ACJ9TGRI20ARFID Module

FCC ID :ACJ9TGRI20A IC: 216H‐CFRI20A HF-RFID Model number: RI20A User Manual GENERAL The RI20A is a highly integrated transceiver module for contactless reader/writer communication at 13.56 MHz. Integration to the end product 1. RI20A module is mounted in the Accessory FZ-VRFG211. 2. Insert Antenna unit into Antenna connectors of RI20A module. Technical Specification a) Dimensions (H x W x D): 17.6mm x 40.15mm x 1.0mm b) Supported RF protocols : ISO/ IEC14443 Type A, Type B, and Felica c) Operating Temperature: -10 to 50 degree Celsius d) Host interface: Serial Peripheral Interface FCC ID :ACJ9TGRI20A IC: 216H‐CFRI20A Regulatory Information Federal Communications Commission Radio Frequency Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Instructions to OEM Integrators The following information must be indicated on the host device of this module; Model : RI20A FCC ID : ACJ9TGRI20A IC: 216H-CFRI20A This module is Part 15.225/RSS-210 limited module. The module is limited to be use by the grantee in its own products, not intended for sale to third parties. Antenna Information Integral loop antenna is used. When the antenna is changed, additional test and certification will be needed. Additional testing, part 15 Subpart B disclaimer The modular transmitter is only FCC authorized for the specific rule parts (i.e., FCC transmitter rules) listed on the grant, and the host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. When the host is changed, additional test and certification will be needed. The final host product still requires Part 15 Subpart B compliance testing with the modular transmitter installed. FCC ID :ACJ9TGRI20A IC: 216H‐CFRI20A Canada-ISED Canada This device complies with ISED Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Cet équipement est conforme aux normes sans licence RSS d’ISED Canada. Son fonctionnement est soumis aux deux conditions suivantes : (1) ce dispositif ne peut produire de brouillage, et (2) ce dispositif doit accepter le brouillage, y compris le brouillage pouvant entraîner le fonctionnement non désiré de l’appareil.. Instructions to OEM Integrators The following information must be indicated on the host device of this module; Model : RI20A FCC ID : ACJ9TGRI20A IC: 216H-CFRI20A This module is Part 15.225/RSS-210 limited module. The module is limited to be use by the grantee in its own products, not intended for sale to third parties. Antenna Information Integral loop antenna is used. When the antenna is changed, additional test and certification will be needed. Additional testing When the host is changed, additional test and certification will be needed.

