ACJ96NKX-TGCA20AUPCS Cordless Handset

Operating Instructions Digital Cordless Phone Model No. KX-TGC210 KX-TGC212 KX-TGC213 Digital Cordless Answering System Model No. KX-TGC220 KX-TGC222 RModel shown is KX-TGC210. Before initial use, see “Getting Started” on page 9. Thank you for purchasing a Panasonic product. Please read these operating instructions before using the unit and save them for future reference. Consulte “Guía Rápida Española”, página 45. For assistance, visit our Web site: http://shop.panasonic.com/support for customers in the U.S.A. Please register your product: http://shop.panasonic.com/support TGC2xxUS(en)_0223_ver301.pdf 12017/02/23 17:34:02 Introduction Model composition .......................................3 Accessory information ..................................3 Important Information For your safety .............................................5 Important safety instructions ........................6 For best performance ...................................6 Other information .........................................7 Specifications ...............................................8 Getting Started Setting up .....................................................9 Controls ......................................................11 Display icons ..............................................12 Language settings ......................................12 Date and time .............................................13 Recording your greeting message .............13 Other settings .............................................13 Making/Answering Calls Making calls ...............................................14 Answering calls ..........................................14 Useful features during a call .......................15 Intercom .....................................................16 Phonebook Phonebook .................................................17 Speed dial ..................................................19 Programming Menu list .....................................................20 Alarm ..........................................................24 Silent mode ................................................24 Call block ....................................................25 Other programming ....................................26 Registering a unit .......................................26 Caller ID Service Using Caller ID service ...............................27 Caller list ....................................................27 Answering System Answering system ......................................29 Turning the answering system on/off .........29 Greeting message ......................................29 Listening to messages ...............................30 Remote operation .......................................31 Answering system settings .........................32 Useful Information Voice mail service ......................................34 Wall mounting (Charger only) ....................35 Error messages ..........................................36 Troubleshooting .........................................37 FCC and other information .........................42 Guía Rápida Española Guía Rápida Española ...............................45 Appendix Customer services .....................................49 Limited Warranty (ONLY FOR U.S.A.) .......50 Index Index...........................................................52 2 Table of Contents TGC2xxUS(en)_0223_ver301.pdf 22017/02/23 17:34:02 Model composition nK X-TGC210 seriesnK X-TGC220 series RM odel shown is KX-TGC212.RM odel shown is KX-TGC222. SeriesModel No. Base unitHandset Part No.Part No.Quantity KX-TGC210 s eries KX-TGC210KX-TGC210KX-TGCA201 KX-TGC212KX-TGC210KX-TGCA202 KX-TGC213KX-TGC210KX-TGCA203 KX-TGC220 s eries KX-TGC220KX-TGC220KX-TGCA201 KX-TGC222KX-TGC220KX-TGCA202 Accessory information Supplied accessories No.Accessory item/Order number Quantity KX-TGC210 K X-TGC220 KX-TGC212 K X-TGC222 KX-TGC213 AAC adaptor/PNLV226-0X111 BTelephone line cord P QJA10075Y (Black) or PQJA10075Z (Transparence) 111 CRechargeable batteries/HHR-4DPA246 D Handset cover * 1 /PNYNTGCA20SR 123 E Charger * 2 –12 *1 The handset cover comes attached to the handset. * 2 PNLC1055ZS (Silver), PNLC1055ZW (White) For assistance, please visit http://shop.panasonic.com/support 3 Introduction TGC2xxUS(en)_0223_ver301.pdf 32017/02/23 17:34:02 ABCDE Additional/replacement accessories P lease contact your nearest Panasonic dealer for sales information (page 49). Accessory itemOrder number Rechargeable batteries HHR-4DPA * 1 RTo order, please visit http://shop.panasonic.com/support Battery type: – Nickel metal hydride (Ni-MH) – 2 x AAA (R03) size for each handset T-adaptorKX-J66 Range extender KX-TGA405 * 2 *1 Replacement batteries may have a different capacity from that of the supplied batteries. *2 By installing this unit, you can extend the range of your phone system to include areas where reception was previously not available. This product can be purchased online. Please visit our Web site: http://shop.panasonic.com/support Other information RD esign and specifications are subject to change without notice. RThe illustrations in these instructions may vary slightly from the actual product. Expanding your phone system Handset (optional): KX-TGDA20 You can expand your phone system by r egistering optional handsets (6 max.) to a single base unit. ROptional handset is a different design from that of the supplied handsets. RYou cannot purchase the supplied handset (KX-TGCA20) separately. 4 For assistance, please visit http://shop.panasonic.com/support Introduction TGC2xxUS(en)_0223_ver301.pdf 42017/02/23 17:34:02 For your safety T o prevent severe injury and loss of life/ property, read this section carefully before using the product to ensure proper and safe operation of your product. WARNING Power connection RU se only the power source marked on the product. RDo not overload power outlets and extension cords. This can result in the risk of fire or electric sho…

Text truncated - open the document above for the full version.

