ACJ932YEP0FX1515SMART ECU

4261 Ikonobe-cho, Tsuzuki-ku, Yokohama City 224-8520, Japan Tel +81-45-939-6111 http://panasonic.co.jp/pas/en/index.html 1 SMART KEY SYSTEM USER MANUAL Panasonic Corporation Automotive & Industrial Systems Company 2 FOB KEY What is the SMART KEY SYSTEM ? 3 Operating Range of SMART KEY SYSTEM * ID authentication is carried out when you operate the door handle knob and the tailgate knob. If the ID authentication succeeds, you can open doors and the tailgate. *bidirectional communication between Car and FOB Key Operating Range of unlocking doors and the tailgate function 4 Operating Range of starting the Engine function Operating Range of starting the Engine function is in the car except on the Instrument Panel, on the Rear shelf. 5 Door Unlock and Lock You can unlock and lock doors from driver’s door handle and assistant’s door handle Door Unlock If a door handle is grasped, all doors and the tailgate are unlocked.At this time, answerback buzzer sounds “pip” and hazard flusher blink twice. Door LockIf a door handle outside portion is touched, all doors and the tailgate are locked.At that time, answerback buzzer sounds “pip” and hazard flusher blink one time. 6 Trunk Unlock and Lock 7 Engine Start Button There are the following five states in the Engine Start Button . 8 How to start Engine 4261 Ikonobe-cho, Tsuzuki-ku, Yokohama City 224-8520, Japan Tel +81-45-939-6111 http://panasonic.co.jp/pas/en/index.html 9 Keyless Entry You can unlock or lock all doors and the tail gate by pressing the Button of a FOB Key. Button FOB Key （ Transmitter included ） Door and Trunk Unlock Please press the Door Unlock Button of a FOB Key. Then all doors and trunk are unlocked and hazard flusher blink two times.Door and Trunk Lock Please press the Lock Button of a FOB Key. Then all doors and the trunk are locked and hazard flusher blink one time. 10 YEP0FX1510 FCC ID Marking FCCID:ACJ932YEP0FX1510 ACJ932YEP0FX1510 *Remove the mechanical key

Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Tel/Fax: 201-348-7758 / [email protected] Richard Mullen, Group Manager Product Safety and Compliance Division Letter of Agency April 8, 2014 PAS-14-F003 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Re: SMART ECU, Models YEP0FX1514, YEP0FX1515, YEP0FX1518 and YEP0FX1519 under FCC ID: ACJ932YEP0FX1515 / Periodic Transmit Operation at 125 kHz To Whom It May Concern: Please be advised Panasonic Corporation of North America hereby authorizes Yoshinobu Asai of Application Section, WiSE Japan, UL Verification Service, UL Japan, Inc. to act on our behalf for a period of one year from the date of this letter, or until otherwise notified. Any and all acts carried out by them on our behalf shall have the same effect as acts of our own. We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. The application for the subject equipment has not been submitted to another TCB for certification. Product Name: SMART ECU, Models YEP0FX1514, YEP0FX1515, YEP0FX1518 and YEP0FX1519 (Period ic T ransmit Operation at 125 kHz) Product Classification: Remote Control / Security Device Transceiver FCC ID: ACJ932YEP0FX1515 Transmitter Rule Part: Part 15C, Section 15.231 (radiated) Applicant & Grantee: Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 FRN Number: 0003762242 Sincerely yours, Richard Mullen Richard Mullen Group Manager Product Safety & Compliance Division Cc: Ms. Arisa Hirata / Email: [email protected] Automotive Electronics Business Division / Product Design Group Automotive & Industrial Systems Company Panasonic Corporation

Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Tel/Fax: 201-348-7758 / [email protected] Richard Mullen, Group Manager Product Safety and Compliance Division Request for Confidentiality April 8, 2014 PAS-14-F003 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Re: SMART ECU, Models YEP0FX1514, YEP0FX1515, YEP0FX1518 and YEP0FX1519 under FCC ID: ACJ932YEP0FX1515 / Periodic Transmit Operation at 125 kHz To Whom It May Concern: In accordance with provisions of Sections 0.457 and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for the below indicated exhibits. This transmitter is not user adjustable and does not have user tune-up procedure. These exhibits contain proprietary, confidential and/or trade secret materials, which would not be routinely made available for public inspection. • Schematic Diagram • Block Diagram • Theory of Operation In accordance with FCC Public DA 04-1705, we request 45 da y short-term confidentiality 1 , starting from the issuance of equipment authorization date, for the below indicated exhibits. These exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. • External Photographs • Internal Photographs • Test Setup Photographs and Test Setup Configuration v User Manual. The above materials contain trade secrets and proprietary information not customarily re leased to the general public. Since this design is a basis from which future technological products will evolve, the public disclosure of these materials can be harmful to the Applicant by providing unfair advantage and benefits to its competitors. Thank you for your attention to this matter. Sincerely, Richard Mullen Richard Mullen Group Manager Product Safety & Compliance Division 1 Public Notice DA 04-1705 does not allow initial requesting of short-term confidentiality of 180 days and instead, after the first 45 days must request for additional days as needed.

