ACJ96NKX-TD7685Isochronous UPCS Portable Station (Handset)

EXHIBIT J Operating Instructions FOR KX-TD7685 Signed by: Michihito Miyazaki Senior Coordinator Technical Regulation January 7, 2008 Document Version 2007-12 Operating Instructions DECT 6.0 Portable Station Model No.KX-TD7685 Thank you for purchasing a Panasonic DECT 6.0 Portable Station. Please read this manual carefully before using this product and save this manual for future use. Please use only the battery provided and charge the battery for about 7 hours before using the handset for the first time. See page 66 for System Requirements. 2Document Version 2007-12 Table of Contents Before Initial Use.............................................................................................. 4 Accessories (included) .......................................................................................4 Installation............................................................................................................5 Battery Installation..............................................................................................5 Charger Connection ...........................................................................................5 Charging the Battery ..........................................................................................5 Charger Wall Mounting ......................................................................................6 Attaching the Belt Clip and Belt Clip Holder.......................................................6 Before Operating the Handset ........................................................................ 7 Location of Controls ...........................................................................................7 Key Lock ............................................................................................................8 Meeting Mode ....................................................................................................9 Selecting the Display Language ......................................................................10 Editing the Standby Display Name ..................................................................10 Editing the Names of the Flexible CO Keys ....................................................11 Adjusting the Ringer Volume ...........................................................................12 Adjusting the Ringer Volume or Turning the Ringer off while Ringing .......12 Changing the Vibrate Setting ...........................................................................13 Adjusting the Receiver/Speaker/Headset Volume..........................................13 Display................................................................................................................14 Soft Keys ............................................................................................................15 Operation Outline ..............................................................................................17 Function Menus .................................................................................................18 Function Keys....................................................................................................19 Flexible CO Keys ...............................................................................................20 Operation ........................................................................................................ 21 Making Calls.......................................................................................................21 Searching for an item stored in the Phonebook ...............................................24 Receiving Calls ..................................................................................................27 Caller ID ...........................................................................................................28 During a Conversation ......................................................................................29 Useful Features..................................................................................................30 Making Use of the Voice Mail Service .............................................................34 Using the Handset Phonebook..................................................................... 35 Handset Phonebook..........................................................................................35 Private Ring......................................................................................................35 Storing an Item in the Handset Phonebook ....................................................35 Storing a New Item...........................................................................................35 Editing a Stored Item........................................................................................36 Storing an Item Using the Predialing................................................................37 Storing an Item Using the Outgoing Call Log...................................................37 Storing an Item Using the Incoming Call Log...................................................38 Storing an Item Using the PBX System Phonebook ........................................39 Storing an Item Using the PBX Extension Phonebook ....................................39 Editing Category Names ..................................................................................40 Assigning Hot Keys...........................................................................................41 Entering Characters ..........................................................................................42 Document Version 2007-12 3 Character Mode Table ..................................................................................... 43 Locking the Handset Phonebook .................................................................... 44 Locking the Handset Phonebook ..............................................…

Text truncated - open the document above for the full version.

