Personal Computer Supplementary Instructions for CDMA This Supplementary Instructions manual points out cases where the operation of the computer will differ from that in the Operating Instructions. ® Model No.CF-29 Series Replace the “Federal Communications Commission Radio Frequency Interference Statement” ( Operating Instructions “Read Me First”) with the following. For U.S.A Names and Functions of Parts Federal Communications Commission Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the Panasonic Service Center or an experienced ra- dio/TV technician for help. Warning To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC RF Exposure Warning: • This computer is provided with PC Card slots that could be used with wireless transmitter(s), which will be specifically rec- ommended, when they become available. Other third-party wire- less transmitter(s) have not been RF exposure evaluated for use with this computer and may not comply with FCC RF expo- sure requirements. • This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. • This equipment must be installed and operated in accordance with provided instructions and minimum 1.5 cm spacing must be provided between antenna and all person’s body (exclud- ing extremities of hands, wrist and feet) during wireless modes of operation. • This equipment may use multiple installed transmitters, which may be capable of simultaneous transmission. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Responsible Party:Matsushita Electric Corporation of America One Panasonic Way Secaucus, NJ 07094 Tel No:1-800-LAPTOP-5 (1-800-527-8675) Except the followings, refer to the Operating Instructions. Antenna LED Indicators ( User Manual for Toughbook with integrated SB555 CDMA modem)

April 14, 2003 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Dear sir/madam: Re: Request for Confidentiality We hereby request that the documentation listed below, submitted with the application for certification, be withheld from public disclosure. This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. We cite trade secrets as the reason and purpose of the request. 1. SB555 Modem Schematics SB555SCH_S_3C.PDF 2. SB555 Bill of Materials SB555BOM_S_3C.PDF. 3. SB555 Detailed Circuit Description SB555DCD_S_3C.PDF 4. SB555 Block Diagram SB555BLK_S_3C.PDF 5. SB555 Tune Up Procedure.pdf Sincerely, Dattesh Kumar Senior Hardware Designer Sierra Wireless, Inc.

August 23, 2004 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Matsushita Electric Industrial Co., Ltd. FCC ID: ACJ9TGCF-29A 731 Confirmation No.: TC205773 Correspondence Reference No.: 13493 Request for Tech. Info.: 08/13/04 Dear Martin: Transmitted herewith, on behalf of Matsushita Electric Industrial Co., Ltd. is an amendment provided in response to the request for technical information dated August 13, 2004. 1. Please find that we have revised the equipment class on the FCC Grant to read PCB. 2. The for informational only SAR report has been deleted from the application. 3. We have uploaded the missing EMC Report for FCC ID: ACJ9TGCF-29A. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: Matsushita Electric Industrial Co., Ltd.

Panasonic FCC ID: ACJ9TGCF-29A EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio & WLAN Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-29A EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio & WLAN Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-29A EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio & WLAN Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-29A EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio & WLAN Model: CF-29mk2

Panasonic FCC ID: ACJ9TGCF-29A EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio & WLAN Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-29A EUT Photographs © 2004 PCTEST Lab. Toughbook w/ Sierra OEM Radio & WLAN Model: CF-29mk2

Spread Spectrum Transceiver (DSS), FCC Rule Part 15.247 PCTEST LAB TEST REPORT 15.247 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 15. 240603345.ACJ Test Dates: Feb. 19-21, 2004 EUT Type: Panasonic Notebook PC w/ CDMA & WLAN FCC ID: ACJ9TGCF-29A Page 40 of 47 © 2004 PCTEST Engineering Laboratory, Inc. CONFIDENTIAL PROPERTY OF PCTEST EXHIBIT B – Labeling Requirements Sample Label & Location New Labeling Requirements Per 2.1074 & 15.19; Docket 95-19 The sample label shown below shall be permanently affixed at a conspicuous location on the device; instruction manual or pamphlet supplied to the user and be readily visible to the purchaser at the time of purchase. However, when the device is so small wherein placement of the label with specified statement is not practical, only the trade name, FCC ID, and the FCC logo must be displayed on the device per Section 15.19 (b)(2). EXHIBIT B – Labeling Requirements (Cont.) Spread Spectrum Transceiver (DSS), FCC Rule Part 15.247 PCTEST LAB TEST REPORT 15.247 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 15. 240603345.ACJ Test Dates: Feb. 19-21, 2004 EUT Type: Panasonic Notebook PC w/ CDMA & WLAN FCC ID: ACJ9TGCF-29A Page 41 of 47 © 2004 PCTEST Engineering Laboratory, Inc. CONFIDENTIAL PROPERTY OF PCTEST Sample Label & Location FCC ID Label

