ACJ96NKX-TGEA20ADECT 6.0 Handset

Installation Manual Additional Digital Cordless Handset Model No. KX-TGEA20 KX-TGHA20 KX-TGEA20KX-TGHA20 Thank you for purchasing a Panasonic product. This unit is an additional handset compatible with the following series of Panasonic Digital Cordless Phone: - KX-TGE210/KX-TGE230/KX-TGE240/KX-TGE260/KX-TGE270 (KX-TGEA20) - KX-TGH260 (KX-TGHA20) (The corresponding models are subject to change without notice.) You must register this handset with your base unit before it can be used. This installation manual describes only the steps needed to register and begin using the handset. Please read the base unit’s operating instructions for further details. Please read this installation manual before using the unit and save it for future reference. For assistance, visit our Web site: http://www.panasonic.com/help for customers in the U.S.A. or Puerto Rico. Printed in Malaysia PNQX6369ZA PT1213MG0 TGEA_TGHA20(en)_1004_ver001.pdf 12013/10/04 18:56:56 Accessory information Supplied accessories Accessory item/Order numberQuantity Charger *1 1 AC adaptor/PNLV233Z1 Rechargeable batteries/HHR-4DPA2 Handset cover *2, *3 1 Belt clip (KX-TGEA20) *4 1 *1 KX-TGEA20: PNLC1050ZB KX-TGHA20: PNLC1051ZB *2 The handset cover comes attached to the handset. *3 KX-TGEA20: PNYNTGEA20BR (Black), PNYNTGEA20SR (Silver) KX-TGHA20: PNYNTGHA20BR *4 PNKE1312Z2 (Black), PNKE1312Z1 (Silver) Note: RPlease read the base unit’s operating instructions for additional/replacement accessories. – Optional headsets (KX-TGEA20): KX-TCA60, KX-TCA93, KX-TCA400, KX-TCA430 Setting up Connections/Wall mounting Connect the AC adaptor to the power outlet. Drive the screws () (not supplied) into the wall, if necessary. ( ) 27.2 mm (1 1 /16 inches) 1 2 1 2 For assistance, please visit http://www.panasonic.com/help Installation TGEA_TGHA20(en)_1004_ver001.pdf 22013/10/04 18:56:56 Note: RUse only the supplied Panasonic AC adaptor PNLV233. RThe AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) RMake sure that the wall and the fixing method are strong enough to support the weight of the unit. Battery installation/Battery charging Important: RUse the supplied rechargeable batteries. For replacement, we recommend using the Panasonic rechargeable batteries noted on page 2. RUSE ONLY rechargeable Ni-MH batteries AAA (R03) size ( 1 ). RDo NOT use Alkaline/Manganese/Ni-Cd batteries. RConfirm correct polarities ( , ). Charge for about 7 hours. RConfirm “Charging” is displayed ( 2 ). RWhen the batteries are fully charged, “Fully charged” is displayed. 1 2 RModel shown is KX-TGEA20. Note: RIf the batteries are fully charged, but the operating time seems to be shorter, clean the battery ends ( , ) and the charge contacts with a dry cloth and charge again. Registering a handset to a base unit 1Base unit: Press and hold MLOCATORN or MHANDSET LOCATORN for about 5 seconds. RDepending on the base unit, a registration tone sounds. For assistance, please visit http://www.panasonic.com/help 3 Installation TGEA_TGHA20(en)_1004_ver001.pdf 32013/10/04 18:56:56 RIf all registered handsets start ringing, press MLOCATORN or MHANDSET LOCATORN again to stop, then repeat this step. 2Handset: Place the handset on the base unit or charger, then wait until a long beep sounds and is displayed. Note: RIf an error tone sounds, or if is displayed, register the handset according to the base unit’s operating instructions. Display language 1MMENUN (right soft key) #110 2MbN: Select the desired setting. a MSAVEN a MOFFN For your safety To prevent severe injury and loss of life/property, read this section carefully before using the product to ensure proper and safe operation of your product. WARNING Power connection RCompletely insert the AC adaptor/power plug into the power outlet. Failure to do so may cause electric shock and/or excessive heat resulting in a fire. RRegularly remove any dust, etc. from the AC adaptor/power plug by pulling it from the power outlet, then wiping with a dry cloth. Accumulated dust may cause an insulation defect from moisture, etc. resulting in a fire. RUnplug the product from power outlets if it emits smoke, an abnormal smell, or makes an unusual noise. These conditions can cause fire or electric shock. Confirm that smoke has stopped emitting and contact the Panasonic Call Center at 1-800-211- PANA (1-800-211-7262). Installation RTo prevent the risk of fire or electrical shock, do not expose the product to rain or any type of moisture. RDo not place or use this product near automatically controlled devices such as automatic doors and fire alarms. Radio waves emitted from this product may cause such devices to malfunction resulting in an accident. 4 For assistance, please visit http://www.panasonic.com/help Installation TGEA_TGHA20(en)_1004_ver001.pdf 42013/10/04 18:56:56 CAUTION Installation and location RThe AC adaptor is used as the main disconnect device. Ensure that the AC outlet is installed near the product and is easily accessible. Battery RWe recommend using the supplied batteries or additional/replacement batteries noted on page 2 for replacement battery information. USE ONLY rechargeable Ni-MH batteries AAA (R03) size. RDo not mix old and new batteries. RDo not open or mutilate the batteries. Released electrolyte from the batteries is corrosive and may cause burns or injury to the eyes or skin. The electrolyte is toxic and may be harmful if swallowed. RExercise care when handling the batteries. Do not allow conductive materials such as rings, bracelets, or keys to touch the batteries, otherwise a short circuit may cause the batteries and/or the conductive material to overheat and cause burns. RCharge the batteries provided with or identified for use with this product only, in accordance with the instructions and limitations specified in this manual. ROnly use a compatible base unit (or charger) to charge the batteries. Do not tamper with the base unit (or charger). Failure to follow these instru…

