Panasonic Corporation of North America One Panasonic Way 4B-8 Secaucus, NJ 07094 Tel: 201.348.7758 / Fax: 201.392.4564 [email protected] RICHARD MULLEN Group Manager Product Safety and Compliance Division DRAFT June 15, 2005 ITPD-04-F117A WLAN Part 15C / Equip Class DTS WLAN Part 15E / Equip Class NII EDDO Parts 22H, 24E / Equip Class PCB Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Authority to Act as FCC Agent and Request for Confidentiality Panasonic Mobile Notebook Computer Model CF-73 Family with Intel WLAN and Sierra EVDO TCB Certification for FCC ID: ACJ9TGCF-733A To Whom It May Concern: On behalf of Panasonic Corporation of North America, we herby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in matters relating to FCC equipment authorization, including the signing of documents relating to these matters. Any and all acts carried out by PCTEST on our behalf shall have the same effect as acts of our own. In accordance with provisions of Section 0.457(d) of the Commission’s Rules and Section 552(b)(4) of the Freedom of Information Act, we request confidentiality for WLAN and EVDO exhibits for Operation Description, Parts Lists, Block Diagram(s) and Schematic Diagram(s). The WLAN transmitter is not user adjustable and does not have a Tune-Up Procedure. These exhibits contain proprietary, confidential and trade secrets material, which would not be routinely made available for public inspection. This project represents Mobile Notebook Computer Model CF-73 Family (CF-73mk4) to be marketed under FCC ID: ACJ9TGCF-733A. This product will be marketed with: (1) CPU type Pentium-M-1.8GHz; (2) Intel WLAN (a+b+g) Module Model WM3B2915ABG with Part 15C operation within 2412~2462 and 5745~5825 MHz at 233 and 103 mW peak conducted RF output power; and Part 15E operation within 5180~5240 and 5260~5320 MHz at 55 and 125 mW peak conducted RF output; and (3) Sierra EVDO Module, Model EM5625D with Part 22H operation within 824.70~848.31 MHz at 0.358 watts ERP; and Part 24E operation within 1851.25~1908.75 MHz at 0.442 watts EIRP. This product was approved as a mobile device with respect to RF exposure compliance. The worst-case RF exposure evaluation for maximum permissive exposure measured at 20cm spacing at 2.437 GHz was ? mW/cm 2 and 5.785 GHz was ? mW/cm 2 . This PC’s keyboard contains WLAN Main TX//RX Inverted F type antenna with 3.66dBi antenna gain and WLAN Aux TX/RX antenna with 3.26dBi antenna gain; and EVDO monopole whip type antenna with 0.68 dBi antenna gain. This product may be marketed with optional Port Replicator Model CF-VEB731, which does not contain any external antenna connector. The basic User Manual contains all general FCC warning notices, including RF exposure warning notices, which includes notice that PC was approved for mobile operation and unless otherwise advised in separate supplemental instructions for individual wireless transmitter(s), requires minimum 1.5 cm spacing. The separate provided WLAN User Manual gives additional warning notice about NII operation. Sincerely yours, Richard Mullen Group Manager

<CF-73 WLANa+b+g model photo> 1) CF-73 Top/Front View Top View Front View 7) Antenna position & Magnified photo (WLAN) Receive only Antenna View Send & Receive Antenna View Receive only WLAN Antenna Send & Receive WLAN Antenna

CONFIDENTIAL PROPERTY OF PCTEST UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (NII), FCC RULE PART 15.407 PCTEST LAB TEST REPORT 15.407 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 0506060410 Test Dates: June 9-10, 2005 EUT Type: Notebook PC w/ WLAN (Intel Centrino Model: 2915ABG) FCC ID: ACJ9TGCF-733A Page 28 of 34 © 2005 PCTEST Engineering Laboratory, Inc. EXHIBIT B – Labeling Requirements Sample Label & Location New Labeling Requirements Per 2.1074 & 15.19; Docket 95-19 The sample label shown below shall be permanently affixed at a conspicuous location on the device; instruction manual or pamphlet supplied to the user and be readily visible to the purchaser at the time of purchase. However, when the device is so small wherein placement of the label with specified statement is not practical, only the trade name, FCC ID, and the FCC logo must be displayed on the device per Section 15.19 (b)(2). CONFIDENTIAL PROPERTY OF PCTEST UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (NII), FCC RULE PART 15.407 PCTEST LAB TEST REPORT 15.407 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 0506060410 Test Dates: June 9-10, 2005 EUT Type: Notebook PC w/ WLAN (Intel Centrino Model: 2915ABG) FCC ID: ACJ9TGCF-733A Page 29 of 34 © 2005 PCTEST Engineering Laboratory, Inc. EXHIBIT B – Labeling Requirements (Cont.) Sample Label & Location FCC ID LABEL