5) WLAN Card position WLAN Card Position 6) WLAN exterior photo WLAN Top View WLAN Bottom View 7) WLAN interior photo WLAN inside Top View WLAN inside Bottom View 8) CDMA module position SB555 Module Adapter Position SB555 Module Adapter Slide Position SB555 Module Adapter View-1 SB555 Module Adapter View-2 9) CDMA Module photo SB555 Module Top View SB555 module Bottom View SB555 Module Interior Top View SB555 Module Interior Bottom View 10) Antenna position (WLAN) Receive only Antenna Cover Send & Receive Antenna Cover Antenna Cover Open Antenna Cover Open 11) Antenna Magnified photo (WLAN) Top View Receive only Antenna View Send & Receive Antenna View 13) Antenna Position (CDMA) Front View Whip Antenna I/F PWB Whip Antenna Antenna Position (Whip Antenna) 14) Antenna Specification WLAN Send & Receive Antenna: (Inverted F type: 1.86dBi max) WLAN Receive only Antenna: (Inverted F type: 2.86dBi max) CDMA Antenna: (Inverted F type: 2.15dBi max)

Panasonic FCC ID: ACJ9TGCF-29A Notebook EUT Photographs © 2004 PCTEST Lab. PC w/ WLAN & GPRS Module Model: CF-29mk2 Panasonic FCC ID: ACJ9TGCF-29A Notebook EUT Photographs © 2004 PCTEST Lab. PC w/ WLAN & GPRS Module Model: CF-29mk2

PCTEST MPE REPORT FCC CERTIFICATION REPORT REVIEWED BY: QUALITY MANAGER TEST REPORT S/N: 15.240603347.ACJ TEST DATES: Feb 13, 2004 EUT TYPE: Notebook PC w/ CDMA Module FCC ID: ACJ9TGCF-29A PAGE 1 OF 2 © 2004 PCTEST Engineering Laboratory, Inc. RF Exposure Evaluation - Maximum Permissible Exposure (MPE) 1. Introduction This document attempts to prove the safety of radiation generated by RF devices to the human body. The limit for Maximum Permissible Exposure (MPE), specified in FCC 1.1210, is listed below. The power generated by this product is measured by a power meter. Through use of the Friis transmission formula and the maximum gain of the antenna, the distance from the product at which compliance with the MPE limit is achieved may be calculated. Alternatively, near field measurements may be performed to demonstrate compliance at a specific measurement distance. Near field probe: Wandel & Goltermann EMR-20. 2. RF Exposure Limit According to FCC 1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures 30-300 61.4 .163 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B) Limits For General Population / Uncontrolled Exposure 30-300 27.5 .073 .2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. Friis Formula Friis transmission formula: Pd = (P out *G) / (4pr 2 ) Where: Pd = power density in mW/cm 2 (MPE limit) P out = output power to antenna in mW G = gain of antenna in linear scale p = 3.1416 r = distance between observation point and center of the radiator in cm Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11.133) PCTEST MPE REPORT FCC CERTIFICATION REPORT REVIEWED BY: QUALITY MANAGER TEST REPORT S/N: 15.240603347.ACJ TEST DATES: Feb 13, 2004 EUT TYPE: Notebook PC w/ CDMA Module FCC ID: ACJ9TGCF-29A PAGE 2 OF 2 © 2004 PCTEST Engineering Laboratory, Inc. 4. EUT Operating Condition Software provided by the client enabled the EUT to transmit and receive data at lowest, middle, and highest channels individually. 5. Climate Condition The temperature and relative humidity: 22°C and 78% RH 6. Measurement Results at 20 cm Channel Channel Frequency (MHz) Output Power Power Density (mW/cm 2 ) 363 835.89 .231 .073 Channel Channel Frequency (MHz) Output Power Power Density (mW/cm 2 ) 600 1880.00 .231 .073 7. Conclusion The device meets the mobile 20cm separation distance as specified in Section 2.1091 of the FCC Rules. An appropriate RF exposure compliance statement will be placed in the user’s manual.

