ACJ96NKX-TG2200Cordless Telephone Answering System

Panasonic Corporation of North America

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Mar 29, 2000
Application Purpose: Original Equipment
Date of Application: Dec 20, 1999
Equipment Note: Cordless Telephone Answering System
Frequency Range: 2401.05600000 - 2479.68000000
Company: Panasonic Corporation of North America
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

2.4GHz FHSS Cordless Answering System Model No.KX-TG2200B Pulse-or-tone-dialing capability Operating Instructions Charge the battery for about 8 hours before initial use. PLEASE READ BEFORE USE AND SAVE. Contents: Location of controls2 Installation5 Handset battery charge10 Making/Answering calls with the base unit11 Making/Answering calls with the cordless handset12 Caller ID Service13 Voice Mail System13 Automated Attendant System14 Answering System15 Listening to messages16 Important Safety Instructions17 FCC and other information19 –2– Please read IMPORTANT SAFETY INSTRUCTIONS on page 17 before use. Read and understand all instructions. Location of controls Base Unit LINE1 Button and Indicator LINE2 Button and Indicator LINE3 Button and Indicator LINE4 Button and Indicator CONF (Conference) Button HOLD Button STOP Button VOICE MAIL Button INTERCOM/ TRANSFER Buttons DIGITAL SP-PHONE (Speakerphone)/HEADSET Button and Indicator MIC (microphone) ANSWER ON Buttons –3– Base Unit REDIAL Button BATTERY Indicator PAUSE/EDIT Button CALL WAIT/FLASH Button FUNCTION Button EXIT Button Navigator Key ( , , , ) ENTER Button CLEAR Button TONE Button Antenna Display Headset Jack –4– Cordless Handset Antenna Display Headset Jack CLEAR Button ENTER/ (Voice Mail) Button CONF (Conference) Button INTERCOM/HOLD/ TRANSFER Button Charge Contacts LINE Buttons TALK Button FUNC (Function)/ EXIT Button TONE Button REDIAL/PAUSE/ EDIT Button CALL WAIT/FLASH Button Navigator Key ( , , , ) –5– Installation Installing the backup battery in the base unit A rechargeable Ni-Cd battery works as emergency power during a power failure. The fully charged backup battery provides the base unit with 20 minutes operation. The battery is charged in the base unit while the AC adaptor is connected. It takes 10 hours to charge fully. Install the backup battery in the battery compartment, and close the cradle cover. •The battery cannot be overcharged. Charger Attention: The product you have purchased is powered by a nickel cadmium battery which is recyclable. At the end of its useful life, under various state and local laws, it is illegal to dispose of this battery into your municipal waste stream. Please call 1-800-8-BATTERY for information on how to recycle this battery. CHARGE Charge Contacts CHARGE Indicator –6– Connect the handset to the base unit Handset Connect the AC adaptor to the base unit Raise the antenna. Power Outlet (AC 120 V, 60 Hz) •USE ONLY WITH Panasonic AC ADAPTOR PQLV12. •The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) Handset Cord AC Adaptor •Use only a Panasonic Handset for the KX-TG2200B. –7– Connecting the telephone line cord to 2 two-line telephone jack LINE 1 LINE 2 Two-Line Telephone Jacks (RJ14C) 4-Wired Telephone Line Cords LINE 3 LINE 4 –8– Connecting the telephone line cords to four single-line telephone jacks For this connection, please purchase two Panasonic T-adaptors and two 2-wired telephone line cords. LINE 1 Single-Line Telephone Jacks (RJ11C) 4-Wired Telephone Line Cords LINE 2 LINE 3 LINE 4 2-Wired Telephone Line Cords 2-Wired Telephone Line Cords T-Adaptor T-Adaptor –9– Connecting the AC Adaptor to the charger •USE ONLY WITH Panasonic AC ADAPTOR TCA1. •The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) Power Outlet (AC 120 V, 60 Hz) AC Adaptor CHARGE –10– Handset battery charge Recharge Recharge the battery when: –"" flashes on the display, or – the handset beeps every minute while it is in use. •Clean the charge contacts of the handset and charger with a soft dry cloth once a month. Clean more often if the unit is subject to grease, dust or high humidity.If not, the battery may not charge properly. •If the battery is fully charged, you do not have to place the handset on the charger until "" flashes. This will maximize the battery life. •The battery cannot be overcharged. To power the cordless handset, charge the battery. Place the handset on the charger for about 8 hours before initial use. •The CHARGE indicator lights. –11– Making/Answering calls with the base unit To make a call When you lift the handset to make a call, the unit will automatically select a free line. Using the digital duplex speakerphone: 1 Press DIGITAL SP-PHONE. •The indicator and the selected line indicator light. 2 Dial a telephone number. 3 Talk into the MIC(microphone). 4 To hang up, press DIGITAL SP-PHONE. •The indicator lights go out. •In step 1, you may select a line manually by pressing the line button instead of DIGITAL SP-PHONE. •To redial the last number:Lift the handset or press DIGITAL SP-PHONE, then press REDIAL. •To adjust the handset volume (4 levels)/speaker volume (8 levels): To increase, press . To decrease, press . •To put a call on hold:Press HOLD. •To release the hold, press the line button. To answer a call Lift the handset. OR Press DIGITAL SP-PHONE, then talk into the MIC(microphone). •You can answer a call by pressing the line button instead of DIGITAL SP-PHONE. –12– To make a call 1 Press TALK. 2 Dial a telephone number. 3 To hang up, press TALK or place the handset on the charger. •The indicator lights go out. •If "Out of range" is displayed and an alarm tone sounds in step 1, move closer to the base unit, and try again. •In step 1, you may select a line manually by pressing the line button instead of TALK. •To redial the last number,press TALK, then press REDIAL. •To adjust the receiver volume (4 levels): To increase, press . To decrease, press . •To put a call on hold, press HOLD. •To release the hold,press the line button. To answer a call Press TALK. •You can answer a call by pressing the line button instead of TALK. Making/Answering calls with the cordless handset –13– Caller ID Service This unit is compatible with a Caller ID service offered by your telephone company. After subscribing to a Caller ID service, the calling party’s information will be shown on t…

