ACJ932CQ-SM5559UBluetooth Modular

Panasonic Corporation of North America

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 02, 2013
Application Purpose: Original Equipment
Date of Application: Jan 02, 2013
Equipment Note: Bluetooth Modular
Frequency Range: 2402.00000000 - 2480.00000000
Company: Panasonic Corporation of North America
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

TEXT MP3 CD Player/Weather Band Receiver PP P/N PP105160 Operating Instructions ¡ Please read these instructions carefully before using this product and keep this manual for future reference. 2 Safety Information QRead the operating instructions for the unit and all other components of your truck audio system carefully before using the system. They contain instructions about how to use the system in a safe and effective manner. We assume no responsibility for any problems resulting from failure to observe the instructions given in this manual. QThis manual uses pictographs to show you how to use the product safely and to alert you to potential dangers resulting from improper connections and operations. The meanings of the pictographs are explained below. It is important that you fully under- stand the meanings of the pictographs in order to use this manual and the system properly. Warning Observe the following warnings when using this unit. TThe driver should not operate the system while driving. Watching the display or operating the system will distract the driver from looking ahead of the vehicle and can cause accidents. Always stop the vehicle in a safe location and use the parking brake before watching the display or operating the system. TUse the proper power supply. This product is designed for operation with a negative grounded 12 V DC battery system. Never operate this product with other battery systems, especially a 24 V DC battery system. TProtect the Deck Mechanism. Do not insert any foreign objects into the slot of this unit. TDo not disassemble or modify the unit. Do not disassemble, modify the unit or attempt to repair the product yourself. If the product needs to be repaired, consult your dealership. TDo not use the unit when it is out of order. If the unit is out of order (no power, no sound) or in an abnormal state (has foreign objects in it, is exposed to water, is smoking, or smells), turn it off immediately and consult your dealership. TAny NOAA broadcast weather report, including current and forecasts, may not reflect your actual weather conditions at your exact time and location. You should always pay attention to your actual weather conditions to make safe decisions accordingly. TKeep accessories out of reach of infants. Accessories can be ingested, so keep them out of the reach of infants. If an infant ingests accesso- ries, please seek immediate medical attention. Observe the following warnings when installing. TDisconnect the lead from the negative (–) bat- tery terminal before installation. Wiring and installation with the negative (–) battery terminal connected may cause electrical shock and injury due to a short circuit. Some cars equipped with the electrical safety system have specific procedures of battery terminal disconnection. FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY SYSTEM RESULTING IN DAMAGE TO THE VEHICLE AND PERSONAL INJURY OR DEATH. TNever use safety-related components for installation, grounding, and other such func- tions. Do not use safety-related vehicle components (fuel tank, brake, suspension, steering wheel, pedals, airbag, etc.) for wiring or fixing the product or its accessories. TCheck for piping, gasoline tank, electric wiring, and other items before installing the product. If you need to open a hole in the vehicle chassis to attach or wire the product, first check where the wire harness, gasoline tank, and electric wiring are located. Then open the hole from outside if pos- sible. TNever install the product in a location where it interferes with your field of vision. TNever have the power cord branched to supply other equipment with power. TAfter installation and wiring, you should check the normal operation of other electrical equip- ment. The continuation of their using in abnormal condi- tions may cause fire, electrical shock or a traffic accident. TMake sure the leads do not interfere with driv- ing or getting in and out of the vehicle. TInsulate all exposed wires to prevent short circuiting. This pictograph intends to alert you to the presence of important operating instructions and installation instructions. Failure to heed the instructions may result in severe injury or death. This pictograph intends to alert you to the presence of important operating instruc- tions and installation instructions. Failure to heed the instructions may result in injury or material damage. Warning Caution 3 Caution Observe the following cautions when using this unit. TKeep the sound volume at an appropriate level. Keep the volume level low enough to be aware of road and traffic conditions while driving. TDo not insert or allow your hand or fingers to be caught in the unit. To prevent injury, do not get your hand or fingers caught in moving parts or in the disc slot. Espe- cially watch out for infants. TThis unit is designed for use exclusively in trucks. TDo not operate the unit for a prolonged period with the engine turned off. Operating the audio system for a long period of time with the engine turned off will drain the bat- tery. TDo not expose the unit to direct sunlight or excessive heat. Otherwise these will raise the interior temperature of the unit, and it may lead to smoke, fire, or other damage to the unit. TDo not use the product where it will be ex- posed to water, moisture, or dust. Exposure of the unit to water, moisture, or dust may lead to smoke, fire, or other damage to the unit. Make especially sure that the unit does not get wet in truck washes or on rainy days. TTo ensure safety, never attempt to preset sta- tions while you are driving. T Depending upon the transmission condition of electro-magnetic waves, the geographical reasons and/or the weather conditions, you may not receive the NOAA radio partially or at all. TMake sure that your weather radio can receive properly before driving, especially, before use in a critical condition. TSet the volume level to low enough before th…

Text truncated - open the document above for the full version.

