EQUIPMENT DESCRIPTION DESCRIPTION OF DIFFERENCES (1.9GHz Cordless Telephone, KX-TGD5 Series and KX-TGD8 Series) KX-TGD5xx (Updated) KX-TGD8xx (New) Model KX-TGD560, KX-TGD530 KX-TGD590C, KX-TGD580C KX-TGD860, KX-TGD830 KX-TGD870C,KX-TGD850C Declaration of FCC ID ACJ96NKX-TGD560A ACJ96NKX-TGD530A ACJ96NKX-TGD860 ACJ96NKX-TGD830 Declaration of IC ID IC:216A-KXTGD590A IC:216A-KXTGD580A IC:216A-KXTGD870 IC:216A-KXTGD850 Appearance P.C. Board Same (P.C. Board number :PNLB2909) Bluetooth Part / module Same DECT part Same AC Adaptor Same Appearance is identical between KX-TGD5xx Model and KX- TGD8xx Model, the differences only; -“CALL BLOCK” key - Color

EQUIPMENT DESCRIPTION DESCRIPTION OF DIFFERENCES (1.9GHz Cordless Telephone, KX-TGD5 Series and KX-TGD8 Series) Series KX-TGD5xx (Original) KX-TGD5xx (Updated) KX-TGD8xx (New) Model number (USA/Canada) KX-TGD560 / KX-TGD590C (With BT) KX-TGD560 / KX-TGD590yy (With BT) *yy: blank ,digit 0-9 or letter A-Z represents country designation KX-TGD860 / KX-TGD870C (With BT) KX-TGD530 / KX-TGD580C (no BT) KX-TGD530 / KX-TGD580yy (no BT) *yy: blank ,digit 0-9 or letter A-Z represents country designation KX-TGD830 / KX-TGD850C (no BT) Appearance Appearance is identical between KX-TGD5xx Model and KX-TGD8xx Model, the differences only; -“CALL BLOCK” key - Color Declaration of FCC ID (USA) ACJ96NKX-TGD560 ACJ96NKX-TGD530 ACJ96NKX-TGD560A ACJ96NKX-TGD530A ACJ96NKX-TGD860 ACJ96NKX-TGD830 Declaration of IC ID(Canada) IC:216A-KXTGD590 IC:216A-KXTGD580 IC:216A-KXTGD590A IC:216A-KXTGD580A IC:216A-KXTGD870 IC:216A-KXTGD850 P.C. Board PNLB2666 PNLB2909 Bluetooth Part / module Original New (Identical) DECT part Identical AC Adaptor PNLV226

Two Riverfront Plaza | Newark, NJ 07102-5490 Ben Botros, Project Manager Safety , Compliance and Quality Assurance Authorization Letter December 14, 2020 PCTP-20-F006 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Panasonic Corporation of North America hereby authorizes Nemko AS to act on our behalf in all matters relating to the preparation of TCB Certification application for the below described product. Any and all acts carried out by Nemko AS on our behalf shall have the same effects as acts of our own for a period of six months from the date of this letter. Type Filing: Original Application for UPCS Cordless Telephone Base Station 1 FCC ID: ACJ96NKX-TGD530A Model Numbers: KX-TGD530(xx) FCC Classification: Isochronous UPCS Base Station (PUB) FCC Rule Part: FCC Part 15, Subpart D Frequency Range: 1921.536 ~ 1928.448 Number Channels: 5 RF Channels / 5x12 = 60 TDMA Duplex Channels RF Exposure: Mobile / MPE (requires minimum 20cm spacing between antenna and body) FCC Rule Part: FCC Part 15, Subpart B FCC Classification: Class B Digital Device (JAB) Responsible Panasonic Corporation of North America Applicant & Grantee: Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Sincerely yours, Ben Botros Project Manager Panasonic Corporation of North America Safety, Compliance and Quality Assurance