EXHIBIT J Operating Instructions FOR KX-TD7695 Signed by: Michihito Miyazaki Senior Coordinator Technical Regulation January 7, 2008 Document Version 2007-12 Operating Instructions DECT 6.0 Portable Station Model No.KX-TD7695 Thank you for purchasing a Panasonic DECT 6.0 Portable Station. Please read this manual carefully before using this product and save this manual for future use. Please use only the battery provided and charge the battery for about 7 hours before using the handset for the first time. See page 66 for System Requirements. 2Document Version 2007-12 Table of Contents Before Initial Use.............................................................................................. 4 Accessories (included) .......................................................................................4 Installation............................................................................................................5 Battery Installation..............................................................................................5 Charger Connection ...........................................................................................5 Charging the Battery ..........................................................................................5 Charger Wall Mounting ......................................................................................6 Attaching the Belt Clip........................................................................................6 Before Operating the Handset ........................................................................ 7 Location of Controls ...........................................................................................7 Key Lock ............................................................................................................8 Meeting Mode ....................................................................................................9 Selecting the Display Language ......................................................................10 Editing the Standby Display Name ..................................................................10 Editing the Names of the Flexible CO Keys ....................................................11 Adjusting the Ringer Volume ...........................................................................12 Adjusting the Ringer Volume or Turning the Ringer off while Ringing .......12 Changing the Vibrate Setting ...........................................................................13 Adjusting the Receiver/Speaker/Headset Volume..........................................13 Display................................................................................................................14 Soft Keys ............................................................................................................15 Operation Outline ..............................................................................................17 Function Menus .................................................................................................18 Function Keys....................................................................................................19 Flexible CO Keys ...............................................................................................20 Operation ........................................................................................................ 21 Making Calls.......................................................................................................21 Searching for an item stored in the Phonebook ...............................................24 Receiving Calls ..................................................................................................27 Caller ID ...........................................................................................................28 During a Conversation ......................................................................................29 Useful Features..................................................................................................30 Making Use of the Voice Mail Service .............................................................34 Using the Handset Phonebook..................................................................... 35 Handset Phonebook..........................................................................................35 Private Ring......................................................................................................35 Storing an Item in the Handset Phonebook ....................................................35 Storing a New Item...........................................................................................35 Editing a Stored Item........................................................................................36 Storing an Item Using the Predialing................................................................37 Storing an Item Using the Outgoing Call Log...................................................37 Storing an Item Using the Incoming Call Log...................................................38 Storing an Item Using the PBX System Phonebook ........................................39 Storing an Item Using the PBX Extension Phonebook ....................................39 Editing Category Names ..................................................................................40 Assigning Hot Keys...........................................................................................41 Entering Characters ..........................................................................................42 Document Version 2007-12 3 Character Mode Table ..................................................................................... 43 Locking the Handset Phonebook .................................................................... 44 Locking the Handset Phonebook ..................................…

Text truncated - open the document above for the full version.

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] Richard Mullen Group Manager Product Safety and Compliance Division Power of Attorney January 18, 2008 PCNF-07-F107 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; We, the undersigned, Panasonic Corporation of North America, hereby authorizes Nemko Canada to act on our behalf in all matters relating to the preparation of TCB Certification application for the below described product in compliance with FCC Part 15D. Any and all acts carried out by Nemko Canada on our behalf shall have the same effects as acts of our own for a period of one year from the date of this letter. Type Equipment: Isochronous UPCS Portable Station (Handset) Product Name: 1920~1930 MHz Digital Cordless Telephone System Handset Model: KX-TD7685 and KX-TD7695 Handset FCC ID: ACJ96NKX-TD7685 Applicant & Grantee: Panasonic Corporation of North America One Panasonic Way, Secaucus, NJ 07094 FRN Number: 0003762242 Responsible Manufacturer: Panasonic Communications Co., Ltd. Responsible Sales Company: Panasonic Consumer Electronics Company Sincerely yours, Richard Mullen Richard Mullen Group Manager Panasonic Corporation of North America Product Safety and Compliance Division

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] Richard Mullen Group Manager Product Safety and Compliance Division Request for Confidentiality January 18, 2008 PCNF-07-F107 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Type Equipment: Isochronous UPCS Portable Station (Handset) Product Name: 1920~1930 MHz Digital Cordless Telephone System FCC Part & Equip Class: FCC Part 15D / UPCS Portable TX Held to Ear / Equip Classification Code PUE Handset Model: KX-TD7685 and KX-TD7695 Handset FCC ID: ACJ96NKX-TD7685 In accordance with provisions of Section 0.457(d) of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for exhibits, which contain Operation Description, Parts List, Block Diagram and Schematic Diagram. This transmitter is not user adjustable and does not have a Tune-Up Procedure. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. In accordance with FCC Public DA 04-1705, we request forty-five day short-term confidentiality, starting from the from the issuance of equipment authorization date, for exhibits which contain Internal Photographs and Operating Instructions (User Manual). This product does not offer user tune-up procedures. The requested short-term confidentiality exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. Sincerely yours, Richard Mullen Richard Mullen Group Manager Panasonic Corporation of North America Product Safety and Compliance Division

