ACJ96NKX-TG9471DECT 6.0 Base

Operating Instructions Digital Corded/Cordless Answering System Model shown is KX-TG9471. Model No. KX-TG9471 KX-TG9472 Before initial use, see “Getting Started” on page 6. Thank you for purchasing a Panasonic product. Please read these operating instructions before using the unit and save them for future reference. This unit is compatible with Caller ID. You must subscribe to the appropriate service offered by your service provider/telephone company. For assistance, visit our Web site: http://www.panasonic.com/help for customers in the U.S.A. or Puerto Rico. Please register your product: http://www.panasonic.com/prodreg Accessory information Expanding your phone system Optional handset feature overview You can expand your phone system by registering optional handsets (6 max.) to a single base unit. ROptional handsets may be a different color from that of the supplied handsets. Introduction Handset (optional): KX-TGA939 Model composition SeriesModel No. Base unitHandset Part No.Part No.Quantity KX-TG9471 seriesKX-TG9471 KX-TG9471KX-TGA9391 KX-TG9472KX-TG9471KX-TGA9392 For your safety To prevent severe injury and loss of life/property, read this section carefully before using the product to ensure proper and safe operation of your product. WARNING Power connection RUse only the power source marked on the product. RDo not overload power outlets and extension cords. This can result in the risk of fire or electric shock. RCompletely insert the AC adaptor/power plug into the power outlet. Failure to do so may cause electric shock and/or excessive heat resulting in a fire. RRegularly remove any dust, etc. from the AC adaptor/ power plug by pulling it from the power outlet, then wiping with a dry cloth. Accumulated dust may cause an insulation defect from moisture, etc. resulting in a fire. RUnplug the product from power outlets if it emits smoke, an abnormal smell, or makes an unusual noise. These conditions can cause fire or electric shock. Confirm that smoke has stopped emitting and contact the Panasonic Call Center at 1-800-211-PANA (1-800-211-7262). RUnplug from power outlets and never touch the inside of the product if its casing has been broken open. RNever touch the plug with wet hands. Danger of electric shock exists. Installation RTo prevent the risk of fire or electrical shock, do not expose the product to rain or any type of moisture. RDo not place or use this product near automatically controlled devices such as automatic doors and fire alarms. Radio waves emitted from this product may cause such devices to malfunction resulting in an accident. RDo not allow the AC adaptor or telephone line cord to be excessively pulled, bent or placed under heavy objects. Operating safeguards RUnplug the product from power outlets before cleaning. Do not use liquid or aerosol cleaners. RDo not disassemble the product. RDo not spill liquids (detergents, cleansers, etc.) onto the telephone line cord plug, or allow it to become wet at all. This may cause a fire. If the telephone line cord plug becomes wet, immediately pull it from the telephone wall jack, and do not use. RDo not excessively pull the corded handset cord from the base unit. This may cause the base unit to fall, resulting in injury. Medical RConsult the manufacturer of any personal medical devices, such as pacemakers or hearing aids, to determine if they are adequately shielded from external RF (radio frequency) energy. (The product operates in the frequency range of 1.92 GHz to 1.93 GHz, and the RF transmission power is 115 mW (max.).) RDo not use the product in health care facilities if any regulations posted in the area instruct you not to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy. CAUTION Installation and location RNever install telephone wiring during an electrical storm. RNever install telephone line jacks in wet locations unless the jack is specifically designed for wet locations. RNever touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. RUse caution when installing or modifying telephone lines. RThe AC adaptor is used as the main disconnect device. Ensure that the AC outlet is installed near the product and is easily accessible. RThis product is unable to make calls when: – the handset batteries need recharging or have failed. – there is a power failure. Battery RWe recommend using the batteries noted on page 4.USE ONLY rechargeable Ni-MH batteries AAA (R03) size. RDo not mix old and new batteries. RDo not open or mutilate the batteries. Released electrolyte from the batteries is corrosive and may cause burns or injury to the eyes or skin. The electrolyte is toxic and may be harmful if swallowed. RExercise care when handling the batteries. Do not allow conductive materials such as rings, bracelets, or keys to touch the batteries, otherwise a short circuit may cause the batteries and/or the conductive material to overheat and cause burns. RCharge the batteries provided with or identified for use with this product only, in accordance with the instructions and limitations specified in this manual. ROnly use a compatible charger to charge the batteries. Do not tamper with the charger. Failure to follow these instructions may cause the batteries to swell or explode. Attention: A nickel metal hydride battery that is recyclable powers the product you have purchased. Please call 1-800-8-BATTERY (1-800-822-8837) for information on how to recycle this battery. For assistance, please visit http://www.panasonic.com/help Important Information Important safety instructions When using your product, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Do not use this product near water for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement or near a swimming pool. 2. Avoid using a tel…

