ACJ96NKX-TG56315.8 GHz FHSS Cordless Telephone System

Temporary Confidential This unit is compatible with Caller ID. To use this feature, you must subscribe to the appropriate service offered by your service provider. Please read these Operating Instructions before using the unit and save for future reference. For assistance, visit our website: http://www.panasonic.com/phonehelp for customers in the U.S.A. or Puerto Rico. Charge the handset battery for 6 hours before initial use. Operating Instructions 5.8 GHz Digital Cordless Phone Model No. KX-TG5621 5.8 GHz Digital Cordless Phone with Dual Handsets Model No. KX-TG5622 5.8 GHz Digital Cordless Phone with Three Handsets Model No. KX-TG5623 5.8 GHz Digital Cordless Answering System Model No. KX-TG5631 Model No. KX-TG5651 5.8 GHz Digital Cordless Answering System with Dual Handsets Model No. KX-TG5632 Model No. KX-TG5652 5.8 GHz Digital Cordless Answering System with Three Handsets Model No. KX-TG5633 Model No. KX-TG5653 5.8 GHz Digital Cordless Answering System with Four Handsets Model No. KX-TG5634 Model shown is KX-TG5621. TG56XX.book Page 1 Tuesday, October 4, 2005 2:10 PM Temporary Confidential Table of Contents 2For assistance, please visit http://www.panasonic.com/phonehelp Introduction Your phone . . . . . . . . . . . . . . . . . . . . . . . 3 Accessory information . . . . . . . . . . . . . . 8 Important safety instructions . . . . . . . . 11 For best performance . . . . . . . . . . . . . . 13 Preparation Setting up the base unit . . . . . . . . . . . . 14 Setting up the handset . . . . . . . . . . . . . 16 Battery charge . . . . . . . . . . . . . . . . . . . 17 Battery replacement . . . . . . . . . . . . . . . 18 Controls . . . . . . . . . . . . . . . . . . . . . . . . 19 Displays . . . . . . . . . . . . . . . . . . . . . . . . 23 Symbols used in these operating instructions . . . . . . . . . . . . . . . . . . . . . . 24 Setting the unit before use . . . . . . . . . . 24 Making/Answering Calls Making calls . . . . . . . . . . . . . . . . . . . . . 26 Answering calls . . . . . . . . . . . . . . . . . . 27 Useful features during a call . . . . . . . . . 27 Phonebook Handset phonebook . . . . . . . . . . . . . . . 29 Copying handset phonebook items . . . 31 Caller ID Service Using Caller ID service . . . . . . . . . . . . . 32 Caller list. . . . . . . . . . . . . . . . . . . . . . . . 34 Programming Programmable settings . . . . . . . . . . . . 36 Answering System Answering system feature . . . . . . . . . . 40 Setting up the answering system . . . . . 41 Listening to messages using the base unit 42 Listening to messages using the handset 43 Remote operation . . . . . . . . . . . . . . . . . 44 Answering system settings . . . . . . . . . . 45 Voice Mail Service Using Voice Mail service. . . . . . . . . . . . 47 Multi-unit Operation Handset locator . . . . . . . . . . . . . . . . . . 49 Intercom . . . . . . . . . . . . . . . . . . . . . . . . 49 Transferring a call . . . . . . . . . . . . . . . . . 