ACJ9TGCF-30AToughbook CF-30 PC with WWAN, WLAN and Bluetooth

Contents Getting Started OPERATING INSTRUCTIONS Personal Computer Model No. CF-30 series Introduction ................................................................. 2 Read Me First ............................................................. 3 Description of Parts .................................................. 10 First-time Operation .................................................. 13 Useful Information On-screen Manual .................................................... 18 Handling and Maintenance ....................................... 19 Reinstalling Software ................................................ 21 Troubleshooting Troubleshooting (Basic) ............................................ 23 Appendix LIMITED USE LICENSE AGREEMENT ................... 27 Specifi cations ........................................................... 29 LIMITED WARRANTY .............................................. 32 Please read these instructions carefully before using this product and save this manual for future use. For further information about the com- puter, you can refer to the on-screen manual. To access the on-screen manual Î page 18 “On-screen Manual” Getting Started Useful Information Troubleshooting Appendix 2 Getting Started Introduction Thank you for purchasing this Panasonic computer. For optimum performance and safety, please read these instruc- tions carefully. „ Terms and illustrations in these instructions CAUTION : Conditions that may result in minor or moderate injury. NOTE : Useful and helpful information. Enter : Press [Enter] key. Fn + F5 : Press and hold [Fn] key, and then press [F5] key. (Start) - [All Programs] : Click (Start), and then click [All Programs]. [start] - [Run] : Click [start], and then click [Run]. You may need to double-click in some cases. Î : Page in these Operating Instructions or in the Reference Manual. : Reference to the on-screen manuals. z indicates Windows Vista ® Business Operating System. z indicates Microsoft ® Windows ® XP Professional Operating System. z Some illustrations are simplifi ed to help your understanding and may look different from the actual unit. z If you do not log on as an administrator, you cannot use some functions or cannot display some screens. z Refer for the latest information about optional products to the catalogs, etc. z In these instructions, the names and terms are referred as follows. y “Windows Vista ® Business” as “Windows” or “Windows Vista” y “Microsoft ® Windows ® XP Professional Service Pack 2 with Advanced Security Technologies” as “Windows”, “Win- dows XP” or “Windows XP Professional” y DVD-ROM & CD-R/RW drive and DVD MULTI drive as “CD/DVD drive” y Circular media including DVD-ROM and CD-ROM as “discs” „ Disclaimer Computer specifi cations and manuals are subject to change without notice. Panasonic Corporation assumes no li- ability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manuals. „ Trademarks Microsoft ® , Windows ® , Windows Vista, the Windows logo, and IntelliMouse are registered trademarks of Microsoft Cor- poration of the United States and/or other countries. Intel, Core, Centrino and PROSet are either registered trademarks or trademarks of Intel Corporation. SDHC Logo is a trademark. Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorpo- rated in the United States and/or other countries. Computrace ® is a registered trademark of Absolute ® Software Corp. Bluetooth™ is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Panasonic Corporation. Panasonic ® is a registered trademark of Panasonic Corporation. Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective own companies. 3 Getting Started Read Me First Models for U.S.A. Federal Communications Commission Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal- lation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interfer- ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the Panasonic Service Center or an experienced radio/TV technician for help. Warning To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral. Also, any changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. FCC RF Exposure Warning: z This computer is provided with PC Card slot that could be used with wireless transmitter(s), which will be specifi cally recommended when they become available. Other third- party wireless transmitter(s) have not been RF exposure evaluated for use with this computer and may not comply with FCC RF exposure requirements. z This computer complies with FCC radiation exposure limits set forth for an uncontrolled environment. z This computer may not be co-located or operated with any other antenna or transmitter. <For computer with installed WLAN/Bluetooth> z This PC with WLAN or/and Bluetooth transmitters installed, has been approv…

Text truncated - open the document above for the full version.