FCC Part 15D – Compliance Information kx-tgd530 fcc_part_15d-compliance_information.doc8-Dec-2006 page 1 (4) rev.1.4 EUT AND PRODUCT INFORMATION Type of Equipment UPCS Applicant Name Panasonic Corporation of North America Responsible Mfr Name Panasonic Co., Ltd. Smart Communication Business Unit Address 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Contact Kazunori Ata FP PP EUT Type/System FCC ID ACJ96NKX-TGD530A Model name KX-TGD530 HW Version PNLB2909 SW Version SW200 Max antenna Gain (dBi) 0dBi Can the EUT be Initiating Device YES YES Does the EUT transmit signaling channels YES YES Max number of slots in use simultaneously 1 slot Test standard: FCC part 15D Other: Industry Canada RSS-213, Issue 2 Frequency Band 1921.536 – 1928.448 MHz # of RF Channels 5 Frame Period 10 ms Max. Burst length 417us / duplex channel Min. Burst Length 106us / signaling channel # of Logical Channels 60 (12 duplex channels per RF carrier) Operating Mode Simplex Duplex FCC Part 15D – Compliance Information kx-tgd530 fcc_part_15d-compliance_information.doc8-Dec-2006 page 2 (4) rev.1.4 ANTENNAS Base (FP) Antenna Type Internal External 1 Wired Antenna 2 Wired Antenna 3 4 Does RX and TX use the same antenna(s)? Yes No Handset (PP) Antenna Type Internal External Does RX and TX use the same antenna(s)? Yes No ANTENNA DIVERSITY Antenna Diversity Supported TX RX Base (FP) and Repeater 1 2 3 4 Handset (PP) 1 2 VOLTAGE AND TEMPERATURE RANGES VOLTAGES FP Nominal Voltage 120V AC Cut-Off Voltage (if applicable) - - - POWER SOURCE Type Manufacturer Base or Repeater PNLV226 (AC Adaptor) Panasonic Handset (PP) (charger) Data Connections PSTN (Base) Others (please specify) .... FCC Part 15D – Compliance Information kx-tgd530 fcc_part_15d-compliance_information.doc8-Dec-2006 page 3 (4) rev.1.4 ANCILLARY EQUIPMENT Description AC Adaptor Type PNLV226 (AC Adaptor) Manufacturer Panasonic HOST DEVICE Description Type Manufacturer ADDITIONAL INFORMATION FCC Part 15D – Compliance Information kx-tgd530 fcc_part_15d-compliance_information.doc8-Dec-2006 page 4 (4) rev.1.4 MANUFACTURERS DECLARATIONS FCC part 15.323 (c)(5) No device or group of co-operating devices located within 1m of each other shall during any frame period occupy more than 6 MHz of aggregate bandwidth, or alternatively, more than one third of the time and spectrum windows defined by the system. Applicant Agrees Yes No FCC part 15.323 (c)(10) The applicant hereby declares that the system in this application does use the criteria of (c)(10) of this section. Applicant Agrees Yes No FCC part 15.323 (c)(11) The applicant hereby declares that system in this application does not use the criteria of (c)(11) of this section. Applicant Agrees Yes No FCC part 15.323 (c)(12) The provisions of (c)(10) or (c)(11) of this section shall not be used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. Applicant Agrees Yes No FCC part 15.307 (b) The Applicant is a participating member of UTAM, Inc. and will provide an affidavit from UTAM, Inc. certifying this. Confirmed By Applicant Yes No ADDITIONAL REMARKS: > DECLARED BY: December 14, 2020 Ben Botros

Two Riverfront Plaza | Newark, NJ 07102-5490 Ben Botros, Project Manager Safety , Compliance and Quality Assurance Request for Confidentiality December 14, 2020 PCTP-20-F006 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Panasonic Corporation of North America hereby authorizes Nemko AS to act on our behalf in all matters relating to the preparation of TCB Certification application for the below described product. Any and all acts carried out by Nemko AS on our behalf shall have the same effects as acts of our own for a period of six months from the date of this letter. Type Filing: Original Application for UPCS Cordless Telephone Base Station 2 FCC ID: ACJ96NKX-TGD530A FCC Rule Part: FCC Part 15, Subpart B (JAB), and D (UPCS) Request For Permanent Confidentiality In accordance with provisions of Sections §§0.457(d) and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for exhibits, which contain: (1) Description of Electrical Circuitry; (2) Schematic Diagrams of Base Unit and RF Unit; and (3) Base Unit Block Diagram. The transmitter is not user adjus table and does not have a Tune-Up Procedure. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. Request For Short-Term Confidentiality In accordance with FCC Public DA 04-1705, we request 180 day short-term confidentiality, starting from the from the issuance of equipment authorization date, for exhibits, which contain: (1) External Photographs of Base Unit and RF Unit; (2) Internal Photographs of Base Unit and RF Unit; (3) Test Setup Photographs; and (4) User Manual. These exhibits contain pre-ma rket information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. Sincerely yours, Ben Botros Project Manager Panasonic Corporation of North America Product Safety and Compliance Department

EXTERNAL PHOTOGRAPHS KX-TGD530 Top View Bottom View

EXHIBIT B MARKINGS Base Unit: The base unit provides with the following marking, or equivalent. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone. NOTE: Above markings are shown on bottom of the base unit.

