ACJKM7KX-FPG371Fax w/ Cordless Telephone Base

Panasonic Corporation of North America
Fax w/ Cordless Telephone Base - FCC ID ACJKM7KX-FPG371 - Panasonic Corporation of North America
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Jun 20, 2002
Application Purpose
Original Equipment
Date of Application
Jun 20, 2002
Equipment Note
Fax w/ Cordless Telephone Base
Frequency Range
2402.00000000 - 2480.00000000
Company
Panasonic Corporation of North America
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

Matsushita Electric Corporation of America Product Safety & Compliance Division 1 Panasonic Way, 4B-8 Richard Mullen Secaucus, NJ 07094 Group Manager Panasonic Quasar Technics Fax: (201) 392-4564 Tel: (201) 348-7758 e-mail: [email protected] June 5, 2002 KM7-02-F003 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia MD 21045 Subject: Original Application for Facsimile Machine with Cordless Telephone Panasonic Facsimile With 2.4 GHz Digital Cordless Telephone Base FCC ID: ACJKM7KX-FPG371 Dear Mr. Randy Ortanez: Enclosed, find Matsushita Electric Industrial Co., Ltd.'s Application for Equipment Authorization dated June 5, 2002. This system is in compliance with Part 15, Subpart C and in accordance with §15.247 of the FCC Rules. The subject device is a facsimile machine with built-in cordless telephone base with operation on 153 channels within the 2402.048 ~ 2479.872 MHz frequency band (low channel 14 @ 2402.048 MHz, middle channel 90 @ 2440.960 MHz and high channel 166 @ 2479.872 MHz). The maximum RF output power (EIRP) for the base unit is mW. This base unit will be marketed with its associated handset, which was previously approved by PCTEST TCB under FCC ID: ACJ96NKX-TG2257. The handset approval included SAR test report that declared maximum peak radiated RF output was 6.6mW (EIRP). The handset SAR test results were: (1) 0.1895 W/kg Brain SAR; and (2) 0.5660 W/kg Body SAR. Both the base and handset have permanently attached antennas with handset using J-type antenna and base unit using collinear antenna. The User Manual will provide RF exposure warnings to include: (1) the base unit’s antenna should be located at least 20 cm from persons body during usage; and (2) the handset should only be carried in the provided belt-clip. The base unit will be TCB certified by CCL under ACTA ID: US: ACJFC10BKX-FPG371. Should you have any questions, please contact the undersigned. Thank you for your attention in this matter. Sincerely yours, Richard Mullen Richard Mullen Group Manager Product Safety & Compliance Division

Cover Letter(s)

June 12, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Matsushita Electric Industrial Co., Ltd. FCC ID: ACJKM7KX-FPG371 Part 15.247 Certification Gentlemen: Submitted herewith, on behalf of Matsushita Electric Industrial Co., Ltd., is an application for Part 15.247 Certification of Spread Spectrum Transceiver (DSSS). Attached are the applicant’s Letter of Authorization, measurement report test data and plots, FCC ID label and location, test setup photographs, internal and external photographs, block diagram, processing gain, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Matsushita Electric Industrial Co., Ltd.

External Photos

© 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS) © 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS) © 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS)

ID Label/Location Info

© 2002 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) FCC ID: ACJKM7KX-FPG371

Internal Photos

© 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS) © 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS) © 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS) © 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS) © 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS) © 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS) © 2002 PCTEST Lab Matsushita FCC ID: ACJKM7KX-FPG371 Fax w/ Cordless Phone & Answering System (DSS)

RF Exposure Info

RF Exposure Measurement 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of this product. In this document, we try to prove the safety of radiation harmfulness to the human body. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1210 is followed. The Gain of the antenna used in this product is measured by power meter. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. Friis Formula Friis transmission formula: Pd = (Pout*G) / (4πr 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale π = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm2. If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11.133) 4. EUT Operating Condition Software provided by the client enabled the EUT to transmit and receive data at lowest, middle, and highest channel individually. 5. Climate Condition The temperature and related humidity: 22 ̊C and 78% RH 6. Test Results (Antenna Configuration) 6.1 Output Power into Antenna & RF Exposure Distance: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Minimum Allowable Distance from Skin (cm) 14 2402 5.55 0.665