Text truncated - open the document above for the full version.

EXHIBIT A STATEMENT OF SECURITY CODE This cordless telephone system has more than 1,000 billion combinations that are provided by the following means: • Provided with 128 bits for security codes. • When shipped from the factory, the security code is decided by the manufacture. It is memorized in a memory IC. • Base and Handset knows each other’s security code information.

Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Tel/Fax: 201-348-7758 / [email protected] Richard Mullen, Group Manager Product Safety and Compliance Department Power of Attorney July 6, 2015 PCTP-15-F017 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Panasonic Corporation of North America hereby authorizes Nemko AS to act on our behalf in all matters relating to the preparation of TCB Certification application for the below described product, which are in compliance with FCC Part 15D. Any and all acts carried out by Nemko AS on our behalf shall have the same effects as acts of our own for a period of one year from the date of this letter. Product Classification: Part 15 Unlicensed PCS Portable Tx Held to Ear (PUE) FCC ID Handset Unit ACJ96NKX-TGEA20A 1 FCC Rule Part: FCC Part 15, Subpart D Frequency Range: 1921.536 ~ 1928.448 MHz Responsible Panasonic Corporation of North America Applicant & Grantee: Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Responsible Manufacturer: Panasonic System Networks Co., Ltd. Sincerely yours, Richard Mullen Group Manager Panasonic Corporation of North America Product Safety and Compliance Department 1 DECT Handset under FCC ID: ACJ96NKX-TGEA20A may be marketed with DECT Bases, which are Part 15D certified under FCC IDs: ACJ96NKX-TGE270, ACJ96NKX-TGE240 and ACJ96NKX-TGE230. Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Tel/Fax: 201-348-7758 / [email protected] Richard Mullen, Group Manager Product Safety and Compliance Department Request for Confidentiality July 6, 2015 PCTP-15-F017 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Product Classification: Part 15 Unlicensed PCS Portable Tx Held to Ear (PUE) FCC ID Handset Unit ACJ96NKX-TGEA20A 2 FCC Rule Part: FCC Part 15, Subpart D In accordance with provisions of Sections 0.457 and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for exhibits, which contain: (1) Antenna Construction; (2) Description of Electrical Circuitry; (3) Schematic Diagrams of Handset Unit and RF Unit; and (4) Block Diagram. The transmitter is not user adjustable and does not have a Tune-Up Procedure. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. In accordance with FCC Public DA 04-1705, we request forty-five day short-term confidentiality, starting from the from the issuance of equipment authorization date, for exhibits, which contain: (1) External Photographs of Handset Unit and RF Unit; (2) Internal Photographs of Handset Unit and RF Unit; (3) Test Setup Photographs; and (4) User Manual. These exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. Sincerely yours, Richard Mullen Group Manager Panasonic Corporation of North America Product Safety and Compliance Department 2 DECT Handset under FCC ID: ACJ96NKX-TGEA20A may be marketed with DECT Bases, which are Part 15D certified under FCC IDs: ACJ96NKX-TGE270, ACJ96NKX-TGE240 and ACJ96NKX-TGE230.