< CF-30 series Addendum for the external antenna(s) > FCC RF Exposure Warning: z This equipment is provided with external antenna connector(s) for connection to optional Car Mounter or Port Replicator for mobile external mounted antenna(s). External antenna(s) must be professionally installed and cannot exceed recommended maximum antenna gain as described in individual provided supplement instructions for wireless transmitters. The Car Mounter is provided with Radiall/Larsen WLAN whip antenna, type NMO5E2400BKTNC with 5dBi antenna gain. The maximum allowable antenna gain for the external WWAN base whip antenna for the cellular band is 2.23dBi and PCS band is 3.84dBi. Also, user must maintain minimum 20 cm spacing between external antenna(s) and all person’s body (excluding extremities of hands, wrist and feet) during wireless modes of operation.

Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7760 / Fax: 201-392-4564 [email protected] BEN BOTROS Project Manager Product Safety and Compliance Division January 23, 2009 ITPD-08-F020A Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Authority to Act as FCC Agent for Mobile Laptop Personal Computer, Model CF-30mk3 Family TCB Certification for FCC ID: ACJ9TGCF-30A • Alps Bluetooth, Model UGNZA • Intel WLAN(a/b/g/n), Model 512AN_MMW • Novatel WWAN (HSDPA3.6), Model EU860D To Whom It May Concern: On behalf of Panasonic Corp. of North America, we herby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in matters relating to FCC equipment authorization, including the signing of documents relating to these matters. Any and all acts carried out by PCTEST on our behalf shall have the same effect as acts of our own. This project represents Mobile Laptop Computer, Model CF-30mk3 Family with Intel CPU type Core2Duo SL9300 (1.60 GHz), which will be marketed under FCC ID: ACJ9TGCF-30A. This product will be marketed with the following co-located transmitters: (1) Alps Bluetooth, Model UGNZA (Alps has no FCC ID): This BT transmitter complies with FCC Part 15C under equipment class code DDS. This BT version is under specification Ver 2.0 + ERD with maximum symbol rate of 1~3Mbps. Refer to test report for exact frequency range and RF output level. (2) Intel WLAN Model 512AN_MMW (802.11a/b/g/n) (Intel FCC ID: PD9512ANM) This combined WLAN and UNII transmitters complies with FCC Parts 15C and 15E under equipment class code DTS. Refer to test report for exact frequency ranges and RF output levels. The UNII portion of this transmitter complies with Dynamic Frequency Selection (DFS) requirements in R&O FCC 03-287 as a client only device without radar detection capability and client software and associated drivers will not initiate any transmission on DFS frequencies, which includes transmissions for beacon ad-hoc peer-to- peer modes. The Intel WLAN theory of operation describes 3x3 MIMO capacity (multiple input/multiple output architecture); however, this end-product usage will be limited to 1x2 MIMO capacity (one WLAN Main TX/RX antenna). The User Manual with provide the following type wording, pursuant to §15.407(e): This PC operation within 5.15~5.25 GHz band is restricted to indoor use only to reduce any potential harmful interference to co-channel Mobile Satellite Systems. Note - Model 512AN_MMW is compatible with 802.11a/b/g/n. To enable marketing in Asia Pacific and Europe, this WLAN may have its 802.11a/n functions disabled by factory set EEPROM settings. As such, the subject PC may also be marketed with Model 512AG_MMW (802.11a/b/g) or Model 512BG_MMW (802.11b/g). (3) Novatel WWAN (HSDPA3.6), Model EU860D (Novatel FCC ID: NBZNRM-EU860D) This combined Cellular and PCS transmitter complies with FCC Parts 22H and 24E under equipment class code PCB. Refer to test report for exact frequency ranges, RF output levels and emission designators. Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201-348-7760 / Fax: 201-392-4564 [email protected] BEN BOTROS Project Manager Product Safety and Compliance Division This PC contains various internal antennas for BT, WLAN and WWAN. Refer to separate provided exhibits for antenna photos and test reports for exact antenna description, antenna gains and locations. This PC may be marketed with optional Car Mounter, Model CF-WEB291, which may contain two unique pass- thru antenna connectors on the bottom of the enclosure for connection to the optional Car Mounter Model CF-WEB291. The Car Mounter has 2 matching unique antenna passive pass-thru connectors, which are hard-wired connected to its rear panel to two external TNC antenna connectors for connection to external WLAN and/or WWAN base whip antennas. The Car Mounter is marketed to only specific non-general consumers, such as police, fire and military and must be professionally installed by following the provided mounting instructions. The Car Mounter is provided with Radiall/Larsen WLAN whip antenna, type NMO5E2400BKTNC with 5 dBi antenna gain. The Car Mounter Supplemental Instructions for this PC combination will advise that the recommended maximum external antenna gains are 5.0 dBi for WLAN at 2412~2462 MHz; 2.23 dBi for Cellular at 824.2~848.8 MHz; and 3.84 dBi for PCS at 1850.2~1908.8 MHz. In accordance with provisions of Section 0.457(d) of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request permanent confidentiality for transmitter’s exhibits, which contain Operation Description, Parts Lists, Block Diagram and Schematic Diagram. The BT and WLAN transmitters are not user adjustable and do not have a Tune-Up Procedure. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. Also, in accordance with FCC Public DA 04-1705, we request forty-five day short-term confidentiality, starting from the from the issuance of equipment authorization date, for exhibits which contain External Photographs, Internal Photographs, Test Setup Photographs and the Operating Instructions (User Manual). The requested short- term confidentiality exhibits contain pre-market information, which could give our competitors unfair advantage should this information be released before this product is actually introduced into the common marketplace. Further, we the undersigned, hereby attest to the fact that the subject product is also classified as Class B Computer and will be authorized under Declaration of Conformity to comply with FCC Part 15B to meet Class B limits. Sincerely yours, Ben Botros Ben Botros Project Manager

