Personal Computer This Supplementary Instructions manual gives you information about Bluetooth. Model No.CF-18/CF-29/CF-73 Series Read Me First........................................................................... 2 About Bluetooth ....................................................................... 3 Connecting to Bluetooth Devices ........................................... 4 Security Setting ........................................................................ 8 LIMITED USE LICENSE AGREEMENT .................................... 9 Supplementary Instructions for Bluetooth™ ENGLISH ENGLISH 2 ENGLISH Read Me First For U.S.A. Trademarks Microsoft and Windows are registered trademarks of Microsoft Corporation of the United States and/or other countries. Bluetooth is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Matsushita Electric Industrial Co., Ltd. Panasonic is a registered trademark of Matsushita Electric Industrial Co., Ltd. NOTE:NOTE provides a useful fact or helpful information. CAUTION:CAUTION indicates a condition that may result in minor or moderate injury. Windows 2000: Information for Microsoft ® Windows ® 2000 Professional users. Windows XP: Information for Microsoft ® Windows ® XP Professional or Windows ® XP Tablet PC Edition users. [Start] - [Run]:This illustration means to click [Start], then to click [Run]. (For some applications, you may need to double-click.) :Where to go for referred information. Illustrations and Terminology in this Manual Federal Communications Commission Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the Panasonic Service Center or an experienced ra- dio/TV technician for help. Warning To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC RF Exposure Warning: • This computer is provided with PC Card slots that could be used with wireless transmitter(s), which will be specifically recommended, when they become available. Other third-party wireless transmitter(s) have not been RF exposure evaluated for use with this computer and may not comply with FCC RF exposure requirements. • This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. • This equipment must be installed and operated in accordance with provided instructions and minimum 1.5 cm spacing must be provided between antenna and all person’s body (exclud- ing extremities of hands, wrist and feet) during wireless modes of operation. • This equipment may use multiple installed transmitters, which may be capable of simultaneous transmission. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Responsible Party:Matsushita Electric Corporation of America One Panasonic Way Secaucus, NJ 07094 Tel No:1-800-LAPTOP-5 (1-800-527-8675) Replace the “Federal Communications Commission Radio Frequency Interference Statement” ( Operating Instructions “Read Me First”) with the following. Information to the User This product and your Health This product, like other radio devices, emits radio frequency elec- tromagnetic energy. The level of energy emitted by this product however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones. Because this product operates within the guidelines found in radio frequency safety standards and recommendations, we believe this product is safe for use by consumers. These standards and recom- mendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situations or environments, the use of this product may be restricted by the proprietor of the building or responsible representa- tives of the organization. These situations may for example include: Using this product on board of airplanes, or In any other environment where the risk of interference to other devices or services is perceived or identified as harmful. If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use this product prior to turning on the product. Regulatory Information We are not responsible for any radio or television interference caused by unauthorized modification of this product. The correction of in- terference caused by such unauthorized modification will be the re- sponsibility of the user. We and its authorized resellers or distribu- tors are not liable for damage or violation of govern…

Text truncated - open the document above for the full version.