FCC Part 15D – Compliance Information pctp-15-f017 (fcc_part_15d-compliance_information under fcc id-acj96nkx-tgea20a) 8-Dec-2006 page 1 (4) rev.1.4 EUT AND PRODUCT INFORMATION Type of Equipment UPCS (DECT 6.0) Applicant Name Panasonic Corporation of North America Responsible Mfr Name Panasonic System Networks Co., Ltd. Communication system Business Unit Address 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Contact Kazunori Ata FP PP EUT Type/System FCC ID ACJ96NKX-TGEA20A (IC:216A-KXTGEA20A) Model name KX-TGEA20 HW Version PNLB2541xx SW Version SW400 Max antenna Gain (dBi) 0dBi Can the EUT be Initiating Device YES YES Does the EUT transmit signaling channels YES YES Max number of slots in use simultaneously 1 slot Test standard: FCC part 15D Other: Industry Canada RSS-213, Issue 2 Frequency Band 1921.536 – 1928.448 MHz # of RF Channels 5 Frame Period 10 ms Max. Burst length 417us / duplex channel Min. Burst Length 106us / signaling channel # of Logical Channels 60 (12 duplex channels per RF carrier) Operating Mode Simplex Duplex FCC Part 15D – Compliance Information pctp-15-f017 (fcc_part_15d-compliance_information under fcc id-acj96nkx-tgea20a) 8-Dec-2006 page 2 (4) rev.1.4 ANTENNAS Base (FP) Antenna Type Internal External 1 2 3 4 Does RX and TX use the same antenna(s)? Yes No Handset (PP) Antenna Type Internal External 1 Pattern Antenna 2 Does RX and TX use the same antenna(s)? Yes No ANTENNA DIVERSITY Antenna Diversity Supported TX RX Base (FP) and Repeater 1 2 3 4 Handset (PP) 1 2 VOLTAGE AND TEMPERATURE RANGES VOLTAGES FP PP Nominal Voltage 120V AC DC 2.4V Cut-Off Voltage (if applicable) - - - POWER SOURCE Type Manufacturer Base or Repeater PNLV226 (AC Adaptor) Panasonic Handset (PP) (charger) PNLC1050 (Charger) Panasonic Data Connections PSTN (Base) Others (please specify) .... FCC Part 15D – Compliance Information pctp-15-f017 (fcc_part_15d-compliance_information under fcc id-acj96nkx-tgea20a) 8-Dec-2006 page 3 (4) rev.1.4 ANCILLARY EQUIPMENT Description AC Adaptor and Charger Type PNLV226 (AC Adaptor), PNLC1050 (Charger) Manufacturer Panasonic HOST DEVICE Description Type Manufacturer ADDITIONAL INFORMATION FCC Part 15D – Compliance Information pctp-15-f017 (fcc_part_15d-compliance_information under fcc id-acj96nkx-tgea20a) 8-Dec-2006 page 4 (4) rev.1.4 MANUFACTURERS DECLARATIONS FCC part 15.323 (c)(5) No device or group of co-operating devices located within 1m of each other shall during any frame period occupy more than 6 MHz of aggregate bandwidth, or alternatively, more than one third of the time and spectrum windows defined by the system. Applicant Agrees Yes No FCC part 15.323 (c)(10) The applicant hereby declares that the system in this application does use the criteria of (c)(10) of this section. Applicant Agrees Yes No FCC part 15.323 (c)(11) The applicant hereby declares that system in this application does not use the criteria of (c)(11) of this section. Applicant Agrees Yes No FCC part 15.323 (c)(12) The provisions of (c)(10) or (c)(11) of this section shall not be used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. Applicant Agrees Yes No FCC part 15.307 (b) The Applicant is a participating member of UTAM, Inc. and will provide an affidavit from UTAM, Inc. certifying this. Confirmed By Applicant Yes No ADDITIONAL REMARKS: > DECLARED BY: July 6, 2015 Richard Mullen

EXTERNAL PHOTOGRAPHS KX-TGEA20 Top View Bottom View

EXHIBIT B MARKINGS Portable Unit: FCC ID Label (Nameplate) The marking will be shown on the battery compartment of the portable unit.