Text truncated - open the document above for the full version.

Cover Letter(s)

EXHIBIT A STATEMENT OF SECURITY CODE The frequency hopping spread spectrum cordless telephone system, Model KX-TG2200(xx) provides with a Digital Security coding of more than 4 billion combinations. More than 4 billion combinations (32 bits) --- Fixed NOTE: When the power failure takes place and the base unit is re-set, this system becomes to provide with a new security code automatically.

External Photos

ID Label/Location Info

EXHIBIT B MARKINGS 1. Base Unit: The base unit provides with the following marking, or equivalent. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone. NOTE: Above markings are shown on bottom of the unit. 2. Portable Unit:

Internal Photos

Test Report S/N: 15.991207656.ACJFCC Part 15.247 Test Date(s): December 07-09, 1999Certification © 1999 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Spread Spectrum Cordless Telephone (Tx 2401.06 - 2479.68 MHz) Test Report S/N: 15.991207656.ACJFCC Part 15.247 Test Date(s): December 07-09, 1999Certification © 1999 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Spread Spectrum Cordless Telephone (Tx 2401.06 - 2479.68 MHz) Test Report S/N: 15.991207656.ACJFCC Part 15.247 Test Date(s): December 07-09, 1999Certification © 1999 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Spread Spectrum Cordless Telephone (Tx 2401.06 - 2479.68 MHz) Test Report S/N: 15.991207656.ACJFCC Part 15.247 Test Date(s): December 07-09, 1999Certification © 1999 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Spread Spectrum Cordless Telephone (Tx 2401.06 - 2479.68 MHz) Test Report S/N: 15.991207656.ACJFCC Part 15.247 Test Date(s): December 07-09, 1999Certification © 1999 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Spread Spectrum Cordless Telephone (Tx 2401.06 - 2479.68 MHz) Test Report S/N: 15.991207656.ACJFCC Part 15.247 Test Date(s): December 07-09, 1999Certification © 1999 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Spread Spectrum Cordless Telephone (Tx 2401.06 - 2479.68 MHz) Test Report S/N: 15.991207656.ACJFCC Part 15.247 Test Date(s): December 07-09, 1999Certification © 1999 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Spread Spectrum Cordless Telephone (Tx 2401.06 - 2479.68 MHz) Test Report S/N: 15.991207656.ACJFCC Part 15.247 Test Date(s): December 07-09, 1999Certification © 1999 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Spread Spectrum Cordless Telephone (Tx 2401.06 - 2479.68 MHz)

