ACJ9TGCF-186CF-18 Personal Computer with WLAN+BT+CDMA

Personal Computer Supplementary Instructions for CDMA This Supplementary Instructions manual points out cases where the operation of the computer will differ from that in the Operating Instructions. ® Model No.CF-18 Series Replace the “Federal Communications Commission Radio Frequency Interference Statement” ( Operating Instructions “Read Me First”) with the following. For U.S.A Names and Functions of Parts Federal Communications Commission Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the Panasonic Service Center or an experienced ra- dio/TV technician for help. Warning To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC RF Exposure Warning: • This computer is provided with PC Card slots that could be used with wireless transmitter(s), which will be specifically rec- ommended, when they become available. Other third-party wire- less transmitter(s) have not been RF exposure evaluated for use with this computer and may not comply with FCC RF expo- sure requirements. • This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. • This equipment must be installed and operated in accordance with provided instructions and minimum 1.5 cm spacing must be provided between antenna and all person’s body (exclud- ing extremities of hands, wrist and feet) during wireless modes of operation. • This equipment may use multiple installed transmitters, which may be capable of simultaneous transmission. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Responsible Party:Matsushita Electric Corporation of America One Panasonic Way Secaucus, NJ 07094 Tel No:1-800-LAPTOP-5 (1-800-527-8675) Except the followings, refer to the Operating Instructions. Antenna LED Indicators ( User Manual for Toughbook with integrated SB55 5 CDMA modem)

KYL-SUM02252004 User Manual for Toughbook with integrated SB555 CDMA modem KYL-SUM02252004 Important Notice Due to the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices are used in a normal manner with a well-constructed network, the Panasonic Toughbook computer with integrated Sierra Wireless SB555 OEM CDMA modem should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Matsushita Electric Industrial Co., Ltd. accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the Panasonic Toughbook computer, or for failure of the Panasonic Toughbook computer to transmit or receive such data. Safety and Hazards Do not operate the integrated Sierra Wireless SB555 CDMA modem in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the integrated CDMA modem MUST BE POWERED OFF. The integrated CDMA modem can transmit signals that could interfere with this equipment. Do not operate the integrated CDMA modem in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the integrated Sierra Wireless SB555 CDMA modem MUST BE POWERED OFF. Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open. Sierra Wireless modems may be used at this time. Disclaimers No part of this manual may be reproduced in any form without the prior written permission of Matsushita Electric Industrial Co., Ltd.. No patent liability is assumed with respect to the use of the information contained herein. Some of the illustrations included with the text may differ slightly in shape from the actual items in order to make the explanation easier to understand. Computers, computer devices, and manuals are subject to change without notice. Matsushita Electric Industrial Co., Ltd. assumes no liability for damage incurred directly or indirectly from errors, omissions, or discrepancies between the computer and the manuals. Trademarks - Panasonic is registered trademark of Matsushita Electric Industrial Co., Ltd.. - Sierra Wireless, the Sierra Wireless logo, and Watcher are trademarks of Sierra Wireless, Inc. - Windows® is a registered trademark of Microsoft Corporation. - Qualcomm® is a registered trademark of Qualcomm Incorporated. - InstallShield® is a registered trademark and service mark of InstallShield Corporation. - Other trademarks are the property of the respective owners. Copyright ©2004 Matsushita Electric Industrial Co., Ltd.. All rights reserved. i KYL-SUM02252004 Table of Contents Introduction ................................................................................... 1 Getting Started ................................................................................... 2 Installation ................................................................................... 3 Activation ................................................................................... 5 Using Watcher TM ................................................................................... 6 LED Indicators and Modem Specifications ................................................... 8 ii KYL-SUM02252004 1: Introduction The Sierra Wireless SB555 OEM CDMA modem is an embedded wireless modem for cellular and North American PCS networks. It enhances the functionality of your Toughbook by adding high speed wireless data service. The SB555 modem functions as a wireless network card. It allows you to connect to the Internet, send and receive e-mail, and connect to a corporate network, without the need of a network cable or phone line. The SB555 modem is designed to provide a wide range of capabilities using CDMA network technology. Implementation of these features will depend on the particular service provider and account features you have chosen. Some features described in this manual may not be supported by your service provider or may not be available with your network account. Contact your service provider for details of the services and accounts available. CDMA2000 1X services The Sierra Wireless SB555 modem operates over a type of wireless network called CDMA (Code Division Multiple Access). CDMA technology provides a variety of connectivity features, depending on your service provider and account: • Express Network SM high-speed packet data, sometimes known as 1xRTT, this supports Internet connections with data rates up to 153.6 kbps (downlink) and 76.8 kbps (uplink). Actual speed will depend on the network. • Circuit switched (dial-up) data, using the earlier CDMA IS-95 specification, supports data connections to any dial-in service at rates up to 14.4 kbps. • Quick 2 Net SM , provides a simplified way to dial into an Internet connection (using circuit switched data) where Express Network (1X) packet service is not available. (available with Verizon Wireless) • SMS (Short Message Service), allows you to send and receive short text messages using the SB555 modem. A CDMA service provider account Companies that operate CDMA networks and provide access to these networks are called service providers. You must have an account with a CDMA service provider to use the SB555 modem. Each SB555 has been provisioned at the factory for use with a particular service provider. This sets the SB555modem to use particular radio channels and enable services specific for that provider. The process of setting up your account is called activation. Activation involves action by the service provider and configuration of…

