ACJ96NKX-TG23562.4GHz FHSS Cordless Telephone System

2.4GHz Digital Cordless Answering System Pulse-or-tone dialing capability Model No. KX-TG2356S PLEASE READ BEFORE USE AND SAVE. Charge the battery for about 6 hours before initial use. Contents: Location of Controls2 Connections4 Battery Installation/Battery Charge 5 Recording a Greeting Message6 Making/Answering Calls with the Handset7 Making/Answering Calls with the Base Unit8 Caller ID Service10 Phone Book10 Automatic Answering Operation11 Listening to Messages11 openLCR Service for Caller IQ Feature12 Important Safety Instructions13 FCC and Other Information15 Operating Instructions Caller ID Compatible – 2 – Location of Controls Please read IMPORTANT SAFETY INSTRUCTIONS on pages 13 before use. Read and understand all instructions. ∫Base unit [SP-PHONE] (Speakerphone) and Indicator [REDIAL] [FLASH/CALL WAIT] [MUTE] VOLUME [ ], [ ] [HOLD/CONF] (Conference) CHARGE Indicator [LOCATOR/INTERCOM] Antenna Display Charge Contacts [ ] (TONE) [MESSAGE] [STOP] [SKIP] [MEMO] [ERASE] [GREETING CHECK] [REPEAT] [ANSWER ON] and Indicator MIC (Microphone) NEW MESSAGE Indicator [GREETING REC] (Record) Hook – 3– ∫Handset [OFF] Display [MENU] [HOLD/INTERCOM] [ ] (TALK) [FLASH/CALL WAIT] [ ] (Speakerphone) Antenna Headset Jack [REDIAL] Charge Contacts [ ] (TONE) Receiver Ringer Indicator Soft Keys Back side Speaker Microphone Navigator Key ([ ], [ ]) – 4– Connections ≥Use only with Panasonic AC adaptor PQLV1 (Order No. PQLV1Z). ≥The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) ≥If your unit is connected to a PBX which does not support Caller ID services, you cannot access those services. ≥The unit will not work during a power failure. If you want to connect a standard telephone to the same telephone jack, use the Panasonic KX-J66 T-adaptor. Single-Line Telephone Jack (RJ11C) Power Outlet (AC 120 V, 60 Hz) AC Adaptor Telephone Line Cord Fasten the cords. Hook Hooks ∫Connect the AC adaptor and the telephone line cord. – 5– Battery Installation/Battery Charge ∫Battery installation 1 Install the battery in the handset. 2 Close the handset cover. ∫Battery Charge To power the handset, charge the battery. Place the handset on the base unit and charge for about 6 hours before initial use. ≥The unit beeps once, the CHARGE indicator lights, and “Charging” is displayed. ≥When the battery is fully charged, “Charge completed” is displayed. ∫Recharge Recharge the battery when: —“Recharge battery” is displayed on the handset, —“” flashes, or —the handset beeps intermittently while it is in use. ≥Clean the handset and the base unit charge contacts with a soft, dry cloth once a month. Clean more often if the unit is subject to grease, dust or high humidity.If not, the battery may not charge properly. ≥If the battery is fully charged, you do not have to place the handset on the base unit until “Recharge battery” is displayed and/or “” flashes. This will maximize the battery life. ≥The battery cannot be overcharged. A nickel metal hydride battery that is recyclable powers the product you have purchased. Please call 1-800-8-BATTERY for information on how to recycle this battery. 1 2 – 6– Recording a Greeting Message 1 Press [GREETING REC]. ≥“To record greeting, press RECORD again” is heard. 2 Within 10 seconds, press [GREETING REC]again to record your greeting. 3 After the long beep, talk clearly, about 20 cm (8 inches) away from the MIC (microphone). ≥The base unit display shows the elapsed recording time. ≥If you record for over 2 minutes, the unit will automatically stop recording. 4 When finished, press [GREETING REC] or [STOP]. ≥To change the message, start again from step 1. You can record a personal greeting message of up to 2 minutes. If you do not record your own message, one of two pre-recorded greetings will be played for callers. All messages (greeting, incoming and voice memo) are stored in digital memory. The total recording time is about 16 minutes. We recommend you recorda brief greeting messagein order to leave more time for recording new messages. – 7– ∫To make a call 1 Press []. 2 Dial a telephone number. ≥After a few seconds, the display will show the length of the call. 3 To hang up, press [OFF]or place the handset on the base unit. To have a hands-free phone conversation 1 Press []. 2 Dial a telephone number. ≥After a few seconds, the display will show the length of the call. 3 When the other party answers, talk into the microphone. 4 To hang up, press [OFF]or place the handset on the base unit. To dial after confirming the entered number 1 Dial a phone number. ≥If you misdial, press Clear. Enter the correct number. ≥If a pause is required when dialing, press Pause where needed. ≥To cancel, press [OFF]. 2 Press []or []. 3 To hang up, press [OFF]or place the handset on the base unit. To redial the last number dialed on the handset, press []or [] and press [REDIAL]. Making/Answering Calls with the Handset – 8– To redial using the redial list (Memory Redial) The last 5 phone numbers dialed with the handset are stored in the redial list. 1 Press [REDIAL]. ≥The last number dialed is displayed. 2 Scroll to the desired number by pressing []or []. ≥You can also scroll through the list by pressing [REDIAL]. ≥To exit the list, press [OFF]. 3 Press []or []. ≥To erase an item,scroll to the desired item then press Erase. ≥If “No items stored” is displayed, the list is empty. To adjust the receiver volume (HIGH, MEDIUM or LOW) or speaker volume (6 levels) while talking: To increase, press []. To decrease, press []. To put a call on hold, press [HOLD/INTERCOM]twice during a conversation. To return to the hold; From the handset, press [] or []. From the base unit, press [SP-PHONE]. ∫To answer a call If the handset is off the base unit, press []. OR Press [], and when the other party answers, talk into the microphone. – 9– ∫To make a call 1 Press [SP-PHONE]. ≥The SP-PHONE indicator lights. 2Dial a telephone number. 3 When the other party answers, talk into the M…