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] Richard Mullen Group Manager Product Safety and Compliance Division FCC Cover Letter / Product Description January 18, 2008 PCNF-07-F107 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Panasonic Corporation of North America requests TCB Certification for the below described product, which is in compliance with FCC Part 15D. Type Equipment: Isochronous UPCS Portable Station Product Name: 1920~1930 MHz Digital Cordless Telephone System FCC Part & Equip Class: FCC Part 15D / UPCS Portable TX Held to Ear / Equip Classification Code PUE Handset Model: KX-TD7685 and KX-TD7695 Handset FCC ID: ACJ96NKX-TD7685 Frequency Range: 1921.536 ~ 1928.448 MHz Number Channels: 5 RF Channels, 5x12 = 60 TDMA Duplex Channels Type Modulation: GFSK (Gaussian Frequency Shift Keying) Conducted Output Power: 0.068 Watts Peak Power (18.3 dBm) Power Supply: NiMH Rechargeable Batteries / 3.6V 650mAh, type N4HHGMB00005 or HHR-P103 / AC Adaptor Model PQLV207 / Handset Battery Charger Antenna: Permanently attached one inverted-F antenna with antenna gain less than 3.0 dBi RF Exposure Evaluation: SAR for Portable Operation. The handset satisfies RF exposure evaluation with acceptable SAR test results with zero spacing between antenna and head and body while used in provided plastic belt clip holder. The User Manual is provided with RF exposure warnings, which includes: (1) To comply with FCC RF exposure requirements, the base unit must be installed and operated 20 cm (8 inches) or more between the product and all person’s body (excluding extremities of hands, wrist and feet); (2) This product may not be collocated or operated in conjunction with any other antenna or transmitter and (3) The handset may be carried and operated with only the specific provided belt-clip. Other non-tested belt-clips or similar body-worn accessories may not comply and must be avoided. Worst-Case SAR: Max SAR 1g = 0.012 W/kg (Head, Right Cheek, Channel 2) UTAM Affidavit: Panasonic was issued Affidavit of Participation to FCC Section 15.307(b) Affidavit #: PAN120707 was issued on December 7, 2006 Remarks: The subject Portable Station (Handset) will be marketed with Cell Stations (Base), which will be FCC Part 15D TCB certified by Nemko Canada under FCC ID’s: ACJ96NKX- T0155 and ACJ96NKX-T0158; and FCC Part 68 certified by Nemko Canada under US: ACJKXNANKX-TD7685. Sincerely yours, Richard Mullen Richard Mullen Group Manager

Panasonic Communications Co., Ltd. FCC ID : ACJ96NKX-TD7685 1 of 1 STATEMENT OF SECURITY CODE This wireless handset has 1000 billion digital security coding combinations that are provided by the following means: • Provided with 40 bits (1000 billion) for security codes.. • When shipped from the factory, the security code is decided by the manufacturer.

Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 1 of 6 External Photos KX-TD7685 General view KX-TD7685 Front view of handset Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 2 of 6 KX-TD7685 Rear view of handset KX-TD7685 Rear view of handset (battery cover & battery removed) Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 3 of 6 KX-TD7685 Rear view of battery charger Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 4 of 6 KX-TD7695 General view KX-TD7695 Front view of handset Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 5 of 6 KX-TD7695 Rear view of handset KX-TD7695 Rear view of handset (battery cover & battery removed) Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 6 of 6 KX-TD7695 Rear view of battery charger

EXHIBIT H EQUIPMENT LABEL: GRANTEE : Panasonic Corporation of North America GRANTEE CODE : ACJ COUNTRY OF ORIGIN : Japan, Malaysia or Vietnam TRADE NAME : PANASONIC MATERIAL OF LABEL : Alminium or Tetron Film or Molded on the Unit Serial number will be printed on the other label, and the serial number label will be affixed on the unit. Signed by: Michihito Miyazaki Senior Coordinator Technical Regulation January 7, 2008 1/1

Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 ID Label / Location Information for KX-TD7685 and KX-TD7695 1) KX-TD7685 Note: This product is sold without battery pack installed. 1 of 2 Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 2) KX-TD7684 Note: This product is sold without battery pack installed. 2 of 2

Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 1 of 5 Internal Photos KX-TD7685 Internal view of handset KX-TD7685 Internal view of handset Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 2 of 5 KX-TD7695 Internal view of handset KX-TD7695 Internal view of handset Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 3 of 5 RF module of KX-TD7685 and KX-TD7695, View of under the shield case Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 4 of 5 Internal view of battery charger for KX-TD7685 Internal view of battery charger for KX-TD7685 Panasonic Communications Co., Ltd. FCC ID: ACJ96NKX-TD7685 5 of 5 Internal view of battery charger for KX-TD7695 Internal view of battery charger for KX-TD7695

DAT-P-152/98-01 SAR_Report_Nemko_6620_662_FCC_CalData_KX-TD 7685 dasy_report_fcc_850_1900_cal_data_2.0.doc/08.01.2005/CH Appendix for the Report Dosimetric Assessment of the Panasonic KX-TD 7685 (FCC ID: ACJ96NKX-TD7685) According to the FCC Requirements Calibration Data November 15, 2007 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Panasonic Communications Co., Ltd. 1 -62, 4 - chome, Minoshima, Hakata - Ku Fukuoka 812-8531 Japan This report shall not be reproduced except in full without the written approval of the testing laboratory.

DAT-P-152/98-01 SAR_Report_Nemko_6620_662_FCC_CalData_KX-TD 7695 dasy_report_fcc_850_1900_cal_data_2.0.doc/08.01.2005/CH Appendix for the Report Dosimetric Assessment of the Panasonic KX-TD 7695 (FCC ID: ACJ96NKX-TD7695) According to the FCC Requirements Calibration Data November 15, 2007 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Panasonic Communications Co., Ltd. 1 -62, 4 - chome, Minoshima, Hakata - Ku Fukuoka 812-8531 Japan This report shall not be reproduced except in full without the written approval of the testing laboratory.