EXTERNAL PHOTOGRAPHS KX-TGCA20 Top View Bottom View

INTERNAL PHOTOGRAPHS Internal View KX-TGCA20 Internal View 2

Report No. 455247-02-R00 Template version: C Nemko Group Nemko Scandinavia AS, Instituttveien 6, P.O. Box 96, 2027 Kjeller, Norway TEL +47 22 96 03 30 EMAIL [email protected] nemko.com/no Test Report Product DECT Handset Name and address of the applicant Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor Newark, 07102-5490, NJ, USA Name and address of the manufacturer Panasonic Corporation 1-62, 4-chome, Minoshima, Hakata-ku Fukuoka, 812-8531, Japan Model KX-TGCA20 / KX-TGCA21 / KX-TGCA22 / KX-TGCA20AC / KX-TGBA31AC Rating 2.4V DC (2x AAA NiMH cells) Trademark Panasonic Serial number See clause 1.1 Additional information DECT 6.0 Tested according to FCC Part 15, subpart B Other Class B Digital Device Industry Canada ICES-003, Issue 7 Information Technology Equipment (ITE) Order number 455247 Tested in period 2022-01-21 to 2022-01-26 Issue date 2022-02-04 Name and address of the testing laboratory Instituttveien 6 Kjeller, Norway www.nemko.com CAB Number: FCC: NO0001 ISED: NO0470 An accredited technical test executed under the Norwegian accreditation scheme Prepared by [Frode Sveinsen] Approved by [G.Suhanthakumar] This report shall not be reproduced except in full without the written approval of Nemko. Opinions and interpretations expressed within this report are not part of the current accreditation. This report was originally distributed electronically with digital signatures. For more information contact Nemko. TEST REPORT FCC Part 15B Report no.: 455247-02-R00 FCC ID: ACJ96NKX-TGCA20A Nemko Norway, Instituttveien 6, Kjeller, Norway Page 2 (12) CONTENTS 1 INFORMATION ................................................................................................................................. 3 1.1 Tested Item ........................................................................................................................................................ 3 1.2 Test Environment ............................................................................................................................................... 3 1.3 Test Engineer(s) ................................................................................................................................................. 3 1.4 Test Equipment .................................................................................................................................................. 3 1.5 Test Configurations ............................................................................................................................................ 3 1.6 Other Comments ................................................................................................................................................ 3 2 TEST REPORT SUMMARY .............................................................................................................. 4 2.1 General .............................................................................................................................................................. 4 2.2 Test Summary .................................................................................................................................................... 5 3 TEST RESULTS ................................................................................................................................ 6 3.1 Power Line Conducted Emissions ...................................................................................................................... 6 3.2 Spurious Emissions (Radiated) ........................................................................................................................... 8 4 MEASUREMENT UNCERTAINTY .................................................................................................. 10 5 TEST SETUPS ................................................................................................................................ 11 5.1 Radiated Emissions Test .................................................................................................................................. 11 5.2 Power Line Conducted Emissions Test ............................................................................................................. 11 6 TEST EQUIPMENT USED .............................................................................................................. 12 TEST REPORT FCC Part 15B Report no.: 455247-02-R00 FCC ID: ACJ96NKX-TGCA20A Nemko Norway, Instituttveien 6, Kjeller, Norway Page 3 (12) 1 INFORMATION 1.1 Tested Item Name Panasonic Model name KX-TGCA20 KX-TGCA21 KX-TGCA22 KX-TGCA20AC KX-TGBA31AC FCC ID ACJ96NKX-TGCA20A FCC / IC Class B Serial number Sample with 50 Ohm connectors: 4552470003 Sample with Integral Antennas: 4552470001 Hardware identity and/or version S1 Software identity and/or version SW400 Desktop Charger PNLC1055 with AC Adaptors PNLV233 (UC), PNLV233 (ZC) Power Supply Secondary Batteries (2x AAA cells, 1.2V, 400mAh) Description of Tested Device(s) The tested equipment is a DECT Handset with Desktop Charger. 1.2 Test Environment Temperature: 20 – 23 ° C Relative humidity: 30 – 50 % Normal test voltage: 2.4 V DC (Nominal Voltage) The values are the limit registered during the test period. 1.3 Test Engineer(s) Frode Sveinsen / Tore Løvlien 1.4 Test Equipment See list of test equipment in clause 6. 1.5 Test Configurations Test Configuration EUT Standby in charger and charging. 1.6 Other Comments All tests were performed with the EUT in charger and charging. TEST REPORT FCC Part 15B Report no.: 455247-02-R00 FCC ID: ACJ96NKX-TGCA20A Nemko Norway, Instituttveien 6, Kjeller, Norway Page 4 (12) 2 TEST REPORT SUMMARY 2.1 General All measurements are traceable to national standards. All tests were performed is accordance with ANSI C63.4-2014 where applicable. Radiated emissions are made in a 10m semi-anechoic chamber. A description of the test facility is on file with FCC and Industry Canada. THIS …

Text truncated - open the document above for the full version.

TEST SET-UP PHOTOS Project no.: 452212 FCC ID: ACJ96NKX-TGCA20A Page 1 (1) Radiated Emissions 30 – 1000 MHz, Charging Power-Line Conducted Emissions