PB0421-0 DHQX1XXXZA/T1 Printed in Taiwan Operating Instructions HF RFID Reader Model No. FZ-VRFG211 series Thank you for using Panasonic products. This p roduct c an be used only for FZ-G2 series. For more details about the attaching this product, please visit the following website: https://askpc.panasonic.co.jp/manual/option/w Maximum radio - frequency power transmitted in the frequency bands Type of wirelessFrequency band Maximum transmit power HF-RFID (Contactless Smart Card Reader) 13.56 MHz 42 dBuA/m at 10 m Disposal of Old Equipment Only for European Union and countries with recycling systems This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic products must not be mixed with general household waste. For proper treatment, recovery and recycling of old products, please take them to applicable collection points in accordance with your national legislation. By disposing of them correctly, you will help to save valuable resources and prevent any potential negative effects on human health and the environment. For more information about collection and recycling, please contact your local municipality. Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation. 36-E-2 For India Declaration of Conformity with the requirements of the E-Waste (Manage- ment) Rules The Product is in conformity with the requirements of the reduction of hazardous substances of the E-Waste Rules. The content of hazardous substance with the exemption of the applications listed in SCHEDULE II of the E-waste Rules: 1. Lead (Pb) - not over 0.1% by weight; 2. Cadmium (Cd) - not over 0.01% by weight; 3. Mercury (Hg) - not over 0.1% by weight; 4. Hexavalent chromium (Cr6+) - not over 0.1% by weight; 5. Polybrominated biphenyls (PBBs) - not over 0.1% by weight; 6. Polybrominated diphenyl ethers (PBDEs) - not over 0.1% by weight. For the purpose of recycling to facilitate effective utilization of resources, please return this product to a nearby authorized collection center, registered dismantler or recycler, or Panasonic service center when disposing of this product. Please see the Panasonic website for further information on col- lection centers, etc. , or call the toll-free number below. Website: https://www.panasonic.com/in/corporate/sustainability/panasonic-india-i-recycle- program.html Service helpline: 1800 103 1333 or 1800 108 1333 Do’s & Don’t: - E-Waste (Management) Amendment Rules 2018 S.No.Do’sDon’t 1All electrical and electronic prod- ucts are required to be handed over only to the Authorized recycler. The product should not be opened by the User himself/herself, but only by authorized service personnel. 2The product should be handed over only to authorized recycler for disposal. The product is not meant for re-sale any unauthorized agencies/scrap dealer/ kabariwalahs. 3Keep the product in isolated area, after it becomes non-functional/ un-repairable so as to prevent its accidental breakage. The product is not meant for mixing into household waste stream. 4For more information about collec- tion and recycling, please contact your local municipality. Do not keep any replaced spare part(s) from the product in exposed area. 5Always Dispose products that have reached end-of life at Panasonic India authorized service center. Do not donate old electronic items to anybody. 6Wherever possible or as instructed, separate the packaging material according to responsible waste disposal options and sorting for recycling. Do not give e-waste to informal and unorganized sectors like Local Scrap Dealer/ Rag Pickers. 7Create environment awareness PAN India Level. Do not dispose your product in garbage bins along with municipal waste that ultimately reaches land- fill. 68-M-3 For Tur key Accordance with the WEEE Regulation. Disposal of Old Equipment and Batteries Only for European Union and countries with recycling systems These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries must not be mixed with general household waste. For proper treatment, recovery and recycling of old products and batteries, please take them to applicable collection points in accor- dance with your national legislation. By disposing of them correctly, you will help to save valuable re- sources and prevent any potential negative effects on human health and the environment. For more information about collection and recycling, please contact your local municipality. Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation. 5 3 - E _Tr-1 ENGLISH „ Supplied accessories Check and identify the supplied accessories. If you do not find the described ac- cessories, contact your support office. � Operating Instructions (this leaflet) ..............................................................1 „ Specification Refer to è Operating Instructions - Reference Manual. „ Regulatory Information For U.S.A. Federal Communications Commission Radio Frequency Interference State- ment Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio fre- quency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equip- ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: � Reorient or relocate the receiving antenna. � Incr ease the separation betwee…

Text truncated - open the document above for the full version.

Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 Tel/Fax: 201-348-7760 / [email protected] Agent Authorization Letter March 9, 2021 MSBD-20-F007 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Original Limited Single Modular Approval for Panasonic RFID Module, Model RI20A under FCC ID: ACJ9TGRI20A - For Installation within Panasonic RFID Accessory, Model FZ-VRFG211 To whom it may concern: Please be notified that Ben Botros of Panasonic Corporation of North America (PNA), hereby authorize UL Japan, Inc. (UL Japan) to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Japan, Inc. on our behalf shall have the same effect as acts of our own. The undersigned hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Japan as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 Tel/Fax: 201-348-7760 / [email protected] j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is for Single Modular, Model RI20A under FCC ID: ACJ9TGRI20A and is valid for a one-year period from the date of this letter. Thank you for your attention in this matter. Sincerely, Ben Botros Manager – Regulatory & Compliance Panasonic Corporation of North America

Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 Tel/Fax: 201-348-7760 / [email protected] Request for Permanent & Short-Term Confidentiality March 9, 2021 MSBD-20-F007 UL Japan, Inc. Consumer Technology Division 4383-326 Asama-cho, Ise-shi Mie, 516-0021, Japan Subject: Original Limited Single Modular Approval for Panasonic RFID Module, Model RI20A under FCC ID: ACJ9TGRI20A For Installation within Panasonic RFID Accessory, Model FZ-VRFG211 To whom it may concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as permanent confidential document from public disclosure. • Theory of Operation • Block Diagram • Schematics Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In addition, please be advised that Panasonic Corporation of North America hereby requests the following filed sensitive information to be held under short-term confidential, pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s Rules and the provisions in FCC Public DA 04-1705. We request temporarily confidentiality of 45 days, starting from the original issued Certification grant date. • External and Internal Photographs • Operating Instructions (User’s Manual) • Test Setup Photographs Panasonic also acknowledges that we will provide appropriate notice to UL Japan should either of the following occur.  If we require additional 45-day extension period, we will notify UL Japan with a new request letter at least seven days prior to the short-term confidentiality expiration date [Note: up to a maximum of 3 extensions only allowed], or  We will immediately notify UL Japan in the event the information regarding the product or the product is made available to the public. UL Japan will them release the documents listed above for public disclosure, pursuant to FCC Public Notice DA 04-1705. . Sincerely, Ben Botros Manager – Regulatory & Compliance Panasonic Corporation of North America

Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 Tel/Fax: 201-348-7760 / [email protected] Applicant/Grantee Panasonic Corporation of North America FCC ID: ACJ9TGRI20A Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The device does not have Metal shielding to cover RF section. Refer to External Photos. N 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. All inputs to the device are buffered through logic U1 inputs. Refer to Schematic Diagram. Y 3 The modular transmitter must have its own power supply regulation. There is no power supply in the module. 3.3V is fed by the final product. N 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The device is equipped with the unique antenna connector. Refer to External photos. Y 5 The modular transmitter must be tested in a stand- alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). The device was installed into the final product for testing. Refer to setup photos. N Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 Tel/Fax: 201-348-7760 / [email protected] 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the de vice in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. The proposed FCC ID label format is to be placed on the module. If FCC ID is not visible when the module is installed into the system, “Contains FCC ID: ACJ9TGRI20A” shall be placed on the outside of final host system. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Refer to “User’s Guide” Exhibit Y Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102-5490 Tel/Fax: 201-348-7760 / [email protected] 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. The device complies with RF exposure compliance requirement Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrat e by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted …

Text truncated - open the document above for the full version.

FCC ID:ACJ9TGRI20A/ IC:216H-CFRI20A External Photos 1/2 1) External photos 1-1) Front 1-2) Rear FCC ID:ACJ9TGRI20A/ IC:216H-CFRI20A External Photos 2/2 1-3) Edge1 1-4) Edge2 1-5) Edge3 1-6) Edge4 Edge 1 Edge 4 Edge 2 Edge 3

FCC ID:ACJ9TGRI20A/ IC: 216H-CFRI20A internal Photos 1/3 1) HF-RFID module position 1-1) Appearance of Accessory For the photos, module position Open Accessory HF-RFID module HF-RFID antenna FCC ID:ACJ9TGRI20A/ IC: 216H-CFRI20A internal Photos 2/3 2) HF-RFID photos 2-1) Module <Front side> <Back side> FCC ID:ACJ9TGRI20A/ IC: 216H-CFRI20A internal Photos 3/3 2-2) Antenna <Front side> <Back side>

FCC ID : ACJ9TGRI 20A IC : 216H-CFRI 20A label position 1.Label of the module. 2 .Label position. RI 20 A module Label of the module Model : RI1 20A FCC ID : ACJ9TGRI 20 A IC : 216H-CFRI 20 A

FCC ID:ACJ9TGRI20A/IC: 216H-CFRI20A Label 1/1 1. Label FCC ID “ACJ9TGRI20A” Label 2. Label location FZ-VRFG211 Contains/Ce contient; FCC ID : ACJ9TGRI20A IC : 216H-CFRI20A FCC ID/IC

FCC ID:ACJ9TGRI20A/ IC: 216H-CFRI20A internal Photos 1/3 1) HF-RFID module position 1-1) Appearance of Accessory For the photos, module position Open Accessory HF-RFID module HF-RFID antenna FCC ID:ACJ9TGRI20A/ IC: 216H-CFRI20A internal Photos 2/3 2) HF-RFID photos 2-1) Module <Front side> <Back side> FCC ID:ACJ9TGRI20A/ IC: 216H-CFRI20A internal Photos 3/3 2-2) Antenna <Front side> <Back side>