FCC CFR47 CERTIFICATION PART 22H and 24E SPURIOUS RADIATION TEST REPORT FOR 800/1900 MHZ CDMA MODULE MODEL NUMBER: SB555 FCC ID: N7NSB555 REPORT NUMBER: 02U1592-1 ISSUE DATE: November 21, 2002 Prepared for SIERRA WIRELESS, INC 13811 WIRELESS WAY RICHMOND, BC V6V 3A4 CANADA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02U1592-1 DATE: NOV 21,2002 FCC ID: N7NSB555 EUT: 800/900 MHZ CDMA MODULE Page 2 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. TEST RESULT CERTIFICATION.................................................................................................3 2. EUT DESCRIPTION.........................................................................................................................4 3. FACILITIES, LABORATORY AND ACCREDITATION...........................................................4 3.1. FACILITIES....................................................................................................................................4 3.2. LABORATORY ACCREDITATION...................................................................................................4 3.3. LIST OF ACCREDITATIONS............................................................................................................5 4. CALIBRATION, METHODOLOGY AND UNCERTAINTY......................................................6 4.1. EQUIPMENT CALIBRATION...........................................................................................................6 4.2. TEST METHODOLOGY...................................................................................................................6 4.3. MEASUREMENT UNCERTAINTY....................................................................................................6 4.4. TEST AND MEASUREMENT EQUIPMENT.......................................................................................7 5. APPLICABLE RULES......................................................................................................................8 5.1. FIELD STRENGTH OF SPURIOUS RADIATION §2.1053.....................................................8 6. TEST SETUP, PROCEDURE AND RESULT................................................................................9 6.1. FIELD STRENGTH OF SPURIOUS RADIATION...................................................................9 7. EUT SETUP PHOTOS....................................................................................................................20 REPORT NO: 02U1592-1 DATE: NOV 21,2002 FCC ID: N7NSB555 EUT: 800/900 MHZ CDMA MODULE Page 3 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: SIERRA WIRELESS, INC. 13811 WIRELESS WAY RICHMOND, BC V6V 3A4 CANADA EUT DESCRIPTION: 800/1900MHZ CDMA MODULE MODEL NUMBER: SB555 DATE TESTED: OCTOBER 21 & NOVEMBER 19, 2002 TYPE OF EQUIPMENT INTENTIONAL RADIATOR EQUIPMENT TYPE CDMA MODULE MEASUREMENT PROCEDURE ANSI 63.4 / 1992, TIA/EIA 603 PROCEDURE CERTIFICATION FCC RULE CFR 47 PART 22 Subpart H and 24 Subpart E Only the radiated spurious emissions are documented in this test report; other requirements (antenna port conducted measurements) are documented separately by Sierra Wireless. Subject to this scope, Compliance Certification Services, Inc. tested the above equipment for compliance with the requirement set forth in CFR 47, PART 22 Subpart H-Cellular Radiotelephone Service and 24 Subpart E-Broadband PCS. The equipment in the configuration described in this report, shows the measured emission levels emanating from the equipment do not exceed the specified limit. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Tested By: Approved and Released For CCS By: FRANK IBRAHIM THU CHAN EMC ENGINEER SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 02U1592-1 DATE: NOV 21,2002 FCC ID: N7NSB555 EUT: 800/900 MHZ CDMA MODULE Page 4 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. EUT DESCRIPTION SB555 Embedded Modem is a dual-band wireless modem supporting both the 800 MHz cellular and 1900 MHz PCS bands. 3. FACILITIES, LABORATORY AND ACCREDITATION 3.1. Facilities The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F Monterey Road, Morgan Hill, California, USA. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 16. 3.2. Laboratory Accreditation The laboratory and associated test faciliti…
