ACJ96NKX-TPA70DECT 6.0 Cordless Telephone System Handset

Base Unit for SIP Cordless Phone Model No.KX-TGP700 Model No. SIP Cordless Handset KX-TPA70/KX-TPA73 Operating Instructions KX-TGP700KX-TPA70/KX-TPA73 Thank you for purchasing this Panasonic product. Please read this manual carefully before using this product and save this manual for future use. Please use the batteries provided and charge the batteries for about 6 hours before using the handset for the first time. Note • In this manual, the suffix of each model number is omitted unless necessary. • The illustrations such as some keys may differ from the appearance of the actual product. • Certain products and features described in this document may not be available in your country or area. Contact your phone system dealer/service provider. • The contents and design of the software are subject to change without notice. Document Version: 2020-01 Introduction Outline This manual describes information about the installation and operation of KX-TGP700, KX-TPA70 and KX-TPA73. Related Documentation •Quick Start Guide Describes basic information about the installation and safety precautions to prevent personal injury and/or damage to property. •Administrator Guide Describes detailed information about the configuration and management of this unit. This guide describes information about the KX-TGP700 only. Manuals and supporting information are provided on the Panasonic Web site at: https://panasonic.net/cns/pcc/support/sipphone/ Font Information The font information for KX-TPA70 and KX-TPA73 is available on the Panasonic Web site at: https://panasonic.net/cns/pcc/support/sipphone/ For Future Reference Record the information in the space below for future reference. Note • The serial number of this product may be found on the labels affixed to the following places: –Base unit (KX-TGP700): the back of the unit –Handset (KX-TPA70/KX-TPA73): the inside of the battery compartment on the back of the handset –Charger (KX-TPA70/KX-TPA73): the bottom of the charger You should note the serial numbers of these units in the space provided and retain this manual as a permanent record of your purchase to aid in identification in the event of theft. • Copyright for Roboto Copyright 2015 Google Inc. All Rights Reserved. Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at http://www.apache.org/licenses/LICENSE-2.0 Introduction 2 Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License. MODEL NO. SERIAL NO. DATE OF PURCHASE NAME OF DEALER DEALER’S ADDRESS DEALER’S TEL. NO. Introduction 3 Introduction 4 Table of Contents 1 Important Information .......................................................... 7 1.1Important Information ................................................................................... 8 1.1.1Data Security ............................................................................................... 8 1.2For Users in European Countries ................................................................ 9 1.3For Users in the United Kingdom ................................................................ 9 1.4For Users in Australia and the United Kingdom ...................................... 10 1.5For Users in New Zealand .......................................................................... 10 1.6For Users in the United States ................................................................... 11 1.7For Users in Canada ................................................................................... 13 1.8For Best Performance ................................................................................. 14 1.9Battery Information (KX-TPA70/KX-TPA73) .............................................. 16 2 Before Operating the Telephones ..................................... 19 2.1Before Operating the Telephones .............................................................. 20 2.1.1System Overview ....................................................................................... 20 2.2Accessory Information ............................................................................... 22 2.2.1Included Accessories ................................................................................. 22 2.3Location of Controls ................................................................................... 24 2.3.1Base Unit (KX-TGP700) ............................................................................ 24 2.3.2Handset (KX-TPA70/KX-TPA73) ................................................................ 27 2.4The Display and Icons ................................................................................ 30 2.4.1Display ....................................................................................................... 30 3 Making Calls ........................................................................ 33 3.1Making Calls ................................................................................................ 34 4 Receiving Calls ................................................................... 35 4.1Answering Calls .......................................................................................... 36 5 Installation and Setup ........................................................ 37 5.1Installation and Setup ................................................................................. 38 5.2Connections ................................................................................................ 38 5.2.1Battery Installation ..................................................................................... 39 5.2.2Attaching the Belt Clip ..............................................…

Text truncated - open the document above for the full version.