Text truncated - open the document above for the full version.

<CF-18 WLANb+g & Bluetooth & CDMA model photo> 1) CF-18 Top/Front View Top View Front View 10) Antenna position Bluetooth Antenna WLAN Left antenna (Send & Receive) WLAN Right Antenna (Receive only) WLAN Right Antenna (receive only) WLAN Left Antenna (send & receive) Antenna Magnified View Antenna cover open view CDMA Antenna Position (Pattern Antenna) 11) Antenna Specification WLAN Right Antenna: Pattern Antenna (Inverted F type: 1.42dBi max) WLAN Left Antenna: Pattern Antenna (Inverted F type: 2.59dBi max) Bluetooth Antenna: Pattern Antenna (Inverted F type: 3.54dBi max) CDMA Antenna: Pattern Antenna (Inverted-F type: 2.15dBi max)

<CF-18 WLANb+g & Bluetooth & CDMA model’s Label Description> 1) FCCID Label 2) FCC DoC Logo FCC ID: ACJ9TGCF-186 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC DoC LABEL FCC ID LABEL

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR TEST REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR.240206074.ACJ Test Dates: Feb. 19-26, 2004 EUT Type: Toughbook w/ CDMA, WLAN and Bluetooth modules FCC ID: ACJ9TGCF-186 Page 1 of 26 © 2004 PCTEST Engineering Laboratory, Inc. APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: Matsushita Electric Industrial Co., Ltd. Dates of Tests: February 13, 2004 1006 Oaza Kadoma, Kadoma, Test Report S/N: SAR.240206074.ACJ Osaka, 571 JAPAN Test Site: PCTEST Lab, Columbia, MD USA Project Number: ITPD-04-F005A FCC ID: ACJ9TGCF-186 APPLICANT NAME: Matsushita Electric Industrial Co., Ltd. EUT Type: Panasonic Toughbook w/ Intel WLAN Module FCC ID: PD9WM3B2200BG and Sierra Wireless CDMA Radio FCC ID: N7NSB555 and Alps Bluetooth Module UGXZ1-116B Tx Frequency: 824.70 – 848.31 MHz (CDMA) / 1851.25 - 1908.75 MHz (PCS) Rx Frequency: 824.70 – 848.31 MHz (CDMA) / 1851.25 – 1908.75 MHz (PCS) Max. RF Output Power: 0.224 W CDMA (23.5 dBm) Conducted 0.224 W PCS (23.5 dBm) Conducted Max. SAR Measurement: 0.07 W/kg CDMA Body Lap SAR; 0.06 W/kg PCS Body Lap SAR 1.01 W/kg CDMA Body Top SAR; 1.01 W/kg PCS Body Top SAR 0.59 W/kg CDMA Body Side SAR; 1.06 W/kg PCS Body Side SAR Trade Name/Model(s): CF-18mk2 FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: Identical Prototype [S/N: 3AKYA20526] Installed Options: WLAN Bluetooth CDMA Radio Module Other This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. P1528 D1.2 (April 2003). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST SAR TEST REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR.240206074.ACJ Test Dates: Feb. 19-26, 2004 EUT Type: Toughbook w/ CDMA, WLAN and Bluetooth modules FCC ID: ACJ9TGCF-186 Page 2 of 26 © 2004 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1. INTRODUCTION / SAR DEFINITION.................................................................................3 2. SAR MEASUREMENT SETUP.............................................................................................4 3. ALIDX-500 E-FIELD PROBE SYSTEM..................................................................................5 4. PROBE CALIBRATION PROCESS.......................................................................................6 5. PHANTOM & EQUIVALENT TISSUES................................................................................7 6. TEST SYSTEM SPECIFICATIONS.........................................................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS...............................................................9 8. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.................................................................10 9. MEASUREMENT UNCERTAINTIES...................................................................................11 10. SAR TEST DATA SUMMARY...........................................................................................12 11. SAR TEST EQUIPMENT...................................................................................................13 12. CONCLUSION...............................................................................................................14 13. REFERENCES..................................................................................................................15 EXHIBIT A. SYSTEM VERIFICATION.......................................................................................16 EXHIBIT A. SAR DATA SUMMARY.....................................................................................17-26 PCTEST SAR TEST REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR.240206074.ACJ Test Dates: Feb. 19-26, 2004 EUT Type: Toughbook w/ CDMA, WLAN and Bluetooth modules FCC ID: ACJ9TGCF-186 Page 3 of 26 © 2004 PCTEST Engineering Laboratory, Inc. 1. INTRODUCTION / SAR DEFINITION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and M…

Text truncated - open the document above for the full version.

Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2 Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2 Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2 Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2 Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2 Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2 Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2 Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2 Panasonic FCC ID: ACJ9TGCF-186 EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth Model: CF-18mk2

PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240206076.ACJ Test Dates: FEB. 19-26, 2004 EUT Type: Panasonic Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth FCC ID: ACJ9TGCF-186 Page 1 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 & 22 Certification Matsushita Electric Industrial Co., Ltd. Dates of Tests: February 19-26, 2004 1006 Oaza Kadoma, Kadoma Test Report S/N: 22/24.240206076.ACJ Osaka, 571 JAPAN Test Site: PCTEST Lab, Columbia MD Project No.: ITPD-04-F005A FCC ID ACJ9TCF-186 APPLICANT Matsushita Electric Industrial Co., Ltd. Classification: Licensed Portable Transmitter Worn on Body (PCT) FCC Rule Part(s): §24(E), §22H; §2 EUT Type: Panasonic Toughbook w/ Intel WLAN Module FCC ID: PD9WM3B2200BG, Sierra Wireless CDMA OEM Radio FCC ID: N7NSB555 AND Alps Bluetooth Module Model: UGXZ1-116B Model: CF-18mk2 Tx Frequency Range: 824.70 – 848.31MHz (CDMA) / 1851.25MHz – 1908.75MHz (PCS CDMA) Rx Frequency Range: 869.70 – 893.31MHz (CDMA) / 1931.25MHz – 1988.75MHz (PCS CDMA) Max. RF Output Power: 0.271 W ERP CDMA (24.333 dBm) / 0.377 W EIRP PCS CDMA (25.751 dBm) Max. SAR Measurement: 0.07 W/kg CDMA Body Lap SAR; 0.06 W/kg PCS Body Lap SAR; 1.01 W/kg CDMA Body Top SAR; 1.01 W/kg PCS Body Top SAR; 0.59 W/kg CDMA Body Side SAR; 1.06 W/kg PCS Body Side SAR Emission Designator(s): 1M25F9W (CDMA) Test Device Serial No. Identical Prototype [S/N: 3AKYA20526] Installed Options: WLAN Bluetooth CDMA Radio Module Other This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240206076.ACJ Test Dates: FEB. 19-26, 2004 EUT Type: Panasonic Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth FCC ID: ACJ9TGCF-186 Page 2 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-9 5.1 EFFECTIVE RADIATED POWER OUTPUT 10 6.1 EQUIVALENT ISOTROPIC RADIATED POWER 11 7.1 RADIATED MEASUREMENTS 12-17 8.1 FREQUENCY STABILITY 18-21 9.1 PLOTS OF EMISSIONS 22 10.1 LIST OF TEST EQUIPMENT 23 11.1 SAMPLE CALCULATIONS 24 12.1 CONCLUSION 25 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT Q: DIPOLE VALIDATION ATTACHMENT R: PROBE CALIBRATION PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240206076.ACJ Test Dates: FEB. 19-26, 2004 EUT Type: Panasonic Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth FCC ID: ACJ9TGCF-186 Page 3 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: Matsushita Electric Industrial Co., Ltd. Address: 1006 Oaza Kadoma, Kadoma Oaza, 571 JAPAN • FCC ID: ACJ9TGCF-186 • Quantity: Quantity production is planned • Emission Designators: 1M25F9W (CDMA) • Tx Freq. Range: 824.70 – 848.31 MHz (CDMA) 1851.25 – 1908.75 MHz (PCS CDMA) • Rx Freq. Range: 869.70 – 893.31 MHz (CDMA) 1931.25 – 1988.75 MHz (PCS CDMA) • Max. Power Rating: 0.271 W ERP CDMA (24.333 dBm) 0.377 W EIRP PCS CDMA (25.751 dBm) • FCC Classification(s): Licensed Portable Transmitter Worn on Body (PCT) • Equipment (EUT) Type: Panasonic Toughbook w/ Intel WLAN Module FCC ID: PD9WM3B2200BG, Sierra Wireless CDMA OEM Radio FCC ID: N7NSB555 and Alps Bluetooth Model: UGXZ1-116B • Modulation(s): CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): § 24(E), §22H • Dates of Tests: February 19-26, 2004 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 22/24.240206076.ACJ • Project No.: ITPD-04-F005A PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240206076.ACJ Test Dates: FEB. 19-26, 2004 EUT Type: Panasonic Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth FCC ID: ACJ9TGCF-186 Page 4 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately …

Text truncated - open the document above for the full version.