Text truncated - open the document above for the full version.

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] Richard Mullen Group Manager Product Safety and Compliance Division Authority to Act as Agent May 9, 2011 PCTP-11-F010 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Panasonic Corporation of North America hereby authorizes Nemko A/S, Instituttveien 6, N-2007 Kjeller, Norway to act on our behalf in all matters relating to the preparation of TCB Certification application for the below described product, which are in compliance with FCC Part 15D. Any and all acts carried out by Nemko AS on our behalf shall have the same effects as acts of our own for a period of one year from the date of this letter. Type Filing: Original Application for 2 Line DECT Base Model KX-TG9471(xx) Family 1 FCC Classification: Isochronous UPCS Base Station (PUB) Product Name: 1921.536 ~1928.448 MHz DECT Cordless Telephone Base Maximum RF Output 90 mW (conducted peak RF output power) FCC ID Base Unit ACJ96NKX-TG9471 Power Supply: AC Adaptor Model PQLV219(FW) with 37 KHz switching power supply AC Adaptor Model PQLV219(UC) with 36 KHz switching power supply Responsible Panasonic Corporation of North America Applicant & Grantee: One Panasonic Way, Secaucus, NJ 07094 FRN Number: 0003762242 Responsible Manufacturer: Panasonic System Networks Co., Ltd. Sincerely yours, Richard Mullen Richard Mullen Group Manager Panasonic Corporation of North America Product Safety and Compliance Division 1 The subject Base will be: (1) FCC Part 68 certified by Nemko CCL under Certification ID Number US: ACJW410BKX-TG9471; and (2) will be marketed with Handset, which was already FCC Part 15D certified by Nemko CCL under FCC ID: ACJ96NKX-TGA939 Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7758 / Fax: 201-392-4564 [email protected] Richard Mullen Group Manager Product Safety and Compliance Division Request for Confidentiality May 9, 2011 PCTP-11-F010 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Type Filing: Original Application for DECT Base Model KX-TG9471(xx) Family FCC ID Base Unit ACJ96NKX-TG9471 In accordance with provisions of Sections 0.457 and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for exhibits, which contain: (1) Antenna Construction; (2) Description of Electrical Circuitry; (3) Schematic Diagrams of Base Unit and RF Unit; and (4) Block Diagram. The transmitter is not user adjustable and does not have a Tune-Up Procedure. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. In accordance with FCC Public DA 04-1705, we request forty-five day short-term confidentiality, starting from the from the issuance of equipment authorization date, for exhibits, which contain: (1) External Photographs of Base Unit and RF Unit; (2) Internal Photographs of Base Unit and RF Unit; (3) Test Setup Photographs; and (4) User Manual. These exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. Sincerely yours, Richard Mullen Richard Mullen Group Manager Panasonic Corporation of North America Product Safety and Compliance Division

EXTERNAL PHOTOGRAPHS KX-TG9471 Bottom View

EXHIBIT B MARKINGS Base Unit: The base unit provides with the following marking, or equivalent. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone. NOTE: Above markings are shown on bottom of the base unit.