Text truncated - open the document above for the full version.

BASE UNIT 4.0VCONVERTOR IC701 TIP RING TEL_JACK VRF RF IC501DSP DC9V+GND DC_JACK + - CHARGE 1 2 4 3 D101 Q106 IC300 Q382,381 Q350 Q104 Q161 KEYPAD KEY UNIT TX DATA RXDATA Vcc ANT IC601 P N G C 9V+ N D

HANDSET 21 CHARGE BATT+ BATT- IC204 IC203 RINGER MIC SPEAKER HEAD SET JACK CN203 LCD IC202 KEYPAD KEY LEDS VCC RF UNIT VRF TX DATA RXDATA IC201DSP ANT

From: [email protected] Sent: Monday, January 05, 2004 11:35 PM To: [email protected]; [email protected]; [email protected]; [email protected] Cc: [email protected]; [email protected]; [email protected]; [email protected]; [email protected]; [email protected] Subject: RE: PCTP-03-F004: Matsushita Electric Industrial C To: Mr. Cheng/ CCS and Mr. Mullen/ MECA-PSCD cc: Mr. Kinoshita/ JQA From: Nawata/ PCTP (Panasonic Communications Co., Ltd.) RE: Matsushita Electric Industrial Co., Ltd., FCC ID:ACJ96NKX-TG2356, AN03T3514 ( do not remove subject line when reply) Dear Mr. Cheng and Mr. Mullen; Thank you very much for your cooperation. Today, I have received the reply from JQA lab. Attached please find our reply letter as following. Our Reply Letter to CCS To: Mr. Mullen; Could you file our reply letter on CCS web site? Question #1: We understand this was resolved. Question #2: JQA lab answered as shown below. JQA considered the difference of the Max conducted output powers between 15.247 test (17.8 dBm) and SAR test (17.67 dB) were due to the tolerances of the measurememt equipments. Answer from JQA: "The measurement uncertainty of each of test items is shown as follows: SAR evaluation: +/-2% 15.247 test: +/- 0.6 dB The measurement value range of the max conducted power measured of test items is shown as follows: SAR evaluation : 17.58dBm to 17.76 dBm 15.247 test : 17.2 dBm to 18.4dBm Therefore, the difference was due to the measurement uncertainty." Question #3: Thank you very much for your advice. We understand the purpose of this measurement, well. I discussed with JQA in this matter, and as a result of the disucusion, JQA does not re-measure the z-scan this time because the Max SAR value was very low level, 0.0928 mW/g (Limit: 1.6 mW/g). If JQA re-measured the z-scan, it is apparent that the Max SAR value should also be a very low level from the limitation. JQA wants to expand z-scan distance to cover 16 cm (or as far as possible) from the bottom surface in future submission. If you should have any question/comment, please feel free to contact us. Thank you very much for your attention and time in this matter. --------------- Original Message ------------------- From: "Steve Cheng" <[email protected]> To: "'?? ??'" <[email protected]>, <[email protected]>, <[email protected]> Cc: <[email protected]>, <[email protected]>, <[email protected]>, "Scott Wang" <[email protected]>, "Mike Kuo" <[email protected]>, "Mika Kaneko" <[email protected]> Date: Mon, 05 Jan 2004 18:17:09 -0800 Hi Nawata-san, Happy new year, and wish you all have a very successful coming year. Regarding to question #3, JQA does tested the SAR with 15 cm simulation liquid filled. The problem is they did not scan Z axis long enough to see the trace settle. Normally, SAR lab will scan Z axis in between 10 to 16cm range to demonstrate no unexpected response detected. Although FCC does not clearly document a specific distance to scan, but experience has tell us that they are looking for a complete settled trace or scan has exceed the liquid/air boundary (at 15cm high). I strongly recommend that JQA to re-conduct the Z scan if possible. Thanks for your attention. Best regards, Steve -----Original Message----- From: [email protected] [mailto:[email protected]. com] Sent: Sunday, January 04, 2004 11:04 PM To: [email protected]; [email protected]; [email protected] Cc: [email protected]; [email protected]; [email protected]; [email protected]; [email protected]; [email protected] Subject: RE: PCTP-03-F004: Matsushita Electric Industrial C To: Mr. Cheng/ CCS Mr. Mullen/ MECA-PSCD From: Nawata/ PCTP (Panasonic Communications, Telecom) RE: FCC ID:ACJ96NKX-TG2356, AN03T3514 Dear Mr. Cheng and Mr. Mullen; Today, I returned our office and found this E-mail. Thank you very much. Question #1: I understand this matter was resolved. Question #2: I contacted JQA lab. Unfortunately, today JQA had their New Year celemony only and did not work in office/lab. I had a short discussion on this matter, and JQA advised they could provide with the answer tomorrow. Question #3: As for this job, could you confirm if this matter is OK as it is, or not? Namely, is it acceptable JQA should extend z-scan distance to cover 16cm from the bottom surface IN FUTURE submission? Regarding "z-scan distance to cover 16cm from the bottom surface", could you advise this issue in details? Because I think OET Bulletin 65 requires the equvalent tissue medium should fill the depth of 15cm from the bottom surface. Thank you very much. ------------------- ORIGINAL MESSAGE -------------------- From: "Steve Cheng" <[email protected]> To: "'Mullen, Richard'" <[email protected]> Cc: "?? ??" <[email protected]>, <[email protected]>, <[email protected]>, "Mullen, Richard C." <[email protected]>, "Scott Wang" <[email protected]>, "Mike Kuo" <[email protected]>, "Mika Kaneko" <[email protected]> Date: Mon, 29 Dec 2003 21:38:17 -0800 Dear Richard-san, Re your response dated 12/26/2003, Question #1: Based upon the theory of operation description, this frequency hopping is TDMA modulation with 8 time slots. In any given time, only four time slots are used for transmitting. Per the SAR test report, crest factor of 1 with 100% duty cycle was used during the SAR tests. Please confirm the handset and base unit were transmitting 100% duty cycle and please provide procedures to describe how this was done. <CCS> OK, you have re-evaluated the SAR reading with the actual duty-cycle of 1:11.3 Question #2: The max. conducted output power measured before SAR evaluation is 17.67dBm which is less than max. conducted output power ( 17.8dBm )measured during 15.247 tests. Please explain the differences. Per FCC review instruction," Conducted power in SAR report should be greater than or equal to what's in EMC report, but not exceeding tu…

Text truncated - open the document above for the full version.