INTERNAL PHOTOGRAPHS Internal View Main Board

FCC ID: ACJ96NKX-TGD530A MPE Calculation for FCC Uncontrolled Environment Formula from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Source Based Time Averaged Duty Cycle is 100% in calculation below Maximum peak output power at antenna input terminal:18.20(dBm) Maximum peak output power at antenna input terminal:0.066(W) Maximum antenna gain:0.00(dBi) Maximum antenna gain:1.000(numeric) Prediction distance:20(cm) Prediction frequency:1925(MHz) Time Averaged Duty Cycle100% MPE limit for uncontrolled exposure at prediction frequency:10.00(W/m^2) Power density at prediction frequency:0.0131(mW/cm^2) Power density at prediction frequency:0.131(W/m^2) Maximum allowable antenna gain:18.81(dBi) Margin of Compliance:18.81(dB) 2 4 R PG S p =

Report No. 318949-02-R02 Template version: D Nemko Norway Nemko AS, Instituttveien 6, P.O. Box 96 Kjeller, 2007 Kjeller, Norway TEL +47 22 96 03 30 FAX +47 22 96 05 50 EMAIL [email protected] ENTERPRISE NUMBER NO974404532 nemko.com/no Test Report Product DECT Base Station with Bluetooth Name and address of the applicant Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor Newark, 07102-5490, NJ, USA Name and address of the manufacturer Panasonic Corporation 1-62, 4-chome, Minoshima, Hakata-ku Fukuoka 812-8531, Japan Model KX-TGD560 KX-TGD590C Rating 5.5V DC (AC Adaptor, 1.5A; 100-240 V AC, 50/60 Hz, 1.2-0.6 A) Trademark Panasonic Serial number / Additional information DECT 6.0, Bluetooth Tested according to FCC Part 15, subpart D Isochronous UPCS Device, 1920 – 1930 MHz Industry Canada RSS 213, Issue 3 2 GHz License-Exempt Personal Communications Services (LE-PCS) Devices Order number 318949 Tested in period 2016-10-25 to 2016-11-01 Issue date 2020-11-17 Name and address of the testing laboratory Instituttveien 6 Kjeller, Norway CAB Number: FCC: NO0001 ISED: NO0470 TEL: +47 22 96 03 30 FAX: +47 22 96 05 50 Prepared by [Frode Sveinsen] Approved by [G.Suhanthakumar] This report shall not be reproduced except in full without the written approval of Nemko. Opinions and interpretations expressed within this report are not part of the current accreditation. This report was originally distributed electronically with digital signatures. For more information please contact Nemko. TEST REPORT FCC part 15D Report no.: 318949-02-R02 FCC ID: ACJ96NKX-TGD560 Nemko Norway, Instituttveien 6, Kjeller, Norway Page 2 (44) CONTENTS 1 INFORMATION ................................................................................................................................. 3 1.1 Tested Item ........................................................................................................................................ 3 1.2 Description of Tested Device ............................................................................................................. 3 1.3 Test Environment ............................................................................................................................... 4 1.4 Test Engineer(s) ................................................................................................................................ 4 1.5 Other Comments ............................................................................................................................... 4 2 TEST REPORT SUMMARY .............................................................................................................. 5 2.1 General .............................................................................................................................................. 5 2.2 Test Summary ................................................................................................................................... 6 3 TEST RESULTS ................................................................................................................................ 7 3.1 Power Line Conducted Emissions ..................................................................................................... 7 3.2 Digital Modulation Techniques ........................................................................................................... 9 3.3 Labeling Requirements ...................................................................................................................... 9 3.4 Channel Frequencies ......................................................................................................................... 9 3.5 Antenna Requirement ...................................................................................................................... 10 3.6 Automatic Discontinuation of Transmission ..................................................................................... 10 3.7 Peak Power Output .......................................................................................................................... 11 3.8 Emission Bandwidth B ..................................................................................................................... 14 3.9 Power Spectral Density ................................................................................................................... 17 3.10 In-Band Unwanted Emissions, Conducted ...................................................................................... 20 3.11 Out-of-band Emissions, Conducted ................................................................................................. 22 3.12 Carrier Frequency Stability .............................................................................................................. 27 3.13 Frame Repetition Stability ................................................................................................................ 28 3.14 Frame Period and Jitter ................................................................................................................... 28 3.15 Monitoring Threshold, Least Interfered Channel .............................................................................. 30 3.16 Threshold Monitoring Bandwidth ..................................................................................................... 32 3.17 Reaction Time and Monitoring Interval ............................................................................................ 33 3.18 Time and Spectrum Window Access Procedure .............................................................................. 35 3.19 Acknowledgements and Transmission Duration .............................................................................. 38 3.20 Dual Access Criteria Check ............................................................................................................. 39 3.21 Alternative Monitori…

Text truncated - open the document above for the full version.