2. Module Position Bluetooth Module WLAN Module GPS Module Bluetooth Module GPS Module Reverse Side WWAN Module Pack Slide Position WWAN Module Pack WWAN Module 3. Module Photo 1) WLAN WLAN Top View WLAN Bottom View WLAN interior photo WLAN inside Top View WLAN inside Bottom View 2) Bluetooth Bluetooth Card Top View Bluetooth Card Bottom View Bluetooth Module inside Top View Bluetooth Module inside Bottom View 3) WWAN WWAN Module Interior Top View WWAN Module Interior Bottom View 4) GPS Module GPS Card Top View GPS Card Bottom View GPS Module inside Top View GPS Module inside Bottom View 4. Antenna Position and Antenna photo [Standard model: no WLAN pass through connector] WWAN Main TX/RX Antenna GPS RX Antenna Bluetooth TX/RX Antenna WLAN Main TX/RX Antenna WWAN RX Antenna WLAN Aux RX Antenna WLAN Main TX/RX Antenna WLAN AUX RX Antenna Bluetooth TX/RX Antenna WAN Main TX/RX Antenna WWAN Aux RX Antenna GPS RX Antenna 5. Antenna Specification [ Standard model: no WLAN pass through connector ] WLAN Main TX/RX Antenna: Pattern Antenna (Inverted F type: 0.94dBi max 2.4GHz) (Inverted F type: 0.17dBi max 5.150-5.350GHz) (Inverted F type: -0.07dBi max 5.470-5.825GHz) WLAN Aux RX Antenna: Pattern Antenna (Inverted F type: Receive only) Bluetooth TX/RX Antenna: Pattern Antenna (Inverted F type: -0.62dBi max) WWAN Main TX/RX Antenna: Whip Antenna (-0.02dBi max 850MHz) (0.10dBi max 1900MHz) WWAN Aux RX Antenna: Pattern Antenna (Inverted F type: Receive only) GPS RX Antenna: Module Antenna 6. Antenna Position and Antenna photo [ Model With WLAN Pass through connector ] WWAN Main TXRX Antenna WLAN Main TX/RX Antenna Bluetooth TX/RX Antenna WLAN Aux RX Antenna WWAN RX Antenna 7. Antenna Specification [ Model with WLAN Pass through connector ] WLAN Aux RX Antenna: Pattern Antenna (Inverted F type: RX only Antenna) WLAN Main Tx/RX Antenna: Pattern Antenna (Inverted F type: 0.16dBi max 2.4GHz) (Inverted F type: -2.54dBi max 5.150-5.350GHz) (Inverted F type: -2.78dBi max 5.470-5.825GHz) Bluetooth TX/RX Antenna: Pattern Antenna (Inverted F type: -0.62dBi max) WWAN Main TX/RX Antenna: Whip Antenna (-0.02dBi max 850MHz) (0.10dBi max 1900MHz) WWAN Aux RX Antenna: Pattern Antenna (Inverted F type: Receive only) GPS RX Antenna: Module Antenna Antenna Position EU860D Main TX/RX WLAN Main TX/RX Antenna WLAN Aux RX Antenna Bluetooth TX/RX AntennaEU860D Aux RX Antenna GPS RX Antenna 300mm 270m 37mm 35mm 90mm WHIP Antenna under side WHIP Antenna Top side

