ACJ9TGCF-27GPRSGSM/GPRS for Notebook Computer

PCPD-01-F016 FCC ID: ACJ9TGCF-27GPRS INSTRUCTIONS MANUAL FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Responsible Party: Matsushita Electric Corporation of America One Panasonic Way Secaucus, NJ 07094 Tel No: 1-800-LAPTOP-5 (1-800-527-8675) Notebook Computer Operating Instructions will include following type user information regarding RF exposure when provided when GSM Module TX FCC ID: ACJ9TGCF-27GPRS: Caution - To comply with FCC RF Exposure Requirements: • Maintain minimum 2.2 cm spacing between computer mounted antenna and person’s body during wireless mode of operation. • This computer is provided with PCMCIA slots that could be used with wireless transmitters, which will be specifically recommended, when they become available. Other third-party wireless transmitters have not been RF exposure evaluated for use with this computer and may not comply with FCC RF exposure requirements.

PCPD-01-F106 FCC ID: ACJ9TG-27GPRS INSTRUCTION MANUAL FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Warning: To assure continued compliance, use only shielded interface cables when connecting computer to peripheral devices. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Responsible Party: Matsushita Electric Corporation of America One Panasonic Way Secaucus, NJ 07094 Tel No: 1-800-LAPTOP-5 (1-800-527-8675) Notebook Computer Operating Instructions will include the following type user information regarding RF exposure when provided with GSM Module TX FCC ID: ACJ9TGCF-27GPRS: Caution - To comply with FCC RF Exposure Requirements: • Maintain minimum 2.2 cm spacing between computer mounted antenna and person’s body during wireless mode of operation. • Optional vehicle mounted antenna must not exceed 3 dBi antenna gain and should be professionally installed. Maintain minimum 20 cm spacing between vehicle mounted antenna and person’s body during wireless mode of operation. • This computer is provided with PCMCIA slots that could be used with wireless transmitters, which will be specifically recommended, when they become available. Other third-party wireless transmitters have not been RF exposure evaluated for use with this computer and may not comply with FCC RF exposure requirements.

confidential © This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. Functional description Figure Figure 11 :: Functional architectureFunctional architecture SIM Controller Battery Management Power Supply G E N E R A L P U R P O S E C O N N E C T O R SIM Supply FLASH SRAM Audio Interface A/D Converter RF F U N C T I O N S CPU Vocoder GPSI or SPI Controller Memory Management Unit Keyboard Controller UART RF Interface I/O Controller R.T.C RF C O N N E C T I O N

© 2001 PCTEST Lab ATTACHMENT E — EXTERNAL PHOTOGRAPHS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS

PCPD-01-F016 FCC ID: ACJ9TGCF-27GPRS Notebook Computer’s DoC label and internal module TX FCC ID label appears on the external bottom enclosure of Notebook Computer. Panasonic Notebook Computer, Model CF-27 Series Contains GSM Module Model CF-27GPRS / TX FCC ID: ACJ9TGCF-27GPRS

© 2001 PCTEST Lab ATTACHMENT F — INTERNAL PHOTOGRAPHS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS

