ACJ9TGCF-296CF-29 Personal Computer with WLAN+BT+CDMA

Personal Computer Supplementary Instructions for CDMA This Supplementary Instructions manual points out cases where the operation of the computer will differ from that in the Operating Instructions. ® Model No.CF-29 Series Replace the “Federal Communications Commission Radio Frequency Interference Statement” ( Operating Instructions “Read Me First”) with the following. For U.S.A Names and Functions of Parts Federal Communications Commission Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the Panasonic Service Center or an experienced ra- dio/TV technician for help. Warning To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC RF Exposure Warning: • This computer is provided with PC Card slots that could be used with wireless transmitter(s), which will be specifically rec- ommended, when they become available. Other third-party wire- less transmitter(s) have not been RF exposure evaluated for use with this computer and may not comply with FCC RF expo- sure requirements. • This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. • This equipment must be installed and operated in accordance with provided instructions and minimum 1.5 cm spacing must be provided between antenna and all person’s body (exclud- ing extremities of hands, wrist and feet) during wireless modes of operation. • This equipment may use multiple installed transmitters, which may be capable of simultaneous transmission. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Responsible Party:Matsushita Electric Corporation of America One Panasonic Way Secaucus, NJ 07094 Tel No:1-800-LAPTOP-5 (1-800-527-8675) Except the followings, refer to the Operating Instructions. Antenna LED Indicators ( User Manual for Toughbook with integrated SB555 CDMA modem)

Personal Computer Supplementary Instructions for CDMA This Supplementary Instructions manual points out cases where the operation of the computer will differ from that in the Operating Instructions. ® Model No.CF-29 Series Replace the “Federal Communications Commission Radio Frequency Interference Statement” ( Operating Instructions “Read Me First”) with the following. For U.S.A Names and Functions of Parts Federal Communications Commission Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the Panasonic Service Center or an experienced ra- dio/TV technician for help. Warning To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC RF Exposure Warning: • This computer is provided with PC Card slots that could be used with wireless transmitter(s), which will be specifically rec- ommended, when they become available. Other third-party wire- less transmitter(s) have not been RF exposure evaluated for use with this computer and may not comply with FCC RF expo- sure requirements. • This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. • This equipment must be installed and operated in accordance with provided instructions and minimum 1.5 cm spacing must be provided between antenna and all person’s body (exclud- ing extremities of hands, wrist and feet) during wireless modes of operation. • This equipment may use multiple installed transmitters, which may be capable of simultaneous transmission. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Responsible Party:Matsushita Electric Corporation of America One Panasonic Way Secaucus, NJ 07094 Tel No:1-800-LAPTOP-5 (1-800-527-8675) Except the followings, refer to the Operating Instructions. Antenna LED Indicators ( User Manual for Toughbook with integrated SB555 CDMA modem)

March 4, 2004 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Dear sir/madam: Re: Request for Confidentiality We hereby request that the documentation listed below, submitted with the application for certification, be withheld from public disclosure. This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. We cite trade secrets as the reason and purpose of the request. 1. SB555 modem schematics SB555SCH_S_3C.PDF 2. SB555 Bill of Materials SB555BOM_S_3C.PDF. 3. SB555 Detailed Circuit Description SB555DCD_S_3C.PDF 4. SB555 Block Diagram SB555BLK_S_3C.PDF 5. SB555 Tune Up Procedure.pdf Sincerely, Dattesh Kumar Senior Hardware Designer Sierra Wireless Inc Comment [y1]: You probably need to change this to “certification”. Check with @Road and see what kind of application they will file. According to FCC, no equipment can be type accepted now.