1 4261 Ikonobe-cho, Tsuzuki-ku , Yokohama City 224-8520, Japan Tel +81-45-939-6111 http://panasonic.net/index.html Automotive Electronics Business Division YEP0FX1515 External photos 80mm 125mm 23.6mm 600 Saedo-cho, Tsuzuki-ku, Yokohama Cit y 224-8539, Japan Tel +81-45-939-1665 http://panasonic.co.jp/pas/en/index.html YEP0FX1514 External Photos 2 YEP0FX1518, YEP0FX1519 External photos 80mm 23.6mm 125mm

4261 Ikonobe-cho, Tsuzuki-ku, Yo kohama City 224-8520, Japan Tel +81-45-939-6111http://panasonic.net/index.html YEP0FX1515, YEP0FX1514, YEP0 FX1518, YEP0FX1519 Label Label Layout No Indication Contents 1 Serial Number 5***** ** 2 QR code Serial number, others 3 Lot Number YYMMDD 4 Model Number YEP0FX1515, YEP0FX1514YEP0FX1518,YEP0FX1519 5 FCC ID ACJ932YEP0FX1515 38320-TR0-*** CY-MH50H4AJ SMART ECUModel:YEP0FX15** CN:1 Panasonic Corporation Made in JapanFCC ID: ACJ932YEP0FX1515 5***** YYMMDD 2 1 3 5 4 YEP0FX1514, 1518, 1519 YEP0FX1515

3 YEP0FX1514, YEP0FX1515, YEP0FX1518, YEP0FX1519 Internal photos 75.0mm 12.0mm Radio block Radio block

Test report No. : 10261262H Page : 2 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 REVISION HISTORY Original Test Report No.: 10261262H Revision Test report No. Date Page revised Contents - (Original) 10261262H May 27, 2014 - - Test report No. : 10261262H Page : 3 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ..................................................................................................... 4 SECTION 2: Equipment under test (E.U.T.) ........................................................................................ 4 SECTION 3: Test specification, procedures & results ........................................................................ 5 SECTION 4: Operation of E.U.T. during testing ................................................................................. 8 SECTION 5: Radiated emission (Fundamental and Spurious Emission) ........................................ 10 SECTION 6: -26dB Bandwidth ............................................................................................................ 12 SECTION 7: 99% Occupied Bandwidth ............................................................................................. 12 APPENDIX 1: Data of EMI test ........................................................................................................... 13 Radiated Emission below 30MHz (Fundamental and Spurious Emission) ................................. 13 Radiated Emission above 30MHz (Spurious Emission) ................................................................. 19 -26dB Bandwidth and 99% Occupied Bandwidth ......................................................................... 25 Duty Cycle .......................................................................................................................................... 31 APPENDIX 2: Test instruments .......................................................................................................... 61 APPENDIX 3: Photographs of test setup ............................................................................................ 62 Radiated Emission ............................................................................................................................. 62 Worst Case Position .......................................................................................................................... 64 Test report No. : 10261262H Page : 4 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 SECTION 1: Customer information Company Name : Panasonic Corporation Address : 4261, Ikonobe-cho, Tsuzuki, Yokohama, 224-8520, Japan Telephone Number : +81-45-939-1144 Facsimile Number : +81-45-939-1917 Contact Person : Masahiro Yoshii SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : SMART ECU Model No. : YEP0FX1515 YEP0FX1518 Serial No. : Refer to Section 4, Clause 4.2 Rating : DC 6.0 to 16.0 V Receipt Date of Sample : March 18, 2014 Country of Mass-production : Japan Condition of EUT : Production prototype (Not for Sale: This sample is equivalent to mass-produced items.) Modification of EUT : No Modification by the test lab 2.2 Product description Model No: YEP0FX1515 / YEP0FX1518 (referred to as the EUT in this report) is the SMART ECU. General Specification Clock frequency(ies) in the system : 16MHz (CPU Main Clock) 32.768kHz (CPU Sub Clock) Radio Specification Equipment Type : Transceiver Frequency of Operation : 125kHz Mode of Operation : Simplex Method of Frequency Generation : Crystal Antenna Type : Ferrite antenna List of Model No. Model No. YEP0FX1515 (Original model: tested model) YEP0FX1518 (Variant model: tested model) YEP0FX1519 (Variant model) YEP0FX1514 (Variant model) Difference from original model * This model controls 4doors. Antennas, Software and Electric circuit * This model controls 5doors. Software and Electric circuit * This model controls 5doors. Appearance * This model controls 4doors. The differences among the above three models do not influence on radio specification. Test report No. : 10261262H Page : 5 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 SECTION 3: Test specification, procedures & results 3.1 Test Specification Test Specification : FCC Part 15 Subpart C: 2014, final revised on March 6, 2014 and effective April 7, 2014 Title : FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators Section 15.207 Conducted Emission Section 15.209 Radiated emission limits, general requirements * The revision on March 6, 2014 does not affect the test specification applied to the EUT. FCC 15.31 (e) This test was performed with the New Battery (DC 12V) and the constant voltage was supplied to this EUT during the tests. Therefore, this EUT complies with the requirement. FCC Part 15.203 Antenna requirement It is impossible for end users to replace the antenna, because the antenna is mounted inside of the vehicle. Therefore, the equipment complies with the antenna requirement of Section 15.203. 3.2 Procedures and results No. Item Test Procedure Specification RemarksDeviation Worst margin Results 1 Conducted Emission <FCC> ANSI C63.4:2003 7. AC powerline conducted emission measurements <IC> RSS-Gen 7.2.4 <FCC> Section 15.207 <IC> RSS-Gen 7.2.4 - N/A *1) N/A N/A 2 Electric Field Strength of Fundamental Emission <FCC> ANSI C63.4:2003 13. Measurement of intent…

