EXHIBIT A STATEMENT OF SECURITY CODE This cordless telephone system has more than 1,000 billion combinations that are provided by the following means: ∑ Provided with 128 bits for security codes. ∑ When shipped from the factory, the security code is decided by the manufacture. It is memorized in a memory IC. ∑ Base and Handset knows each other’s security code information.

Page: 1/1 Date: April 12, 2011 DESCRIPTION OF DIFFERENCES between ORIGINAL and SIMILARITY Name of Appliance : Cordless Telephone System SIMILARITY Model No. : KX-TG6671 (Base Unit) FCC ID : ACJ96NKX-TG6671 ORIGINAL Model No. : KX-TG651 (Base Unit) FCC ID : ACJ96NKX-TG6531 Approval Date : December 9, 2009 ORIGINAL NEW KX-TG6531 KX-TG6671 RF Type and Appearance 1.9GHz US-DECT 1.9GHz US-DECT P.C. Board 1.9GHz Antennas are different. RF Unit (1.9GHz Portion) Same 1.9GHz RF Unit RF Unit (1.9GHz Portion) NOTE: The 1.9GHz RF unit of KX-TG6671 is identical to that of KX-TG6531 except for antennas.

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] Richard Mullen Group Manager Product Safety and Compliance Division Authority to Act as Agent May 6, 2011 PCTP-11-F008 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Panasonic Corporation of North America hereby authorizes Nemko A/S, Instituttveien 6, N-2007 Kjeller, Norway to act on our behalf in all matters relating to the preparation of TCB Certification application for the below described product, which are in compliance with FCC Part 15D. Any and all acts carried out by Nemko AS on our behalf shall have the same effects as acts of our own for a period of one year from the date of this letter. Type Filing: Original Application for DECT Base Model KX-TG6671(xx) Family 1 FCC Classification: Isochronous UPCS Base Station (PUB) Product Name: 1921.536 ~1928.448 MHz DECT Cordless Telephone Base FCC ID Base Unit ACJ96NKX-TG6671 Power Supply: AC Adaptor Models PNLV226(FW) or PNLV226(UC) with 37 KHz switching power supply Responsible Panasonic Corporation of North America Applicant & Grantee: One Panasonic Way, Secaucus, NJ 07094 FRN Number: 0003762242 Responsible Manufacturer: Panasonic System Networks Co., Ltd. Sincerely yours, Richard Mullen Richard Mullen Group Manager Panasonic Corporation of North America Product Safety and Compliance Division 1 The subject Base will be: (1) FCC Part 68 certified by Nemko CCL under Certification ID Number US: ACJW410BKX-TG6671; and (2) will be marketed with Handset, which was already FCC Part 15D certified by Nemko CCL under FCC ID: ACJ96NKX-TGA660 Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] Richard Mullen Group Manager Product Safety and Compliance Division Request for Confidentiality May 6, 2011 PCTP-11-F008 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Type Filing: Original Application for DECT Base Model KX-TG6671(xx) Family FCC ID Base Unit ACJ96NKX-TG6671 In accordance with provisions of Sections 0.457 and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for exhibits, which contain: (1) Antenna Construction; (2) Description of Electrical Circuitry; (3) Schematic Diagrams of Base Unit and RF Unit; and (4) Block Diagram. The transmitter is not user adjustable and does not have a Tune-Up Procedure. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. In accordance with FCC Public DA 04-1705, we request forty-five day short-term confidentiality, starting from the from the issuance of equipment authorization date, for exhibits, which contain: (1) External Photographs of Base Unit and RF Unit; (2) Internal Photographs of Base Unit and RF Unit; (3) Test Setup Photographs; and (4) User Manual. These exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. Sincerely yours, Richard Mullen Richard Mullen Group Manager Panasonic Corporation of North America Product Safety and Compliance Division

