ACJ96NKX-TC1403900MHz Cordless Telephone

Panasonic Corporation of North America

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: Mar 07, 2001
Application Purpose: Original Equipment
Date of Application: Mar 04, 2001
Equipment Note: 900MHz Cordless Telephone
Frequency Range: 925.20000000 - 927.50000000
Company: Panasonic Corporation of North America
Country: United States

Documents & Files

Select a file to view

Operational Description

Schematics

↗

Test Report

↗

Test Setup Photos

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Block Diagram

EXHIBIT G-2 EXHIBIT G-1

Cover Letter(s)

March 1, 2001 Federal Communications Commission Authorization & Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:Matsushita Electric Industrial Co., Ltd. FCC ID: ACJ96NKX-TC1403 Gentlemen: Submitted herewith, on behalf of Matsushita Electric Industrial Co., Ltd., is an application for Part 15 certification of the following low-power wireless transmitter: FCC ID:ACJ96NKX-TC1403 MODELS:KX-TC1403 / KX-TC1402 Equip. Class:Low Power Transceiver (DXT) EUT Type:900 MHz Cordless Telephone FREQ. Range:902.20 – 904.90 MHz (Base) 925.20 – 927.50 MHz (Handset) Attached is the authorization letter, measurement report (measurement data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagrams, schematic diagrams, circuit description and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Richard Mullen (Panasonic-MECA)

External Photos

© 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1403 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1403 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1403 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1403 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1403 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1403 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1403 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone

ID Label/Location Info

EXHIBIT B MARKINGS BASE UNIT: The base unit provides with the following marking, or equivalent. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone. 8 B 2 2 HAC FCC ID : ACJ96NKX-TC1403 Matsushita Electric Industrial Co., Ltd. Product of Mexico QQGT20001ZA Distributed by Panasonic Consumer Electronics Company Division of Matsushita Electric Corp. of America, Secaucus, NJ 07094 Model No. KX - TC1403 I.T.E. POWER SOURCE : 9V 200mA (USE ONLY WITH Panasonic AC ADAPTOR PQLV15) REN : 0.0B Complies with Part 68, FCC Rules FCC Reg. No. ACJMEX - W9-E - 8 B 2 2 HAC FCC ID : ACJ96NKX-TC1403 Matsushita Electric Industrial Co., Ltd. Product of Mexico QQGT20003ZA Distributed by Panasonic Consumer Electronics Company Division of Matsushita Electric Corp. of America, Secaucus, NJ 07094 Model No. KX - TC1402 I.T.E. POWER SOURCE : 9V 200mA (USE ONLY WITH Panasonic AC ADAPTOR PQLV15) REN : 0.0B Complies with Part 68, FCC Rules FCC Reg. No. ACJMEX - W9-E - Model No. KX - TC1403 FCC ID : ACJ96NKX-TC1403 Matsushita Electric Industrial Co.,Ltd. Product of Mexico QQGT20002ZA Model No. KX - TC1402 FCC ID : ACJ96NKX-TC1403 Matsushita Electric Industrial Co.,Ltd. Product of Mexico QQGT20002ZA FCC ID: ACJ96NKX-TC1403 EXHIBIT D EXHIBIT D FCC ID: ACJ96NKX-TC1403

Internal Photos

© 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone © 2001 PCTEST Lab FCC ID: ACJ96NKX-TC1403 Model: KX-TC1402 NVLAP Lab Code: 100431-0 PANASONIC 900MHz Cordless Phone