Internal Photos

Operational Description

EXHIBIT E DESCRIPTION OF ELECTRICAL CIRCUITRY 1. BASE UNIT: A) WHEN A BELL SIGNAL ENTERS FROM TEL LINE 1) The bell detection circuit, i.e., the photo-coupler(PC401) begins to operate and its output is inputted through C101 to PC101, then fed to pin 36 of CODEC IC702. When the CODEC detects the Bell signal, it sends a signal from pin 20 to pin45 of Sub CPU IC701 2) To obtain a display synchronized with the bell signal, an IN USE signal is output from pin 79 of IC701(CPU) and INUSE LED(LED907) is lighted up. 3) A portable phone receives a bell from the base station. When the portable phone is switched from the STANDBY to TALK, the base station receives a carrier modulated by data indicating the switch from STANDBY to TALK. B) WHEN A LINE LOOP IS MADE BY A PORTABLE PHONE 1) When the operator of the portable phone switches STANDBY to TALK, the TALK mode data enters the base station and is demodulated at the RF Unit of the base station, and is inputted to pin 78 of IC818. 2) In this time, an IN USE signal is output from pin 79 of IC701, and the IN USE LED (LED907) is lighted up. C) RECIEVER UNIT OPERATION 1) A signal is received by antenna is inputted to RF unit. In the RF unit the received signal is demodulated and shaped digital base band signal. 2) The digital base band signal goes from pin 8 of RF unit is inputted to pin 78 of IC818. 3) In the IC818 BMC block pick up ADPCM signal from digital base band signal and pass to the ADPCM transcoder of IC818. In the ADPCM transcoder the incoming ADPCM signal is transcoded to LOG-PCM signal, u-law. 4) The LOG-PCM signal goes out from 28 pin of IC818 is inputted to pin 25 of DSP IC104~ IC404( defined by line number ) and goes out from pin 25 of DSP to pin 26, 30 of IC702. 5) In the IC 702 LOG-PCM signal is expanded to Linear PCM and decode to audio signal. The audio signal is transmitted to the telephone line by IC103 ~ IC403 defined by line number. D) TRANSMISSION UNIT OPERATION 1) An audio signal from the line passes through the interface diode D101 ~ D401and T101~ T401, defied by line number. This signal is amplified by IC101 ~ IC401. 2) The audio signal goes out from pin 7 of IC101 ~ IC401 is inputted to IC702. In the IC702 the audio signal is coded to Linear – PCM signal and companded to LOG – PCM signal, u-law. 3) The LOG – PCM signal goes out from pin 27, 29 of IC 702 is inputted to pin 27 of DSP, IC104~ IC404. 4) The LOG – PCM signal goes out from pin 27 of IC104~IC404 is inputted to pin 29 of IC818 and transcoded to ADPCM signal. 5) The ADPCM signal goes to BMC block and formed TX data. 6) The TX data goes from pin 79 of IC818 is inputted to pin 22 of RF unit. The modulated signal goes out from RF unit to antenna. EXHIBIT E DESCRIPTION OF ELECTRICAL CIRCUITRY 2. PORTABLE UNIT: A) RECEIVER UNIT OPERATION 1) A signal is received by antenna is inputted to RF unit. In the RF unit the received signal is demodulated and shaped digital base band signal. 2) The digital base band signal goes from pin 8 of RF unit is inputted to pin 26 of IC1. 3) In the IC1 BMC block pick up ADPCM signal from digital base band signal and pass to the ADPCM transcoder of IC1. In the ADPCM transcoder the incoming ADPCM signal is transcoded to LOG-PCM signal, u-law. 4) The LOG-PCM signal goes from BMC block to DSP block is expanded to Linear –PCM and decoded to audio signal. 5) The audio signal goes from pin 125 and pin 126 with balance to speaker. B) TRANSMISSION UNIT OPERATION 1) When selected TALK key, Handset go into TALK mode. 2) The audio signal from microphone is inputted to pin 134 and pin 137 of IC1 with Balance. 3) In the IC1 the audio signal is coded to Linear – PCM signal and also companded to LOG – PCM signal in DSP block. 4) The LOG - PCM signal goes from DSP block to BMC block is transcoded to ADPCM signal and formed TX data. 5) The TX data goes out from pin 17 of IC1 is inputted to pin 22 of RF unit. The modulated signal goes out from RF unit to antenna.