4) WLAN Card position Magnified View WLAN Card Position 5) WLAN exterior photo WLAN Top View WLAN Bottom View 6) WLAN interior photo WLAN inside Top View WLAN inside Bottom View

PCTEST MPE REPORT FCC CERTIFICATION REPORT REVIEWED BY: QUALITY MANAGER TEST REPORT S/N: 0506060409 TEST DATES: June 9-10, 2005 EUT TYPE: Notebook PC w/ Intel WLAN FCC ID: ACJ9TGCF-733A PAGE 1 OF 3 © 2005 PCTEST Engineering Laboratory, Inc. RF Exposure Evaluation - Maximum Permissible Exposure (MPE) 1. Introduction This document attempts to prove the safety of radiation generated by RF devices to the human body. The limit for Maximum Permissible Exposure (MPE), specified in FCC 1.1210, is listed below. The power generated by this product is measured by a power meter. Through use of the Friis transmission formula and the maximum gain of the antenna, the distance from the product at which compliance with the MPE limit is achieved may be calculated. Alternatively, near field measurements may be performed to demonstrate compliance at a specific measurement distance. Near field probe: Wandel & Goltermann EMR-20. 2. RF Exposure Limit According to FCC 1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures 30-300 61.4 .163 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B) Limits For General Population / Uncontrolled Exposure 30-300 27.5 .073 .2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. Friis Formula Friis transmission formula: Pd = (P out *G) / (4pr 2 ) Where: Pd = power density in mW/cm 2 (MPE limit) P out = output power to antenna in mW G = gain of antenna in linear scale p = 3.1416 r = distance between observation point and center of the radiator in cm Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11.133) PCTEST MPE REPORT FCC CERTIFICATION REPORT REVIEWED BY: QUALITY MANAGER TEST REPORT S/N: 0506060409 TEST DATES: June 9-10, 2005 EUT TYPE: Notebook PC w/ Intel WLAN FCC ID: ACJ9TGCF-733A PAGE 2 OF 3 © 2005 PCTEST Engineering Laboratory, Inc. 4. EUT Operating Condition Software provided by the client enabled the EUT to transmit and receive data at lowest, middle, and highest channels individually. 5. Climate Condition The temperature and relative humidity: 22°C and 78% RH 6. Measurement Results Frequency (MHz) Level (dBm) Measurement Distance Front MPE reading mW/cm 2 Rear MPE reading mW/cm 2 Right MPE reading mW/cm 2 Left MPE reading mW/cm 2 Limit 824.70 25.473 20cm .0610 .100 .067 .101 .537 2412 23.32 Frequency (MHz) Level (dBm) Measurement Distance Front MPE reading mW/cm 2 Rear MPE reading mW/cm 2 Right MPE reading mW/cm 2 Left MPE reading mW/cm 2 Limit 835.890 25.733 20cm .065 .100 .067 .102 .543 2437 23.67 . Frequency (MHz) Level (dBm) Measurement Distance Front MPE reading mW/cm 2 Rear MPE reading mW/cm 2 Right MPE reading mW/cm 2 Left MPE reading mW/cm 2 Limit 848.31 25.483 20cm .054 .097 .056 .101 .547 2462 23.65 PCTEST MPE REPORT FCC CERTIFICATION REPORT REVIEWED BY: QUALITY MANAGER TEST REPORT S/N: 0506060409 TEST DATES: June 9-10, 2005 EUT TYPE: Notebook PC w/ Intel WLAN FCC ID: ACJ9TGCF-733A PAGE 3 OF 3 © 2005 PCTEST Engineering Laboratory, Inc. Frequency (MHz) Level (dBm) Measurement Distance Front MPE reading mW/cm 2 Rear MPE reading mW/cm 2 Right MPE reading mW/cm 2 Left MPE reading mW/cm 2 Limit 1851.25 26.081 20cm .063 .091 .059 .087 1.00 2412 23.32 Frequency (MHz) Level (dBm) Measurement Distance Front MPE reading mW/cm 2 Rear MPE reading mW/cm 2 Right MPE reading mW/cm 2 Left MPE reading mW/cm 2 Limit 1880 26.551 20cm .062 .090 .060 .089 1.00 2437 23.67 Frequency (MHz) Level (dBm) Measurement Distance Front MPE reading mW/cm 2 Rear MPE reading mW/cm 2 Right MPE reading mW/cm 2 Left MPE reading mW/cm 2 Limit 1908.75 26.521 20cm .066 .085 .065 .082 1.00 2462 23.65 1. Data taken with all transmitters operating simultaneously 7. Conclusion The device meets the mobile 20cm separation distance as specified in Section 2.1091 of the FCC Rules. An appropriate RF exposure compliance statement will be placed in the user’s manual. * All data was taken with WLAN transmitting at full power.