<CF-29 WLANb+g & Bluetooth & CDMA model photo> 1) CF-29 Front View Front View 10) Antenna position (WLAN) Receive only Antenna Cover Send & Receive Antenna Cover Antenna Cover Open Antenna Cover Open 11) Antenna Magnified photo (WLAN) Top View Receive only Antenna View Send & Receive Antenna View 12) Antenna position (Bluetooth) Bluetooth Antenna 13) Antenna Position (CDMA) Front View Whip Antenna I/F PWB Whip Antenna Antenna Position (Whip Antenna) 14) Antenna Specification WLAN Send & Receive Antenna: (Inverted F type: 1.86dBi max) WLAN Receive only Antenna: (Inverted F type: 2.86dBi max) Bluetooth Antenna: (Inverted F type: 1.47dBi max) CDMA Antenna: (Inverted F type: 2.15dBi max)

<CF-29 WLANb+g & Bluetooth & CDMA model’s Label Description> 1) FCCID Label 2) FCC DoC Logo FCC ID: ACJ9TGCF-296 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Magnified View FCC DoC LABEL FCC ID LABEL

<CF-29 WLANb+g & Bluetooth & CDMA model photo> 1) CF-29 Front View Front View 2) Bluetooth module position (Rotate +90 deg Figure) Bottom View of Bluetooth Module with Daughter Board 3) Bluetooth Module exterior photo Top View of Bluetooth Module with Bottom View of Bluetooth module with Daughter-Board Daughter-Board Top View of Bluetooth Module Bottom View of Bluetooth Module 4) Bluetooth Module Interior photo Bluetooth Module without shield 5) WLAN Card position WLAN Card Position 6) WLAN exterior photo WLAN Top View WLAN Bottom View 7) WLAN interior photo WLAN inside Top View WLAN inside Bottom View 8) CDMA module position SB555 Module Adapter Position SB555 Module Adapter Slide Position SB555 Module Adapter View-1 SB555 Module Adapter View-2 9) CDMA Module photo SB555 Module Top View SB555 module Bottom View SB555 Module Interior Top View SB555 Module Interior Bottom View 10) Antenna position (WLAN) Receive only Antenna Cover Send & Receive Antenna Cover Antenna Cover Open Antenna Cover Open 11) Antenna Magnified photo (WLAN) Top View Receive only Antenna View Send & Receive Antenna View 12) Antenna position (Bluetooth) Bluetooth Antenna 13) Antenna Position (CDMA) Front View Whip Antenna I/F PWB Whip Antenna Antenna Position (Whip Antenna) 14) Antenna Specification WLAN Send & Receive Antenna: (Inverted F type: 1.86dBi max) WLAN Receive only Antenna: (Inverted F type: 2.86dBi max) Bluetooth Antenna: (Inverted F type: 1.47dBi max) CDMA Antenna: (Inverted F type: 2.15dBi max)

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR TEST REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR.240206085.ACJ Test Dates: Feb., 13, 2004 EUT Type: Toughbook w/ Dual-Band CDMA, WLAN and Bluetooth modules FCC ID: ACJ9TGCF-296 Page 1 of 24 © 2004 PCTEST Engineering Laboratory, Inc. APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: Matsushita Electric Industrial Co., Ltd. Dates of Tests: February 13, 2004 1006 Oaza Kadoma, Kadoma, Test Report S/N: SAR.240206085.ACJ Osaka, 571 JAPAN Test Site: PCTEST Lab, Columbia, MD USA Project Number: ITPD-04-F008A FCC ID: ACJ9TGCF-296 APPLICANT NAME: Matsushita Electric Industrial Co., Ltd. EUT Type: Panasonic Toughbook w/ Intel WLAN Module FCC ID: PD9WM3B2200BG