Text truncated - open the document above for the full version.

Test report No. : 10261262H Page : 62 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 APPENDIX 3: Photographs of test setup Radiated Emission Sedan type (YEP0FX1515) Photo 1 Photo 2 Test report No. : 10261262H Page : 63 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Radiated Emission Wagon type (YEP0FX1518) Photo 1 Photo 2 Test report No. : 10261262H Page : 64 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Worst Case Position SMART ECU (Sedan Type (YEP0FX1515)) Below 30MHz X-axis Above 30MHz Horizontal: X-axis / Vertical: X-axis (With FRDR Antenna) Horizontal: X-axis / Vertical: X-axis (With TR Antenna) Horizontal: X-axis / Vertical: X-axis (With M/TI Antenna) Horizontal: X-axis / Vertical: X-axis (With F Antenna) X-axis Y-axis Z-axis Test report No. : 10261262H Page : 65 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Worst Case Position SMART ECU (Wagon Type(YEP0FX1518)) Below 30MHz X-axis Above 30MHz Horizontal: X-axis / Vertical: X-axis (With FRDR Antenna) Horizontal: X-axis / Vertical: X-axis (With R Antenna) X-axis Y-axis Z-axis Test report No. : 10261262H Page : 66 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Worst Case Position FRDR Antenna Sedan type (YEP0FX1515) Below 30MHz Z-axis Above 30MHz Horizontal: X-axis / Vertical: X-axis Wagon type (YEP0FX1518) Below 30MHz X-axis Above 30MHz Horizontal: X-axis / Vertical: X-axis X-axis Y-axis Z-axis Test report No. : 10261262H Page : 67 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Worst Case Position TR Antenna / M/TI Antenna TR Antenna Below 30MHz Z-axis Above 30MHz Horizontal: X-axis / Vertical: X-axis M/TI Antenna Below 30MHz X-axis Above 30MHz Horizontal: X-axis / Vertical: X-axis X-axis Y-axis Z-axis Test report No. : 10261262H Page : 68 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Worst Case Position F Antenna Below 30MHz X-axis Above 30MHz Horizontal: X-axis / Vertical: X-axis X-axis Y-axis Z-axis Test report No. : 10261262H Page : 69 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Worst Case Position R Antenna Below 30MHz Z-axis Above 30MHz Horizontal: X-axis / Vertical: X-axis X-axis Y-axis Z-axis Test report No. : 10261262H Page : 70 of 70 Issued date : May 27, 2014 FCC ID : ACJ932YEP0FX1515 UL Japan, Inc. Ise HQ EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 4.2 Configuration and peripherals DC 12V A 1 B 3 4 5 C D E 6 F 2 * Cabling and setup were taken into consideration and test data was taken under worse case conditions. Description of EUT and Support equipment No. Item Model number Serial number Manufacturer Remarks A SMART ECU YEP0FX1515 001 Panasonic Corporation EUT YEP0FX1518 001 B FRDR Antenna TR0-7B000-000 L14 Panasonic Corporation EUT TV0-7B000-000 1 C TR Antenna 38387-TF0-003 16 Panasonic Corporation EUT D M/TI Antenna 38387-TF0-003 12 Panasonic Corporation EUT E F Antenna *1) 38387-SZW-003 13 Panasonic Corporation EUT R Antenna *2) 38387-SLE-003 32 F Switch Jig - - Panasonic Corporation - *1) Used for ECU: YEP0FX1515 *2) Used for ECU: YEP0FX1518 List of cables used No. Name Length (m) Shield Remarks Cable Connector 1 DC Cable 1.2 Unshielded Unshielded - 2 Signal Cable 0.8 Unshielded Unshielded - 3 Antenna Cable 1.0 Unshielded Unshielded - 4 Antenna Cable 1.0 Unshielded Unshielded - 5 Antenna Cable 1.0 Unshielded Unshielded - 6 Antenna Cable 1.0 Unshielded Unshielded - End of Report