FIG 1 Basic Model KX-TG2356 FIG 2 Bottom View FIG 3 Internal View FIG 4 PC Board (Another Side) FIG 5 PC Board (RF Cover Removed)

EXHIBIT B MARKINGS Base Unit: The base unit provides with the following marking, or equivalent. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone. Nameplate NOTE: Above markings are shown on bottom of the base unit. Portable Unit: FCC ID Label The marking is shown on the battery compartment of the portable unit.

FIG 6 Portable Unit FIG 7 Battery Compartment Removed FIG 8 PC Board FIG 9 PC Board (Another side) FIG 10 PC Board (RF Cover Removed)

FIG 6 Portable Unit FIG 7 Battery Compartment Removed FIG 8 PC Board FIG 9 PC Board (Another side) FIG 10 PC Board (RF Cover Removed)

Exhibit 5 Transmitted Duty Cycle Plots Duty Cycle Plots Handset Duty Cycle: 100 × (0.900/9.960) = 9.04% Duty Cycle Plots Base Unit Duty Cycle: 100 × (0.840/9.930) = 8.46%

EXHIBIT A STATEMENT OF SECURITY CODE This cordless telephone system has 1,099 billion digital security coding combinations that are provided by the following means: • Provided with 40 bits (1,099 billion) for security codes. • When shipped from the factory, the security code is decided by the manufacture. It is memorized in a memory IC. • Base and Handset knows each other’s security code information.

APPENDIX 1 System Validation Plots Date/Time: 10/31/03 11:10:40 Test Laboratory: JAPAN QUALITY ASSURANCE ORGANIZATION File Name: Validation031031.da4 System Validation DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:714 Program: Validation Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: HSL2450 (σ = 1.835 mho/m, ε r = 37.82, ρ = 1000 kg/m 3 ) Phantom section: Flat Section Measurement Standard: DASY4 (High Precision Assessment) DASY4 Configuration: zProbe: ET3DV6 - SN1678; ConvF(5, 5, 5); Calibrated: 2003/02/07 zSensor-Surface: 4mm (Mechanical And Optical Surface Detection) zElectronics: DAE3 Sn508; Calibrated: 2003/01/31 zPhantom: SAM 1194; Type: QD 000 P40 CA; Serial: 1194 zMeasurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 Antenna Input Power 250 mW/Area Scan (5x5x1): Measurement grid: dx=20mm, dy=20mm Reference Value = 95.3 V/m Power Drift = -0.03 dB Maximum value of SAR = 14.6 mW/g Antenna Input Power 250 mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Peak SAR (extrapolated) = 27.9 W/kg SAR(1 g) = 13.2 mW/g; SAR(10 g) = 6.07 mW/g Reference Value = 95.3 V/m Power Drift = -0.03 dB Maximum value of SAR = 14.5 mW/g 0 dB = 14.5mW/g Date/Time: 11/01/03 10:29:46 Test Laboratory: JAPAN QUALITY ASSURANCE ORGANIZATION File Name: Validation031101.da4 System Validation DUT: Dipole 2450 MHz; Type: D2450V2; Serial: D2450V2 - SN:714 Program: Validation Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: M2450 (σ = 1.993 mho/m, ε r = 53.17, ρ = 1000 kg/m 3 ) Phantom section: Flat Section Measurement Standard: DASY4 (High Precision Assessment) DASY4 Configuration: zProbe: ET3DV6 - SN1678; ConvF(4.6, 4.6, 4.6); Calibrated: 2003/02/07 zSensor-Surface: 4mm (Mechanical And Optical Surface Detection) zElectronics: DAE3 Sn508; Calibrated: 2003/01/31 zPhantom: SAM 1194; Type: QD 000 P40 CA; Serial: 1194 zMeasurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 Antenna Input Power 250 mW/Area Scan (5x5x1): Measurement grid: dx=20mm, dy=20mm Reference Value = 88.3 V/m Power Drift = -0.04 dB Maximum value of SAR = 13.9 mW/g Antenna Input Power 250 mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Peak SAR (extrapolated) = 29.1 W/kg SAR(1 g) = 13.1 mW/g; SAR(10 g) = 5.91 mW/g Reference Value = 88.3 V/m Power Drift = -0.04 dB Maximum value of SAR = 14.3 mW/g 0 dB = 14.3mW/g