and Sierra Wireless CDMA Radio FCC ID: N7NSB555 and Alps Bluetooth Module UGXZ1-116B Tx Frequency: 824.70 – 848.31 MHz (CDMA) / 1851.25 - 1908.75 MHz (PCS) Rx Frequency: 824.70 – 848.31 MHz (CDMA) / 1851.25 – 1908.75 MHz (PCS) Max. RF Output Power: 0.224 W CDMA (23.5 dBm) Conducted 0.224 W PCS (23.5 dBm) Conducted Max. SAR Measurement: 0.04 W/kg CDMA Body Lap SAR; 0.29 W/kg CDMA Body Top SAR 0.03 W/kg PCS Body Lap SAR; 0.20 W/kg PCS Body Top SAR Trade Name/Model(s): CF-29mk2 FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: Identical Prototype [S/N: 3JKSA00051] Installed Options: WLAN Bluetooth CDMA Radio Module Other This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. P1528 D1.2 (April 2003). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST SAR TEST REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR.240206085.ACJ Test Dates: Feb., 13, 2004 EUT Type: Toughbook w/ Dual-Band CDMA, WLAN and Bluetooth modules FCC ID: ACJ9TGCF-296 Page 2 of 24 © 2004 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1. INTRODUCTION / SAR DEFINITION.................................................................................3 2. SAR MEASUREMENT SETUP..............................................................................................4 3. ALIDX-500 E-FIELD PROBE SYSTEM..................................................................................5 4. PROBE CALIBRATION PROCESS.......................................................................................6 5. PHANTOM & EQUIVALENT TISSUES.................................................................................7 6. TEST SYSTEM SPECIFICATIONS.........................................................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................9 8. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.................................................................10 9. MEASUREMENT UNCERTAINTIES...................................................................................11 10. SAR TEST DATA SUMMARY............................................................................................12 11. SAR TEST EQUIPMENT...................................................................................................13 12. CONCLUSION...............................................................................................................14 13. REFERENCES..................................................................................................................15 EXHIBIT A. SYSTEM VERIFICATION.......................................................................................16 EXHIBIT A. SAR DATA SUMMARY....................................................................................17-24 PCTEST SAR TEST REPORT FCC Measurement Report Reviewed by: Quality Manager SAR Filename: SAR.240206085.ACJ Test Dates: Feb., 13, 2004 EUT Type: Toughbook w/ Dual-Band CDMA, WLAN and Bluetooth modules FCC ID: ACJ9TGCF-296 Page 3 of 24 © 2004 PCTEST Engineering Laboratory, Inc. 1. INTRODUCTION / SAR DEFINITION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biologica…