PCTP-11-F008 / FCC ID: ACJ96NKX-TG6671 FCC Part 15D – Compliance Information pctp-11-f008 (part 15d declaration letter for dect base under acj96nkx-tg6671).doc 8-Dec-2006 page 1 (4) rev.1.4 EUT AND PRODUCT INFORMATION Type of Equipment UPCS (DECT 6.0) Applicant Name Panasonic System Networks Co., Ltd. Address Fukuoka, Japan Contact Yukio Kaneko FP PP Repeater EUT Type/System FCC ID ACJ96NKX-TG6671 Model name KX-TG6671 HW Version SW Version Max antenna Gain 0.0 dBi Can the EUT be Initiating Device YES YES YES Does the EUT transmit signaling channels YES YES YES Max number of slots in use simultaneously 6 Test standard: FCC part 15D Other: Industry Canada RSS-213, Issue 2 Frequency Band 1921.536 – 1928.448 MHz # of RF Channels 5 Frame Period 10 ms Max. Burst length 416μs / duplex channel Min. Burst Length 106μs / signaling channel # of Logical Channels 60 (12 duplex channels per RF carrier) Operating Mode Simplex Duplex PCTP-11-F008 / FCC ID: ACJ96NKX-TG6671 FCC Part 15D – Compliance Information pctp-11-f008 (part 15d declaration letter for dect base under acj96nkx-tg6671).doc 8-Dec-2006 page 2 (4) rev.1.4 ANTENNAS Antenna Type Internal External 1 2 3 4 Base (FP) Does RX and TX use the same antenna(s)? Yes No Antenna Type Internal External 1 2 Handset (PP) Does RX and TX use the same antenna(s)? Yes No ANTENNA DIVERSITY Diversity Supported Antenna TX RX 1 2 3 Base (FP) 4 1 Handset (PP) 2 VOLTAGE AND TEMPERATURE RANGES VOLTAGES FP PP Repeater Nominal Voltage 120 V AC Cut-Off Voltage (if applicable) POWER SOURCE Type Manufacturer Base or Repeater AC Adaptor Models PNLV226(FW) or PNLV226(UC) with 37 kHz switching power supply Panasonic Handset (PP) (charger) Data Connections PSTN Others (please specify) .... PCTP-11-F008 / FCC ID: ACJ96NKX-TG6671 FCC Part 15D – Compliance Information pctp-11-f008 (part 15d declaration letter for dect base under acj96nkx-tg6671).doc 8-Dec-2006 page 3 (4) rev.1.4 ANCILLARY EQUIPMENT Description Type Manufacturer HOST DEVICE Description Type Manufacturer ADDITIONAL INFORMATION PCTP-11-F008 / FCC ID: ACJ96NKX-TG6671 FCC Part 15D – Compliance Information pctp-11-f008 (part 15d declaration letter for dect base under acj96nkx-tg6671).doc 8-Dec-2006 page 4 (4) rev.1.4 MANUFACTURERS DECLARATIONS FCC part 15.323 (c)(5) No device or group of co-operating devices located within 1m of each other shall during any frame period occupy more than 6 MHz of aggregate bandwidth, or alternatively, more than one third of the time and spectrum windows defined by the system. Applicant Agrees Yes No FCC part 15.323 (c)(10) The applicant hereby declares that the system in this application does use the criteria of (c)(10) of this section. Applicant Agrees Yes No FCC part 15.323 (c)(11) The applicant hereby declares that system in this application does not use the criteria of (c)(11) of this section. Applicant Agrees Yes No FCC part 15.323 (c)(12) The provisions of (c)(10) or (c)(11) of this section shall not be used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. Applicant Agrees Yes No FCC part 15.307 (b) The Applicant is a participating member of UTAM, Inc. and will provide an affidavit from UTAM, Inc. certifying this. Confirmed By Applicant Yes No ADDITIONAL REMARKS: DECLARED BY: Date: May 12, 2011 Name (print): Richard Mullen Signature: Richard Mullen

EXTERNAL PHOTOGRAPHS KX-TG6671 Bottom View

EXHIBIT B MARKINGS Base Unit: The base unit provides with the following marking, or equivalent. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone. NOTE: Above markings are shown on bottom of the base unit.