INTERNAL PHOTOGRAPHS Internal View Main Board RF Portion

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antennaValid for frequencies from 30 to 100.000 MHz Maximum peak output power at antenna input terminal: 19.40 (dBm) Maximum peak output power at antenna input terminal: 87.096359 (mW) Antenna gain(typical): 0.30 (dBi) Maximum antenna gain: 1.071519305 (numeric) Prediction distance: 20 (cm) Prediction frequency: 1925 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.00 (mW/cm^2) Power density at prediction frequency: 0.018567 (mW/cm^2) Maximum allowable antenna gain: 17.61 (dBi) Margin of Compliance: 17.31 (dB) 2 4 R PG S π =

Nemko AS, Gaustadalléen 30, P.O.Box 73 Blindern, NO-0314 Oslo Norway T +47 22 96 03 30 F +47 22 96 05 50 Enterprise number NO974404532 Visiting address: Nemko Kjeller, Instituttveien 6, P.O.Box 96, NO-2027 Kjeller Norway T +47 64 84 57 00 F +47 64 84 57 05 Test report no. : 174870-3 Item tested : KX-TG9471 Type of equipment : UPCS Base Station FCC ID : ACJ96NKX-TG9471 Client : Panasonic System Networks Co., Ltd. FCC Part 15, subpart D Isochronous UPCS Device 1920 - 1930 MHz Industry Canada RSS-213, Issue 2 2 GHz Licence-exempt Personal Communications Service Devices (LE-PCS) 5 May 2011 Authorized by : .............................................. G. Suhantakumar Technical Verificator TEST REPORT FCC part 15D Report no.: 174870-3 FCC ID: ACJ96NKX-TG9471 Nemko AS, N-2007 Kjeller Page 2 (24) CONTENTS 1 GENERAL INFORMATION ............................................................................................................... 3 1.1 Testhouse Info ................................................................................................................................... 3 1.2 Client Information .............................................................................................................................. 3 1.3 Responsible Manufacturer (if other than client) ................................................................................. 3 2 TEST INFORMATION ....................................................................................................................... 4 2.1 Tested Item........................................................................................................................................ 4 2.2 Description of Tested Device ............................................................................................................. 4 2.3 Exposure Evaluation .......................................................................................................................... 4 2.4 Test Environment .............................................................................................................................. 5 2.5 Test Period ........................................................................................................................................ 5 2.6 Test Engineer(s) ................................................................................................................................ 5 2.7 Test Equipment ................................................................................................................................. 5 2.8 Other Comments ............................................................................................................................... 5 3 TEST REPORT SUMMARY .............................................................................................................. 6 3.1 General .............................................................................................................................................. 6 3.2 Test Summary ................................................................................................................................... 7 4 TEST RESULTS ................................................................................................................................ 8 4.1 Power Line Conducted Emissions ..................................................................................................... 8 4.2 Coordination with fixed microwave .................................................................................................. 12 4.3 Digital Modulation Techniques ........................................................................................................ 12 4.4 Labeling Requirements ................................................................................................................... 12 4.5 Antenna Requirement...................................................................................................................... 13 4.6 Channel Frequencies ...................................................................................................................... 13 4.7 Peak Power Output ......................................................................................................................... 14 4.8 Spurious Emissions (Radiated) ....................................................................................................... 17 5 TEST SETUPS ................................................................................................................................ 23 5.1 Radiated Emissions Test, Semi-Anechoic Chamber ....................................................................... 23 5.2 Power Line Conducted Emissions Test ........................................................................................... 23 6 TEST EQUIPMENT USED .............................................................................................................. 24 TEST REPORT FCC part 15D Report no.: 174870-3 FCC ID: ACJ96NKX-TG9471 Nemko AS, N-2007 Kjeller Page 3 (24) 1 GENERAL INFORMATION 1.1 Testhouse Info Name : Nemko AS Address : Nemko Kjeller Instituttveien 6 N-2007 Kjeller, NORWAY Telephone : +47 64 84 57 00 Fax : +47 64 84 57 05 E-mail: [email protected] FCC test firm registration # : 994405 IC OATS registration # : 2040D-1 Total Number of Pages: 24 1.2 Client Information Name : Panasonic System Networks Co., Ltd. Address : 1-62, 4-Chome, Minoshima, Hakata-ku, Fukuoka 812-8531 Japan Telephone : +81-92-477-1405 Fax : +81-92-477-1487 Contact: Name : Mr. Junji Sumi Telephone : +81 92 477 1405 E-mail : [email protected] 1.3 Responsible Manufacturer (if other than client) Name : / Address : / TEST REPORT FCC part 15D Report no.: 174870-3 FCC ID: ACJ96NKX-TG9471 Nemko AS, N-2007 Kjeller Page 4 (24) 2 Test Information 2.1 Tested Item Name : Panasonic Model name : KX-TG9471 FCC ID : ACJ96NKX-TG9471 Industry Canada ID : 216A-KX…

Text truncated - open the document above for the full version.