Appendix 2 SAR Testr Plots Date/Time: 10/31/03 16:18:40 Test Laboratory: JAPAN QUALITY ASSURANCE ORGANIZATION File Name: Left_Touch_Low.da4 Cheek/Touch 1ch (2400.914355MHz) DUT: F.H.S.S. Cordless Telephone (Handset); Type: KX-TG2356; Serial: -- Program: Left Head Communication System: FHSS; Frequency: 2401 MHz;Duty Cycle: 1:11.07 Medium: HSL2450 (σ = 1.835 mho/m, ε r = 37.82, ρ = 1000 kg/m 3 ) Phantom section: Left Section Measurement Standard: DASY4 (High Precision Assessment) DASY4 Configuration: zProbe: ET3DV6 - SN1678; ConvF(5, 5, 5); Calibrated: 2003/02/07 zSensor-Surface: 4mm (Mechanical And Optical Surface Detection) zElectronics: DAE3 Sn508; Calibrated: 2003/01/31 zPhantom: SAM 1194; Type: QD 000 P40 CA; Serial: 1194 zMeasurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 Cheek/Touch Position/Area Scan (16x10x1): Measurement grid: dx=10mm, dy=10mm Reference Value = 1.84 V/m Power Drift = 0.03 dB Maximum value of SAR = 0.0336 mW/g Cheek/Touch Position/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Peak SAR (extrapolated) = 0.0673 W/kg SAR(1 g) = 0.0335 mW/g; SAR(10 g) = 0.0182 mW/g Reference Value = 1.84 V/m Power Drift = 0.03 dB Maximum value of SAR = 0.035 mW/g 0 dB = 0.035mW/g Date/Time: 10/31/03 16:51:44 Test Laboratory: JAPAN QUALITY ASSURANCE ORGANIZATION File Name: Left_Touch_Middle.da4 Cheek/Touch 45ch (2440.156641MHz) DUT: F.H.S.S. Cordless Telephone (Handset); Type: KX-TG2356; Serial: -- Program: Left Head Communication System: FHSS; Frequency: 2440 MHz;Duty Cycle: 1:11.07 Medium: HSL2450 (σ = 1.835 mho/m, ε r = 37.82, ρ = 1000 kg/m 3 ) Phantom section: Left Section Measurement Standard: DASY4 (High Precision Assessment) DASY4 Configuration: zProbe: ET3DV6 - SN1678; ConvF(5, 5, 5); Calibrated: 2003/02/07 zSensor-Surface: 4mm (Mechanical And Optical Surface Detection) zElectronics: DAE3 Sn508; Calibrated: 2003/01/31 zPhantom: SAM 1194; Type: QD 000 P40 CA; Serial: 1194 zMeasurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 Cheek/Touch Position/Area Scan (16x10x1): Measurement grid: dx=10mm, dy=10mm Reference Value = 1.72 V/m Power Drift = -0.08 dB Maximum value of SAR = 0.0309 mW/g Cheek/Touch Position/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Peak SAR (extrapolated) = 0.0655 W/kg SAR(1 g) = 0.0312 mW/g; SAR(10 g) = 0.0167 mW/g Reference Value = 1.72 V/m Power Drift = -0.08 dB Maximum value of SAR = 0.033 mW/g 0 dB = 0.033mW/g Date/Time: 10/31/03 17:25:48 Test Laboratory: JAPAN QUALITY ASSURANCE ORGANIZATION File Name: Left_Touch_High.da4 Cheek/Touch 90ch (2480.292773MHz) DUT: F.H.S.S. Cordless Telephone (Handset); Type: KX-TG2356; Serial: -- Program: Left Head Communication System: FHSS; Frequency: 2480 MHz;Duty Cycle: 1:11.07 Medium: HSL2450 (σ = 1.835 mho/m, ε r = 37.82, ρ = 1000 kg/m 3 ) Phantom section: Left Section Measurement Standard: DASY4 (High Precision Assessment) DASY4 Configuration: zProbe: ET3DV6 - SN1678; ConvF(5, 5, 5); Calibrated: 2003/02/07 zSensor-Surface: 4mm (Mechanical And Optical Surface Detection) zElectronics: DAE3 Sn508; Calibrated: 2003/01/31 zPhantom: SAM 1194; Type: QD 000 P40 CA; Serial: 1194 zMeasurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 Cheek/Touch Position/Area Scan (16x10x1): Measurement grid: dx=10mm, dy=10mm Reference Value = 1.88 V/m Power Drift = 0.03 dB Maximum value of SAR = 0.0312 mW/g Cheek/Touch Position/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Peak SAR (extrapolated) = 0.0736 W/kg SAR(1 g) = 0.0321 mW/g; SAR(10 g) = 0.0165 mW/g Reference Value = 1.88 V/m Power Drift = 0.03 dB Maximum value of SAR = 0.0325 mW/g 0 dB = 0.0325mW/g Date/Time: 10/31/03 17:58:42 Test Laboratory: JAPAN QUALITY ASSURANCE ORGANIZATION File Name: Left_Tilt_Low.da4 Ear/Tilt 1ch (2400.914355MHz) DUT: F.H.S.S. Cordless Telephone (Handset); Type: KX-TG2356; Serial: -- Program: Left Head Communication System: FHSS; Frequency: 2401 MHz;Duty Cycle: 1:11.07 Medium: HSL2450 (σ = 1.835 mho/m, ε r = 37.82, ρ = 1000 kg/m 3 ) Phantom section: Left Section Measurement Standard: DASY4 (High Precision Assessment) DASY4 Configuration: zProbe: ET3DV6 - SN1678; ConvF(5, 5, 5); Calibrated: 2003/02/07 zSensor-Surface: 4mm (Mechanical And Optical Surface Detection) zElectronics: DAE3 Sn508; Calibrated: 2003/01/31 zPhantom: SAM 1194; Type: QD 000 P40 CA; Serial: 1194 zMeasurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 Ear/Tilt Position/Area Scan (16x10x1): Measurement grid: dx=10mm, dy=10mm Reference Value = 2.16 V/m Power Drift = 0.04 dB Maximum value of SAR = 0.096 mW/g Ear/Tilt Position/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Peak SAR (extrapolated) = 0.186 W/kg SAR(1 g) = 0.0928 mW/g; SAR(10 g) = 0.0463 mW/g Reference Value = 2.16 V/m Power Drift = 0.04 dB Maximum value of SAR = 0.1 mW/g 0 dB = 0.1mW/g Date/Time: 10/31/03 18:30:36 Test Laboratory: JAPAN QUALITY ASSURANCE ORGANIZATION File Name: Left_Tilt_Middle.da4 Ear/Tilt 45ch (2440.156641MHz) DUT: F.H.S.S. Cordless Telephone (Handset); Type: KX-TG2356; Serial: -- Program: Left Head Communication System: FHSS; Frequency: 2440 MHz;Duty Cycle: 1:11.07 Medium: HSL2450 (σ = 1.835 mho/m, ε r = 37.82, ρ = 1000 kg/m 3 ) Phantom section: Left Section Measurement Standard: DASY4 (High Precision Assessment) DASY4 Configuration: zProbe: ET3DV6 - SN1678; ConvF(5, 5, 5); Calibrated: 2003/02/07 zSensor-Surface: 4mm (Mechanical And Optical Surface Detection) zElectronics: DAE3 Sn508; Calibrated: 2003/01/31 zPhantom: SAM 1194; Type: QD 000 P40 CA; Serial: 1194 zMeasurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 Ear/Tilt Position/Area Scan (16x10x1): Measurement grid: dx=10mm, dy=10mm Reference Value = 1.87 V/m Power Drift = -0.1 dB Maximum value of SAR = 0.0834 mW/g Ear/Tilt Position/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Peak SAR (extrapolated) = 0.164 W/kg SAR(1 g) = 0.0…