WISMO2C-2 Hardware Specifications confidential © Page : 1 / 69 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. Version : 1.0 Date : 11 th August 2000 Référence : WM_MKT_WISMO2C-2_HSP_001_001 WISMO2C-2 Hardware Specifications 11/08/00 confidential © Page : 2 / 69 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. Level/ Indice Date/ Date History of the evolution / Historique des évolutions Writer / Rédacteur 0.106/05/99 CreationJMB 0.216/06/99 Connector ModificationsJMB 0.318/06/99 SIM UpdatePBE 0.402/08/99 SPK load updatePJS 0.512/08/99 SIM and connector updatePBE 0.615/09/99 Battery connection exampleJMB Boot resistor modification SIM max current update 0.723/09/99 General UpdatePBE 0.827/12/99 Validation LGI/DMA/PJS/PBE 0.910/04/00 Modification of Mechanical DrawingsPJS 1.007/00Rework of the documentMNA Name / NomFunction / Fonction Date/ Date Signature/ Signature Written by / Rédigé par M.NAUProduct Line Manager07/00 Validated by / Validé par P.BECHEHardware Department Manager Approved by / Approuvé par P.CALVEZProduct Marketing Senior Manager WISMO2C-2 Hardware Specifications 11/08/00 confidential © Page : 3 / 69 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable. Contents / Sommaire 1Introduction ................................................................................... 6 1.1Scope ..................................................................................................... 6 2General description ........................................................................ 7 2.1General information ................................................................................ 7 2.2RF functionalities .................................................................................... 8 2.3Baseband functionalities......................................................................... 8 2.4Firmware ................................................................................................ 8 3Interfaces ....................................................................................... 9 3.1Functional description ............................................................................ 9 3.2General Purpose Connector (GPC)......................................................... 10 3.2.1 Power supply........................................................................................ 10 3.2.2 Digital I/O.............................................................................................. 14 3.2.3 LCD interface........................................................................................ 14 3.2.4 SPI Auxiliar bus .................................................................................... 15 3.2.5 Keyboard interface ................................................................................ 16 3.2.6 Serial link .............................................................................................. 17 3.2.7 SIM interface ........................................................................................ 18 3.2.8 General Purpose Input/Output............................................................... 21 3.2.9 Analog to Digital Converter ................................................................... 22 3.2.10Audio .............................................................................................. 23 3.2.11Battery charging interface ............................................................... 32 3.2.12ON / ~OFF....................................................................................... 35 3.2.13BOOT.............................................................................................. 38 3.2.14Reset signal (~RST) ........................................................................ 39 3.2.15External Interrupt (~INTR) ............................................................... 41 3.2.16VCC output ..................................................................................... 42 3.2.17VCC_RTC (Real Time Clock) ............................................................. 42 3.3RF interface .......................................................................................... 44 3.3.1 RF connection....................................................................................... 45 3.3.2 RF performances................................................................................... 47 3.3.3 Antenna specifications.......................................................................... 48 4Technical specifications............................................................... 49 4.1Interfaces.............................................................................................. 49 4.2Climatic and mechanical environments................................................. 52 4.3Mechanical specifications ..................................................................... 53 4.3.1 Physical characteristics......................................................................... 53 4.3.2 Mechanical drawings ........................................................................... 53 WISMO2C-2 Hardware Specifications 11/08/00 confidential © Page : 4 / 69 This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exlcusive de WAVECOM. Il…

Text truncated - open the document above for the full version.