Nemko AS, Gaustadalléen 30, P.O.Box 73 Blindern, NO-0314 Oslo Norway T +47 22 96 03 30 F +47 22 96 05 50 Enterprise number NO974404532 Visiting address: Nemko Comlab, Gåsevikveien 8, P.O.Box 96, NO-2027 Kjeller Norway T +47 64 84 57 00 F +47 64 84 57 05 Test report no. : 106355-6 Item tested : KX-TG9391 Type of equipment : UPCS Base FCC ID : ACJ96NKX-TG9391 Client : Panasonic Communications Co., Ltd. FCC Part 15, subpart D Isochronous UPCS Device 1920 - 1930 MHz Industry Canada RSS-213, Issue 2 2 GHz Licence-exempt Personal Communications Service Devices (LE-PCS) 17 June 2008 Authorized by : .......................... .................... Egil Hauger Technical Verificator TEST REPORT FCC part 15D Project no.: 106355-6 FCC ID: ACJ96NKX-TG9391 Nemko AS, N-2007 Kjeller Page 2 (59) CONTENTS 1 GENERAL INFORMATION ............................................................................................................... 3 1.1 Testhouse Info................................................................................................................................... 3 1.2 Client Information .............................................................................................................................. 3 1.3 Manufacturer (if other than client)...................................................................................................... 3 2 TEST INFORMATION ....................................................................................................................... 4 2.1 Tested Item........................................................................................................................................ 4 2.2 Test Environment .............................................................................................................................. 5 2.3 Test Period ........................................................................................................................................ 5 2.4 Test Engineer(s) ................................................................................................................................ 5 2.5 Test Equipment ................................................................................................................................. 5 2.6 Other Comments ............................................................................................................................... 5 3 TEST REPORT SUMMARY .............................................................................................................. 6 3.1 General.............................................................................................................................................. 6 3.2 Test Summary ................................................................................................................................... 7 4 TEST RESULTS................................................................................................................................ 8 4.1 Power Line Conducted Emissions..................................................................................................... 8 4.2 Coordination with fixed microwave .................................................................................................. 17 4.3 Digital Modulation Techniques ........................................................................................................ 17 4.4 Labeling Requirements ................................................................................................................... 17 4.5 Antenna Requirement...................................................................................................................... 18 4.6 Channel Frequencies ...................................................................................................................... 18 4.7 Automatic Discontinuation of Transmission .................................................................................... 19 4.8 Peak Power Output ......................................................................................................................... 20 4.9 Emission Bandwidth B..................................................................................................................... 25 4.10 Power Spectral Density ................................................................................................................... 28 4.11 In-Band Unwanted Emissions, Conducted ...................................................................................... 31 4.12 Out-of-band Emissions, Conducted................................................................................................. 33 4.13 Carrier Frequency Stability .............................................................................................................. 38 4.14 Frame Repetition Stability ............................................................................................................... 39 4.15 Frame Period and Jitter ................................................................................................................... 39 4.16 Monitoring Threshold, Least Interfered Channel ............................................................................. 42 4.17 Threshold Monitoring Bandwidth ..................................................................................................... 44 4.18 Reaction Time and Monitoring Interval ............................................................................................ 45 4.19 Time and Spectrum Window Access Procedure ............................................................................. 47 4.20 Acknowledgements and Transmission Duration ............................................................................. 50 4.21 Dual Access Criteria Check............................................................................................................. 51 4.22 Alternative Monito…

Text truncated - open the document above for the full version.

FCC ID: ACJ96NKX-TG9471 Project no.: 174870 Page 1 of 1 PHOTOS OF TEST SET-UP – Panasonic KX-TG9471 Radiated Emissions Test Power-Line Conducted Emissions Test