Cover Letter(s)

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division Limited Modular Approval Request November 20, 2012 PTW-12-F006 UL Compliance Certification Services Certification Division 471773 Benicia Street Frement, CA. 94538 USA Re: Request for Limited Modular Approval Bluetooth Module, Model NF2301 For Installation Within Car Radio, Model CQ-SM5559U To Whom It May Concern: (1) Have its own RF shielding: This module transmitter does not have its own RF shielding. Instead, it gets installed within Panasonic controlled end-product car radio, which provides the required RF shielding. (2) The module transmitter must have buffered modulation/data inputs: The data input to this module transmitter has buffered modulation/data inputs so as not to allow generating excessive data speed and abnormal modulation. (3) The module transmitter must have its own power supply regulation: Panasonic controlled end-product car radio provides 12VDC to the module transmitter and its internal power supply regulator automatically adjusts it to 3.7 VDC operating power. (4) The module transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c): This equipment has a unique coupling antenna connector, and the installation is to be done at our authorized end-product car radio manufacturing facilities. Therefore, the equipment complies with the antenna requirement of section 15.203. (5) Tested in a stand-alone configuration: The module transmitter is installed within Panasonic controlled end-product car radio and the car radio was tested in stand alone test mode. The DC power lines and data input/output lines connected to the module do not contain any ferrite cores. The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. All peripherals used during the testing are unmodified and commercially available. (6) The module transmitter must be labeled with its own FCC ID, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module: The module transmitter itself contains FCC ID label; and as it will always be installed within Panasonic controlled end-product car radio, the car radio outer enclosure will have label which states: Contains FCC ID: ACJ932CQ-SM5559U Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division November 20, 2012 PTW-12-F006 (7) The module transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements: The installation of the Module Transmitter will be performed at our authorized end-product car radio manufacturing facilities and all necessary items of compliance are provided. (8) The module transmitter must comply with any applicable RF exposure requirements: The module transmitter complies with FCC radiation exposure requirement for mobile operation while installed only within Panasonic controlled car radio and its physical construction and installation guarantees minimum 20 cm spacing between antenna and user’s body. Thank you for your attention to this matter. Sincerely, Richard Mullen Richard Mullen Group Manager Product Safety & Compliance Division

Cover Letter(s)

Approval sheet Page 2 of 9 ASC_RFANT5220110A0T_V13 Oct. 2010 FEATURES Surface Mounted Devices with a small dimension of 5.2 x 2.0 x 1.1 mm 3 meet future miniaturization trend. Embedded and LTCC (Low Temperature Co-fired Ceramic) technology is able to future integrate with system design as well as beautifying the housing of final product. High Stability in Temperature / Humidity Change APPLICATIONS Bluetooth Wireless LAN HormRF ISM band 2.4GHz wireless applications DESCRIPTION Walsin Technology Corporation develops a new ceramic embedded antenna specified for 2.4 GHz ISM Band application, as shown in below “CONSTRUCTION”. Both of Wireless LAN IEEE 802.11b and Bluetooth TM typically located on this unlicensed frequency band which range covers from 2.4GHz to 2.4835GHz. To fulfil the friendly usage for antenna, this antenna has been designed to a typical 150MHz bandwidth through Walsin’s advanced LTCC (Low Temperature Co-fired Ceramic) technology and superior product design via 3D EM Simulation Skill. This antenna has a rectangular ceramic body with a tiny dimension of 5.2x 2.0 x 1.1 mm 3 meet the future SMT automation and miniaturization requirements on modern portable devices. CONSTRUCTION Fig 1. Outline of 2.4GHz Antenna – RFANT5220110A0T Fig 2. Dimension L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm A = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm WTC L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm A = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm WTC L= 2.0 ±0.2 mm T= 1.15 ±0.10 mm W = 5.2 ± 0.2 mm A = 0.40 ± 0.25 mm A = 0.40 ± 0.25 mm WTC Identification mark Soldering terminal W T C W T C Feeding Identification mark Soldering terminal W T C W T C Feeding Approval sheet Page 3 of 9 ASC_RFANT5220110A0T_V13 Oct. 2010 SOLDER LAND PATTERN DESIGN Figure ELECTRICAL CHARACTERISTICS RFANT5220110A0T Specification Working Frequency Range 2.4 GHz ～ 2.5GHz Gain 2 dBi (Typical) VSWR 2 max. Polarization Linear Azimuth Bandwidth Omni-directional Impedance 50Ω Rated Power (max.) 3 Watts Maximum Input Power 5 Watts for 5 minutes Operation Temperature -40 ̊C ~ +85 ̊C Remark: The specification is defined based on the test board dimension as in below Approval sheet Page 4 of 9 ASC_RFANT5220110A0T_V13 Oct. 2010 Antenna on Test Board ( FR4 Thickness 0.8mm) Antenna S11 on Measured Board: Measured Frequency (GHz) 2.67 2.7425 2.82 Return Loss( S11)( dBmax.) <-10 <-10 <-10 Measured Board + S11: Bandwidth >150MHzBandwidth >150MHz Empty Area Empty Area 18x9 mm 50Ω ΩΩ ΩFeed line GROUND 30x18 mm 1mm 3.3mm 1.5mm WTC 2.5mm 18mm Empty Area Empty Area 18x9 mm 50Ω ΩΩ ΩFeed line GROUND 30x18 mm 1mm 3.3mm 1.5mm WTC 2.5mm 18mm Antenna position