RF Exposure Info

Test Report S/N: SAR.200320110.ACJSAR Measurement Report Test Date(s): March 24, 2000FCC Part 15.247 Certification © 2000 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. Test Report S/N: SAR.200320110.ACJSAR Measurement Report Test Date(s): March 24, 2000FCC Part 15.247 Certification © 2000 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. Test Report S/N: SAR.200320110.ACJSAR Measurement Report Test Date(s): March 24, 2000FCC Part 15.247 Certification © 2000 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. Test Report S/N: SAR.200320110.ACJSAR Measurement Report Test Date(s): March 24, 2000FCC Part 15.247 Certification © 2000 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. Test Report S/N: SAR.200320110.ACJSAR Measurement Report Test Date(s): March 24, 2000FCC Part 15.247 Certification © 2000 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. Test Report S/N: SAR.200320110.ACJSAR Measurement Report Test Date(s): March 24, 2000FCC Part 15.247 Certification © 2000 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD.

RF Exposure Info

File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00032409_ZOOM.VLT Start : 24-Mar-100 01:03:31 pm End : 24-Mar-100 01:14:10 pm FCC ID : ACJ96NKX-TG2200 Model Number : KX-TG2200B-R-H Serial Number : 1 Frequency : 2401.056 MHz Peak Trans. Pwr : 0.210 W Start Trans. Pwr: 0.210 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : AP109 Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 52.200 Mixture Conductivity = 2.850 Comment : PANASONIC FHSS CORDLESS PHONE CHAN. 0 BASE FIXED ANTENNA Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.983 AP109 Amplifier Channel Settings : 0.172 0.187 0.220 Max Location : X = 0.000, Y = -0.500, Z = 0.000 (cm) Value = 5.860 Measured Values (volts) = 5.815E-003 4.860E-003 4.283E-003 3.677E-003 3.107E-003 2.487E-003 1.983E-003 1.724E-003 1.614E-003 1.701E-003 1.764E-003 1.741E-003 1.659E-003 1.356E-003 1.062E-003 7.255E-004 4.256E-004 3.906E-004 4.411E-004 6.744E-004 8.849E-004 Calc. Voltage @ Surface (Vs) = 0.0066 Voltage @ 1.00 cm (Vt) = 0.0036 Ave. Voltage (Vs+Vt)/2 = 0.0051 Ave. SAR over 1 g (mW/g) = 0.4613 0.0 0.1 0.2 0.3 0.4 0.5 0.6 mW/g -1012345 Z centimeters SAR Scan File : 00032409_ZOOM Start : 24-Mar-100 01:03:31 pm End : 24-Mar-100 01:14:10 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2401.056MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 File : 00032409_ZOOM Start : 24-Mar-100 01:03:31 pm End : 24-Mar-100 01:14:10 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2401.056MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 0.533 0.503 0.472 0.441 0.410 0.380 0.349 0.318 0.287 0.257 File : 00032409_ZOOM Start : 24-Mar-100 01:03:31 pm End : 24-Mar-100 01:14:10 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2401.056MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 0.533 0.503 0.472 0.441 0.410 0.380 0.349 0.318 0.287 0.257 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00032410_ZOOM.VLT Start : 24-Mar-100 01:21:45 pm End : 24-Mar-100 01:33:16 pm FCC ID : ACJ96NKX-TG2200 Model Number : KX-TG2200B-R-H Serial Number : 1 Frequency : 2440.800 MHz Peak Trans. Pwr : 0.270 W Start Trans. Pwr: 0.270 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : AP109 Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 52.200 Mixture Conductivity = 2.850 Comment : PANASONIC