ACJ96NBB-HGW700802.11b/g Wireless Router

Network Camera Management System Operating Instructions Model No. BB-HGW700A Please read this manual before using and save this manual for your future reference. Panasonic Web Site: http://www.panasonic.com for customers in the USA or Puerto Rico Operating Instructions 2 Introduction Thank you for purchasing the Panasonic Network Camera Management System. Please check the following items when unpacking. Before using Please read the Important Safety Instructions on Page 4 before using. Read and understand all instructions. For Operation Assistance •Call 1-800-272-7033 •Refer to the Panasonic web site http://www.panasonic.com Operating Instructions AC adaptor Ethernet cable (Category 5 straight cable) Cable clamper Screws and Washers — 1 pc. — 1 pc. — 1 pc. — 1 pc. — 2 pcs. [For assistance, please call: 1-800-272-7033] Operating Instructions 3 Abbreviations •UPnP is the abbreviation for Universal Plug and Play. Trademarks •Ethernet is a registered trademark of Xerox Corporation in the United States and/or other countries. •Microsoft, MSN, Windows and DirectX are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. •Screen shots reprinted with permission from Microsoft Corporation. •All other trademarks identified herein are the property of their respective owners. Network Camera Management System Memo Serial Number MAC Address Name and address of dealer Date of purchase For your future reference Attach your purchase receipt here. Operating Instructions 4 IMPORTANT SAFETY INSTRUCTIONS When using this unit, basic safety precautions should always be followed to reduce the risk of fire, electric shock, or personal injury. 1.Read and understand all instructions. 2.Keep these instructions. 3.Heed all warnings. 4.Follow all instructions. 5.Do not install this product near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 6.Protect the AC adaptor cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 7.Do not touch the unit or the AC adaptor during lightning storms. 8.Unplug this apparatus when unused for long periods of time. 9.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as when the AC adaptor cord or plug is damaged, the apparatus does not operate normally, or it has been dropped. SAVE THESE INSTRUCTIONS [For assistance, please call: 1-800-272-7033] Operating Instructions 5 Table of contents 1 Product Introduction .............................................................................. 7 1.1 Main Features ................................................................................................................ 7 1.2 Feature Locations ..........................................................................................................8 1.2.1 Front View................................................................................................................................... 8 1.2.2 Rear View ................................................................................................................................... 8 1.2.3 Indicators .................................................................................................................................... 9 2 Accessing This Product ....................................................................... 10 2.1 Functions .....................................................................................................................10 2.1.1 Top page................................................................................................................................... 10 2.1.2 Setup ........................................................................................................................................ 12 2.1.3 IPv6 Setup ................................................................................................................................ 14 2.1.4 Camera Portal .......................................................................................................................... 15 3 Functions............................................................................................... 19 3.1 Using the Functions .....................................................................................................19 3.1.1 Registering ISPs....................................................................................................................... 19 3.1.2 Confirming Connection to the Internet...................................................................................... 27 3.1.3 Managing the Connection Mode............................................................................................... 28 3.1.4 Using Camera........................................................................................................................... 30 3.1.5 Registering a Camera Automatically ........................................................................................31 3.1.6 Using Wireless.......................................................................................................................... 37 3.1.7 Using Viewnetcam.com ............................................................................................................ 44 3.2 Using Advanced Setup................................................................................................. 46 3.2.1 Accessing this Product from the Internet..................................................................................46 3.2.2 Improving Security.................................................................................................................... 52 3.2.3 Using Options .....................................................................................................…

Text truncated - open the document above for the full version.

Block Diagram (Main Block) Main Block Figure [ Power supply] [WAN block ] CPU ROMCS3N Inductors LED (Power) Address bus RMII ADDRESS miniPC LED R/G INITSW Clock 18.432MHz RTCRST 10/100Base 4port Transceiver 10BaseT/100BaseTX (LAN) RJ45 connector × 4 LED(LAN × 4) Inductors VDD15 VSW15 VDD33 VDD332 VRF33 Clock 25MHz [RF block] [LAN block ] [Control block] REG IC RESET IC Initialize SW DC LED(PPP) LEDPPP LED (Wireless LAN) GPIO ACARMN Voltage deteft IC CLKX FLASH ROM Program Memory SDCS0 N 10/100Base 1port Transceiver LED(WAN) RMII 50MHz DC/DC VSW25 REG IC +2.5V +1.5V +3.3V Data bus RJ45 connector × 1 MiniPCI bus DATA DC12V from AC adapter ••••• •• MB ••• ••• SDRAM Main Memory