External Photos

ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 2 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT (B) Host Devise (Car Radio) 1. 2. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 3 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 3. 4. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 4 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 5.

Internal Photos

ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 1 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT (A) Bluetooth Module 1. 2. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 5 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 6. 7. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 6 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 8. 9. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 7 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 10. 11. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 8 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 12. 13. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 9 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 14. 15. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 10 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 16. 17. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 11 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 18. 19. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 12 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 20. 21. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 13 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 22. 23. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 14 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 24. 25. ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 15 of 15 Sheets Rev. No 2.1 CONSTRUCTED PHOTOS of EUT 26. 27.

RF Exposure Info

FCC ID: ACJ932CQ-SM5559U RF Exposure Evaluation of E.U.T. : Bluetooth Module FCC ID. : NF2301 MODEL : ACJ932CQ-SM5559U for APPLICANT : Panasonic Corporation of North America ADDRESS : One Panasonic Way 4B-8 Secaucus, NJ 07094 Prepared by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5, DINGFU VIL., LINKOU DIST., NEW TAIPEI CITY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : 12-11-RBF-021-MPE FCC ID: ACJ932CQ-SM5559U Product Information: Type of EUT: Bluetooth Module FCC ID: ACJ932CQ-SM5559U Manufacturer: Panasonic Taiwan Co., Ltd. Model: NF2301 Description: Bluetooth module Maximum output power (including manufacturing tolerance): 4.0 dBm or 2.511mW The following table lists the provided authorized antennas: Antenna Gain Model Antenna Type (dBi) Numeric RFANT5220110A0T Ceramic Embedded Antenna 2 1.58 Below is an example of the RF Exposure Statement: IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. No change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. FCC ID: ACJ932CQ-SM5559U Relative Requirement for Compliance According to section 1.1310 of FCC 47 CFR Part 1, limits for maximum permissible exposure (MPE) are as following: TABLE 1 – LIMITS FOR MAXIMUN PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 .................. 6141.63*(100) 6 3-30 ..................... 1842/f4.89/f *(900/f 2 ) 6 30-300 .................. 61.40.1631.0 6 300-1500 ............... ............................................f/300 6 1500-100,000 ......... ............................................5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 ............... 6141.63*(100) 30 1.34-30 ............... 824/f2.19/f*(180/f2) 30 30-300 .................. 27.50.0730.2 30 300-1500 ............... ............................................f/1500 30 1500-100,000 ......... ............................................1.0 30 f = frequency in MHz * = Plane-wave equivalent power density NOTE 1 TO TABLE 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational / controlled limits apply provided he or she is made aware of the potential for exposure. NOTE 2 TO TABLE 1: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC ID: ACJ932CQ-SM5559U RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0 mW/cm 2 uncontrolled exposure limit. The formula shown in OET Bulletin 65 is used in the calculation. Equation from page 19 of OET Bulletin 65, Edition 97-01 is: S= PG / 4πR 2 where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) hence R= (PG / 4πS) 1/2 For our device P = 2.511mW G = 1.58 R = 20 cm S = (2.511 * 1.58) / (4*π*20 2 ) = 0.0008 mW/cm 2 < 1.0 mW/cm 2 For complying the FCC limits for general population/uncontrolled exposure, the power density limit is 1.0 mW/cm 2 . The calculation result of the power density at a distance of 20 cm of our device is less than the limit. This means that according to OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01), the equipment fulfills the requirements on power density for general population/uncontrolled exposure and therefore fulfills the requirements of 47 CFR Part 15.247 (b)(5).

