ACJRCDSR-IHFA54Rice Cooker

Panasonic Corporation of North America

Click to zoom

Application Details

Equipment Class: 8CC - Part 18 Consumer Device
Date of Grant: Sep 26, 1999
Application Purpose: Original Equipment
Date of Application: Jul 27, 1999
Equipment Note: Rice Cooker
Frequency Range: 0.21000000 - 0.30000000
Company: Panasonic Corporation of North America
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

July 28, 1999 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:Matsushita Electric Industrial Co., Ltd. FCC ID: ACJRCDSR-IHFA54 Gentlemen: Submitted herewith, on behalf of Matsushita Electric Industrial Co. Ltd., and Tokin EMC Engineering Co. Ltd., is an application for Part 18 Certification of the following ISM Consumer Device: FCC ID:ACJRCDSR-IHFA54 MODEL:IH-MS2000 TRADE NAME:SUZUMO EUT TYPE:IH Rice Cooker FCC CLASS:Part 18 – ISM Consumer Device (8CC) Attached is the letter of authorization, measurement report (from Tokin EMC Engineering Co. Ltd.), FCC ID label & location, test setup photographs, internal and external photographs, block diagram, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Matsushita Electric Industrial Co., Ltd. Tokin EMC Engineering Co., Ltd.

External Photos

ID Label/Location Info

© 1999 PCTEST Lab FCC ID SAMPLE LABEL LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) Matsushita Electric Industrial Co., Ltd. RICE COOKER DIVISION 5 SAHO, YASHIRO-CHO, KATO-GUN, HYOGO 673-14, JAPAN TEL :(0795)42-7020-l FAX :(0795) 42-7029 SUZUMO IIHICommerciaI RICE COOKER Model NOAH-MS2000 208V 60Hz 375OW FOR USE ON INDIVIDUAL BRANCH CIRCUIT ONLY. FCC ID:ACJRCDSR-IHFA54 This device comp lies with Part 18 of the FCC Rules. Operation ISsub ject tothe following two conditions. . This device may not cause harmlul Interference. . This device must accepl any interference received, including inlerlerence that may cause undesired operalion. Suzumo Machinery Co.,Ltd. Tokyo Japan Made in Japan Serial No.

Internal Photos

Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd. Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd. Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd. Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd. Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd. Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd. Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd. Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd. Test Report S/N: 18.990727452.ACJFCC Part 18 Certification © 1999 PCTEST Lab IH Rice Cooker FCC ID: ACJCDSR-IHFA54 NVLAP Lab Code: 100431-0 Matsushita Electric Industrial Co., Ltd.