OPERATING INSTRUCTIONS Personal Computer Appendix LIMITED USE LICENSE AGREEMENT..........32 Hard Disk Backup Function .............................34 Hard Disk Data Erase Utility............................38 Specifications...................................................39 LIMITED WARRANTY.....................................41 Troubleshooting List of Error Codes ........................................25 Dealing with Problems (Summary).......................26 Reinstalling Software ....................................30 Operation Starting Up/Shutting Down............................16 Touch Pad (Basic Operation).............................19 Reference Manual .........................................20 Useful Information .........................................21 Getting Started Read Me First..................................................3 Names and Functions of Parts ........................9 First-time Operation ......................................11 Contents [Additional Manual] Reference Manual This manual can be accessed on your computer. Refer to page 20 on how to access the Reference Manual. Reference Manual •Read Me First •Key Combinations Reference Manual •Touch Pad •Touchscreen •Panasonic Hand Writing •Standby/Hibernation Functions •Security Measures •Computing on the Road •Battery Power •Multimedia Pocket •PC Cards •RAM Module •Port Replicator •External Display •Printer •USB Devices •Modem •LAN •Wireless LAN •Hard Disk Drive •Setup Utility Reference Manual •Technical Information •DMI Viewer •List of Error Codes •Dealing with Problems (Advanced) Appendix Getting Started Operation Troubleshooting Model No.CF-29 Series Please read these instructions carefully before using this product and save this manual for future use. XP2000 •LED Indicators 2 Getting Started Introduction Thank you for purchasing the Panasonic computer. Read the operating instructions thoroughly for proper operation of your new computer. Illustrations and Terminology in this Manual Copyright This manual is copyrighted by Matsushita Electric Industrial Co., Ltd. with all rights reserved. No part of this manual may be reproduced in any form without the prior written permission of Matsushita Electric Industrial Co., Ltd. No patent liability is assumed with respect to the use of the information contained herein. ©2003 Matsushita Electric Industrial Co., Ltd. All Rights Reserved. Disclaimer Computer specifications and manuals are subject to change without notice. Matsushita Electric Industrial Co., Ltd. assumes no liability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manuals. Trademarks Microsoft, Windows and the Windows logo are registered trademarks of Microsoft Corporation of the United States and/or other countries. PS/2 ® is a registered trademark of International Business Machines Corporation. Intel, Pentium, SpeedStep and PROSet are either registered trademarks or trademarks of Intel Corporation. Adobe ® and Acrobat ® are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. Panasonic is a registered trademark of Matsushita Electric Industrial Co., Ltd. Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective owner companies. * For the Model No., insert the 12 digit number (for example, CF-29CTKGZKM) located on the bottom of the computer. NOTE:NOTE provides a useful fact or helpful information. CAUTION:CAUTION indicates a condition that may result in minor or moderate injury. WARNING:WARNING indicates a hazard that may result in moderate or serious injury. Windows XP :Information for Microsoft ® Windows ® XP Professional users. “Windows” or “Windows XP” in this manual. Windows 2000 : Information for Microsoft ® Windows ® 2000 Professional users. “Windows” or “Windows 2000” in this manual. Enter :This illustration means to press the [Enter] key. Fn + F5 :This illustration means to press and hold the [Fn] key, then press the [F5] key. [Start] - [Run]:This illustration means to click [Start], then to click [Run]. For some applications, you may need to double- click. :Where to go for referred information. :This illustration means to refer to the Reference Manual, which is available on your computer. Refer to page 20 on how to access this manual. Some of the illustrations in this manual may differ slightly in shape from the actual items in order to make the explanation easier to understand. The “CD drive” is a description about drives, such as DVD-ROM, CD-ROM, CD-R/RW, and DVD-ROM & CD-R/RW drives. This manual covers two types of models, as distinguished by the type of LCD screen (models with touchscreen and models without touchscreen). If the user has logged on without the administrator authority, some functions may not be executable, and some screens may be not displayed as shown in this manual. If this happens, log on with the administrator authority to enable these functions. Confirm the latest information on optional products in catalogs, etc. Customer's Record Serial No. or Date of Purchase Model No.* Code No. Dealer's Name Dealer's Address 3 Getting Started Read Me First Federal Communications Commission Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipmen…

Text truncated - open the document above for the full version.

<CF-29 WLANb+g & Bluetooth & GPRS model photo> 1) CF-29 Front View Front View 2) Bluetooth module position (Rotate +90 deg Figure) Bottom View of Bluetooth Module with Daughter Board

<CF-29 WLANb+g & Bluetooth & GPRS model’s Label Description> 1) FCCID Label 2) FCC DoC Logo FCC ID: ACJ9TGCF-295 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Magnified View FCC DoC LABEL FCC ID LABEL