INTERNAL PHOTOGRAPHS Internal View Internal View 2 Bottom View

SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_CalData Page 1 of 20 The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-00. Appendix for the SAR Test Report Dosimetric Assessment of the Portable Device KX-TGEA20 from Panasonic (FCC ID: ACJ96NKX-TGEA20A) According to the FCC Requirements Calibration Data July 15, 2015 IMST GmbH Carl-Friedrich-Gauß-Str. 2 - 4 47475 Kamp-Lintfort Germany Customer Panasonic System Networks Co., Ltd. 1 - 62, 4 - chome Minoshima, Hakata, Fukuoka 812-8531 Japan

SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Conf Page 1 of 30 The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-00. SAR Test Report Dosimetric Assessment of the Portable Device KX-TGEA20 from Panasonic (FCC ID: ACJ96NKX-TGEA20A) According to the FCC Requirements August 18, 2015 IMST GmbH Carl-Friedrich-Gauß-Str. 2 - 4 47475 Kamp-Lintfort Germany Customer Panasonic System Networks Co., Ltd. 1 - 62, 4 - chome Minoshima, Hakata, Fukuoka 812-8531 Japan The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Conf Page 2 of 30 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR Executive Summary The KX-TGEA20 is a new cordless phone (Portable Device) from Panasonic operating in the 1920 MHz -- 1930 MHz frequency range. The device has an integrated antenna and works in US DECT standard. The objective of the measurements done by IMST was the dosimetric assessment of one device in a worst case setup in head and body worn configuration. Since there was a special test software available, SAR tests were conducted with a specific channel and maximum output power during the measurement. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the 47 CFR § 2.1093 [47CFR] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. Additional information and guidelines given by the following FCC documents were used:  SAR Measurement Requirements for 100 MHz to 6 GHz [KDB 865664 D01 v01r03]  Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies [KDB 447498 D01 v05r02] All measurements have been performed in accordance to the recommendations given by the system manufacturer SPEAG AG, Switzerland. SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Conf Page 3 of 30 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR Compliance Statement The Panasonic KX-TGEA20 cordless phone (FCC ID: ACJ96NKX-TGEA20A) is in compliance with the following standards for uncontrolled exposure:  47 CFR § 2.1093 [47CFR],  ANSI / IEEE C95.1-1999 [IEEE C95.1-1999] The phone was tested in addition to the head positions in the following body worn configurations:  front towards the phantom, headset attached, distance 0 mm  back towards the phantom, headset attached, distance 0 mm The maximum results of SAR for the KX-TGEA20 are as follows: Worst Case SAR Results Band Frequency [MHz] CH Phantom Configuration Fig. No. Plot No. Highest Reported SAR 1g [W/kg] SAR 1g Limit [W/kg]. US DECT 1924.992 2 Left Head Cheek 15 1 0.046 1.6 PASS Body Worn Front 19 7 0.036 1.6 PASS Prepared by: ...................................... Reviewed by: ........................................ Dessislava Patrishkova Alexander Rahn Test Engineer Quality Assurance SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Conf Page 4 of 30 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR Table of Contents SUBJECT OF INVESTIGATION ........................................................................................................................ 5 1 FCC EXPOSURE CRITERIA ..................................................................................................................... 5 1.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES ................ 6 1.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS ......................................... 6 2 THE FCC MEASUREMENT PROCEDURE .............................................................................................. 7 2.1 GENERAL REQUIREMENTS ................................................................................................................... 7 2.2 DEVICE OPERATING NEXT TO A PERSON’S EAR ..................................................................................... 7 2.2.1 PHANTOM REQUIREMENTS ............................................................................................................... 7 2.2.2 TEST POSITIONS ............................................................................................................................. 7 2.2.3 TEST TO BE PERFORMED ................................................................................................................. 9 3 BODY-WORN CONFIGURATIONS ........................................................................................................ 10 3.1 POC (PTT) POSITION ........................................................................................................................ 11 3.2 PHANTOM REQUIREMENTS ................................................................................................................. 11 3.3 TEST TO BE PERFORMED ................................................................................................................... 11 3.3.1 MEASUREMENT VARIABILITY .......................................................................................................... 11 4 THE MEASUREMENT SYSTEM ............................................................................................................. 12 4.1 PHANTOMS ........................................................................................................................................ 13 4.2 E-FIELD-PROBES ............................................................................................................................... 14 4.3 MEASUREMENT PROCEDURE .............................................................................................................. 15 4.4 UNCERTAINTY ASSESSMENT ............................…