FCC CFR47 CERTIFICATION PART 22H and 24E SPURIOUS RADIATION TEST REPORT FOR 800/1900 MHZ CDMA MODULE MODEL NUMBER: SB555 FCC ID: N7NSB555 REPORT NUMBER: 02U1592-1 ISSUE DATE: November 21, 2002 Prepared for SIERRA WIRELESS, INC 13811 WIRELESS WAY RICHMOND, BC V6V 3A4 CANADA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02U1592-1 DATE: NOV 21,2002 FCC ID: N7NSB555 EUT: 800/900 MHZ CDMA MODULE Page 2 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION.................................................................................................3 2. EUT DESCRIPTION.........................................................................................................................4 3. FACILITIES, LABORATORY AND ACCREDITATION...........................................................4 3.1. FACILITIES....................................................................................................................................4 3.2. LABORATORY ACCREDITATION...................................................................................................4 3.3. LIST OF ACCREDITATIONS............................................................................................................5 4. CALIBRATION, METHODOLOGY AND UNCERTAINTY......................................................6 4.1. EQUIPMENT CALIBRATION...........................................................................................................6 4.2. TEST METHODOLOGY...................................................................................................................6 4.3. MEASUREMENT UNCERTAINTY....................................................................................................6 4.4. TEST AND MEASUREMENT EQUIPMENT.......................................................................................7 5. APPLICABLE RULES......................................................................................................................8 5.1. FIELD STRENGTH OF SPURIOUS RADIATION §2.1053.....................................................8 6. TEST SETUP, PROCEDURE AND RESULT................................................................................9 6.1. FIELD STRENGTH OF SPURIOUS RADIATION...................................................................9 7. EUT SETUP PHOTOS....................................................................................................................20 REPORT NO: 02U1592-1 DATE: NOV 21,2002 FCC ID: N7NSB555 EUT: 800/900 MHZ CDMA MODULE Page 3 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: SIERRA WIRELESS, INC. 13811 WIRELESS WAY RICHMOND, BC V6V 3A4 CANADA EUT DESCRIPTION: 800/1900MHZ CDMA MODULE MODEL NUMBER: SB555 DATE TESTED: OCTOBER 21 & NOVEMBER 19, 2002 TYPE OF EQUIPMENT INTENTIONAL RADIATOR EQUIPMENT TYPE CDMA MODULE MEASUREMENT PROCEDURE ANSI 63.4 / 1992, TIA/EIA 603 PROCEDURE CERTIFICATION FCC RULE CFR 47 PART 22 Subpart H and 24 Subpart E Only the radiated spurious emissions are documented in this test report; other requirements (antenna port conducted measurements) are documented separately by Sierra Wireless. Subject to this scope, Compliance Certification Services, Inc. tested the above equipment for compliance with the requirement set forth in CFR 47, PART 22 Subpart H-Cellular Radiotelephone Service and 24 Subpart E-Broadband PCS. The equipment in the configuration described in this report, shows the measured emission levels emanating from the equipment do not exceed the specified limit. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Tested By: Approved and Released For CCS By: FRANK IBRAHIM THU CHAN EMC ENGINEER SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 02U1592-1 DATE: NOV 21,2002 FCC ID: N7NSB555 EUT: 800/900 MHZ CDMA MODULE Page 4 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. EUT DESCRIPTION SB555 Embedded Modem is a dual-band wireless modem supporting both the 800 MHz cellular and 1900 MHz PCS bands. 3. FACILITIES, LABORATORY AND ACCREDITATION 3.1. Facilities The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F Monterey Road, Morgan Hill, California, USA. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 16. 3.2. Laboratory Accreditation The laboratory and associated test faciliti…

Text truncated - open the document above for the full version.

 2002 Sierra Wireless, Inc. This document contains information which is proprietary and confidential to Sierra Wireless, Inc. Disclosure to persons other than the officers, employees, agents, or subcontractors of the Company or licensee of this document without the prior written permission of Sierra Wireless, Inc. is strictly prohibited. FCC Part 22 and 24 800/1900 MHz CDMA DUAL BAND MODULE Model: SB555-S FCC ID: N7NSB555 Prepared by SIERRA WIRELESS INC. 13811 WIRELESS WAY RICHMOND, BC V6V 3A4 CANADA Test Date(s): September 2002 SIERRA…

Text truncated - open the document above for the full version.