Reviewed by: FCC ID: ACJ9TGCF-30A FCC Pt. 22/24 GSM/EDGE/WCDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0811141629.ACJ November 20 - 21, 2008 Toughbook Model: CF-30 Page 1 of 58 © 2009 PCTEST Engineering Laboratory, Inc. REV 3.6GWC 07/26/2008 Applicant Name: Date of Testing: Panasonic Corporation of North America November 20 - 21, 2008 One Panasonic Way, 4B-8 Test Site/Location: Secaucus, NJ 07094 PCTEST Lab., Columbia, MD, USA United States Test Report Serial No.: 0811141629.ACJ FCC ID: ACJ9TGCF-30A APPLICANT: PANASONIC CORPORATION OF NORTH AMERICA Application Type: Certification FCC Classification: PCS Licensed Transmitter (PCB) FCC Rule Part(s): §2; §22(H), §24(E) EUT Type: Toughbook Model: CF-30 Model(s): CF-30 Tx Frequency Range: 824.20 - 848.80MHz (Cell. GSM) / 1850.20 - 1909.80MHz (PCS GSM) 826.40 - 846.60MHz (Cell. WCDMA) / 1852.4 - 1907.6MHz (PCS WCDMA) Max. RF Output Power: 1.445 W ERP Cell. GSM (31.6 dBm) / 0.571 W EIRP PCS GSM (27.57 dBm) 0.155 W ERP Cell. WCDMA (21.9 dBm) / 0.155 W EIRP PCS WCDMA (21.89 dBm) 0.411 W ERP EDGE850 (26.14 dBm) / 0.254 W EIRP EDGE1900 (24.05 dBm) Emission Designators: 243KGXW (Cellular GSM), 246KGXW (PCS GSM) 246KG7W (EDGE850), 246KG7W (EDGE1900) 4M18F9W (Cellular WCDMA), 4M19F9W (PCS WCDMA) Test Device Serial No.: identical prototype [S/N: 8GKSA00009] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. This device also contains functions that are not operational in U.S. territories. This report is applicable only to U.S. operations. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 & 24 Certification Reviewed by: FCC ID: ACJ9TGCF-30A FCC Pt. 22/24 GSM/EDGE/WCDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0811141629.ACJ November 20 - 21, 2008 Toughbook Model: CF-30 Page 2 of 58 © 2009 PCTEST Engineering Laboratory, Inc. REV 3.6GWC 07/26/2008 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT............................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 SCOPE ................................................................................................................................................ 4 1.2 TESTING FACILITY............................................................................................................................. 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.3 LABELING REQUIREMENTS.............................................................................................................. 5 3.0 DESCRIPTION OF TESTS ..............................................................................................................6 3.1 MEASUREMENT PROCEDURE......................................................................................................... 6 3.2 OCCUPIED BANDWIDTH EMISSION LIMITS .................................................................................... 6 3.3 CELLULAR - BASE FREQUENCY BLOCKS....................................................................................... 6 3.4 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 7 3.5 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 7 3.6 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.7 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL.............................................. 7 3.8 RADIATED SPURIOUS AND HARMONIC EMISSIONS ..................................................................... 8 3.9 PEAK-AVERAGE RATIO ..................................................................................................................... 8 3.10 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 8 4.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 5.0 SAMPLE CALCULATIONS ............................................................................................................10 6.0 TEST RESULTS .............................................................................................................................11 6.1 SUMMARY......................................................................................................................................... 11 6.2 CONDUCTED OUTPUT POWER ...................................................................................................... 12 6.3 EFFECTIVE RADIATED POWER OUTPUT DATA .......…

Text truncated - open the document above for the full version.