CONFIDENTIAL PROPERTY OF PCTEST UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (NII), FCC RULE PART 15.407 15.240217125-R1.ACJ PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE MANUFACTURER NAME & ADDRESS: DATE & LOCATION OF TESTING: Panasonic Corporation of North America Date(s) of Tests: June 9-10, 2005 One Panasonic Way, 4B-8 Test Report S/N: 0506060411 Secaucus, NJ 07094 Test Site: PCTEST Lab, Columbia, MD Project Number: ITPD-04-F117A FCC ID: ACJ9TGCF-733A APPLICANT: Panasonic Corporation of North America SUMMARY: Model No.: CF-73 Equipment EUT Type: Notebook PC w/ WLAN (Intel Centrino Model: 2915ABG) Max. Output Power: 17.36 dBm (Peak) Conducted (Low Band) 20.96 dBm (Peak) Conducted (High Band) Frequency Range: 5180 – 5240 MHz (Low Band) 5260 – 5320 MHz (High Band) FCC Classification: Unlicensed National Information Infrastructure (NII) FCC Rule Part(s): Parts 15.407; ANSI C-63.4-2001 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4-2001. If the EUT contains any additional embedded transmitters, then those transmitters were active during all tests. The JBC portion of this EUT is covered in the DOC report. Radiated data was taken with the highest gain antenna. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. CONFIDENTIAL PROPERTY OF PCTEST UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (NII), FCC RULE PART 15.407 Page i © 2005 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS ATTESTATION STATEMENTS.............................................................................................................................1 FCC PART 15 E MEASUREMENT REPORT COVER PAGE................................................................................................2 1.0 INTRODUCTION.......................................................................................................................................................3 1.1 EVALUATION PROCEDURE.......................................................................................................................................................................................................3 1.2 SCOPE................................................................................................................................................................................................................................................3 1.3 PCTEST TEST LOCATION............................................................................................................................................................................................................3 2.0 PRODUCT INFORMATION......................................................................................................................................4 2.1 EQUIPMENT DESCRIPTION........................................................................................................................................................................................................4 2.2 ENCLOSURE....................................................................................................................................................................................................................................4 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS................................................................................................................................................................4 3.0 DESCRIPTION OF TEST............................................................................................................................................5 3.1 CONDUCTED EMISSIONS..........................................................................................................................................................................................................5 3.2 RADIATED EMISSIONS.................................................................................................................................................................................................................6 4.0 ANTENNA REQUIREMENTS.....................................................................................................................................7 5.0 TEST EQUIPMENT CALIBRATION DATA...............................................................................................................8 6.1 CONCLUSION.....................................................................................................................9 EXHIBIT A. SUMMARY OF TEST RESULTS.......................................................................................................................10 EXHIBIT A. 26dB BANDWIDTH MEAUREMENT..............................................................................................................11-13 EXHIBIT A. OUTPUT POWER MEASUREMENT................................................................................................................14-15 EXHIBIT A. PEAK POWER SPECTRAL DENSITY................................................................................................................16-17 EXHIBIT A. PEAK EXCURSION RATIO DENSITY..........................................................................................................…

Text truncated - open the document above for the full version.

Panasonic FCC ID: ACJ9TGCF-733A EUT Photographs © 2005 PCTEST Lab. Toughbook w/ Sierra EVDO & WLAN Module Model: CF-73