Internal Photos

Schematics

1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA 22 BASE BOARD SCHEMATICS (NETWORK & POWER SUPPLY SECTION) L30410uHL30510uHL30610uH C3371nF CONDAT C3401nFC3381nF C3390.1uF R344 100K Q3082DS601ASTX CHGDET 9V R34110 1/4W Q3062SD601ASTX R33912K CHG_CTRL 1234 567 CON3014P-JACK AB DC+DC- 12 VR301DSS301 F301AR390NT C305K680p 500V C304K680p 500V C324DNA C323K0.68uF C321K0.15uF C322K0.15uF C3280.1uF C3020.1uF C301DNA R306DNA R3044K7 R305100K R3034K7 1/4W R302100K 1/4W R32647K R3254K7 R324DNA R323100K R322100K L30133uH L30233uH L30310uH Vin 1 GND 2 Vout 3 IC301REG 5V(DPAK) Z302 MA4300MTA(DNA) C327 330uF 16V(DNA) D303ISS119TA Q3052SC4116PL D302 MA110TX(DNA) 5V RINGDET Q3012SA1625 Q3022N6517C HKSW Z301 MA4180MTA C30610nF R3141K5 R313 47 R312DNA R311 33 1/4W R31039K R3082K2 R309DNA R307DNA C318DNA C316 K0.1uF C315K10nF C314DNA C312K68nF C311K10nF C310100pF C3090.1uF C307DNA C308 10uF 25V TXOUT Q303C2120 R3153K3 C31310uF 16V R3194K7 C317DNA R317220K R320560 R3164K7 Q304 2SD601ASTX C32033nF RXIN 5V 12 VR302DSS301 9V C32610nF + 1 - 2 ~ 3 ~ 4 D301MD4S R321DNA Z305 MA4300MTA Z304 MA4300MTA R343390 12 Z303 MA4300MTA C3411000pF 123 CON302 CHARGE CONTACT TP301 TP302 TP303 TP304 TP305 TP306 TP307 TP308 TP309 TP310 TP311 TP313 TP316 TP317 TP319 TP320 TP321 TP322TP323 TP324 TP326 TP327 TP328 TP329 TP330 TP331 TP332 TP333 TP334 TP336 TP347 TP349 TP350 TP351 TP353 5V C3331nF C3341nF + - C3291nF(0805)(0805)(0805) (0805)(0805)(0805) (0805) (0805) (0805) (0805) (0805) (0805) (0805) (RADIAL) (AXIAL & RADIAL) (AXIAL & RADIAL) D304ISS119TA D305ISS119TA C3190.1uF 3V2 C3360.1uF R33815K AUDIO_OUT TXOUT TP343 TP344 TP345 DTMF C332 33nF R32868K Vin 1 GND 2 Vout 3 IC302TO-92(DNA) HKSW RINGDET RXIN TXOUT AUDIO_OUT CHGDET CHG+CHG- CONDAT R33047 C33010uF Q3072SD601ASTX R33310K R331100K 3V2 AUDIO_MUTE R342DNA R3321K R3370 R3360 1 LINE 1 HKSW 1 GND SCH20B01520096 R349SMD C342SMD R347A&R R340A&R TP349 TP349 R346A&R Q310A&R R348A&R HKSW TA1 TA1 18 NOTE: To ultracharge model is necesarychange these resistors:R339 ----------> 1.2K R347 ----------> 15 29 JAN 2001 FASTRACK 1 0.40 0.40 29/01/01 BETA RELEASE GILBERTO SOSA GILBERTO SOSA 29/01/0129/01/0129/01/01 JORGE BUENO VICTOR MTZ. REV DATE DESCRIPTION APPROVED DRAWING BYCHECKED BYAPPROVED BY NAME DATE SIGN DESCRIPTIONDRAWING NUMBERDATES:\tel_ped\La (TC1403B)\Others\H\F1hr0301.DDB - Documents\1bnw030.sch SIZE: A3 SHEET OF REV: PROJECT TITLE 1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA BASE BOARD SCHEMATICS(MICROPROCESSOR SECTION) 12 FASTRACK 1 12 CON102 ANT C113 1nF 3KV L102 8n2H(0603) ANT ANTENNA TP131 TP133 R1251M 1/4W D101ISS119TAD102ISS119TA TP142 R104100K C1010.1uF X1014MHz R11610M C10822pFC10922pF C104100uF L101100uH R111 10K DTMF R10947K C10647nF R119100K R106100K CHGDET SW101 PAGE VDD DS101In use / Charge R121270 3V2 VDD 3V2 HKSW 3V2 EN RINGDET R12310K CONDAT C10210nF CLK CHG_CTRL R122120K C1112200pF C107K10nF R11568K TP101 TP102 TP105 TP107 TP109 TP115 TP116TP117 TP118 TP119 TP120 TP124 TP125 TP126 TP127 TP128 TP130 TP134 