© 2001 PCTEST Lab ATTACHMENT L — SAR MEASUREMENT REPORT © 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Matsushita Electric Industrial Co., Ltd. Dates of Tests: July 23-24, 2001 1006 Oaza Kadoma Test Report S/N: SAR.210716441.ACJ Kadoma, Osaka 571 JAPAN Test Site: PCTEST Lab, Columbia, MD USA Attention: K. Nishikawa (MEICL) Richard Mullen (PSCD, MECA) FCC ID ACJ9TGCF-27GPRS APPLICANT MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. EUT Type: Notebook PC w/ GSM PCS Module (AMPS/CDMA) Frequency Range: Tx: 1850.2 — 1909.8MHz (GSM) Rx: 1930.2 — 1989.8MHz (GSM) Max. RF Output Power: 1.03 Watts EIRP (30.15 dBm) Trade Name/Model(s): Tough Book CF-27GPRS FCC Classification: Licensed Portable Transmitter Application Type: Certification Serial Number: n/a (pre production) FCC Rule Part(s): 2.1093; ET Docket 96.326; 24(E); 22(H) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210716441.ACJ SAR Measurement Report FCC Part 24 Certification © 2001 PCTEST Lab i Table of Contents 1.1 SCOPE 1 2.1 INTRODUCTION / SAR DEFINITION 2 3.1 SAR MEASUREMENT SET-UP 3 4.1 E-FIELD PROBE SYSTEM 4 5.1 E-FIELD PROBE CALIBRATION PROCESS 5-6 6.1 PHANTOM, HOLDER, & EQUIVALENT TISSUE 7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS 9 9.1 TEST POSITION OF THE PHONE 10 10.1 BODY SAR TEST SETUP 11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS 12 12.1 MEASUREMENT UNCERTAINTIES 13 13.1 TEST DATA SUMMARY 14 14.1 SAR TEST EQUIPMENT LIST 15 15.1 CONCLUSION 16 16.1 REFERENCES 17 Test Report S/N: SAR.210716441.ACJ SAR Measurement Report Test Date(s): July 23-24, 2001 FCC Part 24 Certification © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module 1 Panasonic FCC ID: ACJ9TGCF-27GPRS SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name: MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. Matsushita Electric Corporation of America Product Safety & Compliance Division Address: One Panasonic Way, Panazip 4B-8 Secaucus, NJ 07094 Attention: Richard Mullen • EUT Type: Notebook PC w/ GSM PCS Module • Trade Name: TOUGH BOOK • Model(s): CF-27GPRS • FCC IDENTIFIER: ACJ9TGCF-27GPRS • S/N: Pre-production • Tx Frequency: 1850.2 — 1909.8 MHz (GSM) • Rx Frequency: 1930.2 — 1989.8 MHz (GSM) • Application Type: Certification • FCC Classification: Licensed Portable Transmitter • Modulation(s): GSM • FCC Rule Part(s): § 2.1093, Docket 96-326; § 24(E); • Max. RF Output Power: 1.03 Watts EIRP (30.15 dBm) • Dates of Tests: July 23-24, 2001 • Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.210716441.ACJ 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.210716441.ACJ SAR Measurement Report Test Date(s): July 23-24, 2001 FCC Part 24 Certification © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module 2 Panasonic FCC ID: ACJ9TGCF-27GPRS 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radio frequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[4] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source. SAR values have been related to threshold levels for potential biological hazards. 2.2 SAR Definition Specific Absorption Rate (SAR) is defined as the time derivative (rate) of the incremental energy (dU) absorbed by (dissipated in) an incremental mass (dm) contained in a volume element (dV) o…

Text truncated - open the document above for the full version.