FCC CFR47 PART 15 SUBPART C CERTIFICATION TEST REPORT FOR RFID MODULE MODEL NUMBER: RI20A FCC ID: ACJ9TGRI20A REPORT NUMBER: 13489138H-A-R1 ISSUE DATE: April 19, 2021 Prepared for PANASONIC CORPORATION OF NORTH AMERICA Two Riverfront Plaza, 9 th Floor, Newark, NJ 07102-5490 Prepared by UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi Mie-ken 516-0021 JAPAN TEL: +81 596 24 8999 FAX: +81 596 24 8124 CERTIFICATE 5107.02 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan. There is no testing item of "Non-accreditation". REPORT NO: 13489138H-A-R1 DATE: April 19, 2021 FCC ID: ACJ9TGRI20A Page 2 of 50 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN TEL: +81 596 24 8999 FAX: +81 596 24 8124 This report shall not be reproduced except in full, without the written approval of UL Japan Revision History Rev. Issue Date Revisions Revised By -- 03/25/2021 Initial Issue T. Shimada 1 04/19/2021 Corrected Model of NFC module T. Shimada REPORT NO: 13489138H-A-R1 DATE: April 19, 2021 FCC ID: ACJ9TGRI20A Page 3 of 50 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN TEL: +81 596 24 8999 FAX: +81 596 24 8124 This report shall not be reproduced except in full, without the written approval of UL Japan TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ........................................................................................................... 4 2. TEST METHODOLOGY ................................................................................................................................ 5 3. FACILITIES AND ACCREDITATION ........................................................................................................... 5 4. CALIBRATION AND UNCERTAINTY .......................................................................................................... 6 4.1. MEASURING INSTRUMENT CALIBRATION ......................................................................................... 6 4.2. SAMPLE CALCULATION ....................................................................................................................... 6 4.3. MEASUREMENT UNCERTAINTY ......................................................................................................... 6 5. TEST PROCEDURE AND RESULTS ........................................................................................................... 7 6. EQUIPMENT UNDER TEST ......................................................................................................................... 8 6.1. DESCRIPTION OF EUT ......................................................................................................................... 8 6.2. MAXIMUM TRANSMITTER FIELD STRENGTH .................................................................................... 8 6.3. DESCRIPTION OF AVAILABLE ANTENNAS ........................................................................................ 8 6.4. SOFTWARE AND FIRMWARE .............................................................................................................. 8 6.5. WORST-CASE CONFIGURATION AND MODE .................................................................................... 8 6.6. MODIFICATIONS ................................................................................................................................... 9 6.7. DESCRIPTION OF TEST SETUP .......................................................................................................... 9 7. TEST AND MEASUREMENT EQUIPMENT ............................................................................................... 11 8. RADIATED EMISSION TEST RESULTS ................................................................................................... 13 8.1. LIMITS AND PROCEDURE .................................................................................................................. 13 8.2. FUNDAMENTAL EMISSION and Spectrum Mask ............................................................................... 16 8.3. SPURIOUS EMISSIONS (0.009 MHz - 30 MHz) .................................................................................. 21 8.4. SPURIOUS EMISSION (30 MHz - 1000 MHz) ..................................................................................... 25 9. AC MAINS LINE CONDUCTED EMISSIONS ............................................................................................. 29 10. FREQUENCY STABILITY ....................................................................................................................... 34 11. 20 dB BANDWIDTH and 99 % Occupied Bandwidth ........................................................................... 37 12. SETUP PHOTOS ..................................................................................................................................... 46 REPORT NO: 13489138H-A-R1 DATE: April 19, 2021 FCC ID: ACJ9TGRI20A Page 4 of 50 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN TEL: +81 596 24 8999 FAX: +81 596 24 8124 This report shall not be reproduced except in full, without the written approval of UL Japan 1. ATTESTATION OF TEST RESULTS COMPANY NAME: PANASONIC CORPORATION OF NORTH AMERICA Two Riverfront Plaza, 9th Floor, Newark, NJ 07102-5490 EUT DESCRIPTION: RFID MODULE MODEL: RI20A SERIAL NUMBER: 0LTSA00140 DATE TESTED: February 1 and 2, 2021 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART C Pass UL Japan, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL Japan, Inc. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance w…