Text truncated - open the document above for the full version.

APPENDIX 3 Dosimetric E-Field Probe - ET3DV6, S/N: 1678

APPENDIX 4 System Validation Dipole - D2450V2, S/N: 714

IssueDate:November28,2003 Page 1 of 23 TEST REPORTEMCSAR - JQA APPLICATION No.: KL80030488R Name of Product: 2.4GHz Frequency Hopping Spread Spectrum Cordless Telephone Model/Type No.: KX-TG2356 FCC ID: ACJ96NKX-TG2356 : Panasonic Communications Co., Ltd.Applicant : 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka, 812-8531 JapanAddress : Panasonic Communications Co., Ltd.Manufacturer : 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka, 812-8531 JapanAddress October 24, 2003Receive date of EUT: PassedFinal Judgement: are obtained TEST RESULTS IN THIS REPORT in use of equipment that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) under METI Japan, Communications Research Lab. (CRL) under MPHPT Japan, and Laboratory for EMF and Authorized by:Microwave Electronics at the Swiss Federal Institute of Technology (ETH) in Zürich, Switzerland. only responds to the test THE TEST RESULTS Takashi Yamanaka, Directorsample. This test report shall not be reproduced JQA KITA-KANSAI Testing Centerexcept in full. Page 2 of 23 DIRECTORY Page A) Documentation Directory2 Test Regulation / General Information3 - 5 SAR Measurement Set-up6 Test Configuration Positions7 - 9 Measurement Process10 Measurement Uncertainties11 Test Conditions12 EUT Tune-up Procedure13 EUT Modification / Responsible Party / Deviation from Standard14 Test results15 - 16 Summary17 EUT Photographs18 B) Test data Test System Validation19 Tissue SimulantVerification20 SAR Measurement Data21 - 22 Appendix23 JQA Application No. : KL80030488RRegulation : CFR 47 FCC Rules Part 2 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 JQA Application No. : KL80030488RRegulation : CFR 47 FCC Rules Part 2 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 Page 3 of 23 TEST REGULATION FCC Rules and Regulations Parts 2 Subpart J (October 1, 2002) - Mobile Devices (§2.1091)- Occupational/Controlled Exposure{{ - Portable Devices (§2.1093)- General Population/Uncontrolled Exposurezz Test procedure: The SAR measurement procedures were specified in FCC/OET Bulletin 65 Supplement C (July, 2001) and IEEE Std. 1528-200X (Draft 6.5, January 2002). TheexposurelimitswerespecifiedinANSI/IEEEC95.1-1999. GENERAL INFORMATION Description of the Equipment Under Test (EUT): 1) Name: 2.4GHz FHSS Cordless Telephone 2) Model/Type No.: KX-TG2356 3) Product Type: Prototype 4) EUT Authorization: - Verification- Certification- D.o.C.