Test Report

Rev. No 1.0 FCC Part 15 EMI TEST REPORT of E.U.T. : Bluetooth Module Model : NF2301 FCC ID : ACJ932CQ-SM5559U for APPLICANT : Panasonic Corporation of North America ADDRESS : One Panasonic Way 4B-8 Secaucus, NJ 07094 Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34. LIN 5, DINGFU VIL., LINKOU DIST., NEW TAIPEI CITY, TAIWAN, 24442, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail : [email protected] Report Number : 12-11-RBF-021 ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Manufacture : Panasonic Taiwan Co., Ltd. 579, Yuan Shan Road, Chung-Ho, Taipei Hsien, Taiwan Description of Device : a) Type of EUT : Bluetooth Module b) Trade Name : Panasonic c) Model No. : NF2301 d) Power Supply : DC 12V Regulation Applied : FCC Rules and Regulations Part 15 Subpart C I HEREBY CERTIFY THAT: The data shown in this report were made in accordance with the procedures given in ANSI C63.4, and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC. Summary of Tests Test Results Radiated Emission Pass Conducted Emission N/A Hopping Channel Separation Pass Number of Hopping frequencies used Pass Hopping Channel Bandwidth Pass Dwell Time of each frequency Pass Output Power Requirement Pass 100 kHz Bandwidth of Frequency Band Edges Requirement Pass Out-of-Band Conducted Emission Requirement Pass ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Rev. No 1.0 Date Test Item Received : Nov. 14, 2012 Date Test Campaign Completed : Nov. 25, 2012 Date of Issue : Nov. 26, 2012 Test Engineer : ( Vincent Chang, Engineer ) Approve & Authorized : S. S. Liou, Section Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Rev. No 1.0 Table of Contents Page 1 GENERAL INFORMATION ....................................................................................................... 1 1.1 Product Description...................................................................................................................... 1 1.2 Test Methodology ........................................................................................................................ 1 1.3 Test Facility.................................................................................................................................. 1 2 PROVISIONS APPLICABLE...................................................................................................... 2 2.1 Definition ..................................................................................................................................... 2 2.2 Requirement for Compliance ....................................................................................................... 3 2.3 Restricted Bands of Operation ..................................................................................................... 5 2.4 Labeling Requirement .................................................................................................................. 6 2.5 User Information .......................................................................................................................... 6 3 SYSTEM TEST CONFIGURATION .......................................................................................... 7 3.1 Justification .................................................................................................................................. 7 3.2 Devices for Tested System........................................................................................................... 7 4 RADIATED EMISSION MEASUREMENT .............................................................................. 8 4.1 Applicable Standard ..................................................................................................................... 8 4.2 Measurement Procedure............................................................................................................... 8 4.3 Measuring Instrument ................................................................................................................ 10 4.4 Radiated Emission Data ............................................................................................................. 11 4.5 Field Strength Calculation.......................................................................................................... 17 4.6 Photos of Radiation Measuring Setup........................................................................................ 18 5 CONDUCTED EMISSION MEASUREMENT ........................................................................ 19 5.1 Description ................................................................................................................................. 19 6 ANTENNA REQUIREMENT .................................................................................................... 20 6.1 Standard Applicable ................................................................................................................... 20 6.2 Antenna Construction................................................................................................................. 20 7 HOPPING CHANNEL SEPARATION..................................................................................... 21 7.1 Standard Applicable ................................................................................................................... 21 7.2 Measurement Procedure............................................................................................................. 21 7.3 M…

Text truncated - open the document above for the full version.

Test Setup Photos

ETC Report No. : 12-11-RBF-021 FCC ID.: ACJ932CQ-SM5559U Sheet 18 of 98 Sheets Rev. No 2.1 4.6 Photos of Radiation Measuring Setup

Contact Information

Applicant

Ben Botros(Project Manager)

[email protected]201-348-7760Fax: 201-348-7760

Technical Contact

Electronics Testing Center, TaiwanS.S. Liou

[email protected]886-2-26023052

NO. 34, LIN 5, DINGFU TSUEN, LINKOU SHIANG, · TAIPEI COUNTY · Taiwan

Non-Technical Contact

Electronics Testing Center, TaiwanS.S. Liou

[email protected]886-2-26023052

Test Firm

Taiwan Testing and Certification CenterAnderson Ku

[email protected]886-2-26023052Fax: +886-2-26010910

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	2.50 mW

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Limited modular approval. Power output listed is conducted. This device has no RF shield. Approval is limited to OEM installation only in the host platform described in this filing. Use in other host devices requires testing for radiated emissions and submission of a Class 2 Permissive Change. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all person. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