Text truncated - open the document above for the full version.

Panasonic FCC ID: ACJ9TGCF-296 Notebook EUT Photographs © 2004 PCTEST Lab. PC w/ Alps Bluetooth & Sierra CDMA Radio Module Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-296 Notebook EUT Photographs © 2004 PCTEST Lab. PC w/ Alps Bluetooth & Sierra CDMA Radio Module Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-296 Notebook EUT Photographs © 2004 PCTEST Lab. PC w/ Alps Bluetooth & Sierra CDMA Radio Module Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-296 Notebook EUT Photographs © 2004 PCTEST Lab. PC w/ Alps Bluetooth & Sierra CDMA Radio Module Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-296 Notebook EUT Photographs © 2004 PCTEST Lab. PC w/ Alps Bluetooth & Sierra CDMA Radio Module Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-296 Notebook EUT Photographs © 2004 PCTEST Lab. PC w/ Alps Bluetooth & Sierra CDMA Radio Module Model: CF-29mk2

CMD80 Base Station Simulator Screen Shots for Maintenance of Max Power Cellular CDMA PCS CDMA Channel 1013 Channel 25 Channel 363 Channel 600 Channel 777 Channel 1175

PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240206087.ACJ Test Dates: FEB. 13, 2004 EUT Type: Panasonic Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth FCC ID: ACJ9TGCF-296 Page 1 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 & 22 Certification Matsushita Electric Industrial Co., Ltd. Dates of Tests: February 13, 2004 1006 Oaza Kadoma, Kadoma Test Report S/N: 22/24.240206087.ACJ Osaka, 571 JAPAN Test Site: PCTEST Lab, Columbia MD Project No.: ITPD-04-F008A FCC ID ACJ9TCF-296 APPLICANT Matsushita Electric Industrial Co., Ltd. Classification: Licensed Portable Transmitter Worn on Body (PCT) FCC Rule Part(s): §24(E), §22H; §2 EUT Type: Panasonic Toughbook w/ Intel WLAN Module FCC ID: PD9WM3B2100, Sierra Wireless CDMA OEM Radio FCC ID: N7NSB555 AND Alps Bluetooth Module Model: UGXZ1-116B Model: CF-29mk2 Tx Frequency Range: 824.70 – 848.31MHz (CDMA) / 1851.25MHz – 1908.75MHz (PCS CDMA) Rx Frequency Range: 869.70 – 893.31MHz (CDMA) / 1931.25MHz – 1988.75MHz (PCS CDMA) Max. RF Output Power: 0.231 W ERP CDMA (23.633 dBm) / 0.352 W EIRP PCS CDMA (25.451 dBm) Max. SAR Measurement: 0.04W/kg CDMA Lap SAR; 0.29W/kg CDMA Top SAR; 0.03W/kg PCS CDMA Lap SAR; 0.20W/kg PCS CDMA Top SAR Emission Designator(s): 1M25F9W (CDMA) Test Device Serial No. Identical Prototype [S/N: 3JKSA00051 ] Installed Options: WLAN Bluetooth CDMA Radio Module Other This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240206087.ACJ Test Dates: FEB. 13, 2004 EUT Type: Panasonic Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth FCC ID: ACJ9TGCF-296 Page 2 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-9 5.1 EFFECTIVE RADIATED POWER OUTPUT 10 6.1 EQUIVALENT ISOTROPIC RADIATED POWER 11 7.1 RADIATED MEASUREMENTS 12-17 8.1 FREQUENCY STABILITY 18-21 9.1 PLOTS OF EMISSIONS 22 10.1 LIST OF TEST EQUIPMENT 23 11.1 SAMPLE CALCULATIONS 24 12.1 CONCLUSION 25 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT Q: DIPOLE VALIDATION ATTACHMENT R: PROBE CALIBRATION PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240206087.ACJ Test Dates: FEB. 13, 2004 EUT Type: Panasonic Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth FCC ID: ACJ9TGCF-296 Page 3 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: Matsushita Electric Industrial Co., Ltd. Address: 1006 Oaza Kadoma, Kadoma Oaza, 571 JAPAN • FCC ID: ACJ9TGCF-296 • Quantity: Quantity production is planned • Emission Designators: 1M25F9W (CDMA) • Tx Freq. Range: 824.70 – 848.31 MHz (CDMA) 1851.25 – 1908.75 MHz (PCS CDMA) • Rx Freq. Range: 869.70 – 893.31 MHz (CDMA) 1931.25 – 1988.75 MHz (PCS CDMA) • Max. Power Rating: 0.231 W ERP CDMA (23.633 dBm) 0.352 W EIRP PCS CDMA (25.451 dBm) • FCC Classification(s): Licensed Portable Transmitter Worn on Body (PCT) • Equipment (EUT) Type: Panasonic Toughbook w/ Intel WLAN Module FCC ID: PD9WM3B2200BG, Sierra Wireless CDMA OEM Radio FCC ID: N7NSB555 and Alps Bluetooth Model: UGXZ1-116B • Modulation(s): CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): § 24(E), §22H • Dates of Tests: February 13, 2004 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 22/24.240206087.ACJ • Project No.: ITPD-04-F008A PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 22/24.240206087.ACJ Test Dates: FEB. 13, 2004 EUT Type: Panasonic Toughbook w/ Sierra OEM Radio, WLAN & Bluetooth FCC ID: ACJ9TGCF-296 Page 4 of 25 © 2004 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of …

Text truncated - open the document above for the full version.