FCC Part 15D – Compliance Information Nemko AS, Instituttveien 6, 2007 Kjeller, Norway kx-tpa70_fcc part 15d declarations Tel: +47 22 96 03 30 Fax: +47 22 96 05 50 Page 1 (5) rev.2.8 28-Feb-2018 Email: [email protected] EUT AND PRODUCT INFORMATION Type of Equipment UPCS (DECT 6.0) Applicant Name Panasonic Corporation Address 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka, 812-8531 Japan Contact Michihito Miyazaki Telephone +81-70-1349-4205 Email [email protected] Brand Name Panasonic Base Station Handset / Portable WRS EUT Type/System ☐ ☒ ☐ FCC ID ACJ96NKX-TPA70 ISED ID (Canada) 216A-KXTPA70 Model name KX-TPA70 HW Version PNLB2824ZAxx SW Version Ver 00.01 Maximum Antenna Gain 1.0 dBi Can the EUT be Initiating Device ☐ YES ☒ YES ☐ YES Does the EUT transmit signaling channels ☐ YES ☐ YES ☐ YES Max. # of slots in use simultaneously 1slot Frequency Band 1921.536 – 1928.448 MHz Number of RF Channels 5 Frame Period 10 ms Max. Burst length 723us Min. Burst Length 390us Min. # of System Channels 60 (12 duplex channels per RF carrier) Supported DECT Slot Types ☒ Full Slot ☒ Long Slot ☐ Double Slot Operating Mode ☐ Simplex ☒ Duplex FCC Part 15D – Compliance Information Nemko AS, Instituttveien 6, 2007 Kjeller, Norway kx-tpa70_fcc part 15d declarations Tel: +47 22 96 03 30 Fax: +47 22 96 05 50 Page 2 (5) rev.2.8 28-Feb-2018 Email: [email protected] ANTENNAS Base Station Antenna Type Internal External 1 ☐ ☐ 2 ☐ ☐ 3 ☐ ☐ 4 ☐ ☐ Does RX and TX use the same antenna(s)? ☐ Yes ☐ No Handset Antenna Type Internal External 1 λ/4 PIFAntenna ☒ ☐ 2 ☐ ☐ Does RX and TX use the same antenna(s)? ☒ Yes ☐ No ANTENNA DIVERSITY Antenna Diversity Supported TX RX Base Station 1 ☐ ☐ 2 ☐ ☐ 3 ☐ ☐ 4 ☐ ☐ Handset 1 ☐ ☐ 2 ☐ ☐ VOLTAGE AND TEMPERATURE RANGES VOLTAGES Base Station Handset or Portable WRS Nominal Voltage DC 2.6V Cut-Off Voltage (if applicable) POWER SOURCE Type Manufacturer Base Station or WRS Handset (Charger) Ni-MH Battery cell X 2 (PQLV219 (AC Adaptor)) Panasonic Connections on Base ☐ PSTN ☐ USB ☐ Ethernet ☒ Others (please specify) ....RF FCC Part 15D – Compliance Information Nemko AS, Instituttveien 6, 2007 Kjeller, Norway kx-tpa70_fcc part 15d declarations Tel: +47 22 96 03 30 Fax: +47 22 96 05 50 Page 3 (5) rev.2.8 28-Feb-2018 Email: [email protected] ANCILLARY EQUIPMENT Description AC Adapter and Charger Type PQLV219 (AC Adaptor) Manufacturer Panasonic HOST DEVICE Description Type Manufacturer ADDITIONAL INFORMATION FCC Part 15D – Compliance Information Nemko AS, Instituttveien 6, 2007 Kjeller, Norway kx-tpa70_fcc part 15d declarations Tel: +47 22 96 03 30 Fax: +47 22 96 05 50 Page 4 (5) rev.2.8 28-Feb-2018 Email: [email protected] MANUFACTURERS DECLARATIONS FCC part 15.323 (c)(5) The applicant declares that the system in this application has more than 20 duplex system access channels defined, and that the system is operating in Least Interfered Channel (LIC) mode in accordance with this section. Applicant Agrees ☒ Yes ☐ No FCC part 15.323 (c)(5) No device or group of co-operating devices located within 1m of each other shall during any frame period occupy more than 6 MHz of aggregate bandwidth, or alternatively, more than one third of the time and spectrum windows defined by the system. Applicant Agrees ☒ Yes ☐ No FCC part 15.323 (c)(10) The applicant hereby declares that the system in this application does use the criteria of (c)(10) of this section. Applicant Agrees ☒ Yes ☐ No FCC part 15.323 (c)(11) The applicant hereby declares that system in this application does not use the criteria of (c)(11) of this section. Applicant Agrees ☒ Yes ☐ No FCC part 15.323 (c)(12) The provisions of (c)(10) or (c)(11) of this section shall not be used to extend the range of spectrum occupied over space or time for the purpose of denying fair access to spectrum to other devices. Applicant Agrees ☒ Yes ☐ No ADDITIONAL REMARKS: > DECLARED BY: 27 September 2019 Date Michihito Miyazaki Name (print) Signature FCC Part 15D – Compliance Information Nemko AS, Instituttveien 6, 2007 Kjeller, Norway kx-tpa70_fcc part 15d declarations Tel: +47 22 96 03 30 Fax: +47 22 96 05 50 Page 5 (5) rev.2.8 28-Feb-2018 Email: [email protected] About this document This document specifies the information that is needed to select the correct testcases and test procedures for testing to FCC Part 15D. The form must be completed by the applicant and submitted to Nemko before testing is started. Preparation of Equipment for Testing Note (a): Number of samples for testing The following samples are needed for FCC 15D testing: RF Conducted Tests: One sample with a 50 ohm antenna connector (preferably SMA Female). Only one antenna connector is needed for these tests even if the equipment has more than one antenna. Monitoring Tests: One sample with 50 ohm antenna connectors fitted to all antennas (preferably SMA female). Additionally we need a companion device that will work together with the EUT, the companion device must also have antenna connectors on all antennas. Radiated Tests: One sample with integral antennas. This sample will be used to measure Antenna Gain, Part 15B and Power-Line Conducted tests. Note (b): Burst Mode All RF tests are performed with the EUT in force transmit, aka burst mode. Software and necessary programming tools must be submitted to Nemko together with the test samples before start of testing. Note (c): Monitoring Tests Monitoring tests are performed in normal operating mode by establishing a connection from the handset (or the initiating device) to the base station (or the responding device). Most tests are performed by establishing connections from the initiating device to the responding device and observing which channel and/or timeslot is used. For monitoring tests we need a EUT and a Companion device that both have antenna connectors on all antennas (preferably SMA female, again). Additionally, we need access to the CLK100 signal on the Base Station, this is necessary becaus…