FHSS CORDLESS PHONE CHAN. 46 BASE FIXED ANTENNA Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.983 AP109 Amplifier Channel Settings : 0.172 0.187 0.220 Max Location : X = 1.000, Y = -0.750, Z = 0.000 (cm) Value = 6.140 Measured Values (volts) = 6.103E-003 5.337E-003 4.726E-003 4.259E-003 3.691E-003 3.106E-003 2.492E-003 1.968E-003 1.750E-003 1.617E-003 1.671E-003 1.765E-003 1.773E-003 1.659E-003 1.476E-003 1.084E-003 7.347E-004 4.124E-004 4.119E-004 4.690E-004 6.829E-004 Calc. Voltage @ Surface (Vs) = 0.0068 Voltage @ 1.00 cm (Vt) = 0.0041 Ave. Voltage (Vs+Vt)/2 = 0.0055 Ave. SAR over 1 g (mW/g) = 0.4963 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 mW/g -1012345 Z centimeters SAR Scan File : 00032410_ZOOM Start : 24-Mar-100 01:21:45 pm End : 24-Mar-100 01:33:16 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2440.800MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 File : 00032410_ZOOM Start : 24-Mar-100 01:21:45 pm End : 24-Mar-100 01:33:16 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2440.800MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 0.559 0.541 0.522 0.504 0.486 0.468 0.449 0.431 0.413 0.395 File : 00032410_ZOOM Start : 24-Mar-100 01:21:45 pm End : 24-Mar-100 01:33:16 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2440.800MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 0.559 0.541 0.522 0.504 0.486 0.468 0.449 0.431 0.413 0.395 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/00032412_ZOOM.VLT Start : 24-Mar-100 01:52:43 pm End : 24-Mar-100 02:04:28 pm FCC ID : ACJ96NKX-TG2200 Model Number : KX-TG2200B-R-H Serial Number : 1 Frequency : 2479.680 MHz Peak Trans. Pwr : 0.267 W Start Trans. Pwr: 0.267 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Body Phantom Posn. : Abdomen Scan Type : ZOOM/SAR Probe Name : AP109 Field Type : E Field Orientation : 0 Degrees Mixture Type = Muscle Mixture Dielectric Constant = 52.200 Mixture Conductivity = 2.850 Comment : PANASONIC FHSS CORDLESS PHONE CHAN. 91 BASE FIXED ANTENNA Robot : PCTEST Probe Offset = 0.20 cm Sensor Factor = 0.0108 Conversion Factor = 0.983 AP109 Amplifier Channel Settings : 0.172 0.187 0.220 Max Location : X = 1.000, Y = -0.750, Z = 0.000 (cm) Value = 6.043 Measured Values (volts) = 5.897E-003 5.341E-003 4.980E-003 3.964E-003 3.592E-003 3.004E-003 2.450E-003 2.016E-003 2.222E-003 1.243E-003 1.633E-003 1.664E-003 1.710E-003 1.619E-003 1.368E-003 1.036E-003 6.386E-004 3.906E-004 3.782E-004 3.654E-004 6.957E-004 Calc. Voltage @ Surface (Vs) = 0.0063 Voltage @ 1.00 cm (Vt) = 0.0039 Ave. Voltage (Vs+Vt)/2 = 0.0051 Ave. SAR over 1 g (mW/g) = 0.4642 0.0 0.1 0.2 0.3 0.4 0.5 0.6 mW/g -1012345 Z centimeters SAR Scan File : 00032412_ZOOM Start : 24-Mar-100 01:52:43 pm End : 24-Mar-100 02:04:28 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2479.680MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 File : 00032412_ZOOM Start : 24-Mar-100 01:52:43 pm End : 24-Mar-100 02:04:28 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2479.680MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 0.550 0.530 0.510 0.490 0.470 0.450 0.430 0.410 0.390 0.370 File : 00032412_ZOOM Start : 24-Mar-100 01:52:43 pm End : 24-Mar-100 02:04:28 pm ACJ96NKX-TG2200/KX-TG2200B-R-H/1;2479.680MHz;W;Helical/In; Body/Abdomen;ZOOM/SAR;AP109/E Field/0 DegreesMuscle/52.200/2.850 0.550 0.530 0.510 0.490 0.470 0.450 0.430 0.410 0.390 0.370