EXHIBIT D PHOTOGRAPHS Model BB-HGW700A Rear View

EXHIBIT B MARKINGS This unit provides with the following markings, or equivalent. NOTE: Above markings are shown on rear of the unit. Label

Internal View P.C. Board

Page 1 of 8 Attchment A 6dB Bandwidth Measurement Test Date: October 8, 2004 Temp.: 24 ; Humi.: 60 %°C a)Mode of EUT : 802.11b CHTransmitting6dB99%Data No.Frequency(MHz)BandwidthBandwidthPage 12412.011.84 MHz15.51 MHzPage 2 62437.011.41 MHz15.48 MHzPage 3 112462.011.80 MHz15.42 MHzPage 4 b)Mode of EUT : 802.11g CHTransmitting6dB99%Data No.Frequency(MHz)BandwidthBandwidthPage 12412.016.69 MHz16.65 MHzPage 5 62437.016.65 MHz16.62 MHzPage 6 112462.016.69 MHz16.62 MHzPage 7 .Note) 1. The point shown on "" is the Maximum Margin Point Tester : Shigeru Kinoshita JQA Application No. : KL80040294TRegulation : CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date : November 25, 2004 FCC ID: ACJ96NBB-HGW700 Page 2 of 8 6dB Bandwidth Measurement Mode of EUT: 801.11b Transmitting Frequency : 2412.0MHz ( 1ch) JQA Application No. : KL80040294TRegulation : CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date : November 25, 2004 FCC ID: ACJ96NBB-HGW700 JQA Application No. : KL80040294TRegulation : CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date : November 25, 2004 FCC ID: ACJ96NBB-HGW700 Page 3 of 8 6dB Bandwidth Measurement Mode of EUT: 801.11b Transmitting Frequency : 2437.0MHz ( 6ch) JQA Application No. : KL80040294TRegulation : CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date : November 25, 2004 FCC ID: ACJ96NBB-HGW700 Page 4 of 8 6dB Bandwidth Measurement Mode of EUT: 801.11b Transmitting Frequency : 2462.0MHz (11ch) JQA Application No. : KL80040294TRegulation : CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date : November 25, 2004 FCC ID: ACJ96NBB-HGW700 Page 5 of 8 6dB Bandwidth Measurement Mode of EUT: 801.11g Transmitting Frequency : 2412.0MHz ( 1ch) JQA Application No. : KL80040294TRegulation : CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date : November 25, 2004 FCC ID: ACJ96NBB-HGW700 Page 6 of 8 6dB Bandwidth Measurement Mode of EUT: 801.11g Transmitting Frequency : 2437.0MHz ( 6ch) JQA Application No. : KL80040294TRegulation : CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date : November 25, 2004 FCC ID: ACJ96NBB-HGW700 Page 7 of 8 6dB Bandwidth Measurement Mode of EUT: 801.11g Transmitting Frequency : 2462.0MHz (11ch) JQA Application No. : KL80040294TRegulation : CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date : November 25, 2004 FCC ID: ACJ96NBB-HGW700 Page 8 of 8 Band-Edge Emission Measurement Test Date: October 8, 2004 Temp.: 24 ; Humi.: 60 %°C a)Mode of EUT : 802.11b 1) Low Band-Edge Measurement CHTransmittingBand-Edge Band-EdgeData Frequency(MHz)Frequency(MHz) Level[dBc]Page 12412.02400.0-37.0Page 9 2) High Band-Edge Measurement CHTransmittingBand-Edge Band-EdgeData Frequency(MHz)Frequency(MHz) Level[dBc]Page 112462.02483.5-39.4Page 10 b)Mode of EUT : 802.11g 1) Low Band-Edge Measurement CHTransmittingBand-Edge Band-EdgeData Frequency(MHz)Frequency(MHz) Level[dBc]Page 12412.02400.0-28.4Page 11 2) High Band-Edge Measurement CHTransmittingBand-Edge Band-EdgeData Frequency(MHz)Frequency(MHz) Level[dBc]Page 112462.02483.5-33.9Page 12 .Note) 1. The point shown on "" is the Maximum Margin Point Tester : Shigeru Kinoshita

JQA Application No. : KL80040294TRegulation: CFR 47 FCC Rules Part 15 Model No.: BB-HGW700AIssue Date: November 25, 2004 FCC ID: ACJ96NBB-HGW700 Page 29 of 44 Test-Setup (Photographs) at worst case Conducted EmissionRadiated Emission Front ViewClose-up Side View