TP135 TP136 TP137 C115DNA CDLBD SCL DATA C1160.1uF VDD C1180.1uF 1234567891011121314 CON101RF MODULE RXIN AUDIO_OUT DATA CLK EN CDLBD RXDATATXDATA 3V2 SCL CDLBDTXDATARXINSCLENCLKDATAAUDIO_OUTRXDATA RXDATA C110K33nF R129 75K R130 36K R131 18K R112 20K R113 39K R114 82K C1034700pF TXDATA P3.3 1 P3.4/T0 2 P3.5/T1 3 P3.6 4 P3.7 5 P1.2/INT4/T2 6 P1.1/INT3/T2EX 7 P1.0/INT2 8 Vss 9 VDD 10 XTAL2 11 XTAL1 12 RSTn 13 P3.0/MOUT0 14 P3.1/MOUT1/INT1 15 P3.2/MOUT2/INT0 16 MIN 17 P1.6/INT8/SCL 18 P1.7/INT9/SDA 19 P0.0 20 P0.1 21 P0.2 22 P0.3 23 P0.4 24 P0.5 25 P0.6 26 P0.7 27 P1.3/INT5 28 P1.4/INT6 29 P1.5/INT7/T2out 30 VDDP 31 Vpp/VssP 32 IC101P8XCL882 R10810K R110 5K1 VDD R127DNA DTMF CHG_CTRL CHGDET RINGDET PAGE CONDAT R11710K R11810K TPBPRO2TPAPRO1 3V2 TP138 C105DNA C1122pF C117100pF AUDIO_MUTE A_MUTE R120 100K Note: Insert for fastcharge model Note: For program tunning upNote: For program tunning down ANT1 SCH20B01520096 R124SMD 3V2 ( ( TPCPRO3 Note: For program TPCPRO3 29 JAN 2001 1 0.40 0.40 29/01/01 BETA RELEASE GILBERTO SOSA GILBERTO SOSA 29/01/0129/01/0129/01/01 JORGE BUENO VICTOR MTZ. REV DATE DESCRIPTION APPROVED DRAWING BYCHECKED BYAPPROVED BY NAME DATE SIGN DESCRIPTIONDRAWING NUMBERDATES:\tel_ped\La (TC1403B)\Others\H\F1hr0301.DDB - Documents\1bup030.sch SIZE: A3 SHEET OF REV: PROJECT TITLE 1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA R23110M C20622pFC20722pF X2014MHz TP248 TP262 C2100.1uF R2045M1 R203100K R201750K R202240K C2020.1uF Q202 2SD601ASTX Q201 2SD601ASTX VDD R20547K RESET IN TP201 TP202 R21633K R21310K R2332K2 RX_DATA C21910nF 12 CONN1BATT CON C2151nF D203MA736 VBAT Z201 MA1Z056TX C2181nF L201 0.1uH(SMD) L202 0.1uH(SMD) L203 0.1uH(SMD) C213 1nF(DNA) C2141nF(DNA) R230 1K 1 CHG3CHG- 1 CHG2SDATA 1 CHG1CHG+ L204 56uH(SMD) C211330uF 6V3 VDD C20910nF C2210.1uF R2351M R236180K Q2052SD601ASTX RESET IN BATTGND C21210nF Z202DNA) Z203 (DNA) (0805) (0805) ESD ROAD (GND) CHG+ SDATACHG- RESET IN TP205 TP250 TP252 TP253 TP254 TP255 TP256 TP257 TP258 TP259 TP260 TP261 C205100pF R24510K C2391nF R2231K R22427 BU201BUZZER D205 MA110TX VBAT Q2032SD601ASTX TP264 TP265 TP266 TP247 SW104 4 SW103 3 SW102 2 SW101 1 SW110 0 SW109 9 SW108 8 SW107 7 SW116 CHAN SW115REDIALSW114 FLASH SW113 TALK SW122PAUSESW121 AUDIO VOL SW120RINGERSW119DIRECT SW105 5 SW111 */Tone SW117 AUTO SW123 KEY1 SW124 KEY2 SW118 PROGRAM SW112 # SW106 6 CLK EN C2034700pF R211 18K TXDATA R210 36K R212 75K TP212 SCL DATA C2040.1uF VDD R208680 DS201LOW BATT LED CDLBD VDD BACK_LIGHT TP207 TP208 TP209 TP210 R209 330 DS202PHONE LED REC201RECEIVER Q2062SB709ARTX R24710K VBAT RX_ON TP227 TP230 TP231 TP232 12 J202ANT ANTANTENNA TP270 1234567891011121314 J1RF MODULE MIC IN AUDIO_OUT DATA CLK EN CDLBD RXDATATXDATA VBAT SCL CDLBDTXDATAMIC INSCLENCLKDATAAUDIO_OUTRXDATA HANDSET BOARD SCHEMATIC 29 JAN 2001 1 1 FASTRACK 1 0.40 TP246 TP237 TP238 TP220TP219 ROW1ROW2ROW3 KP1KP2KP3KP4KP5KP6 KP1 KP2 KP3 KP4 KP5 KP6 VDD P3.3 1 P3.4/T0 2 P3.5/T1 3 P3.6 4 P3.7 5 P1.2/INT4/T2 6 P1.1/INT3/T2EX 7 P1.0/INT2 8 Vss 9 VDD 10 XTAL2 11 XTAL1 12 RSTn …

