ACJ96NKX-THA142.4 GHz Wireless USB Adaptor

Temporary Confidential This unit is compatible with Caller ID. To use this feature, you must subscribe to the appropriate service offered by your service provider. Please read these Operating Instructions before using the unit and save for future reference. For assistance, visit our website: http://www.panasonic.com for customers in the U.S.A. or Puerto Rico. 2.4 GHz Expandable Cordless USB adaptor Model No. KX-THA14 Operating Instructions %QXGTHO2CIG6JWTUFC[/C[#/ Temporary Confidential Introduction 2 For assistance, please visit http://www.panasonic.com/consumersupport Expanding your phone You can expand the system by adding handsets (monochrome display handsets and color display handset), wireless camera unit, USB wireless adaptor, and repeater, sold separately. Using these accessories, you can have a video call, monitor on a room where the color display handset or wireless camera is located and taking pictures. Note: LUp to 8 handsets (KX-THA11/KX-THA12/KX-THA16) and up to 10 other Bluetooth featured units (KX-THA13/KX-THA14 and a maximum of 5 cellular phones) can be registered to a single base unit. A B C D G H F E TH102.book Page 8 Thursday, May 12, 2005 6:47 PM Temporary Confidential Introduction 4 For assistance, please visit http://www.panasonic.com/consumersupport Important safety instructions +PVTQFWEVKQPHO2CIG/QPFC[/C[2/ Medical €Consult the manufacturer of any personal medical devices, such as pacemakers or hearing aids, to determine if they are adequately shielded from external RF (radio frequency) energy. (The unit operates inthe frequency range of 2.4 GHz to 2.48GHz, and the power output level can range from 0.04 to 0.25 watts.) Do not use the unit in health care facilities if any regulations posted in the area instruct you not to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF (radio frequency) enegy. Temporary Confidential Introduction 6 For assistance, please visit http://www.panasonic.com/consumersupport For best performance Base unit location/noise The base unit and handset use radio waves to communicate with each other. For maximum distance and noise-free operation, we recommend the following: LPlacing the unit away from electrical appliances such as a TV, personal computer or another cordless phone. LPlacing the base unit in a HIGH and CENTRAL location with no obstructions such as walls. LRaising the antennas vertically. LIf you use the handset near a microwave oven which is being used, noise may be heard. Move away from the microwave oven and closer to the base unit. LIf you use the handset near another cordless phone’s base unit, noise may be heard. Move away from the other cordless phone’s base unit and closer to your base unit. Environment LKeep the unit away from electrical noise generating devices, such as fluorescent lamps and motors. LThe unit should be kept free from excessive smoke, dust, high temperature and vibration. LThe unit should not be exposed to direct sunlight. LDo not place heavy objects on top of the unit. LWhen you leave the unit unused for a long period of time, unplug this unit from power outlet. LThe unit should be kept away from heat sources such as heaters, kitchen stoves, etc. It should not be placed in rooms where the temperature is less than 5 °C (41 °F) or greater than 40 °C (104 °F). Damp basements should also be avoided. LThe maximum calling distance may be shortened when the unit is used in the following places: Near obstacles such as hills, tunnels, undergrounds, near metal objects such as wire fences, etc. LOperating near 2.4 GHz electrical appliances may cause interference. Move away from the electrical appliances. Routine care LWipe the outer surface of the unit with a soft cloth. Do not use benzine, thinner or any abrasive powder. +PVTQFWEVKQPHO2CIG/QPFC[/C[2/ Temporary Confidential Making/Answering Calls 7 Overview TG5861AL(e).book Page 25 Thursday, May 12, 2005 6:55 PM Wireless connection with the USB adaptor The USB adaptor permits a wireless connection between a PC and base unit. For example, you can sit in your garden with a Laptop and still surf the Internet. The USB adaptor is supplied with power via the USB port. Temporary Confidential Preparation For assistance, please visit http://www.panasonic.com/consumersupport Connections Connecting to a computer 2TGRCTCVKQPHO2CIG6JWTUFC[/C[#/ Connect the USB adaptor to the USB port of your computer as shown below. 8 Temporary Confidential Preparation For assistance, please visit http://www.panasonic.com/consumersupport 9 Controls USB adaptor AUSB plug BLED CAnntena 2TGRCTCVKQPHO2CIG6JWTUFC[/C[2/ Temporary Confidential Useful Information 15 For assistance, please visit http://www.panasonic.com/consumersupport FCC and other information CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this device. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: − Reorient or relocate the receiving antenna. − Increase the separation between the equipment and receiver. − Connect…

Text truncated - open the document above for the full version.

EXHIBIT A STATEMENT OF SECURITY CODE This device is a Wireless USB Adaptor, and has 281,475 billion digital security coding combinations that are provided by the following means: • Provided with 48bit (281,475billion) for security codes. • When shipped from the factory, the security code is decided by the manufacture. It is memorized in a memory IC. • This model and the host unit can register each other's security code while the registration mode.

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201.348.7758 / Fax: 201.392.4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division Date: August 12, 2005 Control No: PCTP-05-F017 731 Confirm No: EA368660 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Original Certification Application for FHSS System (FCC Equipment Code DSS) 2.4 GHz FHSS Wireless USB Adaptor, Model KX-THA14 FCC Certification for FCC ID: ACJ96NKX-THA14 To Whom It May Concern: Enclosed, find Panasonic Corporation of North America’s original application for the subject transmitter. This product is in compliance with Part 15, Subpart C and Section 15.247. In accordance with provisions of Section 0.457(d) of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request confidentiality for exhibits E, F, G and I, which contain Description of Electrical Circuitry, Schematic Diagram, Block Diagram and FHSS Description. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. The subject USB Adaptor uses frequency hopping spread spectrum operation within 2402~2480 MHz band. This adaptor uses permanently attached whip antenna with 2.14 dBi nominal antenna gain and has 51 mW maximum peak conducted output power. RF exposure evaluation is satisfied by: (1) MPE for mobile operation at 20 cm spacing with calculated results of 0.01670 mW/cm 2 ; and (2) SAR for portable operation at zero spacing with measured results of 1.43 W/kg for Body. This USB Adaptor will be authorized under Declaration of Conformity in compliance with FCC Part 15B to meet Class B limits when computer system tested in accordance with ANSI C63.4-2003. This USB Adaptor may be used with associated cordless telephone base unit, which will be separately FCC certified under FCC ID: ACJ96NKX-TH102. Please advise the undersigned if you have any questions or comments for this filing. Thank you for your attention in this matter. Sincerely yours, Richard Mullen Richard Mullen Group Manager

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201.348.7758 / Fax: 201.392.4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division Date: October 19, 2005 Control No: PCTP-05-F017 Attn: Steven Dayhoff / FCC Equipment Authorization Branch Applicant: Panasonic Corporation of North America FCC ID: ACJ96NKX-THA14 CRN: 29593 731 Confirm No: EA368660 Product Type: 2.4 GHz Wireless USB Adaptor, Model KX-THA14 This is in response to the subject Correspondence Reference Number 29593 issued on September 19, 2005. UL Apex, who performed the SAR Test Report, explained the following regarding how the signal timing and crest factor for SAR was determined. The test was measured in the maximum packet size of each mode. For Mode 1; Ratio of packet time ; ON time : OFF time = 5 : 1 Crest factor formula ; =(ON+OFF) / ON = 6/5 = 1.2 For Mode 2; Ratio of packet time ; ON time : OFF time = 3 : 1 Crest factor formula ; =(ON+OFF) / ON = 4/3 = 1.3 Please advise if you should have any other questions or comments. Thank you for your attention in this matter. Sincerely yours, Richard Mullen Richard Mullen Group Manager

Temporary Confidential EXTERNAL PHOTOGRAPHS KX-THA14 Temporary Confidential Back View

EXHIBIT B MARKINGS This unit provides with the following markings, or equivalent. Above markings are shown on FCC ID Label back side of the unit.