50 Conference calls . . . . . . . . . . . . . . . . . . 51 Call share . . . . . . . . . . . . . . . . . . . . . . . 51 Registering a unit . . . . . . . . . . . . . . . . . 52 Useful Information Wall mounting . . . . . . . . . . . . . . . . . . . . 53 Belt clip (optional) . . . . . . . . . . . . . . . . . 57 Headset (optional) . . . . . . . . . . . . . . . . 57 Error messages . . . . . . . . . . . . . . . . . . 58 Troubleshooting . . . . . . . . . . . . . . . . . . 59 FCC and other information . . . . . . . . . . 64 Specifications . . . . . . . . . . . . . . . . . . . . 68 Warranty . . . . . . . . . . . . . . . . . . . . . . . . 69 Customer services . . . . . . . . . . . . . . . . 71 Index Index . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 TG56XX.book Page 2 Tuesday, October 4, 2005 2:10 PM Temporary Confidential Introduction For assistance, please visit http://www.panasonic.com/phonehelp3 Your phone Thank you for purchasing a Panasonic cordless telephone. These operating instructions can be used for the following models: NKX-TG5621/KX-TG5622/KX-TG5623 NKX-TG5631/KX-TG5632/KX-TG5633/KX-TG5634 TG56XX.book Page 3 Tuesday, October 4, 2005 2:10 PM Temporary Confidential Introduction 4For assistance, please visit http://www.panasonic.com/phonehelp NKX-TG5651/KX-TG5652/KX-TG5653 Important: LReferences in these operating instructions to the charger and multiple handsets are for KX-TG5622, KX-TG5623, KX-TG5632, KX-TG5633, KX-TG5634, KX-TG5652, and KX- TG5653 users only. TG56XX.book Page 4 Tuesday, October 4, 2005 2:10 PM Temporary Confidential Introduction For assistance, please visit http://www.panasonic.com/phonehelp5 Main feature differences among these models FeatureKX-TG5621 KX-TG5622 KX-TG5623 KX-TG5631 KX-TG5632 KX-TG5633 KX-TG5634 KX-TG5651 KX-TG5652 KX-TG5653 Page Answering system–rr45 Voice mail servicer––47 Talking Caller ID––r32 TG56XX.book Page 5 Tuesday, October 4, 2005 2:10 PM Temporary Confidential Introduction 6For assistance, please visit http://www.panasonic.com/phonehelp Expanding your phone system For the following models, you can expand the system by adding an accessory handset(s), sold separately. NKX-TG5622 NKX-TG5632 NKX-TG5633 Accessory handset (up to 1) KX-TGA562 Accessory handset (up to 2) KX-TGA562 Accessory handset (up to 1) KX-TGA562 + + + TG56XX.book Page 6 Tuesday, October 4, 2005 2:10 PM Temporary Confidential Introduction For assistance, please visit http://www.panasonic.com/phonehelp7 NKX-TG5652 Accessory handset (up to 1) KX-TGA562 + TG56XX.book Page 7 Tuesday, October 4, 2005 2:10 PM Temporary Confidential Introduction 8For assistance, please visit http://www.panasonic.com/phonehelp Accessory information Included accessories NKX-TG5621/KX-TG5622/KX-TG5623 1234 56 No.Accessory itemsOrder number Quantity KX-TG 5621S KX-TG 5621W KX-TG 5622M KX-TG 5623M 1AC adaptor for base unitPQLV1Z1111 2Telephone line cordPQJA10075Z1111 3Wall mounting adaptorPQKL10068Z11––– PQKL10068Z2––11 PQKL10068Z3–1–– 4BatteryHHR-P1041123 5Handset coverPQYNTG5421SR1––– PQYNTG5421WR–…