INTERNAL PHOTOGRAPHS Internal View Main Board Main Board RF cover removed RF Portion

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to isotropicR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 19.90 (dBm) Maximum peak output power at antenna input terminal: 97.72 (mW) Antenna gain(typical): 0.1 (dBi) Maximum antenna gain: 1.023 (numeric) Prediction distance: 20 (cm) Sourse Based Time Average Duty Cycle: 100 (%) Prediction frequency: 1925 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.000 (mW/cm^2) Power density at prediction frequency: 0.019894 (mW/cm^2) Power density at prediction frequency: 0.1989 (W/m^2) Margin of Compliance: 17.0 (dB) 2 4 R PG S π =

Nemko AS, Gaustadalléen 30, P.O.Box 73 Blindern, NO-0314 Oslo Norway T +47 22 96 03 30 F +47 22 96 05 50 Enterprise number NO974404532 Visiting address: Nemko Kjeller, Instituttveien 6, P.O.Box 96, NO-2027 Kjeller Norway T +47 64 84 57 00 F +47 64 84 57 05 Test report no. : 174870-2 Item tested : KX-TG6671 Type of equipment : UPCS Base Station FCC ID : ACJ96NKX-TG6671 Client : Panasonic System Networks Co., Ltd. FCC Part 15, subpart D Isochronous UPCS Device 1920 - 1930 MHz Industry Canada RSS-213, Issue 2 2 GHz Licence-exempt Personal Communications Service Devices (LE-PCS) 5 May 2011 Authorized by : .............................................. G. Suhantakumar Technical Verificator TEST REPORT FCC part 15D Report no.: 174870-2 FCC ID: ACJ96NKX-TG6671 Nemko AS, N-2007 Kjeller Page 2 (25) CONTENTS 1 GENERAL INFORMATION ............................................................................................................... 3 1.1 Testhouse Info ................................................................................................................................... 3 1.2 Client Information .............................................................................................................................. 3 1.3 Responsible Manufacturer (if other than client) ................................................................................. 3 2 TEST INFORMATION ....................................................................................................................... 4 2.1 Tested Item........................................................................................................................................ 4 2.2 Description of Tested Device ............................................................................................................. 4 2.3 Exposure Evaluation .......................................................................................................................... 4 2.4 Test Environment .............................................................................................................................. 5 2.5 Test Period ........................................................................................................................................ 5 2.6 Test Engineer(s) ................................................................................................................................ 5 2.7 Test Equipment ................................................................................................................................. 5 2.8 Other Comments ............................................................................................................................... 5 3 TEST REPORT SUMMARY .............................................................................................................. 6 3.1 General .............................................................................................................................................. 6 3.2 Test Summary ................................................................................................................................... 7 4 TEST RESULTS ................................................................................................................................ 8 4.1 Power Line Conducted Emissions ..................................................................................................... 8 4.2 Coordination with fixed microwave .................................................................................................. 13 4.3 Digital Modulation Techniques ........................................................................................................ 13 4.4 Labeling Requirements ................................................................................................................... 13 4.5 Antenna Requirement...................................................................................................................... 14 4.6 Channel Frequencies ...................................................................................................................... 14 4.7 Peak Power Output ......................................................................................................................... 15 4.8 Spurious Emissions (Radiated) ....................................................................................................... 18 5 TEST SETUPS ................................................................................................................................ 24 5.1 Radiated Emissions Test, Semi-Anechoic Chamber ....................................................................... 24 5.2 Power Line Conducted Emissions Test ........................................................................................... 24 6 TEST EQUIPMENT USED .............................................................................................................. 25 TEST REPORT FCC part 15D Report no.: 174870-2 FCC ID: ACJ96NKX-TG6671 Nemko AS, N-2007 Kjeller Page 3 (25) 1 GENERAL INFORMATION 1.1 Testhouse Info Name : Nemko AS Address : Nemko Kjeller Instituttveien 6 N-2007 Kjeller, NORWAY Telephone : +47 64 84 57 00 Fax : +47 64 84 57 05 E-mail: [email protected] FCC test firm registration # : 994405 IC OATS registration # : 2040D-1 Total Number of Pages: 25 1.2 Client Information Name : Panasonic System Networks Co., Ltd. Address : 1-62, 4-Chome, Minoshima, Hakata-ku, Fukuoka 812-8531 Japan Telephone : +81-92-477-1405 Fax : +81-92-477-1487 Contact: Name : Mr. Junji Sumi Telephone : +81 92 477 1405 E-mail : [email protected] 1.3 Responsible Manufacturer (if other than client) Name : / Address : / TEST REPORT FCC part 15D Report no.: 174870-2 FCC ID: ACJ96NKX-TG6671 Nemko AS, N-2007 Kjeller Page 4 (25) 2 Test Information 2.1 Tested Item Name : Panasonic Model name : KX-TG6671 FCC ID : ACJ96NKX-TG6671 Industry Canada ID : 216A-KX…

Text truncated - open the document above for the full version.