Report No. 408178-09-R00 Template version: D Nemko Norway Nemko AS, Instituttveien 6, P.O. Box 96 Kjeller, 2007 Kjeller, Norway TEL +47 22 96 03 30 FAX +47 22 96 05 50 EMAIL [email protected] ENTERPRISE NUMBER NO974404532 nemko.com/no Test Report Product DECT Base Station Name and address of the applicant Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor Newark, 07102-5490, NJ, USA Name and address of the manufacturer Panasonic Corporation 1-62, 4-chome, Minoshima, Hakata-ku Fukuoka, 812-8531, Japan Model KX-TGD530 KX-TGD580AC Rating 120V 60Hz (Input: 120V ~60Hz 0.1A; Output: 5.5V 0.5A, 2.75W) Trademark Panasonic Serial number See page 3 Additional information DECT 6.0 Tested according to Parts of FCC Part 15, subpart D Isochronous UPCS Device, 1920 – 1930 MHz Parts of Industry Canada RSS 213, Issue 3 2 GHz License-Exempt Personal Communications Services (LE-PCS) Devices Order number 408178 Tested in period 2020-10-15 to 2020-10-28 Issue date 2020-12-14 Name and address of the testing laboratory Instituttveien 6 Kjeller, Norway www.nemko.com CAB Number: FCC: NO0001 ISED: NO0470 TEL: +47 22 96 03 30 FAX: +47 22 96 05 50 An accredited technical test executed under the Norwegian accreditation scheme Prepared by [Frode Sveinsen] Approved by [G.Suhanthakumar] This report shall not be reproduced except in full without the written approval of Nemko. Opinions and interpretations expressed within this report are not part of the current accreditation. This report was originally distributed electronically with digital signatures. For more information please contact Nemko. TEST REPORT FCC part 15D Report no.: 408178-09-R00 FCC ID: ACJ96NKX-TGD530A IC: 216A-KXTGD580A Nemko Norway, Instituttveien 6, Kjeller, Norway Page 2 (24) CONTENTS 1 INFORMATION ................................................................................................................................. 3 1.1 Tested Item ........................................................................................................................................ 3 1.2 Description of Tested Device ............................................................................................................. 3 1.3 Normal Test Conditions ..................................................................................................................... 4 1.4 Test Engineer(s) ................................................................................................................................ 4 1.5 Digital Modulation Techniques ........................................................................................................... 4 1.6 Labeling Requirements ...................................................................................................................... 4 1.7 Antenna Requirement ........................................................................................................................ 4 1.8 Channel Frequencies ......................................................................................................................... 5 1.9 Other Comments ............................................................................................................................... 5 2 TEST REPORT SUMMARY .............................................................................................................. 6 2.1 General .............................................................................................................................................. 6 2.2 Test Summary ................................................................................................................................... 7 3 TEST RESULTS ................................................................................................................................ 8 3.1 Power Line Conducted Emissions ..................................................................................................... 8 3.2 Automatic Discontinuation of Transmission ..................................................................................... 10 3.3 Peak Power Output .......................................................................................................................... 11 3.4 Emission Bandwidth B ..................................................................................................................... 13 3.5 Power Spectral Density ................................................................................................................... 15 3.6 In-Band Unwanted Emissions, Conducted ...................................................................................... 17 3.7 Out-of-band Emissions, Conducted ................................................................................................. 19 4 MEASUREMENT UNCERTAINTY .................................................................................................. 22 5 TEST SETUPS ................................................................................................................................ 23 5.1 Conducted Emission Test ................................................................................................................ 23 5.2 Power Line Conducted Emissions Test ........................................................................................... 23 6 TEST EQUIPMENT USED .............................................................................................................. 24 TEST REPORT FCC part 15D Report no.: 408178-09-R00 FCC ID: ACJ96NKX-TGD530A IC: 216A-KXTGD580A Nemko Norway, Instituttveien 6, Kjeller, Norway Page 3 (24) 1 INFORMATION 1.1 Tested Item Name Panasonic Model name KX-TGD530 (US Models) KX-TGD580AC (Canadian Models) FCC ID ACJ96NKX-TGD530A ISED ID 216A-KXTGD580A Serial number Conducted Sample: 1081780001 Radiated Sample: 4081780002 Hardware identity and/or version PNLB2909 Software identity and/or version SW200 Frequency Range 1921.536 …

Text truncated - open the document above for the full version.

TEST SET-UP PHOTOS KX-TGD530A/KX-TGD580AC Project no.: 408178 FCC ID: ACJ96NKX-TGD530A IC: 216A-KXTGD580A Page 1 (1) Radiated Emissions 30 – 1000 MHz Radiated Emissions 1 – 18 GHz Power-Line Conducted Emissions