Test Report

EMC TEST REPORT - FOR CERTIFICATION - for MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD. 1006, Oaza Kadoma, Kadoma-city Osaka 571-0050 Equipment Under Test:IH Rice Cooker ( model name : IH-MS2000 ) FCC ID :ACJRCDSR-IHFA54 Category:FCC Part 18 Induction Cooking Ranges Tokin Report No.:T3K997101 Date of Issue:July 12, 1999 Hiro Shida Manager, Tsukuba Testing Lab. Tokin EMC Engineering Co., Ltd. - ATTENTION -- The test results in this report relate only to the following EUTs, and this report shall not be reproduced except in full, without the written approval of the laboratory. FCC Part 18 T3K997101 Contents Page 1 DESCRIPTION OF DEVICE ........................................................................ 1 2 TEST FACILITY............................................................................................... 2 3 SUMMARY OF RESULTS 3.1 Electromagnetic Emissions............................................................................. 2 3.2 Modifications to the EUT............................................................................... 2 4 TESTED SYSTEM DETAILS 4.1 Peripherals and Others ................................................................................. 3 4.2 Type of Used Cables .................................................................................... 3 5 TECHNICAL COUNTERMEASURE.................................................................. 3 6 TEST RESULTS 6.1 RFI Voltage Measurement 6.1.1 Measurement Instrumentation Used........................................................ 4 6.1.2 Measurement Procedure......................................................................... 4 6.1.3 Measurement Uncertainty....................................................................... 4 6.1.4 Test Data............................................................................................... 5 ∼ 6 6.2 RFI Field Strength Measurement 6.2.1 Measurement Instrumentation Used........................................................ 7 6.2.2 Measurement Procedure......................................................................... 8 6.2.3 Measurement Uncertainty....................................................................... 8 6.2.4 Test Data............................................................................................... 9 ∼ 10 7 MEASUREMENT PHOTOS Photo 7.1Setup with the Maximized RFI Voltage Emission Level........................11 Photo 7.2Setup with the Maximized RFI Field Strength Emission Level..............12 Page 1 of 12 FCC Part 18 T3K997101 Report processed by Hiroko Nakamura Masayuki Kuramochi, Engineer 12/Jul./1999 1 DESCRIPTION OF DEVICE A)Kind of Equipment :IH Rice Cooker B)FCC ID :ACJRCDSR-IHFA54 C)Model Name :IH-MS2000 D)Serial No. :None E)Type of Sample Tested :Pre-production F)High Frequency Used :21kHz ( Cooking ) 30kHz ( Warming ) 32.195MHz ( Crystal ) G)Rating Power Supply :1phase AC208V, 18A, 60Hz H)Tested Power Supply :1phase AC208V, 60Hz I)Date of Manufacture :June 1999 J)Manufacturer :Matsushita Electric Industrial Co., Ltd. 5, Saho, Yashiro-cho, Kato-gun, Hyogo 673-14, Japan K)Description of Operating :Cooking mode Warming mode L)Date of Sample Received :July 05, 1999 M)Test Engineer :Masayuki Kuramochi Page 2 of 12 FCC Part 18 T3K997101 Report processed by Hiroko Nakamura Masayuki Kuramochi, Engineer 12/Jul./1999 2 TEST FACILITY The open field test site and conducted measurement facility are used for this measurement, where is located following address. This site was fully described in a report dated Jan.31,1994, that was submitted to the FCC. And we had accepted in a letter dated Apr.8,1994 (31040/SIT). This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200221-0. Tokin EMC Engineering Co., Ltd. Tsukuba Testing Laboratory, Open Field Test Site No.3 and Shielded Room No.2 Address ; 28-1, Kitahara-aza, Hanashimashinden-ohaza, Tsukuba-city, Ibaragi 305-0875, Japan 3 SUMMARY OF RESULTS 3.1 Electromagnetic Emission RFI Voltage Measurement ..............................PASS RFI Field Strength Measurement ....................PASS Although the measured emissions indicate that the EUT complies with the required limits, some measurements are close to these limits. When the uncertainty of measurement is considered, there is some possibility that the EUT may not be compliant. Test results are traceable to JQA, MKK and NIST. 3.2 Modifications to the EUT This EUT was taken countermeasures. Page 3 of 12 FCC Part 18 T3K997101 Report processed by Hiroko Nakamura Masayuki Kuramochi, Engineer 12/Jul./1999 4 TESTED SYSTEM DETAILS 4.1 Peripherals and Others :None 4.2 Type of Used Cables : Description Length Type of shield Model name Manufacturer AC power cable 1.2m Non-shielded None SHINAGAWA AC power cable 0.5m Non-shielded None SHINAGAWA 5 TECHINICAL COUNTERMEASURE 5-1 Addition to flicker circuit for IH Rice Cooker. Detail of filter circuit : Common coil : 1300μH × 1pcs Normal coil : 210μH × 4pcs Across the capacitor : 3.3μH × 6pcs Earth Inductor : 460μH × 1pcs Page 4 of 12 FCC Part 18 T3K997101 Report processed by Hiroko Nakamura Masayuki Kuramochi, Engineer 12/Jul./1999 6 TEST RESULTS 6.1 RFI Voltage Measurement 6.1.1 Measurement Instrumentation Used ( model/serial no./manufacturer/Tokin control no./last calibration/next calibration ) Field strength meter ......................( FCKL1528/1528124/Schwarzbeck/RE039/02 Oct.’98/Oct.’99 ) L.I.S.N. .......................................( 9117-5-TS-50-N/962131/SOLAR/LI053/13 Oct.’98/Oct.’99 ) L.I.S.N. .......................................( 9117-5-TS-50-N/962132/SOLAR/LI054/13 Oct.’98/Oct.’99 ) Spectrum analyzer ........................( TR4135/67800068/Advantest/SP004/11 Dec.’98/Dec.’99) Coaxial cable................................( ---/---/---/DK125/02 Mar.’99/Mar.’00 ) Shielded room...............................( Tsukuba No.2-S/---/Tokin/SA017/---/--- ) 6.1.2 Measurement Procedure The power line conducted interference measurements were performed according to MP-5…

Text truncated - open the document above for the full version.

Test Setup Photos

Page 11 of 12 FCC Part 18 T3K997101 7 MEASUREMENT PHOTOS Photo 7.1 Setup with the Maximized RFI Voltage Emission Level Page 12 of 12 FCC Part 18 T3K997101 Photo 7.2 Setup with the Maximized RFI Field Strength Emission Level