Text truncated - open the document above for the full version.

EXHIBIT A STATEMENT OF SECURITY CODE This cordless telephone system has 1,099 billion digital security coding combinations that are provided by the following means: • Provided with 40 bits (1,099 billion) for security codes. • When shipped from the factory, the security code is decided by the manufacture. It is memorized in a memory IC. • Base and Handset knows each other’s security code information.

Panasonic Corporation of North America Three Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201.392.6115 / Fax: 201.392.4564 [email protected] Robert Wegner Group Manager Product Safety and Compliance Division Date: November 7, 2005 Control No: PCTP-05-F029 731 Confirm No: EA494874 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Original Certification Application for Frequency Hopping Spread Spectrum Transmitter Panasonic 5.8 GHz FHSS Cordless Telephone System, Model KX-TG5631 Family FCC Certification for FCC ID: ACJ96NKX-TG5631 To Whom It May Concern: Enclosed, find our original application for the subject transmitter. This product is in compliance with Part 15, Subpart C and Section 15.247. In accordance with provisions of Sections 0.457(d) and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for exhibits, which contains Description of Circuitry, Schematic Diagram, Block Diagram and FHSS Operation of Description and Overview of Frequency Hopping Algorithm. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. Also, in accordance with FCC Public Notice DA 04-1705, we request temporary confidentiality for exhibits, which contain External and Internal Photographs and the User Manual. The subject product is cordless telephone system, which has mobile base unit and portable handset. The transceiver portion of this product uses frequency hopping spread spectrum transmitter with FSK modulation with operation within 5725 ~ 5850 MHz. The base and handset have a maximum peak conducted RF output of 0.102 watts and 0.076 watts. The base uses left and right permanently attached colliner antenna with nominal 3 dBi antenna gain and the handset uses permanently attached 5/8 λ pattern antenna with nominal 4 dBi antenna gain. The handset unit is classified as portable and SAR test reports was generated on representative handset model KX-TGA560. The SAR test report was generated with maximum transmit power (EIRP) at 21.1 dBm (0.129 watts) with 20% duty cycle based on averaged and crest factor of 5. The worst-case handset SAR test results for head position was 0.395 W/Kg and for body position was 0.412 W/Kg. The base unit is classified as mobile and the User Manual will contain the following type FCC RF Exposure Warning: “This product complies with FCC radiation exposure limits set forth for an uncontrolled environment. To comply with FCC RF exposure requirements the base unit must be installed and operated with its antenna located 20 cm or more between antenna and all person’s body (excluding extremities of hands, wrist and feet). The handset unit may be carried and operated with only the specific provided belt-clip. Other non-tested belt-clips or similar body-worn accessories may not comply and must be avoided. The base and handset units must not be co-located or operated in conjunction with any other antenna or transmitter.” The telephone interface portion of this product’s base was FCC Part 68 TCB certified by CCL under identification number US: ACJW401BKX-TG5631. Sincerely yours, Robert Wegner Robert Wegner Group Manager

Panasonic Corporation of America Three Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201.348.7758 / Fax: 201.392.4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division Date: January 5, 2006 Control No: PCTP-05-F029 731 Confirm No: EA494874 To: Diane Poole / FCC Equipment Authorization Branch FCC ID: ACJ96KX-TG5631 Applicant: Panasonic Corporation of North America Corr. Ref No: EA494874 731 Confirm No: 30235 and 30236 Date of FCC E-Mail: December 30, 2005 Product Name: Panasonic 5.8 GHz FHSS Cordless Telephone System, Model KX-TG5631 Family Dear Diane Poole: 1. The electronic filed FCC Form 731 line for Equipment Specification declared Section 15.247 operating frequency band 5725 ~ 5850 MHz. However, the subject product will operate within 5759.70240 ~ 5838.18697 MHz frequency band. Today we will updated amended test reports to reflect this operating frequency band, which includes tested at low, middle and high frequencies bands. 2. We understand as this product uses frequency hopping spread spectrum modulation that the filed electronic FCC Form 731 line for Equipment Class should be amended from code “DTS” for Digital Transmission System to code “DSS” for Spread Spectrum Transmitter. 3. The SAR Test Report page 7 inadvertently referenced compliance with IEEE 802.11b. Today we will updated amended SAR test report to amend page 7 to remove reference to IEEE 802.11b. Thank you for your attention in this matter. Sincerely yours, Richard Mullen Richard Mullen Group Manager

Temporary Confidential EXTERNAL PHOTOGRAPHS KX-TG5631 Temporary Confidential Rear View Temporary Confidential Bottom View

Temporary Confidential EXTERNAL PHOTOGRAPHS Handset KX-TGA560 Temporary Confidential Battery Cover Open

EXHIBIT B MARKINGS Base Unit: The base unit provides with the following marking, or equivalent. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone. Nameplate NOTE: Above markings are shown on bottom of the base unit. Portable Unit: FCC ID Label The marking will be shown on the battery compartment of the portable unit.