{z { 5) Transmitting Frequency: 2400.914355 MHz - 2480.292773 MHz 6) Receiving Frequency: 2398.914355 MHz - 2478.292773 MHz 7) Max. RF Output Power: 17.67 dBm (Handset), 18.45 dBm (Base Unit) 8) Power Rating: DC 3.6V (Handset), AC 120V 60Hz (Base Unit) Definitions for symbols used in this test report: - Black box indicates that the listed condition, standard or equipment is applicablez for this Report. - Blank box indicates that the listed condition, standard or equipment is not applicable{ for this Report. JQA Application No. : KL80030488RRegulation : CFR 47 FCC Rules Part 2 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 Page 4 of 23 Description of the Antenna: HandsetType: Shortening dipole antenna Dimensions: Maximum width 12.5 mm Maximum length 44.6 mm Location: Right side Base UnitType: Collinear antenna Dimensions: Maximum width 13.3 mm Maximum length 144.0 mm Location: Right side Battery Option: Handset : Ni-MH Battery Pack HHR-P104 Base Unit : None (supplied by AC Adapter PQLV1) Probe Specification: Construction: Symmetricaldesign with triangular core Built-in optical fiber for surface detection system Built-in shielding against static changes Calibration: In air form 10 MHz to 2.5 GHz In head tissue simulating liquid (HSL) and muscle tissue simulating liquid at 900 MHz, 1800 MHz (accuracy ± 9.5%; k=2) and 2450 MHz (accuracy ± 8.9%; k=2) Frequency: 10MHzto3GHz(dosimetry); Linearity: ±0.2 dB (30 MHz to 3 GHz) Directivity: ± 0.2 dB in HSL (rotation around probe axis) ± 0.4 dB in HSL (rotation normal probe axis) Dynamic Range: 5 μW/g to >100mW/g;Linearity:±0.2dB Surface Detection : ± 0.2 mm repeatability in air and clear liquids over diffuse reflecting surfaces Dimensions: Overall length 330 mm Tip length16 mm Body diameter 12 mm Tip diameter 6.8 mm Distance from probe tip to dipole centers 2.7 mm JQA Application No. : KL80030488RRegulation : CFR 47 FCC Rules Part 2 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 Page 5 of 23 Twin SAM Phantom: The shell corresponds to the specifications of the Specific Anthropomorphic Mannequin (SAM) phantom defined in IEEE 1528-200X, CENELEC 50361 and IEC 62209. It enables the dosimetric evaluation of left and right head phone usage as well as body mounted usage at the flat phantom region. A cover prevents evaporation of the liquid. Reference markings on the phantom allow the complete setup of all predefined phantom positions and measurement grids by manually teaching three points with the robot. Shell Thickness: 2 ± 0.2 mm Filling Volume: Volume Approx. 25 liters Dimensions: 810 × 1000 × 500 mm (H × L × W) Mounting Device for Transmitters: The Mounting Device enables the rotation of the mounted transmitter in spherical coordinates, whereby the rotation point is the ear opening. The devices can be easily and accurately positioned according to IEC, IEEE, CENELEC, FCC or other specifications. The device holder can be locked at different phantom locations (left head, right head, flat phantom). Typical Composition of Ingredients for Liquid Tissue: IngredientsFrequency (MHz) (% by weight)83519002450 HeadBodyHeadBodyHeadBody Water41.4552.4054.9040.4062.7073.20 Salt (NaCl)1.451.400.180.500.500.04 Sugar56.0045.000.0058.000.000.00 HEC1.001.000.001.000.000.00 Bactericide 0.100.100.000.100.000.00 Triton X-1000.000.000.000.0036.800.00 DGBE0.000.0044.920.000.0026.70 Salt : 99 % Pure Sodium ChlorideSugar : 98 % Pure Sucrose ++ Water : De-ionized, 16 M resistivityHEC : Hydroxyethyl CelluloseΩ…