Text truncated - open the document above for the full version.

Two Riverfront Plaza | Newark, NJ 07102-5490 Ben Botros, Project Manager Safety , Compliance and Quality Assurance Authorization Letter November 26, 2019 PCNF-19-F068 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Panasonic Corporation of North America hereby authorizes Nemko AS to act on our behalf in all matters relating to the preparation of TCB Certification application for the below described product. Any and all acts carried out by Nemko AS on our behalf shall have the same effects as acts of our own for a period of six months from the date of this letter. Type Filing: Original Application for DECT Cordless Telephone Handset Model Numbers: KX-TPA70(xx) FCC Classification: PUE FCC Rule Part: FCC Part 15, Subpart D Frequency Range: 1921.536 ~ 1928.448 Number Channels: 5 RF Channels / 5x12 = 60 TDMA Duplex Channels RF Exposure: Mobile / MPE (requires minimu m 20cm spacing between antenna and body) FCC Rule Part: FCC Part 15, Subpart B FCC Classification: Class B Digital Device (JAB) FCC ID: ACJ96NKX-TPA70 Responsible Panasonic Corporation of North America Applicant & Grantee: Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Sincerely yours, Ben Botros Project Manager Panasonic Corporation of North America Safety, Compliance and Quality Assurance

Two Riverfront Plaza | Newark, NJ 07102-5490 Ben Botros, Project Manager Safety , Compliance and Quality Assurance Request for Confidentiality November 26, 2019 PCNF-19-F068 Federal Communication Commission Equipment Authorization Division / Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 To whom it may concern; Panasonic Corporation of North America hereby authorizes Nemko AS to act on our behalf in all matters relating to the preparation of TCB Certification application for the below described product. Any and all acts carried out by Nemko AS on our behalf shall have the same effects as acts of our own for a period of six months from the date of this letter. Type Filing: Original Application for DECT Cordless Telephone Handset Model Numbers: KX-TPA70(xx) FCC ID: ACJ96NKX-TPA70 FCC Rule Part: FCC Part 15, Subpart B and D Request For Permanent Confidentiality In accordance with provisions of Sections §§0.457(d) and 0.459 of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for exhibits, which contain: (1) Antenna Construction; (2) Description of Electrical Circuitry; (3) Schematic Diagrams of Base Unit and RF Unit; and (4) Base Unit Block Diagram. The transmitter is not user adjustable and does not have a Tune-Up Procedure. These exhibits contain proprietary, confidential and trade secrets material , which would not be routinely made available for public inspection. Request For Short-Term Confidentiality In accordance with FCC Public DA 04-1705, we request ninety day short-term confidentiality, starting from the from the issuance of equipment authorization date, for exhibits, which contain: (1) External Photographs of Base Unit and RF Unit; (2) Internal Photographs of Base Unit and RF Unit; (3) Test Setup Photographs; and (4) User Manual. These exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. Sincerely yours, Ben Botros Project Manager Panasonic Corporation of North America Safety, Compliance and Quality Assurance

1 of 4 EXHIBIT D-1 EXTERNAL PHOTOGRAPHS 2 of 4 EXHIBIT D-1 EXTERNAL PHOTOGRAPHS 3 of 4 EXHIBIT D-1 EXTERNAL PHOTOGRAPHS 4 of 4 EXHIBIT D-1 EXTERNAL PHOTOGRAPHS

EXHIBIT B PRODUCT LABELING GRANTEE : Panasonic Corporation of North America GRANTEE CODE : ACJ COUNTRY OF ORIGIN : Vietnam TRADE NAME : PANASONIC MATERIAL OF LABEL : Aluminum or Polyester Film or Molded on the Unit Serial number will be printed on the other label, and the serial number label will be affixed on the unit.

1 of 5 EXHIBIT D-2 INTERNAL PHOTOGRAPHS 2 of 5 EXHIBIT D-2 INTERNAL PHOTOGRAPHS 3 of 5 EXHIBIT D-2 INTERNAL PHOTOGRAPHS 4 of 5 EXHIBIT D-2 INTERNAL PHOTOGRAPHS 5 of 5 EXHIBIT D-2 INTERNAL PHOTOGRAPHS