Text truncated - open the document above for the full version.

SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Plots Page 1 of 9 The Testcenter facility ‘Dosimetric Test Lab’ within IMST GmbH is accredited by the German National ‘Deutsche Akkreditierungsstelle GmbH (DAkkS)’ for testing according to the scope as listed in the accreditation certificate: D-PL-12139-01-00. Appendix for the SAR Test Report Dosimetric Assessment of the Portable Device KX-TGEA20 from Panasonic (FCC ID: ACJ96NKX-TGEA20A) According to the FCC Requirements SAR Distribution Plots July 15, 2015 IMST GmbH Carl-Friedrich-Gauß-Str. 2 - 4 47475 Kamp-Lintfort Germany Customer Panasonic System Networks Co., Ltd. 1 - 62, 4 - chome Minoshima, Hakata, Fukuoka 812-8531 Japan The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Plots Page 2 of 9 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR SAR Distribution Plots for Head and Body Worn Configuration Test Laboratory: IMST GmbH, DASY Yellow (II); File Name: TGEA20_yplm_1.da4 DUT: Panasonic; Type: KX-TGEA20; Serial: KX-TGEA20A Program Name: DECT Communication System: DECT Handset; Frequency: 1924.99 MHz;Duty Cycle: 1:24 Medium parameters used: f = 1925 MHz; σ = 1.47 mho/m; ε r = 40.1; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(7.95, 7.95, 7.95); Calibrated: 24.07.2014 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 19.02.2015 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Cheek Left/Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.037 mW/g Cheek Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.82 V/m; Power Drift = 0.040 dB Peak SAR (extrapolated) = 0.071 W/kg SAR(1 g) = 0.034 mW/g; SAR(10 g) = 0.018 mW/g Maximum value of SAR (measured) = 0.038 mW/g Fig. 1: SAR distribution for DECT US, channel 2, cheek position, left side of head (July 13, 2015) SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Plots Page 3 of 9 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR Test Laboratory: IMST GmbH, DASY Yellow (II); File Name: TGEA20_yplm_2.da4 DUT: Panasonic; Type: KX-TGEA20; Serial: KX-TGEA20A Program Name: DECT Communication System: DECT Handset; Frequency: 1924.99 MHz;Duty Cycle: 1:24 Medium parameters used: f = 1925 MHz; σ = 1.47 mho/m; ε r = 40.1; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(7.95, 7.95, 7.95); Calibrated: 24.07.2014 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 19.02.2015 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Tilted Left/Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.017 mW/g Tilted Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.45 V/m; Power Drift = 0.153 dB Peak SAR (extrapolated) = 0.032 W/kg SAR(1 g) = 0.017 mW/g; SAR(10 g) = 0.00995 mW/g Maximum value of SAR (measured) = 0.019 mW/g Fig. 2: SAR distribution for DECT US, channel 2, tilted position, left side of head (July 13, 2015) SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Plots Page 4 of 9 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR Test Laboratory: IMST GmbH, DASY Yellow (II); File Name: TGEA20_yprm_1.da4 DUT: Panasonic; Type: KX-TGEA20; Serial: KX-TGEA20A Program Name: DECT Communication System: DECT Handset; Frequency: 1924.99 MHz;Duty Cycle: 1:24 Medium parameters used: f = 1925 MHz; σ = 1.47 mho/m; ε r = 40.1; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(7.95, 7.95, 7.95); Calibrated: 24.07.2014 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 19.02.2015 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Cheek Right/Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.028 mW/g Cheek Right/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 4.13 V/m; Power Drift = 0.197 dB Peak SAR (extrapolated) = 0.047 W/kg SAR(1 g) = 0.027 mW/g; SAR(10 g) = 0.016 mW/g Maximum value of SAR (measured) = 0.030 mW/g Fig. 3: SAR distribution for DECT US, channel 2, cheek position, right side of head (July 13, 2015) SAR_Report_Nemko_60320_6150389_FCC_DECT_KX-TGEA20_Plots Page 5 of 9 SAR_Report_FCC_DECT_WiFI_Head_Body_1.0/10.12.2013/AR Test Laboratory: IMST GmbH, DASY Yellow (II); File Name: TGEA20_yprm_2.da4 DUT: Panasonic; Type: KX-TGEA20; Serial: KX-TGEA20A Program Name: DECT Communication System: DECT Handset; Frequency: 1924.99 MHz;Duty Cycle: 1:24 Medium parameters used: f = 1925 MHz; σ = 1.47 mho/m; ε r = 40.1; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(7.95, 7.95, 7.95); Calibrated: 24.07.2014 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 19.02.2015 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Tilted Right/Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.016 mW/g Tilted Right/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 3.51 V/m; Power Drift = 0.081 dB Peak SAR (extrapolated) = 0.029 W/kg SAR(1 g) = 0.017 mW/g; SAR(10 g) = 0.00914 mW/g Maximum value of SAR (measured) = 0.019 mW/g Fig. 4: SAR distribution for DECT US, channel 2, tilted position, right side of head (July 13, 2015) SAR_Report_…