Text truncated - open the document above for the full version.

Test Report

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road 6660-B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 15.249 Certification MATSUSHITA Electric Industrial Co., Ltd.Dates of Tests: February 15-16, 2001 1006 Oaza KadomaTest Report S/N: TX.210212090.ACJ Kadoma, Osaka 571 JAPANTest Site: PCTEST Lab, Columbia MD Attention:M. Mori, Manager (MEICL-KM4) Rich Mullen (MECA-PSCD) FCC ID ACJ96NKX-TC1403 APPLICANT MATSUSHITA Electric Industrial Co., Ltd. FCC Rule Part(s):§ 15.249 (Subpart C – Intentional Radiator) Classification:Low Power Transceiver, Rx Verified (DXT) EUT Type:900MHz Cordless Telephone (Base/Handset) Frequency Range:902.20 MHz ~ 904.90 MHz (Base) 925.20 MHz ~ 927.50 MHz (Handset) Trade Name: Panasonic Model(s):KX-TC1403/KX-TC-1402 This device has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified is ANSI C63.4-1992 with the following remarks (Note Codes): (#68) This grant does not pertain to Registration requirements under Part 68. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Lab Code 100431-0 © 2001 PCTEST Engineering Laboratory, Inc. Part 15.249 TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1SCOPE 1 2.1INTRODUCTION (SITE DESCRIPTION) 2 3.1PRODUCTION INFORMATION 3 4.1DESCRIPTION OF TESTS (CONDUCTED & RADIATED) 4-5 5.1ANTENNA REQUIREMENT/APPLIED MODULATION 6 6.1LIST OF SUPPORT EQUIPMENT 7 7.1FREQUENCY MEASUREMENTS (Fundamental & Harmonics) 8-15 8.1FREQUENCY MEASUREMENTS (Fundamental & Spurious) 16-17 9.1LINE-CONDUCTED EMISSIONS18 10.1SAMPLE CALCULATIONS19 11.1ACCURACY OF MEASUREMENT 20 12.1LIST OF TEST EQUIPMENT21 13.1CONCLUSION22 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H:OPERATIONAL DESCRIPTION ATTACHMENT I:TEST SETUP PHOTOGRAPHS ATTACHMENT J: EXTERNAL PHOTOGRAPHS ATTACHMENT K: INTERNAL PHOTOGRAPHS ATTACHMENT L: USER’S MANUAL Test Report S/N: TX.210212090.ACJFCC Part 15.249 Subpart C Dates of Tests: February 15-16, 2001Transmitter Certification © 2001 PCTEST LabFCC ID: ACJ96NKX-TC1403 (902 – 928 MHz)1 PANASONIC 900MHz Cordless Phone MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name:MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. Address:1006 Oaza Kadoma Kadoma, Osaka 571 JAPAN Attention:Mr. M. Mori, Manager (MEICL-KM4) Rich Mullen, Project Manager (MECA-PSCD) • FCC ID:ACJ96NKX-TC1403 • Model(s):KX-TC1403/KX-TC-1402 • Trade Name:Panasonic • EUT Type:900MHz Cordless Phone • Equipment Class:Low Power Transceiver, Rx Verified (DXT) • Application Type:Certification • Frequency Range:902.20 – 904.90 (Base) 925.20 – 927.50 (Handset) • FCC Rule Part(s):§ 15.249 (Subpart C - Intentional Radiator) • Dates of Tests:February 15-16, 2001 • Place of Tests:PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N:TX.210212090.ACJ Test Report S/N: TX.210212090.ACJFCC Part 15.249 Subpart C Dates of Tests: February 15-16, 2001Transmitter Certification © 2001 PCTEST LabFCC ID: ACJ96NKX-TC1403 (902 – 928 MHz)2 PANASONIC 900MHz Cordless Phone 2.1 INTRODUCTION The measurement procedure described in Section 15.249 of FCC Rules, and American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from MATSUSHITA Electric Industrial Co., Ltd. 900MHz Cordless Phone FCC ID: ACJ96NKX-TC1403. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 2.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure 1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: TX.210212090.ACJFCC Part 15.249 Subpart C Dates of Tests: February 15-16, 2001Transmitter Certification © 2001 PCTEST LabFCC ID: ACJ96NKX-TC1403 (902 – 928 MHz)3 PANASONIC 900MHz Cordless Phone 3.1 Product Information 3.2 Equipment Description The Equipment Under Test (EUT) is the MATSUSHITA Electric Industrial Co., Ltd. (Panasonic Models: KX-TC1…

Text truncated - open the document above for the full version.