Temporary Confidential INTERNAL PHOTOGRAPHS Internal View Temporary Confidential RF Cover Open Temporary Confidential P.C.Board (Another Side)

Temporary Confidential INTERNAL PHOTOGRAPHS P.C.Board Temporary Confidential RF Cover Open Temporary Confidential P.C.Board (Another Side)

Test report No. : 26CE0011-HO-5a Page : 1 of 65 FCC ID : ACJ96NKX-TG5631 Issued date : November 02, 2005 Revised date : November 02, 2005 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 SAR TEST REPORT Test Report No. : 26CE0011-HO-5a Applicant : Panasonic Communications Co., Ltd. Type of Equipment : Cordless Telephone Model No. : KX-TGA560 FCC ID : ACJ96NKX-TG5631 Test standard : FCC47CFR 2.1093 FCC OET Bulletin 65, Supplement C Test Result : Complied Max. SAR Measured : Head 0.395W/kg (5759.70240MHz) Body 0.412W/kg (5798.05084MHz) 1. This test report shall not be reproduced except full or partial, without the written approval of UL Apex Co., Ltd. 2. The results in this report apply only to the sample tested. 3. This equipment is in compliance with the above standard. We hereby certify that the data contain a true representation of the SAR profile. 4. The test results in this test report are traceable to the national or international standards. Date of test : October 24-25 ,2005 Tested by : Miyo Ikuta EMC Services Approved by : Tetsuo Maeno Site Manager of EMC Services Test report No. : 26CE0011-HO-5a Page : 2 of 65 FCC ID : ACJ96NKX-TG5631 Issued date : November 02, 2005 Revised date : November 02, 2005 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 CONTENTS PAGE SECTION 1 : Client information............................................................................................................................................ 3 SECTION 2 : Equipment under test (E.U.T.)........................................................................................................................ 3 2.1 Identification of E.U.T. ...................................................................................................................................... 3 2.2 Product Description ............................................................................................................................................ 4 SECTION 3 : Test standard information............................................................................................................................... 5 3.1 Requirements for compliance testing defined by the FCC ................................................................................. 5 3.2 Exposure limit .................................................................................................................................................... 6 SECTION 4 : Test result ......................................................................................................................................................... 7 4.1 Result of Max. SAR value .................................................................................................................................. 7 4.2 Test Location ...................................................................................................................................................... 7 SECTION 5 : Operation of E.U.T. during testing................................................................................................................. 7 5.1 Operating modes................................................................................................................................................. 7 5.2 Description of the head test setup ....................................................................................................................... 8 5.3 Method of measurement (Head SAR) ................................................................................................................ 9 5.4 Description of the Body-worn test setup and Method ........................................................................................ 9 SECTION 6 : Test surrounding.............................................................................................................................................. 10 6.1 Measurement uncertainty ................................................................................................................................... 10 SECTION 7 : Confirmation before testing ............................................................................................................................ 11 7.1 Output Power Measurement results .................................................................................................................... 11 SECTION 8 : Measurement results........................................................................................................................................ 12 8.1 Head 5800MHz SAR.......................................................................................................................................... 12 8.2 Body-worn 5800MHz SAR ................................................................................................................................ 13 APPENDIX 1 : Photographs of test setup............................................................................................................................ 14 APPENDIX 2 : Test instruments.......................................................................................................................................... 22 Equipment & calibration information ..................................................................................................................... 23 1. Equipment used................................................................................................................................................... 23 2. Dosimetry assessment setup................................................................................................................................ 24 3. Configuration and peripherals............................................................…