© 2001 PCTEST Lab ATTACHMENT M — SAR TEST DATA MODEL:CF-27GPRS Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Medium Parameters 1900 MHz Muscle: σ = 1.52 mho/m ε r = 53.3 ρ = 1.00 g/cm 3 Antenna Position -- In; Crest Factor 7.0 SAR (1g): 0.560 mW/g, SAR (10g): 0.404 mW/g Panasonic PC with PCS Single Mode phone Module Body SAR PCS GSM mode Channel 512 (1850.2 MHz) Conducted PWR = 30 dBm 07-23-01 SAR Tot [mW/g] 5.66E-2 2.26E-1 3.96E-1 5.66E-1 PCTEST ENGINEERING LAB., INC. MODEL:CF-27GPRS Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Medium Parameters 1900 MHz Muscle: σ = 1.52 mho/m ε r = 53.3 ρ = 1.00 g/cm 3 Antenna Position -- Out; Crest Factor 7.0 SAR (1g): 0.846 mW/g, SAR (10g): 0.596 mW/g Panasonic PC with PCS Single Mode phone Module Body SAR PCS GSM mode Channel 512 (1850.2 MHz) Conducted PWR = 30 dBm 07-23-01 SAR Tot [mW/g] 8.22E-2 3.29E-1 5.75E-1 8.22E-1 PCTEST ENGINEERING LAB., INC. MODEL:CF-27GPRS Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Medium Parameters 1900 MHz Muscle: σ = 1.52 mho/m ε r = 53.3 ρ = 1.00 g/cm 3 Antenna Position -- In; Crest Factor 7.0 SAR (1g): 0.611 mW/g, SAR (10g): 0.450 mW/g Panasonic PC with PCS Single Mode phone Module Body SAR PCS GSM mode Channel 649 (1877.6 MHz) Conducted PWR = 29.9 dBm 07-23-01 SAR Tot [mW/g] 5.79E-2 2.32E-1 4.05E-1 5.79E-1 PCTEST ENGINEERING LAB., INC. MODEL:CF-27GPRS Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Medium Parameters 1900 MHz Muscle: σ = 1.52 mho/m ε r = 53.3 ρ = 1.00 g/cm 3 Antenna Position -- Out; Crest Factor 7.0 SAR (1g): 0.848 mW/g, SAR (10g): 0.596 mW/g Panasonic PC with PCS Single Mode phone Module Body SAR PCS GSM mode Channel 649 (1877.6 MHz) Conducted PWR = 29.9 dBm 07-23-01 SAR Tot [mW/g] 8.22E-2 3.29E-1 5.75E-1 8.22E-1 PCTEST ENGINEERING LAB., INC. MODEL:CF-27GPRS Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Medium Parameters 1900 MHz Muscle: σ = 1.52 mho/m ε r = 53.3 ρ = 1.00 g/cm 3 Antenna Position -- In; Crest Factor 7.0 SAR (1g): 0.615 mW/g, SAR (10g): 0.453 mW/g Panasonic PC with PCS Single Mode phone Module Body SAR PCS GSM mode Channel 810(1909.8 MHz) Conducted PWR = 30 dBm 07-23-01 SAR Tot [mW/g] 6.02E-2 2.41E-1 4.21E-1 6.02E-1 PCTEST ENGINEERING LAB., INC. MODEL:CF-27GPRS Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Medium Parameters 1900 MHz Muscle: σ = 1.52 mho/m ε r = 53.3 ρ = 1.00 g/cm 3 Antenna Position -- Out; Crest Factor 7.0 SAR (1g): 0.820 mW/g, SAR (10g): 0.579 mW/g * Max outside Panasonic PC with PCS Single Mode phone Module Body SAR PCS GSM mode Channel 810 (1909.8MHz) Conducted PWR = 30 dBm 07-23-01 SAR Tot [mW/g] 8.13E-2 3.25E-1 5.69E-1 8.13E-1 PCTEST ENGINEERING LAB., INC.

