UL Japan, Inc. 4383-326 Asama-cho, Ise-shi, Mie 516-0021 Japan FCC ID: ACJ932AT1601 To whom it may concern, We, UL Japan, Inc., hereby declare that Car Radio, model : AT1601 (FCC ID: ACJ932AT1601) of Panasonic Corporation is exempt from RF exposure SAR evaluation as its output power meets the exclusion limits stated in FCC Part 2 §2.1093. KDB 447498D01(v05r02) has the following exclusion for portable devices: The 1g and 10g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances < 50 mm are determined by: [(measured maximum average output power(mW))/(Minimum separation distance(mm))]•[ √ f (GHz)] < 3.0 for 1g SAR and < 7.5 for 10g extremity SAR where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is < 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. This device f = 2.48 GHz, distance = 5mm (minimum separation distance: 5 mm was used in the calculation) and the measured maximum average output power was 1 mW So for this device: 1 mW [measured maximum average output power] / 5 mm [minimum separation distance] * ( √ 2.48) = 0.3 *This is less than 3.0, so no SAR is required. Even taking into account the tolerance, this device can be satisfied with the limits. Thank you for your attention to this matter. Makoto Hosaka Engineer Consumer Technology Division UL Japan, Inc.

Test report No. : 10763065S-A-R1 Page : 1 of 46 Issued date : August 31, 2015 FCC ID : ACJ932AT1601 UL Japan, Inc. Shonan EMC Lab. 1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN Telephone : +81 463 50 6400 Facsimile : +81 463 50 6401 13-EM-F0429 RADIO TEST REPORT Test Report No. : 10763065S-A-R1 Applicant : Panasonic Corporation Type of Equipment : Car Radio Model No. : AT1601 FCC ID : ACJ932AT1601 Test regulation: FCC Part 15 Subpart C: 2015 Test Result : Complied 1. This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc. 2. The results in this report apply only to the sample tested. 3. This sample tested is in compliance with the above regulation. 4. The test results in this report are traceable to the national or international standards. 5. The opinions and the interpretations to the result of the description in this report are outside scopes where UL Japan has been accredited. 6. This test report covers Radio technical requirements. It does not cover administrative issues such as Manual or non-Radio test related Requirements. (if applicable) 7. This report is a revised version of " 10763065S-A ". " 10763065S-A " is replaced with this report. 8. Date of test: June 1 to July 12, 2015 Representative test engineer: Hikaru Shirasawa Engineer Consumer Technology Division Approved by: Ichiro Isozaki Manager Consumer Technology Division RTL02610 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan. There is no testing item of "Non-accreditation". Test report No. : 10763065S-A-R1 Page : 2 of 46 Issued date : August 31, 2015 FCC ID : ACJ932AT1601 UL Japan, Inc. Shonan EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 REVISION HISTORY Original Test Report No.: 10763065S-A Revision Test report No. Date Page revised Contents - (Original) 10763065S-A July 27, 2015 - - 1 10763065S-A-R1 August 31, 2015-(Full revision) Correction of stable voltage description Addition of FCC ID description Test report No. : 10763065S-A-R1 Page : 3 of 46 Issued date : August 31, 2015 FCC ID : ACJ932AT1601 UL Japan, Inc. Shonan EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ....................................................................................................... 4 SECTION 2: Equipment under test (E.U.T.) ......................................................................................... 4 SECTION 3: Test specification, procedures & results .......................................................................... 5 SECTION 4: Operation of E.U.T. during testing .................................................................................. 8 SECTION 6: Radiated Spurious Emission .......................................................................................... 10 SECTION 7: Antenna Terminal Conducted Tests .............................................................................. 11 APPENDIX 1: Test data ........................................................................................................................ 12 20dB Bandwidth and Carrier Frequency Separation ......................................................................... 12 Number of Hopping Frequency ........................................................................................................ 15 Dwell time ......................................................................................................................................... 17 Maximum Peak Output Power .......................................................................................................... 20 Average Output Power ...................................................................................................................... 21 Radiated Spurious Emission ............................................................................................................. 24 Conducted Spurious Emission .......................................................................................................... 35 Conducted Emission Band Edge compliance ................................................................................... 41 99%Occupied Bandwidth ................................................................................................................. 43 APPENDIX 2: Test instruments ........................................................................................................... 45 APPENDIX 3: Photographs of test setup ............................................................................................. 46 Radiated Spurious Emission ............................................................................................................. 46 Test report No. : 10763065S-A-R1 Page : 4 of 46 Issued date : August 31, 2015 FCC ID : ACJ932AT1601 UL Japan, Inc. Shonan EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 SECTION 1: Customer information Company Name : Panasonic Corporation Address : 4261 Ikonobe-cho, Tsuzuki-ku, Yokohama-city, 224-8520, Japan Telephone Number : +81-50-3689-7126 Facsimile Number : +81-45-931-0806 Contact Person : Takahisa Sakai SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Car Radio Model No. : AT1601 Serial No. : Refer to Section 4, Clause 4.2 Rating : DC 12 V Receipt Date of Sample : June 4, 2015 Country of Mass-production : Czech Republic, Thailand, Taiwan Condition of EUT : Engineering prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No Modification by the test lab 2.2 Product Description Model: AT1601 (referred to as the EUT in this report) is a Car Radio. General Specification Clock frequency(ies) in the…

Text truncated - open the document above for the full version.

Test report No. : 10763065S-A Page : 46 of 46 Issued date : July 27, 2015 UL Japan, Inc. Shonan EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 APPENDIX 3: Photographs of test setup Radiated Spurious Emission Front(Below 1 GHz) Rear(Below 1GHz) Rear(Above 1GHz) End of Report