Text truncated - open the document above for the full version.

Report No. 290700-1 Template version: C Nemko Norway Nemko AS, Instituttveien 6, P.O. Box 96 Kjeller, 2007 Kjeller, Norway TEL +47 22 96 03 30 FAX +47 22 96 05 50 EMAIL [email protected] ENTERPRISE NUMBER NO974404532 nemko.com/no Test Report Product DECT Handset Name and address of the applicant Panasonic Corporation of North America Two Riverfront Plaza, 9 th Floor Newark, NJ 07102-5490 Name and address of the manufacturer Panasonic System Networks Co., Ltd. 1-62, 4-chome, Minoshima, Hakata-ku Fukuoka 812-8531, Japan Model KX-TGEA20 Rating 2.4V DC (Secondary Batteries, 2x AAA NiMH cells) Trademark Panasonic Serial number / Additional information DECT 6.0 Tested according to FCC Part 15, subpart D Isochronous UPCS Device, 1920 – 1930 MHz Industry Canada RSS 213, Issue 3 2 GHz License-Exempt Personal Communications Services (LE-PCS) Devices Order number 290700 Tested in period 2015.06.30 to 2015.07.02 Issue date 2015.07.23 Name and address of the testing laboratory Instituttveien 6 Kjeller, Norway FCC No: 994405 IC OATS: 2040D-1 TEL: +47 22 96 03 30 FAX: +47 22 96 05 50 Prepared by [Frode Sveinsen] Approved by [G.Suhanthakumar] This report shall not be reproduced except in full without the written approval of Nemko. Opinions and interpretations expressed within this report are not part of the current accreditation. This report was originally distributed electronically with digital signatures. For more information please contact Nemko. TEST REPORT FCC part 15D Report no.: 290700-1 FCC ID: ACJ96NKX-TGEA20A Nemko Norway, Instituttveien 6, Kjeller, Norway Page 2 (46) CONTENTS 1 INFORMATION ................................................................................................................................. 3 1.1 Tested Item........................................................................................................................................ 3 1.2 Description of Tested Device ............................................................................................................. 3 1.3 Exposure Evaluation .......................................................................................................................... 3 1.4 Test Environment .............................................................................................................................. 4 1.5 Test Engineer(s) ................................................................................................................................ 4 1.6 Test Equipment ................................................................................................................................. 4 1.7 Other Comments ............................................................................................................................... 4 2 TEST REPORT SUMMARY .............................................................................................................. 5 2.1 General .............................................................................................................................................. 5 2.2 Test Summary ................................................................................................................................... 6 3 TEST RESULTS ................................................................................................................................ 7 3.1 Power Line Conducted Emissions ..................................................................................................... 7 3.2 Digital Modulation Techniques ........................................................................................................ 10 3.3 Labeling Requirements ...................…