RF Exposure Info

© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B 6660-B DobbinDobbin Road Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Matsushita Electric Industrial Co., Ltd.Dates of Tests: March 24, 2000 1006 Oaza KadomaTest Report S/N: SAR.200320110.ACJ Kadoma, Osaka 571 JAPANTest Site: PCTEST Lab, Columbia, MD Attention: K. Nawata (KMECL) Rich Mullen (PSCD, MECA) FCC ID ACJ96NKX-TG2200 APPLICANT Matsushita Electric Industrial Co., Ltd. EUT Type:2.4GHz Spread Spectrum Cordless Telephone (FHSS) - Base FCC Classification:Spread Spectrum Transmitter (DSS) Method/System:Frequency Hopping Spread Spectrum (FHSS) Tx/Rx Frequency:2401.056 – 2479.680 MHz Max. RF Output Power:0.270W EIRP (24.32 dBm) Trade Name/Model(s):PANASONIC KX-TG2200B-H (Base) Application Type:Certification Serial Number:n/a (pre production) FCC Rule Part(s):2.1093; ET Docket 96.326 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). 200320110.ACJ SAR Measurement ReportFCC Part 15.247 Certification © 2000 PCTEST Labi Table of Contents 1.1 SCOPE1 2.1 INTRODUCTION / SAR DEFINITION2 3.1 SAR MEASUREMENT SET-UP3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM4 5.1 E-FIELD PROBE SYSTEM5-6 6.1 PHANTOM & EQUIVALENT TISSUES7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS9 9.1 TEST POSITION OF THE EUT10 10.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS11 11.1 MEASUREMENT UNCERTAINTIES12 12.1 TEST DATA SUMMARY13 13.1 SAR TEST EQUIPMENT LIST14 14.1 CONCLUSION / REFERENCES15 Test Report S/N: SAR.200320110.ACJSAR Measurement Report Test Dates: March 24, 2000FCC Part 15.247 Certification Digital Spread Spectrum Cordless Telephone (Base) © 2000 PCTEST LabPANASONIC FCC ID: ACJ96NKX-TG22001 SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant:Matsushita Electric Industrial Co., Ltd. Address:1006 Oaza Kadoma Kadoma, Osaka 571 JAPAN Attention: K. Nawata (KMECL) Rich Mullen (PSCD, MECA) • EUT Type:Digital Spread Spectrum Cordless Telephone System (Base) • FCC Rule Part(s):§ 2.1093, Docket 96-326 • Trade Name:PANASONIC • FCC IDENTIFIER:ACJ96NKX-TG2200 • Model(s):KX-TG2200B-H (BASE) • S/N:Pre-production • Tx/Rx Frequency:2401.056 – 2479.680 MHz • Application Type: Certification • FCC Classification:Spread Spectrum Transmitter (DSS) • Max. RF Output Power:0.270W EIRP (24.32 dBm) • Method/System:Frequency Hopping Spread Spectrum System (FHSS) • Dates of Tests:March 24, 2000 • Place of Tests:PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.:SAR.200320110.ACJ 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Test Report S/N: SAR.200320110.ACJSAR Measurement Report Test Dates: March 24, 2000FCC Part 15.247 Certification Digital Spread Spectrum Cordless Telephone (Base) © 2000 PCTEST LabPANASONIC FCC ID: ACJ96NKX-TG22002 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[4] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source. SAR values have been related to threshold levels for potential biological hazards. 2.2 SAR Definition Specific Absorption Rate (SAR) is defined as the time derivative (rate) of the incremental energy (dU) absorbed by (dissipated in) an incremental mass (dm) contained in a volume element (dV) of a given density (ρ). It is also defined…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report S/N: SAR.200316077.ACJ SAR Measurement Report Test Date(s): March 16-17, 2000 FCC Part 15.247 Certification © 2000 PCTEST Lab PANASONIC FCC ID: ACJ96NKX-TG2200 NVLAP Lab Code: 100431-0 Frequency Hopping Spread Spectrum Cordless Telephone Test Report S/N: SAR.200316077.ACJ SAR Measurement Report Test Date…