Temporary Confidential INTERNAL PHOTOGRAPHS Internal View Temporary Confidential RF Cover Open Temporary Confidential P.C. Board Another Side

Test report No. : 25IE0110-HO-3A Page : 2 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 CONTENTS Page Chapter 1 : Client information ..................................................................................................................................................... 3 Chapter 2 : Equipment under test (E.U.T.) ................................................................................................................................. 4 Chapter 3 : Requirements for compliance testing defined by the FCC..................................................................................... 6 Chapter 4 : Dosimetry assessment setup...................................................................................................................................... 6 Chapter 5 : Test system specifications ......................................................................................................................................... 10 Chapter 6 : Measurement uncertainty ......................................................................................................................................... 11 Chapter 7 : Evaluation procedure ................................................................................................................................................ 12 Chapter 8 : Exposure limit............................................................................................................................................................ 13 Chapter 9 : Measurement Outline................................................................................................................................................ 14 SECTION 9.1 : Outline of EUT ......................................................................................................................................... 14 SECTION 9.2 : EUT Tune-up procedure ........................................................................................................................... 14 SECTION 9.3 : Method of measurement ........................................................................................................................... 14 Chapter 10 : Output power Measurement results ...................................................................................................................... 15 Chapter 11 : SAR Measurement results (PC model 1) ............................................................................................................... 16 SECTION 11.1 : Information of NotePC ........................................................................................................................... 16 SECTION 11.2 : Test setup of EUT ................................................................................................................................... 17 SECTION 11.3 : Simulated tissue liquid parameter ........................................................................................................... 20 SECTION 11.4 : System validation data ............................................................................................................................ 21 SECTION 11.5 : Measurement results ............................................................................................................................... 22 Chapter 12 : SAR Measurement results (PC model 2) Reference data 1.................................................................................. 24 SECTION 12.1 : Information of NotePC ........................................................................................................................... 24 SECTION 12.2 : Test setup of EUT ................................................................................................................................... 25 SECTION 12.3 : Simulated tissue liquid parameter ........................................................................................................... 27 SECTION 12.4 : System validation data ............................................................................................................................ 28 SECTION 12.5 : Measurement results (Reference only).................................................................................................... 29 Chapter 13 : SAR Measurement results (PC model 3) Reference data 2.................................................................................. 31 SECTION 13.1 : Information of NotePC ........................................................................................................................... 31 SECTION 13.2 : Test setup of EUT ................................................................................................................................... 32 SECTION 13.3 : Simulated tissue liquid parameter ........................................................................................................... 34 SECTION 13.4 : System validation data ............................................................................................................................ 35 SECTION 13.5 : Measurement results (Reference only).................................................................................................... 36 Chapter 14 : Equipment & calibration information ................................................................................................................... 38 Chapter 15 : References ................................................................................................................................................................ 39 APPENDIX 1 : Photographs of test setup ................................................................................................................................. 40 APPENDIX 2 …

Text truncated - open the document above for the full version.

Test report No. : 25IE0110-HO-3A Page : 101 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 APPENDIX 6 : System Validation Dipole (D2450V2,S/N: 713) Test report No. : 25IE0110-HO-3A Page : 102 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 103 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 104 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 105 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 106 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 107 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 108 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 109 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 110 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 111 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 APPENDIX 7 : Dosimetric E-Field Probe Calibration (ET3DV6,S/N: 1684) Test report No. : 25IE0110-HO-3A Page : 112 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 113 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 114 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 115 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 116 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 117 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 118 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 119 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 Test report No. : 25IE0110-HO-3A Page : 120 of 120 Issued date : June 20, 2005 Revised date : June 21, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124

UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Applicant: Panasonic Communications Co.,Ltd. Type of Equipment : W ireless USB Adaptor M odel No. : K X-TH A14 FCC ID: ACJ96NKX-THA14 Panasonic Communications Co.,Ltd. declares that Model : W ireless USB Adaptor complies with FCC radiation exposure requirement specified in the FCC Rules 2.1093. The “KX-THA14“ has 51.29 mW of conducted Peak Output power and 83.95 mW of EIRP. This kind of equipment is below 60/frequency[GHz] mW (TCB Exclusion List) so that SA R testing is excluded. The Following calculation is the reference data for 20cm distance. RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided with the “KX-THA14“ as calculated from FCC OET Bulletin 65 Appendix A, Table (B) Limits for General Population / Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0mW /cm^2 uncontrolled exposure limit. The Friis formula used was: S = (P * G) / (4* π * r 2 ) Where P = 51.29 mW (M aximum peak output power) G = 1.64 Numerical Antenna gain; equal 2.14 dBi r =20.0 cm For: KX-THA14S = 0.01670 mW/cm 2 No. : 25IE0110-HO-1 RF Exposure / SAR Statement Test report No. : 25IE0110-HO-1 Page : 2 of 59 Issued date : June 20, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(01.06.05) CONTENTS PAGE SECTION 1: Client information ......................................................................................................... 3 SECTION 2: Equipment under test (E.U.T.)..................................................................................... 3 SECTION 3: Test specification, procedures & results...................................................................... 4 SECTION 4: Operation of E.U.T. during testing .............................................................................. 6 SECTION 5: Conducted Emission...................................................................................................... 7 SECTION 6: Spurious Emission ......................................................................................................... 8 SECTION 7: Bandwidth ...................................................................................................................... 9 SECTION 8: Maximum Peak Output Power .................................................................................... 9 SECTION 9: Carrier Frequency Separation ..................................................................................... 9 SECTION 10: Number of Hopping Frequency ................................................................................. 9 SECTION 11: Dwell time..................................................................................................................... 9 APPENDIX 1: Photographs of test setup .........................................................................................10 Conducted Emission .............................................................................................................................. 10 Spurious Emission (Radiated)............................................................................................................... 11 Worst Case Position (X-axis + Ant. 5deg. :Horizontal / Z-axis + Ant. 5deg.:Vertical) ..................... 12 APPENDIX 2:Test instruments ......................................................................................................... 13 APPENDIX 3: Data of EMI test......................................................................................................... 14 Conducted Emission .............................................................................................................................. 14 [Mode 1]................................................................................................................................................ 21 Carrier Frequency Separation [Mode 1].............................................................................................. 21 20dB Bandwidth [Mode 1]..................................................................................................................... 23 Number of Hopping Frequency [Mode 1] ............................................................................................25 Dwell Time [Mode 1].............................................................................................................................. 28 Maximum Peak Output Power [Mode 1] .............................................................................................31 Radiated Spurious Emission [Mode 1] ................................................................................................. 32 Conducted Spurious Emission [Mode 1] .............................................................................................. 37 [Mode 2]................................................................................................................................................ 41 Carrier Frequency Separation [Mode 2].............................................................................................. 41 20dB Bandwidth [Mode 2]..................................................................................................................... 43 Number of Hopping Frequency [Mode 2] ............................................................................................45 Dwell Time [Mode 2].............................................................................................................................. 47 Maximum Peak Output Power [Mode 2] .................................................................…

Text truncated - open the document above for the full version.

Test report No. : 25IE0110-HO-1 Page : 10 of 59 Issued date : June 20, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(01.06.05) APPENDIX 1: Photographs of test setup Conducted Emission Front Rear Test report No. : 25IE0110-HO-1 Page : 11 of 59 Issued date : June 20, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(01.06.05) Spurious Emission (Radiated) Front Rear Test report No. : 25IE0110-HO-1 Page : 12 of 59 Issued date : June 20, 2005 FCC ID : ACJ96NKX-THA14 UL Apex Co., Ltd. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 MF060b(01.06.05) Worst Case Position (X-axis + Ant. 5deg. :Horizontal / Z-axis + Ant. 5deg.:Vertical) EUT: X-axis Ant: 5deg. EUT: Y-axis Ant: 90deg. EUT: Z-axis Ant: 175deg.