DAT-P-152/98-01 SAR_Report_Nemko_6620_662_FCC_DECT_1900_KX-TD 7685 Page 1 of 33 Report Dosimetric Assessment of the Portable Device Panasonic KX-TD 7685 (FCC ID: ACJ96NKX-TD7685) According to the FCC Requirements November 14, 2007 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Dasy_Report_ F CC_DEC T _1900 _2.0.doc/08.11.2 007/CH Customer Panasonic Communication Co., Ltd. 1 - 62, 4 - chome, Minoshima, Hakata - Ku Fukuoka 812-8531 Japan The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. SAR_Report_Nemko_6620_662_FCC_DECT_1900_KX-TD 7685 Page 2 of 33 Dasy_Report_FCC_DECT_1900_2.0.doc/08.11.2007/CH Executive Summary The KX-TD 7685 is a cordless telephone (Portable Device) from Panasonic operating in the 1920 MHz frequency range (US DECT Standard). The device has an integrated antenna. The objective of the measurements done by IMST was the dosimetric assessment of one device in the 1920 MHz frequency range. The handset was set to use one specific frequency during the measurements. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [OET 65] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. All measurements have been performed in accordance to the recommendations given by SPEAG. SAR_Report_Nemko_6620_662_FCC_DECT_1900_KX-TD 7685 Page 3 of 33 Dasy_Report_ F CC_DEC T _1900 _2.0.doc/08.11.2 007/CH Compliance statement The Panasonic KX-TD 7685 cordless telephone (FCC ID: ACJ96NKX-TD7685) is in compliance with the Federal Communications Commission (FCC) Guidelines [OET 65] for uncontrolled exposure. The phone was tested in addition to the head positions in the following configuration: Body worn with the following accessory: • belt clip, with headset, (antennas towards the phantom, distance 0 mm) Maximum SAR 1g = below the detection limit prepared by: ........................................... reviewed by: ..................................... Alexander Rahn André van den Bosch test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gauß-Straße 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 378 Fax +49- 2842-981 399 email: [email protected] SAR_Report_Nemko_6620_662_FCC_DECT_1900_KX-TD 7685 Page 4 of 33 Dasy_Report_FCC_DECT_1900_2.0.doc/08.11.2007/CH Table of Contents 1 SUBJECT OF INVESTIGATION.................................................................................................................... 5 2 THE IEEE STANDARD C95.1-1999 AND THE FCC EXPOSURE CRITERIA....................................... 5 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES........... 5 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS....................................... 6 2.3 SAR LIMIT.................................................................................................................................................. 6 3 THE FCC MEASUREMENT PROCEDURE................................................................................................. 7 3.1 GENERAL REQUIREMENTS......................................................................................................................... 7 3.2 DEVICE OPERATING NEXT TO A PERSON’S EAR....................................................................................... 7 4 BODY-WORN CONFIGURATIONS............................................................................................................ 10 4.1 POC (PTT) POSITION............................................................................................................................. 11 4.2 PHANTOM REQUIREMENTS...................................................................................................................... 11 4.3 TEST TO BE PERFORMED......................................................................................................................... 11 5 THE MEASUREMENT SYSTEM................................................................................................................. 11 5.1 PHANTOM................................................................................................................................................. 13 5.2 PROBE...................................................................................................................................................... 13 5.3 MEASUREMENT PROCEDURE.................................................................................................................. 14 5.4 UNCERTAINTY ASSESSMENT................................................................................................................... 15 6 SAR RESULTS............................................................................................................................................... 16 7 APPENDIX....................................................................................................................................................... 17 7.1 ADMINISTRATIVE DATA............................................................................................................................ 17 7.2 DEVICE UNDER TEST AND TEST CONDITIONS......................................................................................... 17 7.3 TISSUE RECIPES...................................................................................................................................... 17 7.4 MATERIAL PARAMETERS......................................................................................................................... 18 7.5 SIMPLIFIED PERFORMANCE CHECKING................................................................................................... 19 7.6 E…

Text truncated - open the document above for the full version.

DAT-P-152/98-01 SAR_Report_Nemko_6620_662_FCC_DECT_1900_KX-TD 7695 Page 1 of 35 Report Dosimetric Assessment of the Portable Device Panasonic KX-TD 7695 (FCC ID: ACJ96NKX-TD7695) According to the FCC Requirements November 14, 2007 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Dasy_Report_ F CC_DEC T _1900 _ 2.0.doc/08.11.2 007/CH Customer Panasonic Communication Co., Ltd. 1 - 62, 4 - chome, Minoshima, Hakata - Ku Fukuoka 812-8531 Japan The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. SAR_Report_Nemko_6620_662_FCC_DECT_1900_KX-TD 7695 Page 2 of 35 Dasy_Report_FCC_DECT_1900_2.0.doc/08.11.2007/CH Executive Summary The KX-TD 7695 is a cordless telephone (Portable Device) from Panasonic operating in the 1920 MHz frequency range (US DECT Standard). The device has an integrated antenna. The objective of the measurements done by IMST was the dosimetric assessment of one device in the 1920 MHz frequency range. The handset was set to use one specific frequency during the measurements. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [OET 65] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. All measurements have been performed in accordance to the recommendations given by SPEAG. SAR_Report_Nemko_6620_662_FCC_DECT_1900_KX-TD 7695 Page 3 of 35 Dasy_Report_ F CC_DEC T _1900 _2.0.doc/08.11.2 007/CH Compliance statement The Panasonic KX-TD 7695 cordless telephone (FCC ID: ACJ96NKX-TD7695) is in compliance with the Federal Communications Commission (FCC) Guidelines [OET 65] for uncontrolled exposure. The phone was tested in addition to the head positions in the following configuration: Body worn with the following accessory: • belt clip, with headset, (antennas towards the phantom, distance 0 mm) Maximum SAR 1g = 0.012 W/kg (Head, right cheek, Channel 2) prepared by: ........................................... revi…

Text truncated - open the document above for the full version.