3) Bluetooth Module exterior photo Top View of Bluetooth Module with Bottom View of Bluetooth module with Daughter-Board Daughter-Board Top View of Bluetooth Module Bottom View of Bluetooth Module 4) Bluetooth Module Interior photo Bluetooth Module without shield 5) WLAN Card position WLAN Card Position 6) WLAN exterior photo WLAN Top View WLAN Bottom View 7) WLAN interior photo WLAN inside Top View WLAN inside Bottom View 8) GPRS module position MC46 Module Adapter Position MC46 Module Adapter Slide Position MC46 Module Adapter Top View MC46 Module Adapter Bottom View 9) GPRS Module photo MC46 Module Label Final Design MC46 Module Top View Note: Above Module Label is not final. MC46 Module Interior View MC46 Module Bottom View 10) Antenna position (WLAN) Receive only Antenna Cover Send & Receive Antenna Cover Antenna Cover Open Antenna Cover Open 11) Antenna Magnified photo (WLAN) Top View Receive only Antenna View Send & Receive Antenna View 12) Antenna position (Bluetooth) Bluetooth Antenna 13) Antenna Position (GPRS) Front View Whip Antenna I/F PWB Whip Antenna Antenna Position (Whip Antenna) 14) Antenna Specification WLAN Send & Receive Antenna: (Inverted F type: 1.86dBi max) WLAN Receive only Antenna: (Inverted F type: 2.86dBi max) Bluetooth Antenna: (Inverted F type: 1.47dBi max) GPRS Antenna: (Inverted F type: 2.15dBi max)

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.240206081-R1.ACJ Test Dates: Feb. 19, 2003 EUT Type: Panasonic Toughbook w/ Siemens GPRS Module, Intel WLAN & Bluetooth FCC ID: ACJ9TGCF-295 Page 1 of 25 © 2004 PCTEST Engineering Laboratory, Inc. APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: Matsushita Electric Industrial Co., Ltd. Dates of Tests: February 19, 2004 1006 Oaza Kadoma, Kadoma, Test Report S/N: SAR.240206081-R1.ACJ Osaka, 571 JAPAN Test Site: PCTEST Lab, Columbia, MD USA Project Number: ITPD-04-F007A FCC ID: ACJ9TGCF-295 APPLICANT NAME: Matsushita Electric Industrial Co., Ltd. EUT Type: Panasonic Toughbook CF-29mk2 w/ Siemens MC46 GPRS Module FCC ID: QIPMC46, Intel Centrino WLAN FCC ID: PD9WM3B2200BG and Alps Bluetooth Module Model: UGXZ1-116B Tx Frequency: 824.20 – 848.80 MHz (GPRS) / 1851.20 – 1909.80 MHz (PCS GPRS) Rx Frequency: 869.20 – 893.80 MHz (GPRS) / 1931.20 – 1988.80 MHz (PCS GPRS) Max. RF Output Power: 1.995 W GPRS (33.00 dBm) Conducted 0.933 W PCS GPRS (30.00 dBm) Conducted 0.056 W (WLAN WM3B2200BG) Conducted Max. SAR Measurement: 0.24 W/kg GPRS Body Lap SAR; 0.57 W/kg GPRS Top SAR; 0.10 W/kg PCS GPRS Body Lap SAR; 0.16 W/kg PCS GPRS Top SAR Trade Name/Model(s): CF-29mk2 FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: Identical Prototype [S/N: 3IKYA001097] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. P1528 D1.2 (April 2002). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.240206081-R1.ACJ Test Dates: Feb. 19, 2003 EUT Type: Panasonic Toughbook w/ Siemens GPRS Module, Intel WLAN & Bluetooth FCC ID: ACJ9TGCF-295 Page 2 of 25 © 2004 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1. INTRODUCTION / SAR DEFINITION.................................................................................3 2. SAR MEASUREMENT SETUP..............................................................................................4 3. ALIDX-500 E-FIELD PROBE SYSTEM..................................................................................5 4. PROBE CALIBRATION PROCESS.......................................................................................6 5. PHANTOM & EQUIVALENT TISSUES.................................................................................7 6. TEST SYSTEM SPECIFICATIONS.........................................................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................9 8. TEST CONFIGURATION POSITION.................................................................................10 9. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.................................................................11 10. MEASUREMENT UNCERTAINTIES...................................................................................12 11. SAR TEST DATA SUMMARY............................................................................................13 12. SAR TEST EQUIPMENT...................................................................................................14 13. CONCLUSION...............................................................................................................15 14. REFERENCES..................................................................................................................16 EXHIBIT A. SYSTEM VERIFICATION.......................................................................................17 EXHIBIT A. SAR DATA SUMMARY.........................................................................................18 EXHIBIT B. SAR TEST DATA .........................................................................................22 EXHIBIT C. SAR TEST SETUP PHOTOGRAPHS .................................................................23 EXHIBIT D. DIPOLE VALIDATION .................................................................................24 EXHIBIT E. PROBE CALIBRATION .................................................................................25 PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.240206081-R1.ACJ Test Dates: Feb. 19, 2003 EUT Type: Panasonic Toughbook w/ Siemens GPRS Module, Intel WLAN & Bluetooth FCC ID: ACJ9TGCF-295 Page 3 of 25 © 2004 PCTEST Engineering Laboratory, Inc. 1. INTRODUCTION / SAR DEFINITION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human …