Nemko AS, Gaustadalléen 30, P.O.Box 73 Blindern, NO-0314 Oslo Norway T +47 22 96 03 30 F +47 22 96 05 50 Enterprise number NO974404532 Visiting address: Nemko Kjeller, Instituttveien 6, P.O.Box 96, NO-2027 Kjeller Norway T +47 64 84 57 00 F +47 64 84 57 05 Test report no. : 137945-3 Item tested : KX-TG6531 Type of equipment : UPCS Base FCC ID : ACJ96NKX-TG6531 Client : Panasonic Communications Co., Ltd. FCC Part 15, subpart D Isochronous UPCS Device 1920 - 1930 MHz Industry Canada RSS-213, Issue 2 2 GHz Licence-exempt Personal Communications Service Devices (LE-PCS) 7 December 2009 Authorized by : .............................................. Egil Hauger Technical Verificator TEST REPORT FCC part 15D Report no.: 137945-3 FCC ID: ACJ96NKX-TG6531 Nemko AS, N-2007 Kjeller Page 2 (52) CONTENTS 1 GENERAL INFORMATION ............................................................................................................... 3 1.1 Testhouse Info ................................................................................................................................... 3 1.2 Client Information .............................................................................................................................. 3 1.3 Responsible Manufacturer (if other than client) ................................................................................. 3 2 TEST INFORMATION ....................................................................................................................... 4 2.1 Tested Item........................................................................................................................................ 4 2.2 Test Environment .............................................................................................................................. 5 2.3 Test Period ........................................................................................................................................ 5 2.4 Test Engineer(s) ................................................................................................................................ 5 2.5 Test Equipment ................................................................................................................................. 5 2.6 Other Comments ............................................................................................................................... 5 3 TEST REPORT SUMMARY .............................................................................................................. 6 3.1 General .............................................................................................................................................. 6 3.2 Test Summary ................................................................................................................................... 7 4 TEST RESULTS ................................................................................................................................ 8 4.1 Power Line Conducted Emissions ..................................................................................................... 8 4.2 Coordination with fixed microwave .................................................................................................. 11 4.3 Digital Modulation Techniques ........................................................................................................ 11 4.4 Labeling Requirements ................................................................................................................... 11 4.5 Antenna Requirement...................................................................................................................... 12 4.6 Channel Frequencies ...................................................................................................................... 12 4.7 Automatic Discontinuation of Transmission .................................................................................... 13 4.8 Peak Power Output ......................................................................................................................... 14 4.9 Emission Bandwidth B ..................................................................................................................... 19 4.10 Power Spectral Density ................................................................................................................... 22 4.11 In-Band Unwanted Emissions, Conducted ...................................................................................... 25 4.12 Out-of-band Emissions, Conducted................................................................................................. 27 4.13 Carrier Frequency Stability .............................................................................................................. 32 4.14 Frame Repetition Stability ............................................................................................................... 33 4.15 Frame Period and Jitter ................................................................................................................... 33 4.16 Monitoring Threshold, Least Interfered Channel ............................................................................. 35 4.17 Threshold Monitoring Bandwidth ..................................................................................................... 37 4.18 Reaction Time and Monitoring Interval ............................................................................................ 38 4.19 Time and Spectrum Window Access Procedure ............................................................................. 40 4.20 Acknowledgements and Transmission Duration ............................................................................. 43 4.21 Dual Access Criteria Check ............................................................................................................. 44 4.22 Alternative Moni…

Text truncated - open the document above for the full version.

FCC ID: ACJ96NKX-TG6671 Project no.: 174870 Page 1 of 1 PHOTOS OF TEST SET-UP – Panasonic KX-TG6671 Radiated Emissions Test Power-Line Conducted Emissions Test