Test Report

PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.220516228.ACJ Test Dates: MAY 28-29, 2002 EUT Type: FAX W/ CORDLESS PHONE & ANSWERING SYSTEM FCC ID: ACJKM7KX-FPG371 Page 1 of 18 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE Matsushita Electric Industrial Co., Ltd. Dates of Tests: May 28-29, 2002 1006 Oaza Kadoma Test Report S/N: 15.220516228.ACJ Kadoma, Osaka 571 Japan Test Site: PCTEST Lab, Columbia MD Attention: Rich Mullen (PSCD) N. Yoshizumi-Kyushu MEICL FCC ID ACJKM7KX-FPG371 APPLICANT Matsushita Electric Industrial Co., Ltd. FCC Rule Part(s): § 15.247; ANSI C-63.4 (1992) Classification: Spread Spectrum Transceiver (DSS) Method/System: Direct Sequence System (DSS) Equipment Type: Fax w/ 2.4GHz Cordless Telephone Base Frequency Range: 2402-2480 MHz Model No(s).: KX-FPG371 Max. RF Power: 0.0055 W (conducted) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63-4. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Approved Signatories: Randy Ortanez — President Alfred Cirwithian — Vice-President 220516228.ACJ PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.220516228.ACJ Test Dates: MAY 28-29, 2002 EUT Type: FAX W/ CORDLESS PHONE & ANSWERING SYSTEM FCC ID: ACJKM7KX-FPG371 Page 2 of 18 TABLE OF CONTENTS ATTACHMENT A - COVER LETTER ATTACHMENT B - ATTESTATION STATEMENT ATTACHMENT C - TEST REPORT SCOPE 3 INTRODUCTION (SITE DESCRIPTION) 4 PRODUCT INFORMATION 5 DESCRIPTION OF TESTS A. CONDUCTED EMISSIONS 6 B. RADIATED EMISSIONS 7 C. RESTRICTED BANDS 8 D. ANTENNA REQUIREMENT 9 E. DIRECT SEQUENCE BANDWIDTH 10 F. MAXIMUM PEAK POWER OUTPUT 11 G. POWER DENSITY 12 RADIATED MEASUREMENTS (FUNDAMENTAL & HARMONICS) 13-15 RADIATED MEASUREMENTS (SPURIOUS) 16 LIST OF TEST EQUIPMENT 17 CONCLUSION 18 ATTACHMENT D - TEST PLOTS ATTACHMENT E - FCC ID LABEL & LOCATION ATTACHMENT F - TEST SET-UP PHOTOGRAPHS ATTACHMENT G - EXTERNAL PHOTOGRAPHS ATTACHMENT H - INTERNAL PHOTOGRAPHS ATTACHMENT I - BLOCK DIAGRAM ATTACHMENT J - SCHEMATIC DIAGRAMS ATTACHMENT K - PROCESSING GAIN ATTACHMENT L - USER’S MANUAL ATTACHMENT M – SAR MPE REPORT PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.220516228.ACJ Test Dates: MAY 28-29, 2002 EUT Type: FAX W/ CORDLESS PHONE & ANSWERING SYSTEM FCC ID: ACJKM7KX-FPG371 Page 3 of 18 MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2983(a) General Information Applicant Name: Matsushita Electric Industrial Co., Ltd. Address: 1006 Oaza Kadoma Kadoma, Osaka 571 JAPAN Attention: Rich Mullen (PSCD) • FCC ID: ACJKM7KX-FPG371 • Class: Spread Spectrum Transceiver (DSS) • Type: Fax w/ 2.4GHz Cordless Telephone Base • Freq. Range: 2402-2480 MHz • Method/System: Direct Sequence System (DSS) • Model No(s): KX-FPG371 • Max. RF Output Power: 0.0055 W (conducted) • USOC Jack: RJ-11 • Rule Part(s): § 15.247 • Dates of Tests: May 28-29, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 15.220516228.ACJ NOTE: The receiver portion was tested and complies with Part 15B under the verification procedure. PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.220516228.ACJ Test Dates: MAY 28-29, 2002 EUT Type: FAX W/ CORDLESS PHONE & ANSWERING SYSTEM FCC ID: ACJKM7KX-FPG371 Page 4 of 18 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) and FCC Public Notice dated July 12, 1995 entitled “Guidance on Measurement for Direct Sequence Spread Spectrum Systems” were used in the measurement of Panasonic Fax w/ Cordless Phone & Answering System Model: KX-FPG371. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39 ° 11'15" N latitude and 76 ° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. PCTEST PT. 15.247 REPORT EVALUATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.220516228.ACJ Test Dates: MAY 28-29, 2002 EUT Type: FAX W/ COR…