Text truncated - open the document above for the full version.

CONFIDENTIAL PROPERTY OF PCTEST FREQUENCY HOPPING SPREAD SPECTRUM (FHSS), FCC RULE PART 15.247 15.230811393.AMW PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE MANUFACTURER NAME & ADDRESS: DATE & LOCATION OF TESTING: Matsushita Electric Industrial Co., Ltd. Date(s) of Tests: February 19, 2004 1006 Oaza Kadoma, Kadoma, Test Report S/N: 15.240206082.ACJ Osaka, 571 JAPAN Test Site: PCTEST Lab, Columbia, MD Project No.: ITPD-04-F007A FCC ID: ACJ9TGCF-295 APPLICANT: Matsushita Electric Industrial Co., Ltd. SUMMARY: Model No.: CF-29mk2 Equipment EUT Type: Panasonic Toughbook CF-29 w/ Alps Bluetooth Kit Module & Siemens GPRS Module Model: MC46 Max. Output Power: 0.0182 W (12.6 dBm) Conducted Frequency Range: 2402 – 2480 MHz FCC Classification: FCC Part 15 Frequency Hopping Spread Spectrum Transceiver (DSS) FCC Rule Part(s): Parts 15.247; ANSI C-63.4-2001 Installed Options: WLAN Bluetooth GPRS Radio Module Other This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4- 2001. Grant Conditions: Listed output power is conducted. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. CONFIDENTIAL PROPERTY OF PCTEST FREQUENCY HOPPING SPREAD SPECTRUM (FHSS), FCC RULE PART 15.247 Page i © 2004 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS ATTESTATION STATEMENTS......................................................................................................................................................1 1.0 INTRODUCTION..............................................................................................................................................................3 1.1 EVALUATION PROCEDURE......................................................................................................................................3 1.2 SCOPE.......................................................................................................................................................................3 1.3 PCTEST TEST LOCATION...........................................................................................................................................3 2.0 PRODUCT INFORMATION............................................................................................................................................4 2.1 EQUIPMENT DESCRIPTION.......................................................................................................................................4 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS.......................................................................................................4 3.0 DESCRIPTION OF TEST...................................................................................................................................................5 3.1 CONDUCTED EMISSIONS.........................................................................................................................................5 3.2 RADIATED EMISSIONS..............................................................................................................................................6 4.0 ANTENNA REQUIREMENTS...........................................................................................................................................7 5.0 TEST EQUIPMENT CALIBRATION DATA......................................................................................................................8 6.0 CONCLUSION.................................................................................................................................................................9 EXHIBIT A – TEST RESULTS.......................................................................................................................................................10 SUMMARY.........................................................................................................................................................................10 20DB BANDWIDTH MEASUREMENT (HANDSET).............................................................................................................11 OUTPUT POWER MEASUREMENT....................................................................................................................................14 BAND EDGE COMPLIANCE...............................................................................................................................................17 CARRIER FREQUENCY SEPARATION.................................................................................................................................18 DWELL TIME......................................................................................................................................................................19 RADIATED HARMONIC MEASUREMENTS (CONT.)...........................................................................................................20 CONDUCTED SPURIOUS MEASUREMENTS......................................................................................................................23 CONDUCTED SPURIOUS MEASUREMENTS......................................................................................................................24 CONDUCTED SPURIOUS MEASUREMENTS.................…

Text truncated - open the document above for the full version.