Text truncated - open the document above for the full version.

Page 1 of 8 -20dB Bandwidth Measurement Test Date: November 12, 2003 Temp.: 29 ; Humi.: 46 %°C CHTransmitting-20dBData No.Frequency(MHz)BandwidthPage 02400.914355630 kHzPage 2 452440.156641654 kHzPage 3 902480.292773675 kHzPage 4 .Note) The point shown on "" is the Maximum Margin Point Tester : Shigeru Kinoshita JQA Application No. : KL80030483Regulation : CFR 47 FCC Rules Part 15 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 Page 2 of 8 -20dB Bandwidth Measurement Transmitting Frequency : 2400.914355 MHz ( 0ch) JQA Application No. : KL80030483Regulation : CFR 47 FCC Rules Part 15 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 JQA Application No. : KL80030483Regulation : CFR 47 FCC Rules Part 15 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 Page 3 of 8 -20dB Bandwidth Measurement Transmitting Frequency : 2440.156641 MHz (45ch) JQA Application No. : KL80030483Regulation : CFR 47 FCC Rules Part 15 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 Page 4 of 8 -20dB Bandwidth Measurement Transmitting Frequency : 2480.292773 MHz (90ch) JQA Application No. : KL80030483Regulation : CFR 47 FCC Rules Part 15 Model No.: KX-TG2356Issue Date : November 28, 2003 FCC ID: ACJ96NKX-TG2356 Page 5 of 8 Band-Edge Emission Measurement Test Date: November 12, 2003 Temp.: 29 ; Humi.: 46 %°C 1) Low Band-Edge Measurement CHTransmittingBand-Edge Band-EdgeData Frequency(MHz)Frequency(MHz) Level[dBc]Page* 02400.9143552400.00…