© 2001 PCTEST Lab ATTACHMENT N — SAR TEST SETUP PHOTOGRAPHS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 Certification Matsushita Electric Industrial Co., Ltd. Dates of Tests: July 18-19, 2001 1006 Oaza Kadoma Test Report S/N: 24.210716441.ACJ Kadoma, Osaka 571 JAPAN Test Site: PCTEST Lab, MD U.S.A. Attention: K. Nawata (MEICL) Richard Mullen (PSCD, MECA) FCC ID ACJ9TGCF-27GPRS APPLICANT MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. Classification: Licensed Portable Transmitter FCC Rule Part(s): §24(E), §2 EUT Type: Notebook PC w/ GSM PCS Module Trade Name/Model(s): Tough Book CF-27GPRS Frequency Range: Tx: 1850.2 — 1909.8MHz (GSM) Rx: 1930.2 — 1989.8MHz (GSM) Max. RF Output Power: 1.03 Watts EIRP (30.15 dBm) Frequency Tolerance: 0.00025% (2.5 ppm) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in § 2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210716441.ACJ Certification © 2001 PCTEST Engineering Laboratory, Inc. FCC Part 24 TABLE OF CONTENTS ATTACHMENT A: TEST REPORT 1.1 SCOPE 1 2.1 INTRODUCTION (SITE DESCRIPTION) 2 3.1 INSERTS 3 4.1 DESCRIPTION OF TESTS 4-5 5.1 TEST DATA (Equivalent Isotropic Radiated Power) 6 6.1 TEST DATA (RADIATED) 7-9 7.1 TEST DATA (FREQUENCY STABILITY) 10-11 8.1 PLOTS OF EMISSIONS 12 9.1 LIST OF TEST EQUIPMENT 13 10.1 SAMPLE CALCULATIONS 14 11.1 CONCLUSION 15 ATTACHMENT B: TEST PLOTS ATTACHMENT C: FCC ID LABEL & LOCATION ATTACHMENT D: TEST SETUP PHOTOGRAPHS ATTACHMENT E: EXTERNAL PHOTOGRAPHS ATTACHMENT F: INTERNAL PHOTOGRAPHS ATTACHMENT G: BLOCK DIAGRAM(S) ATTACHMENT H: SCHEMATIC DIAGRAM(S) ATTACHMENT I: PARTS LIST / TUNE UP PROCEDURE ATTACHMENT J: OPERATIONAL DESCRIPTION ATTACHMENT K: USER’S MANUAL ATTACHMENT L: SAR MEASUREMENT REPORT ATTACHMENT M: SAR TEST DATA ATTACHMENT N: SAR TEST SETUP PHOTOGRAPHS © 2001 PCTEST Lab ATTACHMENT A — TEST REPORT Test Report S/N: 24.210716441.ACJ FCC Part 24 Dates of Tests: July 18-19, 2001 Certification © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module 1 Panasonic FCC ID: ACJ9TGCF-27GPRS MEASUREMENT REPORT 1.1 Scope Product Evaluation and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: Matsushita Electric Industrial Co., Ltd. Matsushita Electric Corporation of America Product Safety & Compliance Division Address: One Panasonic Way, Panazip 4B-8 Secaucus, NJ 07094 Attention: Richard Mullen • FCC ID: ACJ9TGCF-27GPRS • Trade Name(s): Tough Book • Model(s): CF-27GPRS • Quantity: Quantity production is planned • Tx Frequency Range: 1850.2 — 1909.8 MHz (GSM) • Rx Frequency Range: 1930.2 — 1989.8 MHz (GSM) • Max. RF Output Power: 1.03 Watts EIRP (30.15 dBm) • FCC Classification: Licensed Portable Transmitter • Equipment (EUT) Type: Notebook PC w/ GSM PCS Module • FCC Rule Part(s): § 24(E), §2 • Application Type: Certification • Modulation: GSM • Frequency Tolerance: ± 0.00025% (2.5 ppm) • Dates of Tests: July 18-19, 2001 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. 210716441.ACJ Test Report S/N: 24.210716441.ACJ FCC Part 24 Dates of Tests: July 18-19, 2001 Certification © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module 2 Panasonic FCC ID: ACJ9TGCF-27GPRS 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. PCTEST Lab is recognized under the National Voluntary Laboratory Accreditation Program for satisfactory compliance with criteria established in Title 15, Part 285 Code of Federal Regulations. These criteria encompass the requirements of ISO/IEC Guide 25 and the relevant requirements of ISO 9002 (ANSI/ASQC Q92-1987) as suppliers of calibration or test results. The Scope of PCTEST Accreditation are for Electromagnetic Compatibility and Telecommunications and FCC. 2.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore- Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: 24.210716441.ACJ FCC Part 24 Dates of Tests: July 18-19, 2001 Certification © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module 3 Panasonic FCC ID: ACJ9TGCF-27GPRS 3.1 INSERTS Function of Active Devices The Function of active devices is shown in Attachment J. Circuit Diagrams & Description (Confidential) The circuit diagrams & description are shown in Attachment H. …

Text truncated - open the document above for the full version.

© 2001 PCTEST Lab ATTACHMENT B — TEST PLOTS)

© 2001 PCTEST Lab ATTACHMENT D — TEST SETUP PHOTOGRAPHS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 100431-0 Panasonic FCC ID: ACJ9TGCF-27GPRS © 2001 PCTEST Lab Notebook PC w/ GSM PCS Module NVLAP Lab Code: 1004…