Test report No. : 12950350H-B-R2 Page : 1 of 68 FCC ID : ACJ96NKX-TPA70 Issued date : February 4, 2020 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999 Facsimile: +81 596 24 8124 Report Cover Page - 13-EM-F0429 Issue # 15.0 SAR TEST REPORT Test Report No. : 12950350H-B-R2 Applicant : Panasonic Corporation Type of Equipment : SIP Cordless handset Model No. : KX-TPA70 FCC ID : ACJ96NKX-TPA70 Test regulation : FCC47CFR 2.1093 Test Result : Complied (Refer to SECTION 4) Reported SAR(1g) Value The highest reported SAR(1g) Head : 0.03 W/kg Body worn : 0.09 W/kg The testing in which “Non-accreditation” is displayed is outside the accreditation scopes in UL Japan. There is no testing item of “Non-accreditation”. 1. This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc. 2. The results in this report apply only to the sample tested. 3. This sample tested is in compliance with the limits of the above regulation. 4. The test results in this report are traceable to the national or international standards. 5. This test report covers SAR technical requirements. It does not cover administrative issues such as Manual or non-SAR test related Requirements. (if applicable) 6. The all test items in this test report are conducted by UL Japan, Inc. Ise EMC Lab. 7. This test report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. 8. The information provided from the customer for this report is identified in SECTION 1. 9 This report is a revised version of 12950350H-B-R1. 12950350H-B-R1 is replaced with this report. Date of test: September 14, 2019 Representative test engineer: Hisayoshi Sato Engineer Consumer Technology Division Approved by : Takayuki Shimada Leader Consumer Technology Division This laboratory is accredited by the NVLAP LAB CODE 200572-0, U.S.A. The tests reported herein have been performed in accordance with its terms of accreditation. *As for the range of Accreditation in NVLAP, you may refer to the WEB address, http://japan.ul.com/resources/emc_accredited/ Test report No. : 12950350H-B-R2 Page : 2 of 68 FCC ID : ACJ96NKX-TPA70 Issued date : February 4, 2020 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999 Facsimile: +81 596 24 8124 REVISION HISTORY Original Test Report No.: 12950350H-B Revision Test report No. Date Page revised Contents - (Original) 12950350H-B September 27, 2019 - - 1 12950350H- B-R1 January 6, 2020 P.1 Correction of Reported SAR(1g) Value in Cover sheet; Body worn: from 0.11 W/kg to 0.09 W/kg 1 12950350H- B-R1 January 6, 2020 P.6 Correction of Antenna Gain in Clause 2.3; from 0.5 dBi to 1.0 dBi 1 12950350H- B-R1 January 6, 2020 P.9 Correction of DECT value in Stand-alone SAR result in Clause 4.2; <Head SAR> Tune-up upper Power: from 21.00 dBm / 125.89 mW to 20.00 dBm / 100.00 mW Scaled factor: from 1.445 to 1.148 Reported SAR: from 0.033 W/kg to 0.026 W/kg <Body worn SAR> Tune-up upper Power: from 21.00 dBm / 125.89 mW to 20.00 dBm / 100.00 mW Scaled factor: from 1.445 to 1.148 Reported SAR: from 0.111 W/kg to 0.088 W/kg 1 12950350H- B-R1 January 6, 2020 P.10 Correction of Maximum tune-up tolerance limit of DECT value in SECTION 5; from 21.00 dBm / 125.89 mW to 20.00 dBm / 100.00 mW 1 12950350H- B-R1 January 6, 2020 P.11, 12 Correction of Output Power value of DECT in Clause 6.2; from 21.00 dBm / 126 mW to 20.00 dBm / 100.00 mW 1 12950350H- B-R1 January 6, 2020 P.15 Correction of Tune-up upper Power value of DECT in Clause 7.1; from 21.00 dBm to 20.00 dBm 1 12950350H- B-R1 January 6, 2020 P.21 - Correction of Tune-up upper Power value in Clause 11.1; from 21.00 dBm to 20.00 dBm - Changes in the following scaled factor values due to changes in the above Tune-up upper Power values; 1921.536 MHz: from 1.455 to 1.156 1924.992 MHz: from 1.452 to 1.153 1928.448 MHz: from 1.445 to 1.148 1 12950350H- B-R1 January 6, 2020 P.21 - Correction of Tune-up upper Power value in Clause 11.2; from 21.00 dBm to 20.00 dBm - Changes in the following scaled factor values due to changes in the above Tune-up upper Power values; 1921.536 MHz: from 1.455 to 1.156 1924.992 MHz: from 1.452 to 1.153 1928.448 MHz: from 1.445 to 1.148 2 12950350H- B-R2 February 4, 2020 P.21 Correction of the table column of Clause 11.2. from 10-g SAR(W/kg) to 1-g SAR(W/kg) Test report No. : 12950350H-B-R2 Page : 3 of 68 FCC ID : ACJ96NKX-TPA70 Issued date : February 4, 2020 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999 Facsimile: +81 596 24 8124 Reference: Abbreviations (Including words undescribed in this report) A2LA The American Association for Laboratory Accreditation NSA Normalized Site Attenuation AC Alternating Current NVLAP National Voluntary Laboratory Accreditation Program AFH Adaptive Frequency Hopping OBW Occupied Band Width AM Amplitude Modulation OFDM Orthogonal Frequency Division Multiplexing Amp, AMP Amplifier P/M Power meter ANSI American National Standards Institute PCB Printed Circuit Board Ant, ANT Antenna PER Packet Error Rate AP Access Point PHY Physical Layer Atten., ATT Attenuator PK Peak AV Average PN Pseudo random Noise BPSK Binary Phase-Shift Keying PRBS Pseudo-Random Bit Sequence BR Bluetooth Basic Rate PSD Power Spectral Density BT Bluetooth QAM Quadrature Amplitude Modulation BT LE Bluetooth Low Energy QP Quasi-Peak BW BandWidth QPSK Quadri-Phase Shift Keying Cal Int Calibration Interval RBW Resolution Band Width CCK Complementary Code Keying RDS Radio Data System Ch., CH Channel RE Radio Equipment CISPR Comite International Special des Perturbations Radioelectriques RF Radio Frequency CW Continuous Wave RMS Root Mean Square DBPSK Differential BPSK Rx Receiving DC Direct Current SA, S/A Spectrum Analyzer DFS Dynamic Frequency Selection SG Signal Generator DQPSK Differe…