 2002 Sierra Wireless, Inc. This document contains information which is proprietary and confidential to Sierra Wireless, Inc. Disclosure to persons other than the officers, employees, agents, or subcontractors of the Company or licensee of this document without the prior written permission of Sierra Wireless, Inc. is strictly prohibited. FCC Part 22 and 24 800/1900 MHz CDMA DUAL BAND MODULE Model: SB555-S FCC ID: N7NSB555 Prepared by SIERRA WIRELESS INC. 13811 WIRELESS WAY RICHMOND, BC V6V 3A4 CANADA Test Date(s): September 2002 SIERRA WIRELESS, INC. FCC Part 22 & 24 Test Report SB555-S Sept 2002 Page 2 of 43 Table of Contents 1 Introduction and Purpose.........................................................................3 2 Test Summary..........................................................................................3 3 Product Description.................................................................................4 4 Test Configuration...................................................................................5 5 RF Power Output.....................................................................................6 5.1 Test Procedure....................................................................................................6 5.2 Test Equipment.................................................................................................... 6 5.3 Test Results.........................................................................................................7 6 Occupied Bandwidth..............................................................................14 6.1 Test Procedure..................................................................................................14 6.2 Test Equipment.................................................................................................. 14 6.3 Test Results.......................................................................................................14 7 Out of Band Emissions at Antenna Terminals......................................17 7.1 Test Procedure..................................................................................................17 7.2 Test Equipment.................................................................................................. 17 7.3 Test Results.......................................................................................................18 8 Frequency Stability vs Temperature......................................................40 8.1 Test Procedure..................................................................................................40 8.2 Test Equipment.................................................................................................. 40 8.3 Test Results.......................................................................................................41 9 Frequency Stability vs Voltage..............................................................42 9.1 Test Procedure..................................................................................................42 9.2 Test Equipment.................................................................................................. 43 9.3 Test Results.......................................................................................................43  2002 Sierra Wireless, Inc. The contents of this page are subject to the confidentiality information on page one. SIERRA WIRELESS, INC. FCC Part 22 & 24 Test Report SB555-S Sept 2002 Page 3 of 43 1 Introduction and Purpose This document provides the FCC test data for the SB555-S module. The tests included in this report are limited to all conducted tests required. Other radiated tests were performed at an external test facility. 2 Test Summary FCC RULE DESCRIPTION OF TEST RESULT PAGE 2.1046 RF Power Output Complies 6 2.1049 Occupied Bandwidth Complies 15 2.1051, 22.901(d) 22.917(f), 24.238(a) Out of Band Emissions at Antenna Terminals Mobile Emissions In Base Frequency Range Complies 18 2.1053 Field Strength of Spurious Radiation Complies See CCS Report 2.1055 Frequency Stability vs Temperature Complies 44 2.1055 Frequency Stability vs Voltage Complies 45 The tests described in this report were performed by Mr. Sean Hoare, under the supervision of Mr Ron Vanderhelm, P.Eng. at Sierra Wireless, Inc. 13811 Wireless Way Richmond, B.C. V6V 3A4 Canada  2002 Sierra Wireless, Inc. The contents of this page are subject to the confidentiality information on page one. SIERRA WIRELESS, INC. FCC Part 22 & 24 Test Report SB555-S Sept 2002 Page 4 of 43 3 Product Description The Sierra Wireless Inc. model SB555-S is a dual band CDMA embedded modem. EUT Type Cellular and PCS CDMA Embedded Modem Whether quantity(>1) production is planned [X] Yes [ ]No Standards CDMA2000 Types of Emission 1M25F9W RF Output Power 824-849 MHz: 23.5 dBm max 1850-1910 MHz: 23.5 dBm max In both bands, power is variable to –50 dBm. Frequency Range 824-849 MHz, 1850-1910 MHz  2002 Sierra Wireless, Inc. The contents of this page are subject to the confidentiality information on page one. SIERRA WIRELESS, INC. FCC Part 22 & 24 Test Report SB555-S Sept 2002 Page 5 of 43 4 Test Configuration Tests were performed on the radio module alone. For frequency stability versus temperature, testing the module requires a wider range of temperature at the higher extreme to account for the insulating and warming affects of the end-user device. We test up to 70 degrees C for the module alone rather than just 50 deg C for the module in the end user device. For the effect of variation of DC power supply on frequency stability, the DC supply to the module was varied to the extremes of its specified voltage range, 3.15 to 4.2 volts. Item # Description Model No. Serial No. 1 Module EUT SB555-S E0207135003503C  2002 Sierra Wireless, Inc. The contents of this page are subject to the confidentiality information on page one. SIERRA WIRELESS, INC. FCC Part 22 & 24 Test Report S…

Text truncated - open the document above for the full version.

Plot 1.1 Cellular Band (Middle Channel) Plot 1.2 PCS Band (High Channel)

FCC CFR47 CERTIFICATION PART 22H and 24E SPURIOUS RADIATION TEST REPORT FOR 800/1900 MHZ CDMA MODULE MODEL NUMBER: SB555 FCC ID: N7NSB555 REPORT NUMBER: 02U1592-1 ISSUE DATE: November 21, 2002 Prepared for SIERRA WIRELESS, INC 13811 WIRELESS WAY RICHMOND, BC V6V 3A4 CANADA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02U1592-1 DATE: NOV 21,2002 FCC ID: N7NSB555 EUT: 800/900 MHZ CDMA MODULE Page 2 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel …
